POWERLOK Rack PDUs Installation instructions

PowerLok Rack PDUs
POWERLOK
RACK POWER DISTRIBUTION
Installation & Operating Manual
Ver. 1.4.3

Rack PDU Installation & Operating Manual
2
Contents
Introduction .................................................................................................................................................3
Safety Precautions ........................................................................................................................................3
Equipment grounding ...............................................................................................................................4
Product Specifications...................................................................................................................................4
Mechanical Specifications.........................................................................................................................4
Electrical Specifications.............................................................................................................................4
Packaging ..................................................................................................................................................5
Regulatory Compliance.................................................................................................................................6
Installation ....................................................................................................................................................6
Power Monitoring..................................................................................................................................... 7
Ethernet Communication.......................................................................................................................... 8
Web Browser ............................................................................................................................................ 9
How to connect your computer with Linked local and Static IP option. ................................................10
Firmware Updating. ....................................................................................................................................19
Limited Warranty........................................................................................................................................19

Rack PDU Installation & Operating Manual
3
Introduction
The innovative PowerLok Rack PDU is a next generation offering for the mission critical industry. All
PowerLOK Rack PDUs are engineered, designed, tested, and manufactured in the United States. Our
automated processes ensure that our customers’ servers run reliably and efficiently in the highly
competitive, 24/7 mission critical industry. PowerLok’s quick-ship program makes configurating, ordering,
and receiving Rack PDUs seamless and easy.
Safety Precautions
Specific safety precautions for this product are as follows:
•All precautions should be taken to guarantee a safe work and operational environment. General
safety precautions must be observed during all aspects of operation of equipment described in this
document. Failure to comply with the safety warnings, procedures, and guidelines presented in this
document is in violation of the safety standards of design, manufacture, and intended use of this
equipment.
•You are responsible for following the safety guidelines and warnings presented in this document for
this equipment. Individuals using Gateview Rack PDUs are expected to follow all the noted warnings
and safety precautions necessary for safe operation of the equipment in your environment. Gateview
Technologies assumes no liability for failure to comply with these requirements.
•Rack PDUs are intended for indoor use only in a controlled environment that adhere to the operating
temperatures within this manual. Any use outside of these constraints may void the warranty.
•Rack PDUs rated for 240/415VAC may be fitted with a NEMA L22-20 or L22-30 plug that is rated for a
higher voltage. Caution must be taken to assure that the rating of the Rack PDU and the supply
voltage match.
•The total capacity of equipment connected to the Rack PDU CANNOT EXCEED the maximum load
rating of the Rack PDU.
DANGER
HAZARDOUS VOLTAGE, CURRENT, AND ENERGY LEVELS ARE PRESENT IN THIS PRODUCT.
INTERNAL CIRCUITS CAN HAVE HAZARDOUS VOLTAGES PRESENT EVEN WITH PDU
CIRCUIT BREAKERS IN THE OFF POSITION. DO NOT OPERATE THE PRODUCT WITH THE
COVER REMOVED.
Professionals installing and operating Rack PDUs are advised of the following:
•Do not try to modify the Rack PDU in anyway, including the input plug, power whip and receptacles.
•Do not drill into or attempt to open any part of the Rack PDU enclosure. There are no serviceable
parts inside the Rack PDU.
•Do not attempt to use the Rack PDU if any part of it is damaged.
•Rack PDUs rated 30A and greater contain magnetic-hydraulic circuit breakers. Circuit breaker
equipped PDUs must be mounted vertically.
•Do not mount the Rack PDU to an unstable enclosure or surface.

