Poulan Pro SM132 User manual

ENGLISH ESPAÑOL FRANÇAIS
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lirelemanueld’instructionsetbienrespectertouslesavertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
SM132
For Occasional Use Only
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2003 Electrolux Home Products, Inc. 530164435 10/31/03
R

2
SAFETY RULES
WARNING: When using gardening
appliances,basic safety precautionsmust al-
ways befollowed to reducetherisk of fireand
serious injury. Read and follow all instruc-
tions.
This power unit can be dangerous! Operator is
responsible for following instructions and warn-
ings on unit andin manual. Read entire instruc-
tion manual before using unit! Be thoroughly fa-
miliarwiththecontrols andtheproperuse ofthe
unit. Restrict theuse of this unit to persons who
have read, understand, and will follow the
instructions and warnings on the unit and in the
manual. Never allow children to operate this
unit.
SAFETY INFORMATION
ON THE UNIT
INSTRUCTION
MANUAL
DANGER: Never use blades or flail-
ing devices. This unitis designedforlinetrim-
meruseonly.Useofanyotheraccessoriesor
attachments will increase the risk of injury.
WARNING: Trimmer line throws ob-
jects violently. You and others can be blinded/in-
jured. Wear eye and leg protection. Keep body
parts clear of rotating line.
Eye Protection
Boots
HazardZone
50 ft.
(15 m)
Keep children, bystanders, and animals 50 feet
(15 meters) away. Stop unit immediately if ap-
proached.
If situations occur which are not covered in
this manual, use care and good judgment. If
youneedassistance,contactyourauthorized
service dealer or call 1--800--554--6723.
OPERATOR SAFETY
SDress properly. Always wear safety
glasses or similar eye protection when op-
erating, or performing maintenance, on
your unit (safety glasses are available).
Eye protection should be marked Z87.
SAlways wearfaceor dustmask if operation
is dusty.
SAlways wear heavy, longpants, long sleeves,
boots, and gloves. Wearing safety leg guards
is recommended.
SAlways wear foot protection. Do not go
barefoot or wear sandals. Stay clear of
spinning line.
SSecurehairaboveshoulderlength. Secure
or remove loose clothing or clothing with
loosely hanging ties, straps, tassels, etc.
They can be caught in moving parts.
SBeing fully covered also helps protect you
from debris and pieces of toxic plants
thrown by spinning line.
SStay Alert. Do not operate this unit when
you are tired, ill, upset or under the influ-
ence of alcohol, drugs, or medication.
Watch what you are doing; use common
sense.
SWear hearing protection.
SNever start or run inside a closed room or
building. Breathingexhaustfumes cankill.
SKeep handles free of oil and fuel.
UNIT / MAINTENANCESAFETY
SDisconnect the spark plug before perform-
ing maintenance except carburetoradjust-
ments.
SLook for and replace damaged or loose
parts before each use. Look for and repair
fuelleaks beforeuse.Keepin goodworking
condition.
SReplace trimmer head parts that are
chipped, cracked, broken, or damaged in
any other way beforeusing the unit.
SMaintain unit according to recommended
procedures. Keep cutting line at proper
length.
SUse only 0.080!(2 mm) diameter Poulan
PRO"brand replacementline. Never use
wire, rope, string, etc.
SInstall required shield properly before using
the unit. Use only specified trimmer head;
makesureitisproperly installedandsecurely
fastened.
SMake sure unit is assembled correctly as
shown in this manual.
SMake carburetor adjustments with lower
endsupportedtopreventline fromcontact-
ing any object.
SKeepothers away whenmakingcarburetor
adjustments.
SUse only recommended Poulan PROrac-
cessories and replacement parts.
SHave all maintenance and service not ex-
plained in this manual performedby an au-
thorized service dealer.
FUEL SAFETY
SMix and pour fuel outdoors.
SKeep away from sparks or flames.
SUse a container approved for fuel.
SDo notsmoke or allow smokingnear fuel or
the unit.
SAvoid spilling fuel or oil. Wipe up all fuel
spills.
SMove atleast 10feet (3meters) awayfrom
fueling site before starting engine.
SStop engine and allow to cool before re-
moving fuel cap.
SAlways store gasoline in a container ap-
proved for flammable liquids.

3
CUTTING SAFETY
WARNING: Inspect the area before
each use. Remove objects (rocks, broken
glass, nails, wire, etc.) which can be thrown
by or become entangledin line. Hard objects
can damage thetrimmer headand be thrown
causing serious injury.
