Powerful Signal SolidRF Signal Plus User manual

Outside Antenna
(Omni)
Inside Antenna
(Dome)
Cell Signal Booster
1
2
3
Coax Cable
Adapters
Coax Cable
4
4
5
Roof Mount
SolidRF Signal Plus
Installation Guide TS002003
Outside Antenna
Attach the antenna vertically to a roof mount or pole at the highest point on the roof.
An omnidirectional antenna does not need to be pointed or aimed.
Cellular Signal Booster
Mount the booster near an AC power outlet in a climate controlled location. If possible,
mount the booster with the shortest run of cable connecting to the outside antenna.
Coax Cables
Bring a coax cable from the roof into the house through a vent or other opening and
connect to the Outside port of booster. Connect another cable from the Inside port
of the booster to the inside antenna. Do not kink, loop, or coil excess cable.
Adapters
Connect the cable adapters between the booster and the coax cable on both the
Inside port and Outside port of the booster.
Inside Antenna
Try to get at least 20’ of vertical separation between the inside and outside antennas
and 10’ of separation between the inside antenna and the booster. Install the dome
antenna in the ceiling close to the center of the home or the area where you most
need signal.
1
2
3
4
Installation Tip:
We strongly recommend that
you do a “soft installation”
before permanently mount-
ing the components and
pulling cables.
• Set up and connect all the
components but don’t
mount any items.
• Bring the outside cable in
through an open window
or door and position the
antennas where you intend
to install them.
• Turn the system on and
check the results. If it’s not
working the way you
expect, give us a call —
we’re happy to help you!
Have Questions? Please call Powerful Signal at 435-634-6800 or visit us online at PowerfulSignal.com
5

Installing a Lighting Surge Protector (sold separately)
If your system includes a Lightning Surge Protector, connect it between the outside
antenna and the coax cable to the booster. Insert an 8- to 10-gauge solid copper ground
wire (not included) into the eyelet of the surge protector and crimp with pliers. Run the
ground wire outside the house to an 8-foot solid copper ground rod (not included).
Installing a Dome Antenna
If your system includes a dome antenna, install it in a location where you have access
above the ceiling. Cut a ¾-inch hole in the ceiling and insert the antenna’s mounting post
and pigtail connector cable through the hole. Twist the mounting nut onto the top of the
post until the antenna is flush with the ceiling. Do not overtighten. Connect the pigtail
cable to a coax cable that runs to the booster.
How to Install Two or More Inside Antennas
If your system includes two or more inside dome or panel antennas, attach the short (typically 2-foot) jumper cable to the
Inside port of the booster. Connect the splitter to the other end of the jumper cable. Connect coax cables to the opposite
end of the splitter and run one to each inside antenna.
Instructions continued:
Mounting Nut
Antenna
Ceiling
Coax Cable
Signal Booster 2-Way Splitter
Cable to Outside Antenna
Inside Antennas
435-634-6800 | www.PowerfulSignal.com