Rack PDU Installation & Operating Manual
4
Equipment grounding
To minimize electrical shock hazard, the Rack PDU chassis/enclosure is connected to the electrical earth
ground pin of the Rack PDU plug. The input power cable must be plugged into an industry electrical code
compatible receptacle which provides connection to the facility electrical safety ground.
Product Specifications
The following section gives the mechanical and electrical specifications of the Rack PDU.
Mechanical Specifications
Chassis dimensions in inches and (mm). See specifications for complete outline drawings.
Vertical PDU
Length
Width
Depth
24L
23.98 (609)
2.18 (55.37)
2.00 (50.80)
36L
35.98 (914)
41L
40.98 (1041)
46L
45.98 (1168)
72L
72.00 (1829)
82L
82.00 (2083)
Electrical Specifications
PDU Utility Wiring
Configuration
Line Current
Rating
UL / CSA
Line Current
Rating*
Number
of Wires
Wire
Gauge
Operating
Temperature
208V 1PH
20A
16A
3
12
0°C - 60°C
(32°F - 148°F)
208V 1PH
30A
24A
3
10
120V/208V WYE 3PH
20A
16A
5
12
120V/208V WYE 3PH
30A
24A
5
10
240V/415V WYE 3PH
20A
16A
5
12
240V/415V WYE 3PH
30A
24A
5
10
208/240V DELTA 3PH
30A
24A
4
10
208/240V DELTA 3PH
35A
30A
4
8
208/240V DELTA 3PH
50A
40A
4
6
208/240V DELTA 3PH
60A
48A
4
6
* Per the National Electrical Code (NEC) and Canadian Electrical Code (CEC) requirements, when in
service, the line current is to be limited to 80% of the PDU’s plug rating.
Rack PDUs rated 30A-60A line current contain 20A circuit breakers for receptacle group protection.
The circuit breakers are UL-489 Listed and rated 5 or 10kAIC depending on model.

Rack PDU Installation & Operating Manual
5
Packaging
Rack PDUs are shipped in molded 1.8 EPS foam and 200 double-wall corrugated cartons.
72L Package
Dimensions
Approx.
Ship Weight
Lifting
Handles
Maximum PDUs
per pallet
Maximum height per
44” x 82” pallet
1-pack
80 x 11 x 5
17
No
48
65” (12 levels)
2-pack
35
96
3-pack
80 x 22 x 5
52
Yes
72
4-pack
68
96
82L Package
Dimensions
Approx.
Ship Weight
Lifting
Handles
Maximum PDUs
per pallet
Maximum height per
44” x 92” pallet
1-pack
90 x 11 x 5
19
No
48
65” (12 levels)
2-pack
37
96
72L Packaging example:

Rack PDU Installation & Operating Manual
6
Regulatory Compliance
Product Safety
Rack PDUs have been safety tested and certified to the following standards:
•USA UL 60950-1: 2nd edition October 2014
•CAN/CSA 22.2 No. 60950-1
•Canada ICES-003 (A) / NMB-003 (A)
•FCC Part 15 Class A compliant
•RoHS compliant
•NOM Addendum
USA Notification
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at their own expense.
Canadian Notification
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Installation
Installation of Rack PDUs into a server rack is performed by using the buttons that are already attached to
the back surface of the Rack PDU. These buttons mate with keyhole slots located in the server rack.
Mounting button detail: Key slot example:
Alternately, Rack PDU mounting buttons may be removed (attached with #6-32 screws) and a customer
supplied bracket designed for Rack PDU mounting may be attached. The attachment screws can be re-
used. A customer supplied #6-32 screw should not penetrate the Rack PDU chassis more than 1/8".

Rack PDU Installation & Operating Manual
7
Power Monitoring
PowerLOK models with monitoring include a local touchscreen display and ethernet communication.
Monitoring accuracy
•Voltage: ± 0.5% at nominal
•Current: ± 1.0% of measurement from 250 mA –1A
•Current: ± 0.5% of measurement from 1A –30A
The touchscreen can rotate 180 degrees. The illustration below is a 30A/208V 3PH Rack PDU example:

Rack PDU Installation & Operating Manual
8
Ethernet Communication
The Rack PDU is equipped with two RJ45 10/100Base-T Ethernet ports to attach to an existing local area
network (TCP/IP v4). This connection allows access to the Rack PDU via a web browser or SNMP client.
The PDU has two RJ45 connectors that are bidirectional; therefore, the user can connect to either of
them to set up your PDU to the network. Furthermore, the user can connect to 12 PDUs in series by
daisy chaining them.
The Rack PDU supports three methods of assigning the IP address, default gateway, and subnet mask.
Addressing mode
Description
Comment
Linked local
IPv4 link-local addresses are assigned
to address block 169.254.0.0 -
169.254.255.255
This addressing mode supports attaching a host
PC/laptop directly to the Rack PDU without
requiring a switch, router or DHCP server.
Static IP
Default PDU network configuration
IP address: 192.168.1.254
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
The static IP information can be changed using a
web browser.
DHCP
The Rack PDU network configuration
information is provided by the DHCP
server.
The local touchscreen display will publish the IP
address assigned to the Rack PDU by the DHCP
server.

