Lanner LVC-2000 User manual

>>
In-Vehicle Computing
Hardware Platforms for mobile applications
LVC-2000
V1.3
User Manual
Release Date: 2022/03/03

Overview
Icon Descriptions
The icons are used in the manual to serve as an
indication of interest topics or important messages.
Below is a description of these icons:
NOTE: This check mark indicates that
there is a note of interest and is
something that you should pay
special attention to while using the
product.
WARNING: This exclamation point
indicates that there is a caution or
warning and it is something that
could damage your property or
product.
Online Resources
The listed websites are links to the on-line product
information and technical support.
Resource Website
Lanner website www.lannerinc.com
Download Center lannerinc.com/support/download-center
Technical Support lannerinc.com/contact/technical-support
Copyright and Trademarks
This document is copyrighted, © 2022. All rights are
reserved. The original manufacturer reserves the right
to make improvements to the products described in
this manual at any time without notice.
No part of this manual may be reproduced, copied,
translated or transmitted in any form or by any means
without the prior written permission of the original
manufacturer. Information provided in this manual
is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its
use, nor for any infringements upon the rights of third
parties that may result from such use.
Acknowledgement
Intel®, Pentium®and Celeron®are registered
trademarks of Intel Corp.
Microsoft Windows and MS-DOS are registered
trademarks of Microsoft Corp.
All other product names or trademarks are properties of
their respective owners.
Compliances and Certification
CE Certification
This product has passed the CE test for environmental
specifications. Test conditions for passing included the
equipment being operated within an industrial
enclosure. In order to protect the product from being
damaged by ESD (Electrostatic Discharge) and EMI
leakage, we strongly recommend the use of CE-
compliant industrial enclosure products.
FCC Class A Certification
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
e Mark Certification
E13 - Luxembourg

Mechanical compliance
Vibration:
General Vibration (operating): Refer to MIL-STD-810G,•
Method 514.6, Procedure I (Transportation), Category
4 – Common carrier (US highway truck vibration
exposure)
General Vibration (non-operating): Refer to MIL-STD-•
810G, Method 514.6, Procedure I (Transportation),
Category 24 – General minimal integrity
Shock:
Operating (Functional Test for Ground Equipment):•
Refer to MIL-STD-810G, Method 516.6, Procedure I,
40g, 11ms
B. Non-Operating (Crash Hazard Shock Test for•
Ground Equipment): Refer to MIL-STD-810G, Method
516.6, Procedure V, 75g, 11ms
Electrical transient conduction along supply lines only
(12V/24V)
Revision History
0.1 2014/09/14 Preliminary
1.0 2014/12/10 Official release
1.1 2015/11/19 Revised COM pinouts
1.2 2016/06/01 Modified MCU and SW
pinouts

Chapter 1: Introduction 5
System Specifications 5
Package Contents 6
Chapter 2: System Components 7
Mechanical Drawings 7
Block Diagram: The MainBoard 10
Front Components 11
Rear Components 12
Internal Connectors and Jumpers 13
Internal Connectors and Jumpers (backside) 14
Connectors and Jumpers List 15
Jumper Settings 16
Connectors 16
Chapter 3: Hardware Setup 21
Preparing the Hardware Installation 21
Disk Drive Installation 21
mSATA Card Installation 22
Wireless Module Installation 22
3G SIM Card Installation 22
Connecting Power 23
Chapter 4: The Flow Chart 24
Appendix A: Using the Ignition System Manager (ISM) 25
Appendix B: Digital Input/Output 26
Appendix C: Accessing the GPS Data from the LVC-2000 32
Appendix D: Programming System Watchdog Timer 34
Appendix E : Terms and Conditions 38
Table of Contents

