Power Glide 60109830 User manual

Model No: 60109830
®
1/3 Sheet Finish Sander
Instruction Manual
Type60109830
Input Voltage120V ~ 60Hz
Input Power 1.2 Amp
No Load Speed12,000 OPM
Pad Dimensions 3-1/2" x 7-3/8" (90 x 187mm)
Paper Size3-5/8" x 9" (92 x 228mm)
Power Cord 18/2 x 6' L
Double InsulatedYes
Technical Data
Made in China
©2010 World Factory, Inc.
Distributed by:
World Factory, Inc.
Westlake, TX 76262
Due to ongoing product development the actual product or products may
vary from the illustrations or photos shown within this manual.
Model No. 60900015
Read the instructions and precautions before use of this product
Please keep this instruction manual for future reference
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CONSUMER SUPPORT AT
1-888-424-3354
OR
IF YOU ARE A STORE MANAGER OR EMPLOYEE IN NEED OF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
220710rev1
Power Glide Limited Warranty
Consumer Power Tools for Home Use to Original Buyer
World Factory, Inc. (Seller) warrants to the original Buyer only, that each POWER GLIDE power tool will
be free from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH ARE
DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER WHICH
HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM REPAIRS OR
ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER MAINTENANCE, NEGLECT OR
ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. To make a claim under this Limited
Warranty, you must return the complete power tool with proof of purchase, transportation prepaid, to
any World Factory, Inc. authorized service center. Call 1-888-424-3354 or E-mail;
[e-mail] for the location of the nearest authorized power tool service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO COMMERCIAL USER OR ACCESSORY ITEMS SUCH
AS CIRCULAR SAW BLADES, DRILL BITS, ROUTER BITS, JIGSAW BLADES, SANDING BELTS OR PADS,
GRINDING WHEELS AND OTHER RELATED ITEMS. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN
DURATION TO ONE (1) YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY
FOR LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if such
invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all prior
agreements, arrangements, or understandings between the parties relating to product warranty.
Rev 08072007

1
WARNING: Read all instructions. Failure to follow all instructions listed below may result in
 electrical shock, fire and/or serious injury. The term “power tool” in all of the warnings listed
below refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
    SAVE THESE INSTRUCTIONS
Work Area
1.Keep your work area clean and well lit. Cluttered and dark areas invite accidents
2.Do not operate power tools in explosive atmospheres, such as in the presences of
flammable liquids, gases, or dust. Power tools create sparks, which may ignite the dust
or fumes.
3.Keep bystanders, children and visitors away while operating a power tool. Distractions can
cause you to loose control.
Electrical Safety
1.Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodfied plugs and matching outlets
will reduce risk of electrical shock.
2. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges,
and refrigerators. There is an increased risk of electrical shock if your body is earthed
or grounded.
3.Do not expose power tool to rain or wet conditions. Water entering a power tool will
increase the risk of electrical shock.
4.Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entaqngled
cords increase the risk of electrical shock.
5.When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electrical shock.
Personal Safety
1.Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in serious personal injury.
2.Use safety equipment. Always wear eye protection. Safety equipment such dust mask, non-
skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions to
reduce personal injuries.
3.Avoid accidental starting. Ensure switch is in the off-position before plugging in. Carrying
tools with your finger on the switch or plugging in power tools that have the switch on
invites accidents.
4.Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
5.Do not overreach. Keep proper footing and balance at all times. This enables better control
of the tool in unexpected situations.
6.Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
7.If devices are provided for connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust-
related hazards.
GENERAL SAFETY RULES
Notes:

