Power It! JD2512U User manual

5" RANDOM ORBIT SANDER
JD2512U
Owner’s Manual
PRODUCT SPECIFICATIONS
Rating:
120 V, 60 Hz AC
Amperes:
2.4 A
Speed:
5,000 –12,000 OPM (no load)
Disc diameter:
5” (125 mm)
Weight:
3 lb 6 oz (1.53 kg)
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 Monday through Friday 9am –5pm
Eastern Time
Technical questions
Replacement parts
Parts missing from package

2
Product specifications ………….……………………………………………………...
1
Table of contents ……………………………………………………………………....
2
General safety warnings ………………………………………………………………
3–4
Eye, ear & lung protection …………………………………………………………….
3–4
Electrical safety ………………………………………………………………………...
4
Power tool safety ……………………………………………………………………....
5–6
General safety rules …………………………………………………………………...
5
Work area ………………………………………………………………….……………
5
Electrical safety ………………………………………………………………………...
5
Personal safety …………………………………………………………………………
5–6
Power tool use and care.………………………………………………………………
6
Service ………………………………………………………………………………….
6
Specific safety rules ……………………………………………………………………
7
Guidelines for extension cords ……………………………………………….………
8
Symbols …………………………………………………………………………………
9
Know your sander …………………………………………………………….............
10
Assembly and operating ………………………………………………………………
11–14
Installing a sanding disc ……………………………………………………………….
11
Speed control switch …………………………………………………………………..
11
ON/OFF switch …………………………………………………………………………
11
Connecting the dust box assembly to the sander ………………………………….
12
Cleaning the dust box …………………………………………………………………
12
Sanding disc selection ………………………………………………………………...
12–13
Sanding …………………………………………………………………………………
13–14
Maintenance …………………………………………………………………………..
14
Exploded view …………………………………………………………………………
15
Parts list ………………………………………………………………………………..
16
Warranty ……………………………………………………………………….………
17
TABLE OF CONTENTS

3
EYE, EAR & LUNG PROTECTION
This instruction manual includes the following:
General Safety Rules
Specific Safety Rules and Symbols
Functional Description
Assembly
Operation
Maintenance
Accessories
!
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during the operation of a power tool.
SAVE THESE INSTRUCTIONS FOR REFERENCE
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is noisy.
!
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions. The important
precautions, safeguards and instructions appearing in this manual are not
meant to cover all possible situations. It must be understood that common
sense and caution are factors which cannot be built into the product.
!

4
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 120V AC operation. It must be connected
to a 120V AC, 15 A circuit that is protected by a time-delayed fuse or circuit
breaker. To avoid shock or fire, replace power cord immediately if it is worn,
cut or damaged in any way.
GENERAL SAFETY WARNINGS
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING: Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain chemicals that are
known to cause cancer, birth defects, or other genetic abnormalities. These
chemicals include:
Lead from lead-based paints
Crystalline silica from bricks, cement, and other masonry products
Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to how
often this type of work is performed. In order to reduce exposure to these
chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specifically designed to filter out
microscopic particles.
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

5
GENERAL SAFETY RULES
WARNING: Read and understand all
instructions. Failure to follow all instructions
listed below may result in electric shock, fire
and/or serious personal injury.
WORK AREA
Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
Do not operate power tools in potentially
explosive environments, such as in the
presence of flammable liquids, gas or dust.
Power tools create sparks that may ignite dust
or fumes.
Keep bystanders, children and visitors away
while operating the tool. Distractions can cause
the operator to lose control.
ELECTRICAL SAFETY
Double insulated tools are equipped with a
polarized plug (one blade is wider than the
other). This plug will only fit into a polarized plug
one way.
If the plug does not fit into the outlet properly,
reverse the plug. If it still does not fit, contact a
qualified electrician to install a polarized outlet.
Do not alter the plug in any way. Double
insulation eliminates the need for the three-
pronged grounded power cord and grounded
power supply system.
Avoid contact between the operator's body and
grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased
risk of electric shock if the operator's body is
grounded.
Do not expose power tools to rain or wet
conditions. Water entering the power tool will
increase the risk of electric shock.
Do not abuse the cord. Do not use the power
cord to carry the tool or to pull the plug out of
the outlet. Keep the power cord away from heat,
oil, sharp edges, and moving parts. Replace a
damaged power cord immediately. A damaged
power cord increases the risk of electric shock.
When operating a power tool outdoors, use an
outdoor-rated extension cord type
“W-A” or “W”. These cords are rated for outdoor
use and they reduce the risk of electric shock.
PERSONAL SAFETY
Stay alert, be aware of the surroundings, and
use common sense when operating a power
tool. Do not use a power tool while tired or
under the influence of drugs, alcohol, or
medication. A moment of inattention while
operating a power tool may result in serious
personal injury.
Dress properly. Do not wear loose clothing or
jewellery.
Contain long hair. Keep hair, clothing, and
gloves away from moving parts. Loose clothing,
jewellery, or long hair can get caught in moving
parts.
POWER TOOL SAFETY
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