Chapter 1:
Introduction
Thank you for choosing LVC-2000. The entry-level
box PC is one of the most compact in-vehicle
computing system which equips with a vibration kit
to eliminate shock and vibration. It is designed to be
installed on a moving transportation system.
LVC-2000 is a fanless in-vehicle computer with MIL-
STD-810G certified shock and vibration resistance.
Built with onboard Intel® Atom™ processor E3845
(codenamed “Bay Trail), the in-vehicle computer
is a value time-to-market solution with enhanced
performance and low power consumption. LVC-2000
also features multiple I/O connectivity including CAN
bus (module optional), LAN port, GPS/G-sensor,
COM ports, multiple Digital I/Os, and mini PCI
Express sockets, making it perfect for vehicle
monitoring, in-car infotainment and fleet
management.
Features:
•Onboard Intel® Quad-core Bay Trail SoC
•Vehicle Power Ignition Management
•2x DB-9 COM at RS232/422/285 (RS-232 by
default)
•The MIO Connector
•MIL-STD-810G Certification for Shock & Vibration
Resistance
•Fanless Design and Aluminum Enclosure
•Wide Operating Temperature Workability
•Support VGA, HDMI dual independent display
interface.
•2x mini-PCIe sockets with two support Wi-Fi
and 3G wireless connection.
•Suspending Kit or wall mounting
•Support 12V DC output @Max 1A
•Onboard Ublox NEO-8N GPS receiver module
System Specifications
Dimensions (WxDxH,) 198W x 165D x 52H
(mm, the unit)
Processor
Intel® BayTrail E3845 1.91 GHz
Optional for E3815 / E3825 /
E3826 / E2827
System
Memory
Module
type DDR3L SO-DIMM x1 (up to 8GB)
BIOS AMI SPI Flash BIOS
Storage mSATA/
SATA
1x mSATA with SATA 3.0Gbps,
1x SATA 2.5” drive bay for HDD/SSD
Ethernet Controller Intel i210IT
Graphic Controller Intel Integrated HD graphic engine
Audio Controller Realtek ALC886-GR
Super I/O
1x LPC Super I/O Fintek F81865F
supporting DIO, Serial ports, Watchdog
Timer, Hardware monitor and
Temperature meter for internal system
I/O
LAN 1x GbE RJ45
Display VGA:
up to 1600x1200@60 24bpp
HDMI: up to 1920x1080 @60
Audio Internal pin header for Mic-in and
Line-out
Serial I/O 2x DB9 RS-232/422/485 (RS-232 by
default)
GPS Ublox NEO-8N GPS receiver
G-sensor ADXL 345
MIO
4x DI (5V or 12V TTL selectable)
4x DO (12V TTL , Max. 100mA)
2x MCU DI
2x Relay
1x 12V Output @Max. 1A
USB 1x USB 3.0 Type A,
2x USB 2.0 by internal pin header
Power
Input
3-pin terminal block (DC9-36V,
GND, Ignition)
Expansion
1x full-size mini-PCIexpress socket (USB
+PCIe) with SIM-card reader 1 x half-size
mini-PCIexpress socket
CAN bus A1 SKU: 1x CAN Bus for J1939/J1708
B1 SKU: 1x CAN Bus (Optional for OEM)
Power Input 1x DC 9~36V, GND and Ignition
MCU
1x MICRO-CONTROLLER
LPC1114FBD48/301 SMD PHILIP, Support
2x DI
Lanner Ignition System
Management
Ignition Control Utility under Windows
Base OS.
Ignition Control Sample Code for Linux
OS
OS Support
Windows
Driver Support:
Windows 7/7 Embedded/8 embedded OS
Image:
W7 FES (64bit & 32bit) / Windows
8(32bit)
Linux Driver Support: Linux kernel 2.6.X or
later

Thermal Solution Fanless system. Heat dissipate from
aluminum enclosure
Mounting Suspending Kit or wall mounting-1
Certications CE, FCC Class A, E13, RoHS
Compliance Vibration: MIL-STD-810G, Method 514.6
Shock:MIL-STD-810G, Method 516.6
Operating
Temperature
Range
Extended -20~60°C (with industrial components)
Package Contents
Your package contains the following items:
LVC-2000 Fanless Embedded System with rubber
stands:
Terminal Block Connectors:•
-Power connector 3 pin x1 (P/N:04AW20031E001)
-MIO Connector 20 pin x1 (P/N: 04AW20203Z101)
HDD Screws x 4 (P/N: 070W102400602)•
Mini-PCIe Screws x 4 (P/N: 070W101000401)•
Order Information

