Power bass XL Series User guide

XL Subwoofer Series
Application Guide
XL-840
XL-840D
XL-1040
XL-1040D
XL-1240
XL-1240D

Thank you and Congratulations
Congratulations on your decision to purchase PowerBass Xtreme “XL” series subwoofers. These top-of-the-
line speakers are the result of years of extensive engineering and testing, resulting in the finest car audio
subwoofers you can purchase today.
At PowerBass USA, Inc. we are confident you will have many years of outstanding enjoyment from your
investment. For maximum performance we recommend that you have your new PowerBass Xtreme product
installed by an Authorized PowerBass Xtreme Dealer. Doing so will also automatically extend your warranty to
a full THREE-YEAR Period.
To learn more about PowerBass Xtreme, please visit us on the World Wide Web at
http://www.powerbassusa.com
∆Warning ∆
Continuous exposure to sound pressure levels in excess of 100 dB can cause permanent hearing loss. PowerBass Xtreme Speakers
are capable of producing sound pressure levels well over 170 dB. Please observe all local sound ordinances while listening to your
PowerBass Xtreme system. PowerBass USA, Inc. accepts no liability for hearing loss, bodily injury, or property damage due to the result
of use or misuse of this product.
3

POWERBASS XTREME XL WOOFER FEATURES
Proprietary 4-layer, Non-pressed Paper, DDC Finish Cone: The premium grade cones on these
subwoofers are blend of papers and wood pulps, and coated in DDC to protect the cone and eliminate
distortion. This results in an extremely stiff cone that is resistant to environmental elements while remain-
ing exceptionally stable even under the stress of high sound pressure levels.
U-turn High Roll Santoprene Surround: This high roll surround is used to ensure long and linear travel
throughout the entire excursion range resulting in more bass output and higher SPL. The nonstandard “U”
design also gives the woofer more cone area to move more air and make more bass.
Composite Basket: Custom tooled Turbine style low resonant cast polycarbonate basket provides a very rigid
high strength foundation.
Chrome Push Input Terminals: These high strength compression loaded speaker terminals ensure
maximum current and power transfer.
Vented BASV Voice Coil Former: These specially designed resin coated high temperature voice coils
insure high power handling and precise linear excursion while maximizing thermal heat dissipation.
Voice Coil: Made with pure EIW wire for high energy and heat transfer. This makes the voice coil highly
efficient, and allows you to play louder for longer.
Xtra Large Motor Structure: Dual stacked magnets for increased SPL and power handling.
(XL-840/840D is a single stack magnet).
Optimally Designed for Both Sealed and Ported Enclosures: for many sonic and installation applica-
tions. This gives you a wide range of uses for the XL-Series Woofers.
Santoprene® is a registered trademark of ExxonMobil Chemical Co.

WIRING GUIDELINES
It is highly recommended that you seek an authorized PowerBass dealer to properly setup, wire
and install your woofers for maximum performance.
There are multiple ways to wire your woofers depending on your amplifier and system configuration. The use
of multiple voice coils offers you more versatility in system configuration. It is important to know the limits of
your amplifier to optimize its performance. It is always better to use your subwoofer in a mono / bridged mode
if your amplifier has the capabilities. There are basically four different types of wiring configurations: Series,
Parallel, Series-Parallel or Parallel-Parallel. It is possible to change the impedance or load by how the speakers
are to be wired and by the quantity of woofers used.
Parallel wiring a dual 4 ohm sub = 2 ohm
Parallel-Parallel wiring two dual 4 ohm subs = 1 ohm Series-Parallel wiring two dual 4 ohm subs = 4 ohm
NOTE: Never connect only one coil of a Dual Voice Coil (DVC) speaker. BOTH voice coils must be
connected to the amplifier
DUAL VOICE COIL WIRING
PARALLEL SERIES
SERIES PARALLEL
PARALLEL-PARALLEL
Series wiring a dual 4 ohm sub = 8 ohm
Amplifier
Amplifier
Amplifier Amplifier
5