SUse only for trimming, scalping, mowing and
sweeping. Do not use for edging, pruning or
hedge trimming.
SKeep firm footing and balance. Do not over-
reach.
SKeep all parts of your body away from muffler
and spinning line. Keep engine below waist
level. A hot muffler can cause serious burns.
SCut from your left to your right. Cutting on
right side of the shield will throw debris away
from the operator.
SUse only in daylight or goodartificial light.
SUse only for jobs explained in this manual.
TRANSPORTINGAND STORAGE
SAllow enginetocool beforestoring ortrans-
porting in vehicle.
SEmpty the fueltank beforestoring or trans-
portingtheunit.Useupfuelleftinthecarbu-
retor by starting the engineandletting itrun
until it stops.
SStoreunitandfuelinareawherefuelvapors
cannot reach sparks or open flames from
water heaters,electric motors or switches,
furnaces, etc.
SStore unit so line limiter blade cannot acci-
dentally cause injury. Theunit can behung
by the shaft.
SStore unit out of reach of children.
SAFETYNOTICE:Exposure to vibrations
through prolonged use of gasoline powered
handtools could cause bloodvessel or nerve
damage in the fingers, hands, and joints of
people prone to circulation disorders or ab-
normal swellings. Prolonged use in cold
weatherhasbeenlinkedtobloodvesseldam-
ageinotherwisehealthypeople. Ifsymptoms
occur such as numbness, pain, loss of
strength, change in skin color or texture, or
loss of feeling in the fingers, hands, or joints,
discontinuetheuseofthis toolandseekmed-
ical attention. An anti--vibrationsystem does
not guarantee the avoidance of these prob-
lems. Users who operate power tools on a
continual and regular basis must monitor
closely their physical conditionand thecondi-
tion of this tool.
SPECIALNOTICE: This unit is equipped
with a temperaturelimiting muffler and spark
arresting screen which meets the require-
mentsofCaliforniaCodes4442and4443. All
U.S. forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey, Ore-
gon, and Washington require by law that
many internal combustion engines be
equippedwithasparkarrestingscreen. Ifyou
operateinalocalewheresuchregulationsex-
ist, youarelegallyresponsibleformaintaining
theoperatingconditionoftheseparts. Failure
to do so is a violation of the law. For normal
homeowneruse,themufflerandsparkarrest-
ing screen will not require any service. After
50 hours of use, we recommend that your
muffler be serviced or replaced by an autho-
rized service dealer.
ASSEMBLY
WARNING: If received assembled,
repeatall steps toensure yourunitis properly
assembled and all fasteners are secure.
Examine parts for damage. Do not use dam-
aged parts.
NOTE:If you need assistance or find parts
missing or damaged, call 1-800-554-6723.
It is normal for the fuel filter to rattle in the
empty fuel tank.
Finding fuel or oil residue onmuffler is normal
due to carburetor adjustments and testing
done by the manufacturer.
ADJUSTINGTHE HANDLE
WARNING: Whenadjustingtheassist
handle,be sure it remains above the safety label
and below the mark or arrow on the shaft.
1. Loosen wing nut on handle.
2. Rotate the handle on the shaftto an upright
position; retighten wing nut.
ATTACHING SHIELD
WARNING: The shield must be prop-
erly installed. The shield provides partial protec-
tion to the operator and others from the risk of
thrown objects, andis equipped witha linelimit-
er blade which cuts excess line to the proper
length. The line limiter blade (on underside of
shield) is sharp and can cut you.
For proper orientation of shield, see KNOW
YOUR TRIMMER illustration in OPERATION
section.
1. Remove wing nut from shield.
2. Insert bracket into slot as shown.
3. Pivot shielduntil boltpasses throughhole
in bracket.
4. Securely tighten wing nut onto bolt.
Wing Nut
Bracket
Slot
Shield
Gearbox
PIVOT

4
OPERATION
KNOW YOUR TRIMMER
READ THISINSTRUCTION MANUALAND SAFETYRULESBEFOREOPERATING YOURUNIT.
Compare theillustrations with your unitto familiarize yourself withthelocationof the various controls
and adjustments. Save this manual for future reference.
Line Limiter
Blade
Shield
Trimmer
Head
Shaft
Assist Handle
ON/OFF Switch
Primer Bulb
Muffler
Throttle
Trigger
Choke Lever
Starter Handle
ON/OFF SWITCH
The ON/OFF switch is located on the trigger
handle and is used to stop the engine. Move the
switch to the OFF position to stop the engine.
