H3C VG Series User manual

Command Manual – Getting Started
H3C VG Series Voice Gateways Table of Contents
i
Table of Contents
Chapter 1 Fundamental Configuration Commands...................................................................1-1
1.1 Command Line Interface Commands................................................................................1-1
1.1.1 display history-command ........................................................................................1-1
1.1.2 quit...........................................................................................................................1-2
1.1.3 return.......................................................................................................................1-2
1.2 Basic System Configuration Commands...........................................................................1-3
1.2.1 clock........................................................................................................................1-3
1.2.2 display base-information.........................................................................................1-4
1.2.3 display clock............................................................................................................1-5
1.2.4 display duration.......................................................................................................1-5
1.2.5 display reboot.......................................................................................................... 1-6
1.2.6 display sysname......................................................................................................1-6
1.2.7 display system cpu..................................................................................................1-7
1.2.8 display system memory........................................................................................... 1-7
1.2.9 display version.........................................................................................................1-8
1.2.10 reboot.................................................................................................................. 1-10
1.2.11 sysname..............................................................................................................1-11
1.2.12 version.................................................................................................................1-11
1.3 Ethernet Configuration Commands .................................................................................1-12
1.3.1 debugging dhcp client...........................................................................................1-12
1.3.2 debugging ethernet............................................................................................... 1-13
1.3.3 debugging physical ...............................................................................................1-13
1.3.4 description (interface)............................................................................................1-14
1.3.5 display interfaces ethernet....................................................................................1-15
1.3.6 duplex....................................................................................................................1-16
1.3.7 hub-enable ............................................................................................................1-17
1.3.8 interface................................................................................................................. 1-17
1.3.9 ip address.............................................................................................................. 1-18
1.3.10 loopback..............................................................................................................1-20
1.3.11 mtu ...................................................................................................................... 1-20
1.3.12 send-frame-type..................................................................................................1-21
1.3.13 speed...................................................................................................................1-22
1.4 Default Route Configuration Commands.........................................................................1-22
1.4.1 ip route-static......................................................................................................... 1-22

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-1
Chapter 1 Fundamental Configuration Commands
1.1 Command Line Interface Commands
1.1.1 display history-command
Syntax
display history-command
View
Any view
Parameter
None
Description
Use the display history-command command, you can view the latest 20 commands
you have entered.
You can press composite keys <Ctrl+P> and <Ctrl+N> to view the previous history
command and the next one respectively.
Example
# Display history commands you have entered.
[VG] display history-command
Current user:h3
No 1. int e 0
No 2. quit
No 3. int e 0
No 4. ing e0
No 5. dis his
No 6. dis current
No 7. dis current
No 8. dis his
No 9. dis his
No10. dis his
No11. dis his
No12. dis his
No13. dis his
No14. dis his

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-2
No15. dis his
No16. dis current
No17. dis current
No18. dis his
No19. dis his
1.1.2 quit
Syntax
quit
View
Any view except system view
Parameter
None
Description
Use the quit command to return from the current view to the upper-level view.
Example
# Return to the system view from Ethernet interface view.
[VG-Ethernet0] quit
[VG]
1.1.3 return
Syntax
return
View
Any view
Parameter
None
Description
Use the return command to return directly to the system view from the current view
(excluding the system view).
Composite key <Ctrl+Z> is equivalent to the command return in function.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-3
Example
# Return to the system view from Ethernet interface view.
[VG-Ethernet0] return
[VG]
1.2 Basic System Configuration Commands
1.2.1 clock
Syntax
clock { systime HH:MM:SS YYYY MM DD | timezone name { add |minus }
HH:MM:SS }
undo clock timezone
View
System view
Parameter
HH:MM:SS: Current time of the VG. the hour ranges 0~23; the minute and second
range 0~59.
YYYY, MM and DD: Date information of the VG. YYYY ranges 1997~2097; MM ranges
1~12; the range of DD is the actual number of days in the month.
timezone name: Sets the time zone name and contains 1 to 32 characters.
add HH:MM:SS: Adds the time zone difference.
minus HH:MM:SS: Reduces the time zone difference.
Description
Use the clock command to set the system clock of the VG.
Use the undo clock timezone command to restore the default system time zone.
By default, if the VG has no hardware real time, then the initial time is 1:00:00, January
1, 1998. But if it has hardware real time, it will set system time to hardware real time.
The timing fails when the VG is powered off, so it is required to set date and time again
for the VG when absolute time is necessary.
Note:
After the VG reboots, the system clock will be restored to the default setting, and the
timezone value saved before rebooting will be adopted.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-4
Related command: display clock.
Example
# Set system time as 17:15:30, July 15, 2005.
[VG] clock systime 17:15:30 2005 7 15
1.2.2 display base-information
Syntax
display base-information [ page ]
View
Any view
Parameter
page: Displays information in pages.
Description
Use the display base-information command to display system statistics.
The statistical information includes software version, current configuration information,
interface information, memory information, interface traffic. The information is
significant for you to get a general idea about the VG.
Example
# Display system statistics.
[VG] display base-information
[Display Version]
......
[Display Current-configuration]
......
[Display Interfaces]
......
[Display Memory Detail]
......
[Display Ip Statistics]
......
[Display Ip Interface]
......