SINGLE VOICE COIL WIRING
Parallel wiring of two single 4 ohm subs = 2 ohms
Parallel wiring of four single 4 ohm subs = 1 ohms
Series/ Parallel wiring of four single
4 ohm subs = 4 ohms
Single 4 ohm woofer
Amplifier
STANDARD
PARALLEL
Amplifier
PARALLEL
Amplifier
SERIES-PARALLEL
Amplifier

INSTALLATION EXPERIENCE
Installation of PowerBass Xtreme Subwoofers requires experience with a variety of mechanical proce-
dures including enclosure construction. This manual only provides general installation and operation in-
structions. If you have any reservations about your installation skills, please contact your local Authorized
PowerBass dealer for assistance.
CHOOSING A SPEAKER ENCLOSURE
MULTI ENCLOSURE COMPATIBILITY the PowerBass Xtreme Subwoofers are engineered to perform
well in various types of enclosures. These subwoofers offer the versatility of being used in either sealed,
vented or band-pass enclosures. For maximum performance we recommend you have your new Power-
Bass Xtreme Subwoofer installed by an Authorized PowerBass Xtreme Dealer.
• SEALED BOX: A sealed or acoustic suspension enclosure is easy to build and typically offers
a smaller size enclosure and greater power handling. It has the most predictable frequency and
phase response; the bass response will roll off slower than that of a ported design. Sealed boxes
typically provide the best musical detail and definition. A well-designed sealed enclosure will exhibit
smooth frequency response with excellent sound quality and great low bass extension. They also
exhibit relatively accurate, punchy bass reproduction for most types of music. If a sealed enclosure
is too large to fit into a specific area of a vehicle, it is possible to decrease the recommended box
volume by using 1.5 pounds per cubic feet of low density, high heat specific box stuffing material.
PowerBass recommends Fiberglass, Dacron, Poly-Fill or long fiber wool for stuffing the enclosure.
(Decreasing the box enclosure however should not exceed 20% of the recommended
size.) When using any type of box stuffing material be sure that the subwoofer’s vented pole piece
is clear from any obstructions, since covering the pole piece will result in loss of bass and can
possibly cause damage to your subwoofer. The most important aspect of a sealed enclosure is to
make sure that it is airtight and solid. If your enclosure has any air leaks or if the panels vibrate or
flex, you will experience a loss of bass output. Using glue and some type of sealant (caulk) on all
seams will ensure a solid constructed box without any air leaks.
7

• VENTED BOX: Also known as a ported or bass reflex enclosure, this type of box is almost as easy
to construct as a sealed enclosure. This design however is more efficient and results in an increase
of bass output at certain frequencies. Although vented enclosure has an output advantage at some
frequencies, it also has a steeper roll off, which will only affect bass frequencies below port tun-
ing. Air inside the port will move in phase with the subwoofer reinforcing frequencies above the F3
(-3dB point). The SPL advantage of the vented enclosure comes from the fact that the effect of the
vent tuning reduces the excursion of the subwoofer near the tuning frequency allowing more SPL
to be produced before the subwoofer bottoms. Damping material should also be used to line the
internal walls to reduce any sonic reflection. Because of the characteristics of a vented enclosure,
subwoofers typically will become unloaded (act as if it is not in a box) at frequencies of ½ octave
below the enclosure tuning frequency. Using a high pass filter / subsonic filter will help prevent the
subwoofer from unloading or exceeding its excursion capabilities. It is important to stay within the
recommended enclosure designs. (PowerBass recommends port placement to coincide on
the same panel or baffle that the subwoofer resides on.)
• BANDPASS ENCLOSURE: The most common band-pass enclosure is a combination of a sealed
and a vented enclosure working together (4th order or single reflex band-pass system). The rear of
the speaker goes into the sealed chamber while the front of the speaker goes into the vented cham-
ber. Because the vent produces all the sound generated from this type of enclosure, sound quality
may not be as good as a well-designed ported or sealed design. Often the sacrifice for sound quality
and subwoofer cone control is greater SPL output. However unlike a sealed or vented enclosure,
you can effectively increase the enclosure sensitivity with the appropriate tuning choices. You can
choose to design a narrow frequency band with very high sensitivity or choose a wide frequency
band with the sacrifice of lower sensitivity. The damping effect of the vented chamber reduces the
motion of the cone so that potentially higher sound output is achieved without the subwoofer reach-
ing its mechanical limits. Minor deviations from design recommendations however may result in
frequency response and distortion problems.
(If you are intending to use multiple subwoofers in your system, PowerBass recommends hav-
ing separate chambers for each subwoofer if the subwoofers will be operated by two different
amplified signals. This will prevent any possible cancellation.)