PRIMER BULB
ThePRIMERBULBremovesairfromthecar-
buretor and fuel lines and fills them with fuel.
This allows you tostart theengine withfewer
pulls on the starter rope. Activate the primer
bulb by pressing it and allowing it to return to
its original form.
CHOKE
The CHOKE helps to supply fuel to the engine
to aid in cold starting. Activate the choke by
moving the choke lever to the FULL CHOKE
position.Aftertheengineattemptsto start,move
the choke lever to the HALF CHOKE position.
Once engine has started, move the choke lever
to the RUN position.
BEFORE STARTING ENGINE
WARNING: Be suretoread thefuel
information in the safety rules before you be-
gin. If you donot understandthe safety rules,
do not attempt to fuel your unit. Call
1-800-554--6723.
FUELING ENGINE
WARNING: Remove fuel cap slowly
when refueling. HELPFUL TIP
Toobtainthecorrectoil mix
ratio, pour 3.2 ounces of
2--cycle synthetic oil into
one gallon of fresh gas.
This engine is certified to operate on unleaded
gasoline. Before operation, gasoline must be
mixed with a good quality synthetic 2-cycle
air-cooled engine oil designed to be mixed at a
ratio of 40:1. Poulan/Weed Eater brand
synthetic oil is recommended.Mix gasoline and
oil at a ratio of 40:1. A 40:1 ratio is obtained by
mixing 3.2 ounces (95 ml) of oil with 1 gallon (4
liters) of unleaded gasoline. DO NOT USE
automotive oil or marine oil. These oils will
cause engine damage. When mixing fuel, follow
instructions printed on container. Once oil is
addedtogasoline,shake containermomentarily
to assure that the fuel is thoroughly mixed.
Always read and follow thesafety rules relating
to fuel before fueling your unit.
IMPORTANT
Experience indicates that alcohol blended fuels
(calledgasohol or using ethanolormethanol)
can attract moisture which leads to separa-
tion and formation of acids during storage.
Acidic gas can damage the fuelsystem of an
enginewhileinstorage.Toavoid engineprob-
lems, empty the fuel system before storage
for30 daysor longer.Drainthe gas tank,start
theengine andlet it run until the fuel lines and
carburetorareempty.Usefreshfuelnextsea-
son. Never use engine or carburetorcleaner
products in the fuel tank or permanent dam-
age may occur. See the STORAGE section
for additional information.
HOW TO STOP YOUR UNIT
STo stop the engine, move the ON/OFF
switch to the OFF position.
SIf engine does not stop, move choke lever
to FULL CHOKE position.

5
ON/OFF Switch
HOW TO START YOUR UNIT
WARNING: The trimmer head will
turnwhile startingthe engine.Avoid any con-
tact with the muffler. A hot muffler can cause
serious burns.
HELPFUL TIP
If your enginestill does not
start after following these
instructions, please call
1--800--554--6723.
STARTING A COLD ENGINE (or a
warm engine after running out of
fuel)
Starting Position
Muffler
Choke
Lever
Starter Handle
Primer Bulb
1. Set unit on a flat surface.
2. Move ON/OFFswitch totheONposition.
3. Slowly press the primer bulb 6 times.
4. Move choke lever to FULL CHOKE by
aligning lever with position shown on de-
cal (see illustration below).
Choke
position
decal
5. Squeeze the throttle trigger fully and hold
through all remaining steps.
6. Pull starter rope handle sharply until en-
ginesoundsasif itistryingtostart,butdo
not pull rope more than 6 times.
7. As soon as engine sounds as if itis tryingto
start, move choke lever to HALF CHOKE
byaligningleverwithpositionshownonde-
cal (see following illustration).
Choke
position
decal
8. Pull starter rope sharply until engine runs,
but no more than 6 pulls. If the engine
doesn’t start after 6 pulls (at the HALF
CHOKE position), move the choke lever to
the FULL CHOKE position and press the
primer bulb 6 times. Squeeze and hold the
throttle trigger and pull the starter rope 2
more times. Move the choke lever to the
HALF CHOKE position and pull the starter
rope until the engine runs, but no more than
6 pulls. If the engine doesn’t start, repeat
procedure 2 additional times. NOTE: If
engine still doesn’t start, it is probably
flooded. Proceed to STARTING A
FLOODED ENGINE.
