PowerAcoustik Gothic GW3-10 User manual

2013
SubwooferS
GW3-10 GW3-12 GW3-15

Thank you for choosing Power Acoustik woofers. Designed and engi-
neered in the USA, this product combines innovative technology with
the finest materials to consistently deliver Absolutely State of the Art
performance, sound quality, reliability, and value. This Power Acous-
tik product reflects our commitment to offer you unparalleled perfor-
mance and quality for years of dependable service and listening en-
joyment.
Polyproplyne Cone
Rubber Surround
2.5” 4-layer VC on Aluminum Former
Nickel Plated 8ga. Compression Terminals
Poly-Cotton Suspension Spider
Vented T-Yoke Back-plate
Woven Polypropylene Dust Cap
Textured Basket with Voice Coil Cooling
Features, Parameters, & Dimensions
www.PowerAcoustik.com
Impedance dual 2ohm dual 2ohm dual 2ohm
Re2.2493 2.1444 2.1796
Fs35.29 34.29 31.21
Qes 1.4673 1.5772 1.2742
Qms 5.4091 5.2909 4.5324
Qts 1.1542 1.2150 0.9946
le0.9646 0.8983 1.0736
dIameteR 10Inch 12Inch 15Inch
sd78.5398 In^2 113.0973 In^2 176.7146 In^2
Vas 30.3894 60.8651 71.3101
Bl9.1083 8.8552 15.0269
mms 244.0387 267.6814 673.0175
cms 83.3188 80.4756 88.6195
sen 81.3 83.6 84.1
cutout dIam 9.6 Inch 11.5Inch 14.5Inch
mount depth 6.0Inch 6.5Inch 7.5Inch
GW3-10 GW3-12 GW3-15

Enclosure Construction
Enclosure Dimensions
Enclosure Recommendations
www.PowerAcoustik.com
Included in this manual are a number of different enclosure sugges-
tions. These are by no means the only enclosures to use, but they
provide a starting point to determine the correct enclosure for your
needs many factors must be addressed (amount of power, vehicle,
placement, crossovers, etc) Therefore, as always, SPL recommends
that your subwoofer be installed by an authorized SPL dealer.
All enclosures should be made of .75” (3/4”) material only. When pos-
sible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the depth
of the enclosure to compensate. All volumes INCLUDE vent/port and
subwoofer displacements. DO NOT change the volume unless you
plan on adding a substantial amount of bracing. For added per-
formance, applying a coat of fiberglass resin to the interior walls will
greatly improve sealing the enclosure. Adding a thin layer of poly-fill
will improve response by smoothing out reflections within the enclo-
sure.
sealed
mIn .75 cu Ft. 1.00 cu Ft. 1.5 cu Ft.
optImum 1.0 cu Ft. 1.5 cu Ft. 2.75 cu Ft.
poRted
mIn 1.0 cu Ft. 1.5 cu Ft. 2.5 cu Ft.
poRt Wxl 3Inch x5.5Inch 4Inch x5Inch 5Inch x7.8Inch
F3 hz34 38 30
opt 1.5 cu Ft. 2.25 cu Ft. 3.0 cu Ft.
poRt Wxl 4Inch x6Inch 6Inch x7Inch 6Inch x7Inch
F3 hz32 34 28