12" x 12" x 12" = 1728 3 Inches"
12”
12”
12”
NOTE: Due to the vented backplate, you must allow an additional 2” behind the subwoofer when
designing your speaker enclosure.
ENCLOSURE VOLUME
To calculate the volume required for your enclosure please refer to the Recommended Enclosures secction
of this guide for your specific model number. These are listed in both cubic feet and liters. One cubic foot is
expressed as 12” x 12” x 12” = 1728 cubic inches (see picture below).
9

TIPS TO GET THE MOST OUT OF YOUR XL WOOFER
Your PowerBass Xtreme subwoofer has been meticulous engineered and designed to handle high power
musical reproduction. Despite their rugged construction, it is possible to damage your speaker if they are
improperly used. In general, you will hear distortion as a so-called warning before any damage occurs.
If you hear distortion in your system, immediately reduce the musical level to the point where the sound
retains its clarity.
1. All PowerBass Xtreme subwoofers require an initial break-in period before it will reach optimum
performance. Like any new precision machinery, allow a minimum of several days to one week with
normal daily usage to ensure that the suspension has properly been broken-in.
2. Be sure you supply the speakers with enough unclipped amplifier power to drive them properly.
(More damage can be done to a speaker by under-powering and clipping your amplifier than any
other way!)
3. Where possible, run your Speakers in mono instead of stereo. Most bass is reproduced in mono so
there is less chance of any cancellation if played in mono.
4. Where possible, wire your Speakers in parallel instead of series. Bass is reproduced either way but
again there is less chance of cancellation in parallel. NOTE: Be sure the amplifier you are using is
stable to the resulting impedance of the speaker load!
5. Where possible, a separate amplifier just for your subwoofers should be used with an electronic
crossover to set the frequency range.
6. Do not block the front of your speakers or ports. You want as much direct air coupling as possible.
Also be sure to round off the inside edges of the port to reduce any port noise.
7. For ported enclosures, keep in mind that you must leave at least twice the port diameter size be-
tween the subwoofer and the port itself. Leave at least one time the port diameter between the port
and any walls of the enclosure.
Note: The XL woofer basket is constructed of composite materials. Please use the enclosed
paper template if you are pre-drilling speaker mounting pilot holes-do not use the woofer as
a template.