6
PERSONAL SAFETY –cont’d
Avoid accidental start-ups. Verify that the switch
is in the OFF position before plugging in the
tool. Carrying a power tool with a finger on the
switch or plugging in a tool that has the switch in
the ON position invites accidents.
Remove adjusting keys and wrenches before
turning the tool ON. A wrench or key that is left
attached to a rotating part of the tool may result
in personal injury.
Do not overreach. Keep proper footing and
balance at all times. Proper footing and balance
allows the operator to maintain better control of
the tool in unexpected situations.
Use safety equipment. Always wear eye
protection.
Use a dust mask, non-skid safety shoes, a
hardhat, or hearing protection when appropriate.
USE AND CARE OF POWER TOOLS
Use clamps or another practical means to
secure and support the workpiece to a stable
platform. Holding the work in a hand or against
the body is not stable, and may lead to loss of
control.
Do not force the tool. Use the correct tool for the
application. The correct tool will do the job better
and safer when used at the rate that it was
designed to work at.
Do not use a power tool if it cannot be turned
ON or OFF using the power switch. A tool that
cannot be controlled using the switch is
dangerous, and must be repaired.
Disconnect the plug from the outlet before
making any adjustments, changing accessories,
or storing the tool. Such preventive safety
measures reduce the risk of accidental start-
ups.
When power tools are not in use, store them out
of the reach of children or untrained persons.
Tools are dangerous in the hands of untrained
users.
Maintain tools with care. Keep cutting tools
sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to
bind, and are easier to control.
Inspect the tool for misalignment or binding of
moving parts, broken parts, and any other
condition that may affect the operation of the
tool. If it is damaged, have the tool serviced
before using it. Many accidents are caused by
poorly maintained tools.
Use only accessories that are recommended by
the manufacturer for this model. Accessories
that are suitable for one tool may become
hazardous when used with another tool.
SERVICE
Tool servicing must be performed by qualified
personnel. Service or maintenance performed
by non-qualified personnel could result in a risk
of injury.
When servicing a tool, use only identical
replacement parts. Follow the instructions in the
Maintenance section of this Manual. The use of
unauthorized parts or failure to follow the
instructions in the Maintenance section of this
Manual may create a risk of electric shock or
injury.
POWER TOOL SAFETY
SAVE THESE INSTRUCTIONS FOR REFERENCE

7
WARNING: Know your random orbit
sander. Read the Owner’s Manual carefully.
Learn the tool’s applications and limitations,
as well as the specific potential hazards
related to this tool. Following this rule will
reduce the risk of electric shock, fire or serious
injury.
Always wear eye protection. Any
power tool can throw foreign
objects into your eyes and cause
permanent eye damage.
ALWAYS wear safety goggles (not glasses) that
comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant
lenses. They ARE NOT safety glasses.
WARNING: Wearing glasses or goggles
that do not comply with ANSI Z87.1 could
cause serious injury if they break.
Always wear hearing protection and a dust
mask when sanding. Use only in a well-
ventilated area. Using personal safety devices
and working in a safe environment reduces the
risk of injury.
WARNING: Always unplug the tool from
the power source before changing the
sanding disc or buffing pad and when
cleaning the tool.
Do not wear gloves, neckties or loose clothing.
Secure workpiece. Use clamps or a vice to hold
the work when practical. It is safer than using
your hand and it frees both hands to operate the
tool.
Do not sand material too small to be securely
held.
Make sure there are no nails or foreign objects
in the part of the workpiece to be sanded.
Always keep hands out of the path of the
sanding pad. Avoid awkward hand positions
where a sudden slip could cause your hand to
move into the path of the sanding pad.
To avoid injury from accidental starting, always
remove the plug from the power source before
installing or removing a sandpaper or dust box.
SPECIFIC SAFETY RULES
SAVE THESE INSTRUCTIONS FOR REFERENCE
!
!
!