9. Oncetheenginestarts,allowittorun10se-
conds, then move the choke lever to OFF
CHOKE by aligning lever with position
shown on decal (see illustration below). Al-
low the unit to run for 30 more seconds at
OFF CHOKE before releasing the throttle
trigger. NOTE: If engine dies with the
choke lever in the OFF CHOKE position,
movethe choke lever to the HALFCHOKE
position and pull the rope until engine runs,
but no more than 6 pulls.
Choke
position
decal
STARTING A WARM ENGINE
1. Move ON/OFFswitch totheONposition.
2. Move the choke lever to the HALF
CHOKE position.
3. Squeeze and hold the throttle trigger.
Keep throttle trigger fully squeezed until
the engine runs smoothly.
4. Pullstarterropesharplyuntilengineruns,
but no more than 5 pulls.
5. Allow engine to run 15 seconds, then
movethechokelevertotheOFFCHOKE
position.
NOTE:If engine has not started, pull starter
rope5morepulls.Ifenginestill doesnotrun,it
is probably flooded.
STARTING A FLOODED ENGINE
Flooded engines can be started by placing
the choke lever in the OFF CHOKE position;
then, pull the rope to clear the engine of ex-
cessfuel.Thiscouldrequirepullingthestarter
handle many times depending on how badly
the unit is flooded.

6
If the unit still doesn’t start, refer to
TROUBLESHOOTING TABLE or call
1-800-554-6723.
OPERATING POSITION
Cut from your left to your right.
ALWAYS WEAR: Eye protection
Long pants
Heavy shoes
WARNING: Alwaysweareyeprotec-
tion. Never lean over the trimmer head.
Rocks ordebriscanricochetorbethrowninto
eyes and face and cause blindness or other
serious injury.
Do not run the engine at a higher speed than
necessary. The cutting line will cut efficiently
when the engine is run at less than full throttle.
At lower speeds, there is less engine noise and
vibration. Thecutting line will last longer andwill
be less likely to “weld” onto the spool.
Always release the throttle trigger and allow the
engine to return to idle speed when not cutting.
To stop engine:
SRelease the throttle trigger.
SMove the ON/OFF switch to the OFF posi-
tion.
TRIMMER LINE ADVANCE
Thetrimmerlinewilladvanceapproximately2
inches (5 cm) each time the bottom of the
trimmerheadis tappedonthe groundwiththe
engine running at full throttle.
Themost efficient line length is the maximum
lengthallowedbythelinelimiter.Alwayskeep
theshield in place whenthetoolis beingoper-
ated.
To advance line:
SOperate the engine at full throttle.
SHoldthetrimmerheadparalleltoandabove
the grassy area.
STap the bottom of the trimmer head lightly on
the ground one time. Approximately 2 inches
(5 cm) of line will be advanced with each tap.
Always tap the trimmer head on a grassy area.
Tapping on surfaces such as concrete or as-
phalt can cause excessive wear to the trimmer
head. If theline isworn down to 2inches (5 cm)
or less, more than one tap will be required to ob-
tain the most efficient line length.
WARNING: Use only 0.080!(2mm)
diameter line. Other sizes of line will not ad-
vance properly and can cause serious injury.
Do not use other materials such as wire,
string, rope, etc. Wire can break off during
cutting and become a dangerous missile that
can cause serious injury.
CUTTING METHODS
WARNING: Use minimum speed
anddonotcrowdthelinewhencuttingaround
hard objects (rock, gravel, fence posts, etc.),
whichcandamagethetrimmerhead,become
entangled in the line, or be thrown causing a
serious hazard.
SThe tip of the line does the cutting. You will
achieve the best performance and
minimum line wearby not crowding theline
into the cutting area. The right and wrong
ways are shown below.
Right Wrong
Tip of line does
the cutting. Line crowded into
work area.
SThe line will easily remove grass and
weedsfromaroundwalls,fences,treesand
flower beds, but it also can cut the tender
bark of trees or shrubs and scar fences.
SFor trimming or scalping, use less than full
throttle to increase line life and decrease
head wear, especially:
SDuring light duty cutting.
SNear objects around which the line can
wrap such as small posts, trees or fence
wire.
SFormowingorsweeping,usefull throttlefor
a good clean job.
TRIMMING -- Hold the bottom of thetrimmer
headabout3 inches(8cm) abovetheground
andatanangle.Allowonlythetipof theline to
make contact. Do not force trimmer line into
work area.