BOX CONSTRUCTION (SEALED OR VENTED): The material used for enclosure walls should be
solid, dense and free of voids or warps. Your enclosure should be made ¾” or 19mm material, Finland
or Baltic birch type plywood is recommended where the enclosure will be transported frequently. High-
density fiberboard - MDF (not chip board) can be used on permanently installed systems.
Minimum of 1” (25mm) or double ¾” (1-1/2”) baffle is recommended on high-powered SPL applications.
Corners must be strong and air tight and should not have any air leaks or openings. Joints should be
properly filled with glue that will not crack under high stress or impact. If the integrity of the glue seal
can’t be determined, hot glue or RTV caulking should be used to seal all seams.
Fiber reinforced resin may also be used to form any difficult shapes. However avoid making large panels
with resin to eliminate any chances of box flexing, cracking or ratting under high pressure. Bracing made
of 2 x 2” or 2 x 4” should be liberally applied either inside or outside the cabinet, depending on whether
the cabinet is to be permanently installed or portable. This principle applies to any walls of the enclosure
spanning more than 18” long.
Any braces should also be liberally glued or screwed down on edge. Edge-wise drilled, and countersunk
holes through the braces can be used for #10-2 Flathead wood screws to avoid the use of more expensive
lag bolts. The majority of strength from an enclosure comes from the glue. When using screws be sure
to pre-drill holes to avoid splitting the wood.
Note: Do not mount the woofer in the enclosure within 24 hours of sealing the internal joints. The
gasses given off as the sealer cures can affect the surround of the speaker resulting in permanent
damage that will void the warranty.
WARNING! The use of silicone rubber to seal in a speaker will void the Warranty! If any sealing
is needed in addition to the speaker’s gasket, use caulking cord or vinyl weather strip.
BREAK IN PERIOD
To get the most from your woofer we recommend a “break-in” period of at least 40 hours at no more than
1/3 of maximum volume.
During this time the cone and spider assembly will gradually break in resulting in greater performance and
more listening enjoyment.
SUBWOOFER CROSSOVER SETTING
Your PowerBass subwoofers will perform best if they are used in conjuction with a subwoofer crossover of
some kind. Using a crossover will remove unwanted high frequencies and allow them to concentrate only
on bass. The two most common types of crossovers are "passive" or "active" (electronic crossovers are
active). Many amplifiers have a built in Low Pass (LPF) electronic crossover circuit. For optimum subwoofer
performance we recommend an initial electronic crossover setting between 80-100Hz and then tuning
the bass to your liking.
11

PREPARING FOR INSTALLATION
NOTE: The tools listed below may be required for basic installation.
• An electric drill with bits
• Saber, circular and jig saw
• Phillips-head and standard screwdrivers
• Wire strippers
• Crimping tool and needle-nose pliers
• Silicone sealant (for enclosures), closed cell weather-stripping (for the speakers)
INSTALLATION PRECAUTIONS
NOTE: Proceed only if you are a qualified installer otherwise; let your dealer do it.
• Always wear protective eyewear when using tools.
• Turn off all stereo and other electrical devices before you begin.
• Disconnect the (-) negative lead from your vehicle’s battery.
• Keep the speakers in the package until final installation, and always rest it with the cone facing up.
Never use force when installing a speaker.
• Locate all fuel lines, brake lines, oil lines, and electrical cables when planning your installation.
• Check to see if there is enough clearance behind the mounting surface before drilling holes or install-
ing screws for proper speaker ventilation.
• Also make sure there’s enough front clearance for speaker cone excursion. Failure to do this could
cause the cone to vibrate against any obstructing object.
• Use a utility knife to trim away fabric from the speaker mounting hole location before drilling. It is
hard to get a good seal if you have both the carpet & subwoofer gasket between the speaker and
the enclosure.
• When running speaker wires through sheet metal, be sure to use grommets to properly insulate the
wires from metal edges.

PARAMETERS FOR POWERBASS XL SERIES WOOFERS
(Due to Constant Improvements, Specifications and Parameters are subject to change without notice)
XL-840 XL-840D XL-1040 XL-1040D
VC Impedance (ohms) 4Ω4Ω+ 4Ω4Ω4Ω+ 4Ω
Test Impedance (ohms) 3.5 1.6 3.7 1.6
Driver Displacement 0.0446 cu ft 0.0446 cu ft 0.0824 cu ft 0.0824 cu ft
Fs (Hz) 43.3 52.119 38.2 35.34
SD (sqCM) 211.24 211.24 363.05 363.05
Vas (Ltr) 9.64 7.132 19.842 26.55
CMS (µM/N) 152.1 112.55 106.014 141.9
Mms (g) 88.9 82.851 163.752 142.9
BL™ 12.83 8.107 14.904 9.04
Qms 3.97 3.757 4.559 3.7
Qes 0.514 0.644 0.655 0.621
Qts 0.455 0.550 0.572 0.534
No (%) 0.14 0.152 0.163 0.18
Spl (dB) 89 83.8 84.2 89.5
Xmax (mm) 6 6 8.5 8.5
Voice Coil Size (inches) 2.0 2.0 2.0 2.0
Frequency Response (Hz) 43-500 43-500 35-500 35-500
Mounting Depth 4.375” 4.375” 5.23” 5.23”
Power (RMS/Peak) 200/400 watts 200/400 watts 350/700 watts 350/700 watts
13