Chapter 2:
System Components
Mechanical Drawings
Mechanical dimensions of the LVC-2000 with the system
itself
Unit: mm

Mechanical dimensions of the LVC-2000 with
anti-vibration kit
Unit: mm

Mechanical dimensions of the LVC-2000 with
wall-mounting kit
Unit: mm

Block Diagram: The MainBoard
The block diagram depicts the relationships among the
interfaces and modules on the motherboard.

Component Description Remarks
F1 GPS Antenna Reserved for GPS antenna
F2 LED Indicator HDD/SSD LED
•Blinking: means data access activities
•Off: means no data access activities or no hard
disk present
Power LED
•On: The computer is on.
•Off: The computer is off .
F3 USB 3.0 Ports USB 3.0 type A connectors.
F4 CAN bus CAN bus connector for controller area network
communication. It supports J1939 &J1708
standards.
Module required to enable it
F5 COM1/COM2 RS-232/422/485 ports for serial communication
Front Components
F1
F2 F3 F4
F5

Rear Components
Component Description Remarks
R1 Multiple-I/O Connector A 20-pin male connector for the
following functions:
•4x DI (5V or 12V TTL selectable)
•4x DO (12V TTL , Max. 100mA)
•2x MCU DI
•2x Relay
•1x 12V Output @Max. 1A
R2 One 10/100/1000Mbps LAN
ports
One RJ-45 (provided by Intel i210IT) jacks
with LED indicators as described below
LINK/ACT (Yellow)
•On/Flashing: The port is linking and
active in data transmission.
•Off: The port is not linking. SPEED
(Green/Amber)
•
•
Amber: The connection speed is
1000Mbps.
Green: The connection speed is
100Mbps
•Off: The connection speed is
10Mbps.
R3 HDMI Port (‡) A HDMI port which is provided by
Intel HD graphics (resolution:
1920x1080@60Hz).
R4 VGA Port (‡) It connects an external VGA
monitor or projector (resolution:
1600x1200@60Hz)
R5 Power-Input (DC) Power-in with ignition support. The system
support a wide range of power input +9~
+36V including the prevalent 12V and 24V
vehicular power system. It has a 2KV ESD
protection on the DC input and ignition
line.
R1 R2
R3
R4 R5
LINK/ACT
SPEED

Internal Connectors and Jumpers
The following picture highlights the location of internal connectors and jumpers. Refer to the table 3.2
Connector List for more details.
JKBMS1
JMCU1
MPCIE2
SATA1 CN1
JLPC1
SATAPWR1
MSATA1
USBF1
JCMOS1
JSPI1
SIM1 MPCIE1
JRI2
JRI1

Internal Connectors and Jumpers (backside)
The following picture highlights the location of internal connectors and jumpers on the backside of the board.
Refer to the table 3.2 Connector List for more details.
SW1

Connectors and Jumpers List
The tables below list the function of each of the board jumpers and connectors by labels shown in the above
section. The next section in this chapter gives pin definitions and instructions on setting jumpers.
Table 3.1 Connector List for External Connectors
Labels Function
CAN1 CAN bus Connector
COM1/COM2 RS-232/422/485 Commmunication Ports
HDMI1 High Denition Multimedia Interface
MIO1 Multiple I/O Connectors
PRJK1 3-Pin DC-in Power Connector with Ignition
Control
USB2 USB 3.0 Connector
VGA1 VGA Connector
Table 3.2 Connector List for Internal Connectors
Labels Function
AUDIO1 Audio Pin Header
JCMOS1 Clear CMOS Jumper
JMCU1 MCU Programming Jumper
JSPI1 Serial Peripheral Interface Bus
JLPC1 Low-pin Count Pin Header
JRI1/JRI2 COM1/COM2 Power Selection
MPCIE1/MPCIE2 Mini-PCIe Connector 1/2
mSATA1 mSATA Connector
JKBMS1 Keyboard/Mouse Connector
JRI1 COM1 Power Selection
JRI2 COM2 Power Selection
SATA1 SATA Driver Connector
SATAPWR1 SATA Power Connector
SIM1 SIM Card Connector
USBF1 USB 2.0 Pin Header