Trimming
3 inches (8 cm)
above ground
SCALPING -- The scalping technique re-
movesunwantedvegetation.Holdthebottom
of the trimmer head about 3 inches (8 cm)
above the ground and at an angle. Allow the
tipofthelinetostrikethegroundaroundtrees,
posts, monuments, etc. This technique in-
creases line wear.

7
MOWING -- Your trimmer is ideal for mowing
in places conventional lawn mowers cannot
reach. In the mowing position, keep the line
parallel to the ground. Avoid pressing the
head into the ground as this can scalp the
ground and damage the tool.
SWEEPING -- Thefanning actionof therotat-
ing line can be used for a quick and easy
clean up. Keep the line parallel to and above
the surfaces being swept and move the tool
from side to side.
MAINTENANCE
WARNING: Disconnect the spark
plug before performing maintenance except
for carburetor adjustments.
HELPFUL TIP
IMPORTANT: Have all
repairs other than the rec-
ommended maintenance
described in the instruction
manual performed by an
authorized service dealer.
If any dealer other than an authorized
service dealer performs work on the
product, Electrolux Home Products,
Inc., may not pay for repairs underwar-
ranty. Itisyourresponsibilitytomaintain
and perform general maintenance.
CHECK FOR LOOSE
FASTENERS AND PARTS
SSpark Plug Boot
SAir Filter
SHousing Screws
SAssist Handle Screw
SDebris Shield
CHECK FOR DAMAGED OR
WORN PARTS
Contact an authorized service dealer for re-
placement of damaged or worn parts.
SON/OFF Switch -- Ensure ON/OFF switch
functions properly by moving the switch to
the OFF position. Make sure enginestops;
then restart engine and continue.
SFuel Tank -- Discontinue use of unit if fuel
tank shows signs of damage or leaks.
SDebris Shield -- Discontinue use of unit if
debris shield is damaged.
INSPECTANDCLEANUNITANDDE-
CALS
SAfter each use, inspect complete unit for
looseordamagedparts. Cleantheunitand
decals usingadampclothwithamilddeter-
gent.
SWipe off unit with a clean dry cloth.
CLEAN AIR FILTER
A dirty air filter decreases engine perform-
ance and increases fuel consumption and
harmful emissions. Always clean after every
5 hours of operation.
1. Clean the air filter cover and the area
around it to keep dirt from falling into the
carburetor chamber when the cover is
opened.
2. Remove parts by pressing button to re-
lease air filter cover (see illustration).
NOTE: To avoid creating a fire hazard or
producing harmful evaporativeemissions, do
not clean filter in gasoline or other flammable
solvent.
3. Wash the filter in soap and water.
4. Allow filter to dry.
5. Replace air filter and close cover.
Air Filter
Air Filter
Cover
Button

8
REPLACE SPARK PLUG
Replace the spark plug each year to ensure
the engine starts easier and runs better. Set
spark plug gap at 0.025 inch (0.6 mm). Igni-
tion timing is fixed and nonadjustable.
1. Twist, then pull off spark plug boot.
2. Remove spark plug from cylinder and
discard.
3. Replace with Champion RCJ-6Y spark
plug and tighten securely with a 3/4inch
(19 mm) socket wrench.
4. Reinstall the spark plug boot.
SERVICE AND ADJUSTMENTS
REPLACINGTHE LINE
1. Remove spool by firmly pulling on tap
button.
2. Clean entire surface of hub and spool.
3. Replace with a pre-wound spool, or cut two
lengths of 12-1/2 feet of 0.080!(2 mm) di-
ameter Poulan PROrbrand line.
WARNING: Never use wire, rope,
string,etc.,whichcanbreakoffandbecomea
dangerous missile.
4. Insert ends of the lines about 1/2 inch (1
cm) into the small holes on the inside of
spool.
Small
Holes
Spool
Hub
Line in Notch
Line in Notch
Line exit holes
5. Wind the line evenly and tightly onto the
spool. Wind in the directionof the arrows
found on the spool.
6. Push thelines intothenotches,leaving3
to 5 inches (7 -- 12 cm) unwound.
7. Insert the lines into the the exit holes in
the hub as shown in the illustration.
8. Align thenotches with the line exit holes.
9. Push spool into hub until it snaps into
place.
10. Pull thelines extendingoutsideofthehub
to release the lines from the notches.