Rack PDU Installation & Operating Manual
9
Web Browser
The Rack PDU is equipped with a web server page accessible over IP. To access, open a browser window
and enter the PDU IP address.
If the PowerLok web page does not appear, the PDU is not connected or the network does not recognize
the PDU. See section: How to connect your PC/laptop with Linked local and Static IP option or call your
network administrator.
For each data set, historical graphing or historical logs can be viewed.
Web page real time and historical graphing
Historical logs
In addition to graphing, PowerLOK also creates historical logs that can be viewed at various scales:

Rack PDU Installation & Operating Manual
10
Admin section of the Web server
How to connect your computer with Linked local and Static IP option
Linked local
Once the user is connected to the network, go to the touchscreen display to identify the assigned
linklo IP address.
IPv4 link-local addresses are assigned to address block 169.254.0.0 - 169.254.255.255

Rack PDU Installation & Operating Manual
11
Open a new browser tab and enter the linklo IP address: 169.254.70.53 to view the web server page as
shown in the example below:
Static IP
The following section describes how to set the user’s computer for a static IP. The PDU has a
static IP of 192.68.29.101 as shown in the touchscreen example below:

Rack PDU Installation & Operating Manual
12
Step 1: Go to control Panel

Rack PDU Installation & Operating Manual
13
Step 2: Select network and internet
Step 3: Select Network and Sharing Center

Rack PDU Installation & Operating Manual
14
Step 4: Select Ethernet
Step 5: Select Properties and then Options

Rack PDU Installation & Operating Manual
15
Step 6: Select Internet Protocol Version 4 (TCP/IPv4)
Step 7: Enter IP address, Subnet mask and Default gateway
with numbers as shown and select OK.

Rack PDU Installation & Operating Manual
16
This completes the necessary steps to configure for static IP. Open a browser and enter
the static IP address to access the PowerLok web server as shown below:
How to setup the PDU with the Static IP to the router
To setup the PDU for your router follow these steps:
Step 1: Use the command prompt and type ipconfig to view the assigned IP address.

Rack PDU Installation & Operating Manual
17
Step 2: To setup the PDU with the IP address in the address block, I used: 192.168.1.10. To
determine if the IP address in not in use, type arp-a command as shown below:
Step 3: Open the web server using your IP address and open the Admin section to select Edit.

Rack PDU Installation & Operating Manual
18
Step 4: Enter your IP address, subnet mask and default gateway and then select Apply.
This should complete the necessary steps to configure for the router. Connect the PDU to the router,
open a browser and enter the static IP address to access the PowerLok web server as shown below:

Rack PDU Installation & Operating Manual
19
Firmware updating.
For firmware update, please contact tech support: [e-mail] or visit our website and contact the
support team from the live chat: http://www.gateview.com/
Firmware is upgraded locally through the ethernet port on the PDU.
For a current MIB (Management Information Base) list, please contact your PowerLOK reseller.
Limited Warranty
Warranty Replacement Procedure: All product warranty procedures are conditional upon the warranty
information set forth in Gateview Technologies Terms and Conditions for a term of three (3) years from the
shipment of the product. Gateview Technologies will provide a replacement product if it is defective in
accordance with the following: This warranty does not apply to normal wear and tear or damage resulting
from misuse, abuse, or neglect. No service or maintenance is required and there are no serviceable parts
inside of the product. Do not attempt to open the Rack PDU or the customer will void the warranty.
The customer should ensure prior to use whether this product is suitable, adequate, or safe for the use
intended. Since individual applications are subject to great variation, Gateview Technologies makes no
representation or warranty as to the suitability or fitness of these products for any specific application and Gateview
Technologies is not responsible for equipment damaged by incorrect communication on the part of the
customer between the customer and Gateview Technologies.
The customer will incur the cost of shipping the defective product to Gateview Technologies, and, if a
replacement is necessary, Gateview Technologies will reimburse the customer for shipping and subsequently
ship a replacement product within fourteen (14) days of receipt of the defective product. If replacement of the
product is not necessary, Gateview Technologies reserves the right to deny reimbursement for the shipping of
the product returned from the customer.
Notices
Version 1.4.3 Copyright © 2021 Gateview Technologies, Inc. All rights reserved.
PO Box 2134, Wake Forest, NC 27588 USA
All Rights Reserved
This product manual is protected by copyright and all rights are reserved.
Gateview Technologies reserves the right to update the product manual at any time. In no event shall Gateview
Technologies be liable for damages resulting from any omission in this document.
Gateview and the PowerLok logos are registered trademarks of Gateview Technologies. Use of the logos for
commercial purposes without the prior written consent of Gateview Technologies may constitute trademark
infringement and unfair competition in violation of federal and state laws.