Jumper Settings
JCMOS1 (Clean CMOS):
This jumper is used to erase data in CMOS. To clear CMOS,
first turn off your system and unplug power source. Then,
by placing the cap on pin 2 and 3 (short pin 2-3), this
jumper can erase the system settings stored in CMOS
memory.
Pin Description
Short 1-2 Normal (default)
Short 2-3 Clear RTC
SW1: Function Select
Default Pin 1&2 ON; Pin 3&4 OFF
Pin Status Description
1ON/OFF MIO_COM5_RX
2ON/OFF MIO_COM5_TX
3 ON/OFF MIO_COM_RXD
4 ON/OFF MIO_COM_TXD
JMCU1: Programming the MCU
Pin Description
Short 1-2 Normal (default)
Short 2-3 Program MCU
1
1 2 3 4
1
Connectors
VGA (VGA1)
Pin Signal Pin Signal Pin Signal
1 RED 6 GND 11 N/A
2 GREEN 7 GND 12 DDC DAT
3 BLUE 8 GND 13 VGA_HS
4 N/A 9 V5S_VGA 14 VGA_VS
5 GND 10 GND 15 VGA_CLK
HDMI (HDMI1)
Pin Description Pin Description
1 HDMI_DATP2_P 2 GND
3 HDMI_DATP2_N 4 HDMI_DATP1_P
5 GND 6 HDMI_DATP1_N
7 HDMI_DATP0_P 8 GND
9 HDMI_DATP0_N 10 HDMI_CLK_P
11 GND 12 HDMI_CLK_N
13 N/A 14 N/A
15 HDMI_DDC_CLK 16 HDMI_DDC_DAT
17 GND 18 V5S_HDMI
19 HDMI_HPD
USBF1 (USB0,1)
Pin Description Pin Description
1 V5S_USB0 6 USBDN1
2 GND 7 USBDP0
3 N/A 8 N/A
4 USBDP1 9 GND
5 USBDN0 10 V5S_USB1
15 14 13 12 11
5 4 3 2 1
1
5

USB3.0 (USB2)
Pin Description Pin Description
1 V5S_USB2 5 USB3_SSRXN
2 USBDN2 6 USB3_SSRXP
3 USBDP2 7 GND
4 GND 8 USB_SSTXP
9 USB_SSTXN
LAN (LAN1)
Pin Description Pin Description
1 MDI_P0_LAN1 8 MDI_N2_LAN1
2 MDI_N0_LAN1 9 MDI_P3_LAN1
3 MDI_P1_LAN1 10 MDI_N3_LAN1
4 MDI_N1_LAN1 11 LNK100_LAN1
5 GND 12 LNK1000_LAN1
6 GND 13 V3P3A
7 MDI_P2_LAN1 14 ACT_LAN1
Serial-ATA Connector (SATA1):
SATA 7-pin signal connector for HDD/SSD. The interface
signal is SATA 3.0 Gbps.
4-pin Serial-ATA Power Connector (SATAPWR1): It is
for connecting the SATA power cord.
SATA1
7 6 5 4 3 2 1
Pin Description
1 GND
2 SATATXP
3 SATATXN
4 GND
5 SATARXN
6 SATARXP
7 GND
SATAPWR1
1 2 3 4
Pin Description
1 VCC12
2 GND
3 GND
4 VCC5_PS
mSATA (MSATA1)
It complies with SATA 3.0Gbps interface
PIN Description PIN Description
1 N/A 30 SMB_CLK
2 V3P3S 31 mSATATXN
3 N/A 32 SMB_DAT
4 GND 33 mSATATXP
5 N/A 34 GND
6 N/A 35 GND
7 N/A 36 N/A
8 N/A 37 GND
9 GND 38 N/A
10 N/A 39 V3P3S
11 N/A 40 GND
12 N/A 41 V3P3S
13 N/A 42 N/A
14 N/A 43 GND
15 GND 44 N/A
16 N/A 45 N/A
17 N/A 46 N/A
18 GND 47 N/A
19 N/A 48 N/A
20 N/A 49 N/A
21 GND 50 GND
22 N/A 51 N/A
23 mSATARXP 52 V3P3S
24 V3P3S 53 N/A
25 mSATARXN 54 N/A
26 GND 55 N/A
27 GND 56 N/A
28 N/A 57 N/A
29 GND 58 N/A
SIM card reader (SIM1)
COM1/COM2 Power Selection (JRI1/JRI2):
JRI1 selects COM1 power voltage and JRI2 selects COM2
power voltage . The default is Ring Indicator (RI) for pin 8
of COM.
Pin No. Description
C1 UIM_PWR
C2 UIM_RST
C3 UIM_CLK
C5 GND
C6 UIM_VPP
C7 UIM_DAT
C5 C7
C1 C3
2
1
6
5
JRI1
2
1
6
5
JRI2
Pin No. Signal
1-2 Default
3-4 VCC5
5-6 VCC12