8
Make sure your extension cord is the proper
size. When using an extension cord, be sure to
use one heavy enough to carry the current the
tool will draw. An undersized cord will cause a
drop in line voltage resulting in loss of power
and overheating. The table on at right shows the
correct size to use according to cord length and
nameplate ampere rating. If in doubt, use the
next heavier gauge. The smaller the gauge
number the heavier the cord.
Be sure your extension cord is properly
wired and in good condition. Always replace a
damaged extension cord or have it repaired by a
qualified electrician before using it. Protect your
extension cord from sharp objects, excessive
heat and damp or wet areas.
Use a separate electrical circuit for your
power tools. This circuit must not be less than
14 gauge wire and should be protected with
either a 15A time delay fuse or circuit breaker.
Before connecting the power tool to the power
source, make sure the switch is in the OFF
position and the power source is the same as
indicated on the nameplate. Running at lower
voltage will damage the motor.
WARNING: Repair or replace damaged
or worn extension cords immediately.
Select the appropriate extension cord gauge
and length using the chart below.
When operating a power tool outdoors, use
an outdoor extension cord marked “W-A” or
“W”. These cords are rated for outdoor use and
reduce the risk of electric shock.
WARNING: Keep the extension cord
clear of the working area. Position the cord
so it will not get caught on the workpiece,
tools or any other obstructions while you are
working with the power tool.
GUIDELINES FOR EXTENSION CORDS
!
MINIMUM GAUGE (AWG) EXTENSION
CORDS (120 V use only)
Ampere rating
Total length in feet
More
than
Not
more
than
7.5 m
(25')
15 m
(50')
30 m
(100')
45 m
(150')
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

9
This symbol designates that this tool is
listed with Canadian requirements by
ETL Testing Laboratories, Inc.
Conforms to UL Std. 745-1, 745-2-4.
Certified to CAN/CSA Std. C22.2 No.
745-1, 745-2-4.
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Liters
kg
Kilograms
H
Hours
N/cm2
Newtons per square
centimeter
Pa
Pascals
OPM
Oscillations per minute
Min
Minutes
S
Seconds
or a.c.
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Directional arrow
Warning symbol
Wear your safety
glasses
Wear a dust mask
Wear hearing protection
SYMBOLS
WARNING: Some of the following symbols may appear on the sander. Study
these symbols and learn their meaning. Proper interpretation of these symbols will
allow for more efficient and safer operation of this tool.
!
JD2512U
3042597

10
KNOW YOUR SANDER
Dust box
assembly
Main handle
Speed control
switch
Sanding
base
Motor vents
Hook & loop
fastening system
ON/OFF
switch
Motor vents
Sandpaper
120 grit
Sandpaper
180 grit
Sandpaper
240 grit

11
INSTALLING A SANDING DISC
WARNING: Remove the plug from the
power source before installing or removing
sandpaper.
1. Firmly press the sanding disc (1) onto the
hook & loop pad (2) (Fig. 1).
NOTES:
a) Place the sanding disc so the holes in the
disc line up with the matching holes in the hook
& loop pad.
b) Press the sanding disc firmly onto the hook &
loop pad.
2. To remove the sanding disc (1), simply
peel the disc away from the hook & loop
pad (2) (Fig. 2).
SPEED CONTROL SWITCH
To run the sander at its slowest speed, turn the
speed control switch wheel (1) to #1 (Fig. 3). To
run the sander at higher speeds, turn the speed
control switch wheel to a higher number on the
wheel. The sander will be running at full speed
when the wheel is set at “MAX”.
ON/OFF SWITCH
To turn the sander ON, push the right hand side
of the switch (1) until the sander starts. To turn
the sander OFF, press the left hand side of the
switch (2) (Fig. 4).
ASSEMBLY AND OPERATING
!
Fig. 1
1
2
1
2
Fig. 2
Fig. 3
1
Fig. 4
1
2