REPLACINGTHE TRIMMER HEAD
1. Align hole in the dust cup with the hole in
the side of the gearbox by rotating the
dust cup.
2. Insert a small screwdriver into aligned
holes. This will keep the shaft from turning
while removing and installing the trimmer
head.
Screwdriver
3. While holding thescrewdriver inposition,
remove trimmer head by turning clock-
wise.
4. Thread replacement trimmer head onto
the shaft by turning counterclockwise.
Tighten until secure.
5. Remove the screwdriver.
CARBURETOR ADJUSTMENT
WARNING: Keep othersaway when
making idle speedadjustments. Thetrimmer
head will be spinning during this procedure.
Wearyourprotectiveequipmentandobserve
all safety precautions.
The carburetor has been carefully set at the
factory.Adjustmentsmaybenecessaryifyou
notice any of the following conditions:
SEngine will not idle when the throttle is
released.
Make adjustments with the unit supportedso
the cutting attachment is off the ground and
will not make contact with any object. Hold
theunitbyhandwhilerunningandmakingad-
justments. Keep all parts of your body away
from the cutting attachment and muffler.
Idle Speed Adjustment
Allow enginetoidle.Adjustspeeduntilengine
runs without stalling (idle speed too slow).
STurn idle speed screw clockwise to increase
engine speed if engine stalls or dies.
STurn idle speedscrew counterclockwise to
decrease engine speed.
Idle Speed
Screw
Air Filter
Cover
Ifyourequirefurtherassistanceorareunsure
about performing this procedure, contact an
authorized service dealer or call
1--800--554--6723.

9
STORAGE
WARNING: Perform the following
steps after each use:
SAllow enginetocool beforestoring ortrans-
porting.
SStore unit and fuel in a well ventilated area
where fuel vapors cannot reach sparks or
open flames from water heaters, electric
motors or switches, furnaces, etc.
SStore unit with all guardsin place. Position
unit so that any sharp object cannot acci-
dentally cause injury.
SStore unit and fuel well out of the reach of
children.
SEASONALSTORAGE
Prepareunit for storageat end of season or if
it will not be used for 30 days or more.
If your unit is to bestored for aperiodof time:
SClean the entire unit before lengthy
storage.
SStore in a clean dry area.
SLightly oil external metal surfaces.
FUEL SYSTEM
Under FUELING ENGINE in the OPERA-
TIONsectionofthis manual,seemessagela-
beled IMPORTANT regarding the use of ga-
sohol in your engine.
Fuel stabilizer is an acceptable alternative in
minimizing the formationof fuel gumdeposits
during storage.Add stabilizer to the gasoline
in the fuel tank or fuel storage container. Fol-
low the mix instructions found on stabilizer
container. Runengine at least 5 minutesafter
adding stabilizer.
HELPFUL TIP
Duringstorageofyourgas/
oil mixture,theoil will sepa-
rate from the gas.
We recommend that you
shake the gas can weekly
toinsureproperblendingof
the gas and oil.
ENGINE
SRemove spark plugand pour1 teaspoonof
40:1,2-cycleengineoil (air cooled)through
the spark plug opening. Slowly pull the
starter rope 8 to 10 times to distribute oil.
SReplacesparkplugwith newoneofrecom-
mended type and heat range.
SClean air filter.
SCheck entire unit for loose screws, nuts,
and bolts. Replace any damaged, broken,
or worn parts.
SAt the beginning of the next season, use
only freshfuelhavingthepropergasolineto
oil ratio.
OTHER
SDo not store gasoline from one season to
another.
SReplaceyourgasolinecanifitstartstorust.

10
TROUBLE CAUSE REMEDY
Engine will not
start. 1. ON/OFF switch in
OFF position.
2. Engine flooded.
3. Fuel tank empty.
4. Spark plug not firing.
5. Fuel not reaching
carburetor.
6. Carburetorrequires
adjustment.
1. Move ON/OFF switch to ON.
2. See “Starting a Flooded Engine” in
Operation Section.
3. Fill tank with correct fuel mixture.
4. Install new spark plug.
5. Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
6. Contact an authorized service dealer.
Engine will
not idle
properly.
1. Carburetorrequires
adjustment.
2. Crankshaft seals worn.
3. Compression low.
1. See “Carburetor Adjustment” in
Service and Adjustments Section.
2. Contact an authorized service dealer.
3. Contact an authorized service dealer.
1. Air filter dirty.
2. Spark plug fouled.
3. Carburetorrequires
adjustment.