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-5
1.2.3 display clock
Syntax
display clock
View
Any view
Parameter
None
Description
Use the display clock command, you display current date and time of the system.
When finding incorrect system time with this command, you can adjust it.
Related command: clock.
Example
# Display current date and time of the system.
[VG] display clock
Current Voice Gateway time:03:05:23 Mar 30 2005
1.2.4 display duration
Syntax
display duration
View
Any view
Parameter
None
Description
Use the display duration command to view the period from system startup to the point
executing this command.
Example
# Display the period from system startup to the point executing this command.
[VG] display duration
Voice Gateway VG10-41 uptime is 0 days 1 hours 38 minutes 4 seconds.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-6
1.2.5 display reboot
Syntax
display reboot
View
Any view
Parameter
None
Description
Use the display reboot command to view system rebooting proposal.
Related command: reboot.
Example
# Display system rebooting schedule.
[VG] display reboot
[10:06:17 May 7 2005] Reboot scheduled for [23:59:59 May 7 2005] by [Console]
Reboot reason: Update Comware program
The above information shows a schedule to reboot the system at 23:59:59, May 7,
2005.
1.2.6 display sysname
Syntax
display sysname
View
Any view
Parameter
None
Description
Use the display sysname command to view system name.
Related command: sysname.
Example
# Display system name.
[VG] display sysname

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-7
VG
1.2.7 display system cpu
Syntax
display system cpu
View
Any view
Parameter
None
Description
Use the display system cpu command to view the CPU occupancy, in percentage.
Example
# Display CPU occupancy.
[VG] display system cpu
Current CPU load: 5%
1.2.8 display system memory
Syntax
display system memory { all | blksize size } [ detail ]
View
Any view
Parameter
all: Displays the occupancy of all memory blocks
blksize size: Displays the occupancy of memory blocks of a specified size. The size
ranges 32, 64, 128, 512, 1024, 2048, 4096, 8196 etc.
detail: Displays details about each memory block, including address, occupied size
etc.
Description
Use the display system memory command to view memory occupancy, including the
sizes of system memory, various memory blocks, unblocked memory, idle memory, and
occupied memory respectively.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-8
Example
# Display occupancy of all memory blocks.
[VG] display system memory all
Total: 19029120 Slice: 1300992 RawSlice: 1706596 Free: 16021532
-------------------------------------------------------------------
Slice Memory Usage:
Block Size 32 Free 1419 Used 420 Total 1839
Block Size 64 Free 5 Used 86 Total 91
Block Size 128 Free 1 Used 315 Total 316
Block Size 256 Free 4 Used 338 Total 342
Block Size 512 Free 2 Used 20 Total 22
Block Size 1024 Free 2 Used 27 Total 29
Block Size 2048 Free 35 Used 350 Total 385
Block Size 4096 Free 8 Used 31 Total 39
----------------------- Slice memory summary -----------------------
Used(Byte) 1027456 Free 1476 Used 1587 Total 3063
Raw Slice Memory Usage:
Total Size: 1662960 Num: 64
------------------ RawSlice detailed information ------------------
(0x00700606*27) (0x02200000*1) (0x02402421*1) (0x02402429*1)
(0x02402428*1) (0x02402427*1) (0x02402426*1) (0x02402425*1)
(0x02402424*1) (0x02402423*1) (0x12012001*3) (0x05005009*3)
(0x0DD0DC0D*1) (0x0DD0DC0C*1) (0x0DD0DC0B*1) (0x0DD0DC0A*1)
(0x0DD0DC09*1) (0x0DD0DC06*1) (0x0DD0DC05*1) (0x05005007*2)
(0x0FE00104*2) (0x0B40B408*1) (0x00D1D101*1) (0x00D0D003*1)
(0x00D0D002*1) (0x00D0D001*2) (0x0B20B201*2) (0x12345670*1)
(0x12345679*1) (0x12345678*1)
1.2.9 display version
Syntax
display version
View
Any view
Parameter
None
Description
Use the display version command to view system version.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-9
By viewing the system version, you can get information about the current software
version, hardware configuration, starting time and so on .
Example
# Display system version.
[VG] display version
H3C Comware Software
Comware software, Version 1.80, Feature 0019
Copyright(c) 2004-2006 Hangzhou Huawei-3Com Tech. Co., Ltd. All rights
reserved.
Without the owner's prior written consent, no decompiling
or reverse-engineering shall be allowed.
H3C VG 10-41 uptime is 0 day(s) 0 hour(s) 2 minute(s) 11 second(s)
System returned to ROM by power-on.
H3C VG 10-41 with 1 MPC 852 Processor
Voice Gateway serial number is 00E0FC1213147654
32M bytes SDRAM
8192K bytes Flash Memory
0K bytes NVRAM
Config Register points to FLASH
Hardware Version is MTR 2.0
CPLD Version is CPLD 1.0
Bootrom Version is 1.04
[WAN ] Eth Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[LAN ] Eth Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[PHONE0] FXS Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[PHONE1] FXS Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[PHONE2] FXS Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[PHONE3] FXS Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0
[LINE ] FXO Hardware Version is 2.0, Driver Version is 1.0,
Cpld Version is 1.0