12
CONNECTING THE DUST BOX ASSEMBLY
TO THE SANDER
1. Slide the dust box connector (1) into the
dust port (2) in the rear of the sander
(Fig. 5).
NOTE: Make sure the dust box connector
key (3) mates with the dust port key way
(4).
2. When the dust box connector is pressed
fully into the dust port, turn the dust box
approximately 15° clockwise to lock the
dust bag onto the sander.
CLEANING THE DUST BOX
1. Remove the dust box assembly from the
dust port by rotating it approximately 15°
counter clockwise and pulling it out of the
dust port.
2. Squeeze the front of the dust box (1) and
remove the dust box cover (2).
3. Open the elasticized end of the dust bag
(3) and remove it from the groove (4) in the
dust box frame.
4. Carefully slide the dust bag (5) off the dust
bag frame.
5. Shake the dust bag in an appropriate
container with the opening pointing
downward to remove the sanding dust.
6. When the dust has been removed from the
dust bag, reassemble the dust bag and
dust box
SANDING DISC SELECTION
Make sure you select the correct size and style
of sanding disc for your sander. The correct disc
will:
Have a diameter of 5"
Have a row of 3/8" holes that match the
hole pattern in the sander base
Have a backing for use with the hook &
loop disc attachment system.
ASSEMBLY AND OPERATING
Fig. 5
1
2
3
4
Fig. 6
12
35
4
For safety reasons, the operator must
read the sections of this Owner’s Manual
entitled "GENERAL SAFETY
WARNINGS", "POWER TOOL SAFETY",
"SPECIFIC SAFETY RULES",
"GUIDELINES FOR EXTENSION CORDS"
and "SYMBOLS" before using this
sander.
Verify the following every time the sander
is used:
1. The sander cord is not damaged.
2. Sander and sanding disc are the
correct type for the job.
3. Sanding disc is in good condition.
4. Safety glasses, hearing protection
and dust mask are being worn.
Failure to observe these safety rules will
significantly increase the risk of injury.
WARNING
!

13
SANDING DISC SELECTION –cont’d
Selecting the correct grit and type of sandpaper
is extremely important in achieving a high
quality sanded finish. Aluminum oxide, silicon
carbide and other synthetic abrasives are best
for power sanding. Natural abrasives such as
flint and garnet are too soft for economical
use in power sanding.
In general, coarse grit will remove most material.
Fine grit will produce the best finish in all
sanding operations. The condition of the surface
to be sanded will determine which grit will do the
best job.
NOTE: Where the sanding disc grits are shown
numerically, higher numbers indicate finer grit
and lower numbers indicate coarser grit.
If the surface is rough, start with a coarse grit
and sand until the surface is uniform. Medium
grit may then be used to remove scratches left
by the coarser grit. Fine grit should be used for
finishing the surface. Always continue sanding
with each grit until the surface is uniform.
SANDING
Clamp or otherwise secure your workpiece to
prevent it from moving under the sander while
being sanded. Secure the workpiece in a vice if
possible.
WARNING: Any unsecured workpiece could
be thrown toward the operator causing injury.
Set the speed control to the desired speed.
Higher speeds tend to cut faster and produce a
smoother finish. Place the sander on the
workpiece so the complete sanding disc surface
is in contact with the workpiece. Turn the sander
ON by pressing on the right hand side of the
ON/OFF switch. Move the sander slowly over
workpiece making successive passes in parallel
lines, circles or crosswise movements. Because
the random orbital motion of the sanding disc
moves in tiny circles, it is not necessary to move
the sander with the grain or in the same
direction for successive passes (Fig. 7).
NOTE: Hold the sander using the handle (1) on
top of the sander (Fig. 8). Be careful NOT to
cover the cooling vents (2) with your hand.
Covering the cooling vents could cause the
motor to be damaged by overheating.
ASSEMBLY AND OPERATING
Fig. 7
Fig. 8
1
2
2
!

14
SANDING –cont’d
DO NOT FORCE THE SANDER. The weight of
the sander usually provides adequate pressure.
Let the sander and the sanding disc do the
work. Applying added pressure will slow the
motor, increase the wear on the sanding disc
and greatly reduce the sander speed. Excessive
pressure will overload the motor causing
possible damage from the motor overheating. It
will also create an inferior finish on sanded
work. Any finish or resin on wood will soften
from the frictional heat, causing sanding disc to
become clogged quickly. Do not sand in one
spot too long as the sander’s rapid action may
remove too much material, making the surface
uneven.
Extended periods of sanding may tend to
overheat the motor. If this occurs, turn sander
OFF, wait until the sanding disc comes to a
complete stop and remove it from the
workpiece. Check to make sure your hands
have not been covering the cooling vents.
Remove the plug from the power source and let
the motor cool before continuing the sanding
operation. Check to make sure the motor
cooling vents are not blocked with sanding dust.
Upon completion of the sanding operation, turn
sander OFF by pressing on the left side of the
ON/OFF switch. Wait until the sanding disc
comes to a complete stop before removing it
from the workpiece.
WARNING: Your sander should only be
turned ON when the entire surface of the
sanding disc is in contact with the workpiece.
Failure to follow this sanding procedure could
result in a loose sanding disc, which could result
in possible injury.
GENERAL
WARNING: When servicing, use only
identical replacement parts. The use of any
other part may create a hazard or cause
product damage.
DO NOT use solvents when cleaning plastic
parts. Plastics are susceptible to damage from
various types of commercial solvents and may
be damaged by their use. Use a clean cloth to
remove dirt, dust, oil, grease etc.
WARNING: Do not allow brake fluids,
gasoline, petroleum-based products,
penetrating oils, etc. to come into contact
with plastic parts. They contain chemicals
that can damage, weaken or destroy plastic.
Remove accumulated dust and debris regularly
using a soft DRY brush.
WARNING: Use safety goggles when
using an air jet to blow dust out of the
sander.
DO NOT abuse power tools. Abusive practices
can damage the tool and the workpiece.
WARNING: DO NOT attempt to modify
tools or create accessories. Any such
alteration or modification is misuse and
could result in a hazardous condition leading
to possible serious injury. It will also void
the warranty.
LUBRICATION
All of the bearings in this tool are lubricated with
a sufficient amount of high-grade lubricant for
the life of the unit under normal conditions.
Therefore, no further lubrication is required.
!
ASSEMBLY AND
OPERATING
MAINTENANCE
!
!
!
!