MPCIE1: Mini-PCIe Connector with one SIM Card
Reader(SIM1). It supports both Wi-Fi and 3G module.
Pin Signal Pin Signal
1 PCIE_WAKE_N 2 VCC3P3_PS
3 N/A 4 GND
5 N/A 6 V1P5_MPCIE
7 E_CLKREQ- 8 UIM_PWR
9 GND 10 UIM_DATA
11 PCIE_CKN3 12 UIM_CLK
13 PCIE_CKP3 14 UIM_RESET
15 GND 16 UIM_VPP
17 RSV 18 GND
19 RSV 20 N/A
21 GND 22 BUF_PLT_RST#
23 PCH_PCIE_RXN3 24 PCIE_PCIE_VCC3AUX
25 PCH_PCIE_RXP3 26 GND
27 GND 28 V1P5_MPCIE
29 GND 30 SMBCLK_RESUME
31 PCH_PCIE_TXN3 32 SMBDATA_RESUME
33 PCH_PCIE_TXP3 34 GND
35 GND 36 PCH_USB_N8
37 GND 38 PCH_USB_P8
39 VCC3P3_PS 40 GND
41 VCC3P3_PS 42 LED_WWAN1-
43 GND 44 LED_WLAN1-
45 RSV 46 N/A
47 RSV 48 V1P5_MPCIE
49 RSV 50 GND
51 RSV 52 VCC3P3_PS
MPCIE2: Mini-PCIe Connector (half-size)
Pin Signal Pin Signal
1 PCIE_WAKE_N 2 VCC3P3_PS
3 N/A 4 GND
5 N/A 6 V1P5_MPCIE
7 E_CLKREQ- 8 UIM2_PWR
9 GND 10 RSV
11 PCIE_CKN4 12 RSV
13 PCIE_CKP4 14 RSV
15 GND 16 RSV
17 RSV 18 GND
19 RSV 20 N/A
21 GND 22 BUF_PLT_RST#
23 PCH_PCIE_RXN4 24 PCIE_PCIE_VCC3AUX
25 PCH_PCIE_RXP4 26 GND
27 GND 28 V1P5_MPCIE
29 GND 30 SMBCLK_RESUME
31 PCH_PCIE_TXN4 32 SMBDATA_RESUME
33 PCH_PCIE_TXP4 34 GND
35 GND 36 PCH_USB_N9
37 GND 38 PCH_USB_P9
39 VCC3P3_PS 40 GND
41 VCC3P3_PS 42 LED_WWAN2-
43 GND 44 LED_WLAN2-
45 RSV 46 N/A
47 RSV 48 V1P5_MPCIE
49 RSV 50 GND
51 RSV 52 VCC3P3_PS
COM1&2
Pin RS-232 RS-422 RS-485
1 DCD TXD- DATA-
2 RXD TXD+ DATA+
3 TXD RXD+
4 DTR RXD-
5 GND
6 DSR
7RTS
8 CTS
9 RI
Multiple I/O Connectors (MIO1): Multiple I/O pins for
functions in serial communication, Digital In/Out, Ignition
detection input for automatic wake-up function
6789
12345
Pin No. Function Function
1 GND
2 12V_OUT 12VDC Power Output
3 IGN_DI0 Input pin for automatic
wakeup
4 IGN_DI1 Input pin for automatic
wakeup
5 EXT_TXD_R COM_TxD
6 EXT_RXD_R COM_RxD
7 DI_0 Digital-In_0
8 DO_0 Digital-Out_0
9 DI_1 Digital-In_1
10 DO_1 Digital-Out_1
11 DI_2 Digital-In 2
12 DO_2 Digital-Out 2
13 DI_3 Digital-In 3
14 DO_3 Digital-Out 3
15 RELAY1_NOPEN RELAY1 Normally Open
16 RELAY1_COMM RELAY1 Common
17 GND Ground
18 GND Ground
19 RELAY2_NOPEN RELAY2 Normally Open
20 RELAY2_COMM RELAY2 Common