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-10
1.2.10 reboot
Syntax
reboot [ mode { interval { hh:mm | mmm } | time { hh:mm [ dd/mm/yyyy ] }
[ reason-string ] } ] [ reason reason-string ] [ cancel ]
View
System view
Parameter
mode: Reboots the system at a preset time point or after a preset interval.
interval { hh:mm | mmm }: Specifies an interval to reboot the system, in time form
(hh:mm) or in digit form (mmm). Value ranges 0~5999 minutes in digit form.
time hh:mm [ dd/mm/yyyy ]: Specifies a time point to reboot the system. If no date is
assigned, it is the current date.
reason-string: Describes the reason for rebooting the system.
cancel: Removes system rebooting at a preset time point or after a preset interval.
Description
Use the reboot command to reboot the VG.
This command is equivalent in function to powering off the VG. But in remote
maintenance mode, you can use this command to restart the VG remotely, instead of
going to the place where the VG is located and restarting it.
Using the command with the keyword interval or time, you can set system rebooting
after a preset interval or at a preset time. This helps in case of online program upgrade
and configuration modification. System rebooting is required before the upgraded
program takes effect and the same is true of modifying some special configurations.
But system rebooting is not recommended when an administrator is maintaining the
system, for this may disturb the normal services. Thiscommand enables you to select a
time when system rebooting does not disturb normal services or disturbs normal
services to the lowest degree.
You should decide whether to save configuration files before restarting the system with
this command.
Example
# Reboot the system.
[VG] reboot
WARNING: System will REBOOT! Continue?[Y/N]y
System is now rebooting, please wait.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-11
1.2.11 sysname
Syntax
sysname sysname
View
Any view
Parameter
sysname: System name, in the range of 1~20 characters.
Description
Use the sysname command to set or modify the system name, which is displayed in
view prompt.
By default, the system name is VG.
Related command: display sysname.
Example
# Set the system name as h3c.
[VG] sysname h3c
[h3c]
1.2.12 version
Syntax
version
View
System view
Parameter
None
Description
Use the version command to display the software version information of the VG.
Example
# display the software version information of the VG.
[VG] version
H3C Comware Software
Comware software, Version 1.80 Feature 0019

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-12
1.3 Ethernet Configuration Commands
1.3.1 debugging dhcp client
Syntax
debugging dhcp client { event | packet | error | all }
undo debugging dhcp client { event | packet | error | all }
View
Any view
Parameter
event: Events of the DHCP client, including address allocation and data update.
packet: DHCP packets received and sent by the DHCP client.
error: Unrecognized packets or error information.
all: Enables all the debugging for the DHCP client, including debugging for event,
packet and error.
Description
Use the debugging dhcp client command to enable debugging for the DHCP client.
Use the undo debugging dhcp client command to disable debugging output.
By default, all the debugging for the DHCP client is disabled.
Example
# Enable debugging for events of the DHCP client.
<VG> debugging dhcp client event
[VG-Ethernet1]ip address dhcp-alloc
[VG-Ethernet1]
User <lijian> execute command <ip add d>.
Ethernet1: FSM state transfer(HALT-->INIT) successfully.
Ethernet1: Send DHCPDISCOVER in 10 seconds.
Ethernet1: Send DHCPDISCOVER success.
Ethernet1: FSM state transfer(INIT-->SELECTING) successfully.
Ethernet1: Select 192.168.70.20 as the server.
Ethernet1: A invalid T2 option appear in DHCPOFFER, use the default value.
Ethernet1: Send DHCPREQUEST packet success.
Ethernet1: FSM state transfer(SELECTING-->REQUESTING) successfully.
Ethernet1: A invalid T2 option appear in DHCPACK, use the default value.
Ethernet1: Alloced ip(192.168.70.1) does not conflict with any other
interface,