4. Carbonbuild-up on
muffler outlet screen.
5. Compression low.
Engine will not
accelerate,
lacks power,
or dies under
a load.
1. Clean or replace air filter.
2. Clean or replace plug
and regap.
3. Contact an authorized service dealer.
4. Contact an authorized service dealer.
5. Contact an authorized service dealer.
Engine
smokes
excessively.
1. Choke partially on.
2. Fuel mixture incorrect.
3. Air filter dirty.
4. Carburetorrequires
adjustment.
1. Adjust choke.
2. Empty fuel tank and refill with
correct fuel mixture.
3. Clean or replace air filter.
4. Contact an authorized service dealer.
Engine runs
hot. 1. Fuel mixture incorrect.
2. Spark plug incorrect.
3. Carburetorrequires
adjustment.
4. Carbonbuild-up on
muffler outlet screen.
1. See “Fueling Engine” in Operation
section.
2. Replace with correct spark plug.
3. Contact an authorized service dealer.
4. Contact an authorized service dealer.
WARNING: Alwaysstopunitanddisconnectsparkplugbeforeperformingall ofthe
recommended remedies below except remedies that require operationof the unit.
TROUBLESHOOTINGTABLE

11
LIMITED WARRANTY
ELECTROLUX HOME PRODUCTS, INC.,
warrants to the original purchaser that each
newPoulanPRO"
""
"brand gasoline tool orat-
tachment is free from defects in material and
workmanship andagrees to repair or replace
under this warranty any defective gasoline
product or attachment as follows from the
original date of purchase.
2 YEARS-- Parts and Labor, when used for
household purposes.
90 DAYS -- Parts and Labor, when used for
commercial, professional, or income produc-
ing purposes.
30 DAYS -- Parts and Labor, if used forrental
purposes.
Thiswarrantyisnottransferableanddoesnot
cover damageor liability caused by improper
handling, improper maintenance, or the use
of accessories and/or attachments not spe-
cifically recommended by ELECTROLUX
HOME PRODUCTS,INC., forthis tool.Addi-
tionally, this warranty does not cover tune-
ups, spark plugs, filters, cutting line, or rotat-
ing head parts that will wear and require
replacement with reasonable use during the
warranty period. This warranty does not cov-
er predelivery setup or normal adjustments
explained in the instruction manual.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
NO CLAIMS FOR CONSEQUENTIAL OR
OTHER DAMAGES WILL BE ALLOWED,
AND THERE ARE NO OTHER EXPRESS
WARRANTIES EXCEPT THOSE EX-
PRESSLY STIPULATED HEREIN.
SOME STATES DO NOT ALLOW LIMITA-
TIONS ON HOW LONG AN IMPLIED WAR-
RANTY LASTS OR THE EXCLUSION OR
LIMITATIONS OF INCIDENTAL OR CON-
SEQUENTIALDAMAGES, SO THEABOVE
LIMITATIONS OR EXCLUSION MAY NOT
APPLY TO YOU.
The policy of ELECTROLUX HOME PROD-
UCTS, INC., is to continuously improve its
products. Therefore, ELECTROLUX HOME
PRODUCTS, INC., reserves the right to
change, modify, or discontinue models, de-
signs, specifications, and accessories of all
products at any time without notice or obliga-
tion to any purchaser.
U.S. EPA
EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OB-
LIGATIONS: The U. S. Environmental
Protection Agency and ELECTROLUX
HOMEPRODUCTS,INC.,arepleasedtoex-
plain the emissions control system warranty
on your year 2002--2004 small off--road en-
gine. ELECTROLUX HOME PRODUCTS,
INC., must warrantthe emission control sys-
temonyoursmall off--roadenginefortheperi-
ods of time listed below provided there has
been no abuse, neglect, or improper mainte-
nance of your small off--road engine. Your
emission control system includes parts such
as the carburetor and the ignition system.