PARAMETERS FOR POWERBASS XL SERIES WOOFERS
(Due to Constant Improvements, Specifications and Parameters are subject to change without notice)
XL-1240 XL-1240D
VC Impedance (ohms) 4Ω4Ω+ 4Ω
Test Impedance (ohms) 3.8 1.6
Driver Displacement 0.139 cu ft 0.139 cu ft
Fs (Hz) 39.763 33.0
SD (sqCM) 551.55 551.55
Vas (Ltr) 38.832 55.20
CMS (µM/N) 89.895 127.8
Mms (g) 178.217 171.9
BL™ 14.814 9.57
Qms 4.038 3.73
Qes 0.771 0.64
Qts 0.647 0.57
No (%) 0.306 0.32
Spl (dB) 86.9 91
Xmax (mm) 8.5 8.5
Voice Coil Size (inches) 2.0 2.0
Frequency Response (Hz) 33-450 33-450
Mounting Depth 5.7” 5.7”
Power (RMS/Peak) 400/800 watts 400/800 watts

RECOMMENDED ENCLOSURES
Please note that these enclosure volume recommendations are for the internal airspace inside the enclo-
sure and include the displacement of the subwoofer and ports. When choosing your enclosure type, please
pay close attention to your specific woofer, failing to use the correct enclosure may result in lower power
handling and poor sound quality. To calculate the internal airspace required, take the internal
dimensions of the box. First multiple these number by themselves and then divide this sum by
1728. (W x H x D) / 1728. Please contact your authorized PowerBass Xtreme dealer for other designs
and specifications. (Even though these subwoofers can be used in a ported enclosure, PowerBass
recommends a sealed enclosure for optimum performance and sound quality.)
XL-840 / XL-840D
Optimum Sealed Volume English Unit Metric Unit
Gross Vb internal 0.5 Cu.ft 14.2 L
Fc, (resonance frequency of the closed box system) 55 Hz 55 Hz
F3 (-3dB Cutoff) 52Hz 52Hz
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 11.5 x 11.5 x 10.25 inch 29.2 x 29.2 x 26 cm
Qtc 0.65 0.65
Pe (Watts-RMS) 50 - 200W 50 - 200W
Acceptable Volumes 0.5 - 1 Cu.ft 14.2 - 28.32L
Optimum Ported Volume English Unit Metric Unit
Gross Vb internal 0.75 Cu.ft 21.24 L
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 13.5 x 13.5 x 10.5 inch 34.3 x 34.3 x 26.67 cm
Internal port opening size, W x H 7.5 x 1.5 inch 19.1 x 3.8 cm
Internal port Length 17 inch 43.18 cm
Fb (Box Tuning) 41Hz 41Hz
F3 (-3dB) 47Hz 47Hz
Pe (Watts-RMS) 50 - 200W 50 - 200W
Subsonic Filter Setting If Applicable 47Hz 47Hz
15

XL-1040 / XL-1040D
Optimum Sealed Volume English Unit Metric Unit
Gross Vb internal 0.75 Cu.ft 21.24 L
Fc, (resonance frequency of the closed box system) 51Hz 51Hz
F3 (-3dB Cutoff) 47Hz 47Hz
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 13.5 x 13.5 x 10.5 inch 34.3 x 34.3 x 26.7 cm
Qtc 0.79 0.79
Pe (Watts-RMS) 100 - 350W 100 - 350W
Acceptable Volumes 0.65 - 1.25 Cu.ft 18.4 - 35.4L
Optimum Ported Volume English Unit Metric Unit
Gross Vb internal 1.5 Cu.ft 42.49 L
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 13 x 16 x 17.5 inch 33 x 40.6 x 44.5 cm
Internal port opening size, W x H 10 x 2 inch 25.4 x 50.8 cm
Internal port Length 15.5 inch 39.4 cm
Fb (Box Tuning) 38 Hz 38 Hz
F3 (-3dB) 40 Hz 40 Hz
Pe (Watts-RMS) 100 - 350W 100 - 350W
Subsonic Filter Setting If Applicable 40Hz 40Hz
COMPATIBILITY
ENCLOSURE
MULTI