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-13
begin to bind.
Ethernet1: Send arp request for alloced address(192.168.70.1) success.
Ethernet1: Move to BOUND state in 1 seconds if received no arp reply.
%10:21:31: Line protocol ip on the interface Ethernet1 is UP
Ethernet1: Recv no arp reply for 192.168.70.1, begin to use the address.
Ethernet1: Process DHCP_CLIENT_KRT message if index(2), message type(1)
Ethernet1: FSM state transfer(REQUESTING-->BOUND) successfully.
1.3.2 debugging ethernet
Syntax
debugging ethernet
undo debugging ethernet
View
Any view
Parameter
None
Description
Use the debugging ethernet command to enable debugging for events of the Ethernet
interface.
Use the undo debugging ethernet command to disable debugging output.
Example
# Enable debugging for events of the Ethernet interface.
[VG] debugging ethernet
Ethernet0: Send a Ethernet_II frame.
Its Destination MAC address is:ff-ff-ff-ff-ff-ff
Its Source MAC address is:00-e0-fc-20-21-80
It's a arp datagram
1.3.3 debugging physical
Syntax
debugging physical {all |receive |transmit } [ interface ethernet
interface-number ]
undo debugging physical {all |receive |transmit } [ interface ethernet
interface-number ]

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-14
View
Any view
Parameter
All: Debugging information switch for all packets transmitted/received on the specified
interface at the physical layer.
Receive: Debugging information switch for all packets received on the specified
interface at the physical layer.
Transmit: Debugging information switch for packets transmitted on the specified
interface at the physical layer.
interface ethernet interface-number: Specified interface number.
Description
Use the debugging physical command to enable debugging information switch for
packets transmitted/received on the specified interface at the physical layer. Use the
undo debugging physical command to disable debugging information switch for
packets transmitted/received on the specified interface at the physical layer.
Example
# Enable debugging information switch for packets transmitted/received on the
specified interface at the physical layer.
[VG] debugging physical receive
1.3.4 description (interface)
Syntax
description string
undo description
View
Interface view
Parameter
string:A string that describes an interface, containing 1 to 64 characters.
Description
Use the description command to configure a string that describes an interface. Use
the undo description command to delete a string that describes an interface.
Using the description command to describe an interface does not affect the running of
the interface. You can run the display command to view this description.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-15
Example
# Mark interface ethernet 0 as lan.
[VG-Ethernet0] description lan
1.3.5 display interfaces ethernet
Syntax
display interfaces ethernet number
View
Any view
Parameter
number: Interface number, which, combined with the parameter type, can define an
interface.
Description
Use the display interfaces ethernet command to view the status and other associated
information about the current Ethernet interface.
The following information is included:
zThe physical status and protocol status
zThe physical attributes (for example interface cable)
zThe IP address
zThe link-layer protocol, and its status and statistics.
zInput/output message statistics
Example
# Display status and other associated information about the Ethernet 0.
[VG] display interfaces ethernet 0
Ethernet0 current state:down, line protocol current state:down
Description: Ethernet interface, Ethernet0 Interface
The Maximum Transmit Unit is 1500
Internet Address is 192.168.80.30(24)
IP Sending Frames' Format is Ethernet_II,Hardware address is
00-e0-fc-20-21-80
Media type is twisted pair, loopback is not set, promiscuous mode not set
Half-duplex mode, 10Mbps-speed mode, link type is autonegotiation
Input queue : (size/max/drops) 0/200/0
FIFO queueing: FIFO
(Outbound queue:Size/Length/Discards)
FIFO: 0/75/0