15
EXPLODED VIEW
2
3
5
6
7
4
1
8
9
10
11
12
13
30 31 32 33 34
35

16
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the sander.
Any attempt to repair or replace electrical parts on this sander may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-866-349-8665 (Monday through Friday 9am –5pm Eastern Time).
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
1190030006
Power cord
1
2
3140010054
cord guard
1
3
4030010099
Tapping screw ST3.9x14
2
4
2030050002
Cord clamp
1
5
1130010125
Variable speed PCB
1
6
1061150011
Switch
1
7
3140080014
Switch cover
1
8
4030010106
Tapping screw ST3.9x19
6
9
3011060006
Housing
1
10
3150060005
Brush box
2
11
2030070001
Brush holder
2
12
4010010053
Bearing 607
1
13
1230010054
Carbon brush
2
14
1010060009
Rotor
1
15
1020060010
Stator
1
16
4010010054
Bearing 6000
1
17
3150010087
Fan
1
18
2030030203
Counter balance
1
19
2010130030
Eccentric wheel
1
20
2030170007
Dust proof washer
1
21
2020130001
Bearing seat
1
22
4010010084
Bearing 6002
1
23
2030020033
Washer
1
24
4040030011
Spring washer, dia.5
5
25
4020080004
Hex screw M5x16
1
26
3150130066
Big washer
1
27
3140050004
Brake ring
1
28
1150020007
Base plate
1
29
4020010017
Base plate screw M5x18
4
30
3180030020
Dust box frame
1
31
4030010136
Tapping screw ST2.9x9
2
32
3190020034
Sealing ring
1
33
3180060017
Dust bag support
1
34
6150030002
Dust bag
1
35
3180020028
Dust box
1
PARTS LIST
!

17
Rev 1.3 20/11/2015
IMPORTED BY:
Wal-Mart Canada Corp.
1940 Argentia Rd.
Mississauga, Ontario L5N 1P9
Walmart.ca
MADE IN CHINA
POWER IT®5" RANDOM ORBIT SANDER WARRANTY
1-YEAR LIMITED WARRANTY:
This POWER IT®brand power tool carries a 1-Year Limited Warranty to the original
purchaser. If the tool fails within one (1) year from the date of purchase, simply bring this
tool with your original sales receipt back to your nearest WALMART retail store. At its
discretion, WALMART agrees to have the tool replaced with the same or similar
WALMART product free of charge, within the stated warranty period, when returned by the
original purchaser with original sales receipt. Notwithstanding the foregoing, this limited
warranty does not cover any damage that has resulted from abuse or misuse of the
Merchandise. This warranty: (1) excludes expendable parts including but not limited to
blades, belts, bits, light bulbs, and/or batteries; (2) shall be void if this tool is used for
commercial and/or rental purposes; and (3) does not cover any losses, injuries to
persons/property or costs. This warranty does give you specific legal rights and you may
have other rights, which vary from province to province. Be careful, tools are dangerous if
improperly used or maintained. Seller’s employees are not qualified to advise you on the
use of this Merchandise. Any oral representation(s) made will not be binding on seller or
its employees. The rights under this limited warranty are to the original purchaser of the
Merchandise and may not be transferred to any subsequent owner. This limited warranty
is in lieu of all warranties, expressed or implied including warranties or merchantability and
fitness for a particular purpose. Seller shall not be liable for any special, incidental, or
consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or able to
replace this product or is willing to refund the purchase price as provided above. For
insurance purposes, seller is not allowed to demonstrate any of these power tools for you.
For questions / comments, technical assistance or repair parts –
Please call toll free at:
1-866-349-8665 (Monday through Friday 9am –5pm (Eastern Standard Time)
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