17
XL-1240 / XL-1240D
Optimum Sealed Volume English Unit Metric Unit
Gross Vb internal 1.25 Cu.ft 35.4 L
Fc, (resonance frequency of the closed box system) 53Hz 53Hz
F3 (-3dB Cutoff) 44Hz 44Hz
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 15 x 15 x 13.5 inch 38.1 x 38.1 x 34.3 cm
Qtc 0.85 0.85
Pe (Watts-RMS) 100 - 400W 100 - 400W
Acceptable Volumes 1.0 - 2.25 cu.ft 28.32 - 63.7 L
Optimum Ported Volume English Unit Metric Unit
Gross Vb internal 2.25 Cu.ft 63.7 L
External Dimensions of the enclosure WXHXD, 3/4" (19mm) MDF 15.5 x 18.5 x 18 inch 39.4 x 47 x 45.7 cm
Internal port opening size, W x H 12.5 x 2.25 inch 31.8 x 57.2 cm
Internal port Length 16 inch 40.6 cm
Fb (Box Tuning) 36Hz 36Hz
F3 (-3dB) 39Hz 39Hz
Pe (Watts-RMS) 100 - 400W 100 - 400W
Subsonic Filter Setting If Applicable 39Hz 39Hz

POWERBASS XTREME LIMITED WARRANTY POLICY
PowerBass USA, Inc. offers limited warranty on PowerBass products under normal use on the following terms:
PowerBass Xtreme Speakers are to be free of defects in material and workmanship for a period
of one (1) year. The warranty is extended to three (3) years for parts and labor, if an Authorized
PowerBass Xtreme Dealer completes the installation.
This warranty applies only to PowerBass products sold to consumers by Authorized PowerBass Dealers in the United States
of America. Products purchased by consumers from a PowerBass dealer in another country are covered only by that coun-
try’s Distributor and not by PowerBass USA.
This warranty covers only the original purchaser of PowerBass product. In order to receive service, the purchaser must
provide PowerBass with a valid purchase receipt from an authorized reseller stating the consumer name, dealer, product
and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equiva-
lent) at PowerBass’s discretion and will not be liable for incidental or consequential damages. PowerBass will not warranty
this product under the following situations:
•Speakersreceivedwithbentframesorwaterdamage
 •Abusesuchasholesinthecone,surroundorrippedspider
 •Voicecoildamageduetoamplierclippingordistortion
 •Productthathasnotbeeninstalledaccordingtothisownersmanual
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of
the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this
limitation may not apply. No person is authorized to assume for PowerBass any other liability in connection with the sale
of this product.
Please call [phone] for PowerBass Customer Service. You must obtain an RA# (Return Authorization Number)
to return any product to PowerBass. The RA number must be prominently marked on the outside of the shipping
carton or the delivery will be refused. Please pack your return carefully; we are not responsible for items damaged in
shipping. Return the defective product along with a copy of the original dated retail sales receipt, plus $12.00 for handling
and diagnostic evaluation to:
PowerBass USA, Inc.,
Attn: Returns (RA#__________)
2133 S. Green Privado, Ontario, CA 91761
Residents of HI, AK and US territories will be charged for return shipping. All inquires regarding service and warranty should
be sent to the above address.
Removed or altered serial numbers will void this warranty

This manual is the exclusive property of PowerBass USA, Inc. Any reproduction of this manual, or use other than its intentions is
strictly prohibited without the express consent of PowerBass USA, Inc. Copyright 2017 PowerBass USA, Inc.

PowerBass Autosound – A division of PowerBass USA, Inc.
2133 S. Green Privado – Ontario, CA 91761
Tel. [phone] – Fax [phone]
www.powerbassusa.com