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-16
Last 5 minutes input rate 0.00 bytes/sec, 0.00 packets/sec
Last 5 minutes output rate 0.00 bytes/sec, 0.00 packets/sec
Input: 76 packets, 9858 bytes
70 broadcasts
6 errors, 0 runts, 0 giants
0 CRC,0 frame errors, 0 overrunners
0 aborted sequences 0 no buffers
0 packets with dribble condition detected
Output:28 packets, 1792 bytes
28 broadcasts
0 errors, 0 underruns, 0 collisions
0 packets had been deferred
1.3.6 duplex
Syntax
duplex { negotiation | full |half }
undo duplex
View
Ethernet interface view
Parameter
negotiation: Negotiation mode
full: Full duplex mode
half: Half duplex mode
Description
Use the duplex command to set the operating mode of the 10/100Base-TX Fast
Ethernet (FE) interface.
Use the undo duplex command to reset the interface mode to the default value.
By default, the Ethernet interface runs in negotiation mode.
When the VG is connected to HUB, it runs in half duplex mode. When connected to the
network device which supports full duplex mode and is set in full duplex mode, for
example LAN Switch, it runs in full duplex mode.
If you set the interface in negotiation mode, the peer interface must be also in
negotiation mode. It is recommended to use the duplex command to set both ends at
the same duplex mode if you are not sure they are in the same mode.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-17
Using the command duplex {full |half } first and then the command speed
negotiation, you can set the interface run in negotiation mode and start the process to
negotiate both speed and operating mode.
Related command: speed, display interfaces ethernet.
Example
# Set 10/100Base-TX FE interface run in full duplex mode.
[VG-Ethernet0]duplex full
1.3.7 hub-enable
Syntax
hub-enable
undo hub-enable
View
System view
Parameter
None
Parameter
Use the hub-enable command to configure the VG to work in HUB mode. Use the
undo hub-enable command to restore the default work mode of the VG.
By default, the VG works in the route mode.
Note:
This command applies on VG 10-40 and VG 10-41 only.
Example
# Configure the VG to work in HUB mode.
[VG] hub-enable
1.3.8 interface
Syntax
interface type number
undo interface type number

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-18
View
Any view
Parameter
type: Interface type. Refer to Table 1-1 for interface types that the VG supports.
number: Interface number. Various types of interfaces of the VG are numbered
respectively, each type starting from 0 or 1.
Description
Use the interface command to enter the specific interface view or create logical
interfaces.
Use the undo interface command to delete a specified logical interface.
You can input the interface type in shortened form, as long as it is not in conflict with
other interface types. For example, you can shorten the Ethernet 0 as e0.
Table 1-1 Interface types that the VG supports
Interface type Description Interface attribute
Dialer Dial interface Logical interface
Ethernet Ethernet interface Physical interface
Loopback Loopback interface Logical interface
Example
# Enter the Ethernet interface view from the system view.
[VG]interface ethernet 0
[VG-Ethernet0]
1.3.9 ip address
Syntax
ip address { ip-address { mask | mask-length } [ sub ] | dhcp-alloc }
undo [ ip address ip-address { mask | mask-length } [ sub ] | dhcp-alloc ]
View
Interface view
Parameter
ip-address: IP address of the Ethernet interface.
mask: Sub-net mask, in dotted decimal notion.

Command Manual – Getting Started
H3C VG Series Voice Gateways Chapter 1 Fundamental Configuration Commands
1-19
mask-length: Length of the sub-net mask.
sub: Sub-IP address of the Ethernet interface.
dhcp-alloc: Configure the VG as the DHCP client to dynamically obtain the IP address.
By default, the allocation of local IP address through DHCP negotiation is disabled.
Description
Use the ip address command to set IP address for the Ethernet interface.
Use the undo ip address command to delete the IP address of the interface.
By default, the IP addresses for Ethernet 0 (WAN) and Ethernet 1 (LAN) are
192.168.192.1 and 192.168.193.1 respectively.
There are five kinds of IP addresses and you can choose one of them accordingly. The
all-0 and all-1 addresses cannot be selected as general IPaddresses, since they are in
special use.
The mask is used to identify the network address in an IP address. For example, if the
IP address of an Ethernet interface is 129.9.30.42 and the mask is 255.255.0.0, then it
can be concluded by combining the IP address and mask that the corresponding
network address is 129.9.0.0.
It usually suffices to configure one IP address for one Ethernet interface. But you can
also configure multiple IP addresses for one interface for its connection with multiple
sub-nets, with one being the primary address and the rest being the sub-address, that
is, secondary address. The configured secondary address becomes the primary one
automatically if no primary address is available.
Note that all of the IP addresses configured for the Ethernet interfaces of the VG can be
in the same sub-net.
Note:
When the VG adopts factory default settings, the Ethernet interface has a default IP
address. If you modify the address or delete it using the undo ip address command
and save your configurations, the default IP address will be lost.
Example
# Configure the master IP address of Ethernet0 as 129.102.0.1 and sub-IP address as
202.38.160.1.
[VG-Ethernet0] ip address 129.102.0.1 255.255.255.0
[VG-Ethernet0] ip address 202.38.160.1 255.255.255.0 sub
# Allocate the local IP address through DHCP negotiation on Ethernet 0.
[VG-Ethernet0] ip address dhcp-alloc