Maximum input/output current for each port is
100mA
For all Input/
output pins:
Voltage Logic Register
DI: <0.8V
DO: <0.4V
Low 0
DI: 10 ~ 12V
DO:12V
High 1
The default BIOS value is 0 for DI and 1 for DO
Pin3 and pin4 can be used for DI wake-up1.
function (Refer to the flow chart in Chapter 4 and
the ISM in Appendix A).
Pin 15, 16, 17 can be used for Digital output2.
control with contact current 9~36V@2A (DO1); Pin
18, 19, 20 can be used for digital output control
with contact current 9~36V@2A in maximum
(DO2).
Keyboard & Mouse connector (JKBMS1)
Low-Pin Count (JLPC1)
Pin Description Pin Description
1 33MHz CLK 2 LAD1
3 RESET 4 LAD0
5 FRAME 6 VCC 3.3
7 LAD3 8 GND
9 LAD2 10 GND
Pin No. Pin Name
1 VCC5_KB
3 MDATA
5 KDATA
7 GND
Pin No. Pin Name
2 KCLK
8 MCLK
SPI (JSPI1)
Pin Description
1 SPI_HOLD
2 N/A
3 SPI_CS0
4 VCC3
5 SPI_MISO
6 N/A
7 N/A
8 SPI_CLK
9 GND
10 SPI_MOSI
Power Input with Ignition Control (PRJK1)
CAN Bus Module Connector (CN1)
Pin No. Pin Name
1 Ignition
2 GND
3 DC_IN
Pin No. Signal Pin No. Signal
1 BAT_12V_24V 2 K_LINE
3 DO 4 N/A
5 GND_CAN 6 GND_CAN
7 PLTRST_BUF1 8 J1850+/J1708+
9 SIO_SIN3 10 J1850-/J1708-
11 SIO_SOUT3 12 CAN_H/J1939+
13 V5S 14 CAN_L/J1939-
13
1
14
2

CAN Bus Connector (CAN1)
AUDIOIN1: Line-out and Mic-in Connector
6789
12345
Pin No. Pin Name
1 J1850-/J1708-
2 GND_CAN
3 CAN_H/J1939+
4 K_LINE
5 CAN_L/J1939-
6 J1850-/J1708-
7J1850+/J1708+
8J1850+/J1708+
9BAT_12V_24V
Pin No. Pin Name
1 MIC_IN_L
2 MIC_IN_R
3 GND_AUO
4 GND_AUO
5 FRONT_OUT_L
6 FRONT_OUT_R