92
Power Tool Use And Care
1.Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it is designed.
2.Do not use power tool if switch does not turn it on or off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
3.Disconnect the plug from the power source and/or battery pack from the power tool before
making any adjustments, changing accessories, or storing the tool. Such preventative
safety measures reduce the risk of starting the tool accidentally.
4.Store idle power tools out of reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Tools are dangerous in the hands
5.Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tools operation. If damaged, have
the power tool repaired before using. Many accidents are caused by poorly maintained tools.
6.Keep cutting tools sharp and clean. Properly maintained tools with sharp cutting edges are
less likely to bind and are easier to control.
7.Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in a manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from those intended could result in hazardous situation.
Service
1.Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Cleaning
WARNING: RISK OF PERSONAL INJURY. Always disconnect tool from power source before
making any adjustment, installing or changing accessories.
1. Clean the tool housing and motor vents after each use.
2. Keep the grip dry, clean and free from oil and grease.
3. Store the tool on a safe and dry place, out of reach of children.
4. Do not use cleaning agents or solvents that could attach the plastic parts of the tool.
5. Turn the tool off immediately and do not operate, until repaired, if tool begins to make
abnormal noise, vibrations, produces smoke or burning odor.
Service
WARNING: Tools service must be performed only by qualified repair personal. Service or
maintenance performed by unqualified personnel could result in a risk of injury. When
servicing a tool, use only identical replacement parts. Follow instruction in the maintenance
section of this manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
Contact World Factory, by phone at 1-888-424-3354, or be E-mail at
[email protected], for the location of the nearest authorized power tool
service center.
Recommended Accessories:
1. Sandpaper
MAINTENANCE
ACCESSORIES

38
Basic Operation
WARNING:
• Always work in a well-ventilated area. Sanding can produce fine dust that can ignite if
exposed to open flame or sparks.
• Risk of electrical shock - do not use tool for wet sanding or polishing with liquids. Do not
expose the tool to rain or water. Do not use in damp locations.
• Always wear eye protection and respirator when sanding.
CAUTION:
• Remove all nails, staples, fasteners, foreign objects or other debris before sanding. Never
sand over these objects.
• Do not operate sander without dust collector.
• Never use the sander without sandpaper or damage to the base could result.
1. Grasp the tool firmly with, both hand, by the grips.
2. Start the tool and allow it to reach full speed.
NOTE: Always start and stop the sander before contacting the workpiece.
3. Lower the sander onto the workpiece surface. Allow the weight of the tool apply friction
between the sandpaper and workpiece. In most cases additional pressure will not be required
4. Move the sander evenly over the work surface maintaining constant motion. Prolong
operation in one location can cause uneven surfaces. Check your progress often as sander
is capable of rapid material removal.
5. For best results, choose the correct sandpaper and grit for the job. Progress from course to a
finer grit of sandpaper to achieve the finish desired. Change sandpaper frequently. Work in a
strait line with the wood grain whenever possible.
Grit Selection and Common Uses Guide:
Course Grit- For rapid material removal, shaping or forming
Medium Grit- For general purpose sanding
Fine Grit- For smoother sanding and scratch removal
Extra Fine Grit- For extra smooth finish and fine scratch removal
Sandpaper Cutting Guide:
Replacement 3.6” x 9” sandpaper sheets
can be made from commercially available
full size 9” x 11” sheets. (SEE FIGURE 6)
Cut each sheet into 3 equal pieces
(1/3 sheet.)
OPERATING INSTRUCTIONS
Figure 6
1.Hold power tool by insulated gripping surfaces when performing an operation where the
cutting tool may contact hidden wiring or its own cord. Contact with a "live"wire will make
exposed metal parts of the tool "live" and shock the operator.
SPECIFIC SAFETY RULES
CALIFORNIA PROPOSITION 65
SYMBOLS
WARNING: RISK OF CHEMICAL EXPOSURE. Use of this tool can generate dust containing
chemicals known to the state of California to cause cancer, birth defects or other reproductive
harm. To reduce exposure to these chemicals, always use approved safety equipment, work
in a well-ventilated area and wear dusk mask that filters out microscopic particles.
Amperes
Volts
Watts
Alternating Current
Direct Current
Double Insulated Class II Tool
Hertz
Revolutions per minute
Minutes
Oscillations per Minute
No Load Speed
Safety Alert
SymbolName
The following symbols are used for this tool:
A or Amp
V
W
~
Hz
.../min or RPM
Min
OPM
No
Cut Line
Cut Line
11"
9"