Where a warrantablecondition exists, ELEC-
TROLUX HOME PRODUCTS, INC., will re-
pair your small off--road engine at no cost to
you. Expenses covered under warranty in-
cludediagnosis,partsandlabor. MANUFAC-
TURER’SWARRANTYCOVERAGE: Ifany
emissions related part on your engine (as
listed under Emissions Control Warranty
Parts List) is defective oradefectin themate-
rialsorworkmanshipoftheenginecausesthe
failure of such an emission related part, the
part will be repaired or replaced by ELEC-
TROLUX HOME PRODUCTS, INC. OWN-
ER’S WARRANTY RESPONSIBILITIES:
As the small off--road engine owner, you are
responsible for the performance of the re-
quired maintenance listed in your instruction
manual. ELECTROLUX HOME PROD-
UCTS, INC., recommends that you retain all
receipts covering maintenanceon your small
off--road engine, but ELECTROLUX HOME
PRODUCTS, INC., cannot deny warranty
solelyforthelack ofreceiptsorforyourfailure
to ensure the performance of all scheduled
maintenance. As thesmall off--roadengine
owner, you should be awarethat ELECTRO-
LUX HOME PRODUCTS, INC., may deny
you warrantycoverage if your small off--road
engine or a partof it has failed due to abuse,
neglect, improper maintenance, unapproved
modifications, or the use ofparts not made or
approvedby theoriginal equipmentmanufac-
turer. Youareresponsibleforpresentingyour
small off--road engine to an ELECTROLUX
HOME PRODUCTS,INC., authorizedrepair
centeras soon as aproblem exists. Warranty
repairs should be completed in a reasonable
amountof time, notto exceed 30days. If you
have any questions regarding your warranty
rightsandresponsibilities,youshouldcontact
your nearestauthorizedservicecenterorcall
ELECTROLUXHOMEPRODUCTS,INC.,at
1--800--554--6723. WARRANTY COM-
MENCEMENT DATE: The warranty period
begins on the date the small off--roadengine
is purchased. LENGTH OF COVERAGE:
This warranty shall be for a period of two
yearsfromtheinitialdateofpurchase. WHAT
IS COVERED: REPAIR OR REPLACE-
MENT OF PARTS. Repair or replacement of
any warranted part will be performed at no
charge to the owner at an approved ELEC-
TROLUX HOME PRODUCTS, INC., servic-
ing center. If you have any questions regard-
ing your warranty rights and responsibilities,
you should contact your nearest authorized

12
service center or call ELECTROLUX HOME
PRODUCTS, INC., at 1--800--554--6723.
WARRANTY PERIOD: Any warranted part
whichis notscheduledforreplacementasre-
quired maintenance, or which is scheduled
only for regular inspection to the effect of “re-
pair or replace as necessary” shall be war-
ranted for 2 years. Any warranted part which
is scheduled for replacement as required
maintenanceshallbewarrantedfortheperiod
of time up to the first scheduled replacement
point for that part. DIAGNOSIS: The owner
shall not be charged for diagnostic labor
which leads to the determination that a war-
ranted part is defective if the diagnostic work
is performed at an approved ELECTROLUX
HOME PRODUCTS, INC., servicing center.
CONSEQUENTIAL DAMAGES: ELEC-
TROLUXHOME PRODUCTS,INC., maybe
liable for damages to other engine compo-
nents caused by the failure of a warranted
part still under warranty. WHAT IS NOT
COVERED:All failurescausedby abuse,ne-
glect, or improper maintenance are not cov-
ered.ADD--ON OR MODIFIED PARTS: The
use of add--on or modified parts can be
grounds for disallowing a warranty claim.
ELECTROLUXHOMEPRODUCTS,INC.,is
not liable to cover failures of warrantedparts
caused by the use of add--on or modified
parts. HOW TO FILE A CLAIM: If you have
any questions regardingyour warrantyrights
andresponsibilities, you should contact your
nearest authorized service center or call
ELECTROLUXHOMEPRODUCTS,INC.,at
1--800--554--6723. WHERE TO GET WAR-
RANTY SERVICE: Warranty services or re-
pairs shall be provided at all ELECTROLUX
HOME PRODUCTS, INC., service centers.
Call 1--800--554--6723. MAINTENANCE,
REPLACEMENT AND REPAIR OF EMIS-
SION RELATED PARTS: Any ELECTRO-
LUXHOMEPRODUCTS,INC.,approvedre-
placement part used in the performance of
any warrantymaintenance orrepair on emis-
sion related parts will be provided without
charge to the owner if the part is under war-
ranty. EMISSION CONTROL WARRANTY
PARTS LIST: Carburetor, Ignition System:
Spark Plug (covered up to maintenance
schedule),IgnitionModule. MAINTENANCE
STATEMENT: The owner is responsible for
the performance of all required maintenance
as definedin the instruction manual.
This engine is certified to be emissions compliant for the following use:
Moderate (50 hours)
Intermediate (125 hours)
Extended (300 hours)