74
CONNECTION TO THE POWER SUPPLY
Electrical Safety
1. Double Insulated tools are equipped with a polarized plug (one blade is wider than the other.)
This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized
outlet. Do not change the plug in any way. Double insulation eliminates the need for the three
wire grounded power cord and grounded power supply system.
2.Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electrical shock if your body is grounded.
3. Don't expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electrical shock.
4. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from the outlet.
Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords
immediately. Damaged cords increase the risk of electrical shock.
Extension Cords
1. Make sure your extension cord is in good condition. When using an extension cord, be sure to
use one heavy enough to carry the current your product will draw. An undersized cord will
cause a drop in line voltage resulting in loss of power and overheating. Table 1 shows the
correct size to use depending on cord length and nameplate Ampere rating. If in doubt, use
the next heavier gauge. The smaller the gauge number, the heavier the cord.
2. When operating a power tool outside, use an outdoor extension cord marked "W-A" or "W".
These cords are rated for outdoor use and reduce the risk of electrical shock.
3. Use only UL listed extension cords. Inspect extension cord before use and never use damaged
or altered extension cords. Follow extension cord manufacturer safety instruction.
4. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords
immediately. Damaged cords increase the risk of electrical shock.
AmpVolts
  25 ft.50ft100ft150 ft
1-5120V18161614
6-10120V16161412
11-12120V14141412
12-16120V1412Not Recommended
Table 1.
Minimum Gage For Power Cord
Total Length of cord in feet
Rating
AWG
ATTACHING A DUST COLLECTION HOSE (optional)
Figure 4
2
1
Sanding operations are inherently dusty. It is recommended that users employ a dust-collection
system when using this sander . To help minimize the amount of dust that escapes into the
surrounding air, this sander is equipped a 1-1/4" dust evacuation chute that can be connected to
a shop vacuum or dust-collection system. Use of a mask or respirator is still recommended even
when a dust-collection system is in use.
1.(See Figure 4) Place a 1-1/4 diameter vacuum/dust-collection hose into the dust chute (1).
2.To remove the dust chute: grasp the dust chute near the tool base (2) and twist left  
(counterclockwise) to release locking tabs. Pull chute from the sander base to remove.
3.Reverse procedure for chute installation.
NOTE: The holes in the sandpaper must be aligned with the holes in the sander base for the dust
collection system to work.

56
CONTENTS
1.On/Off Trigger Switch
2.lock On Button
3.Grip
4.Dust Chute
5.Sandpaper Clamps
6.Sanding Pad
4
3
GETTING TO KNOW YOUR TOOL
Figure 1
6
FUNCTIONAL DESCRIPTION
On/Off Trigger Switch
1. (SEE FIGURE 2) To start sander, pull the
trigger switch (1).
2. To stop sander, release the trigger.
3.For continuous operation, pull the trigger (1)
and press the lock-on button (2). The sander
will continue to run until the trigger is pulled
fully and then released.
ASSEMBLY
WARNING: Risk of personal injury. Always disconnect the sander from the power outlet before
making any adjustment, installing or changing the sandpaper or dust bag.
Installing Sandpaper
1. (SEE FIGURE 3) Release the rear sandpaper
clamp by pulling up on the clamp lever (2)
until it disengages from the base tab (3).
Rotate clamp to the full open position.
2. Place the narrow edge of the sandpaper (4)
between the clamp and the sander base (grit
side up). Note: Use sandpaper provided or
1/3 of any standard 9" x 11" sandpaper
sheet (approximately 3.6" x 9").
3. Rotate clamp to the closed position and
secure clamp lever behind base tab.
4. Wrap the sandpaper tightly around the
pad (5) on the bottom of the sander base.
Insert the loose edge between the front
clamp and the sander base and secure with
 the clamp in a similar manner.
Figure 3
Figure 2
1.Sander
2.Dust Chute
3.Sandpaper (1/pcs 100grit)
4.Instruction Manual
5
3
12
3
5
12
2
4
open
