Powermat PM-APW-20C User manual

PM0744
ORIGINAL INSTRUCTIONS
USER MANUAL
BATTERY SAW
ON BOOM
PM-APW-20C

2
Table of Contents
Table of Contents ................................................ .................................................. ............................................... 2
WARNING / INFORMATION SYMBOLS .............................................. ........................................... 3
INTENDED USE OF THE DEVICE ................................................ .................................................. ............... 5
SAFETY RULES ................................................ .................................................. .................... 5
General safety instructions ............................................... .................................................. ... 5
Protection against electric shock .............................................. ............................................ 6
General safety regulations for power tools ............................................. ........................... 6
Safety instructions for working with chainsaws ........................................... 8
Additional safety instructions ............................................... ............................................ 10
Safety instructions for chargers .............................................. ......................................... 11
TECHNICAL DATA ................................................ .................................................. .............................. 12
DESCRIPTION OF THE DEVICE CONSTRUCTION ............................................... .................................................. ................ 13
OPERATING THE DEVICE ................................................ .................................................. ....................... 13
Installation ................................................. .................................................. ........................................... 15
Operation ................................................. .................................................. ........................................... 16
CUTTING TECHNIQUES ................................................ .................................................. .................................. 17
Cutting small branches ............................................... .................................................. .......................... 17
Cutting branches (Fig. 11.) .......................................... .................................................. ..................... 17
Cutting large branches (Fig. 12.) ......................................... .................................................. ............... 17
CHARGING AND CHANGING THE BATTERY .............................................. .................................................. ......... 17
Indicators - charger diodes .............................................. .................................................. .............. 17
Battery connection / disconnection .............................................. .................................................. ....... 18
Battery charge indicator ............................................... .................................................. .......... 18
TRANSPORT ................................................. .................................................. ........................................ 18
MAINTENANCE AND CLEANING ............................................... .................................................. ............. 18
Replacing / turning the saw chain and guide bar ........................................... ........................... 19
Chain sharpening ................................................ .................................................. .......................... 19
Checking automatic chain lubrication .............................................. ............................... 19
Storage ................................................. .................................................. ........................... 19
SERVICE ................................................. .................................................. ................................................ twenty
GUARANTEE ................................................. .................................................. ....................................... twenty
Manufacturer's Warranty Exclusions ............................................... .................................................. ... twenty
PART DIAGRAM ................................................ .................................................. ................................. 21
DISPOSAL OF USED DEVICES ............................................... .................................................. ....... 22
MANUFACTURER'S DATA ................................................ .................................................. ........................... 22

3
DECLARATION OF CONFORMITY ................................................ .................................................. .................... 23
WARNING / INFORMATION SYMBOLS
ATTENTION: Before using the device, carefully read the operating instructions and safety ATTENTION: Before using the device, carefully read the operating instructions and safety
instructions. Keep the instructions.
ATTENTION: The charger should only be used in dry rooms.ATTENTION: The charger should only be used in dry rooms.
ATTENTION: Do not expose to rain or other precipitation. ATTENTION: Do not expose to rain or other precipitation.
ATTENTION: Keep a safe distance from bystanders during work.ATTENTION: Keep a safe distance from bystanders during work.
ATTENTION: For items rejected during work.ATTENTION: For items rejected during work.
ATTENTION: Keep a distance of min. 15m from bystanders.ATTENTION: Keep a distance of min. 15m from bystanders.
ATTENTION: When working, make sure that there are no bystanders within a 360-degree ATTENTION: When working, make sure that there are no bystanders within a 360-degree
radius.
ATTENTION: Disconnect the device from the power supply before carrying out maintenance and ATTENTION: Disconnect the device from the power supply before carrying out maintenance and
cleaning.
ATTENTION: Wear ear protection. ATTENTION: Wear ear protection.

4
ATTENTION: Wear safety goggles. ATTENTION: Wear safety goggles.
ATTENTION: The use of a dust mask is recommended. ATTENTION: The use of a dust mask is recommended.
ATTENTION: Wear protective gloves. ATTENTION: Wear protective gloves.
ATTENTION: Wear appropriate safety shoes. ATTENTION: Wear appropriate safety shoes.
ATTENTION: Use a protective helmet. ATTENTION: Use a protective helmet.
ATTENTION: Do not expose the battery to temperatures above 50 ABOUT C.ATTENTION: Do not expose the battery to temperatures above 50 ABOUT C.ATTENTION: Do not expose the battery to temperatures above 50 ABOUT C.ATTENTION: Do not expose the battery to temperatures above 50 ABOUT C.
ATTENTION: Do not expose the battery to contact with water.ATTENTION: Do not expose the battery to contact with water.
ATTENTION: Do not use the battery in an explosive or flammable environment.ATTENTION: Do not use the battery in an explosive or flammable environment.
Protection class II
CROSSED BASKET SIGN: The order for the selective collection of waste equipment and the CROSSED BASKET SIGN: The order for the selective collection of waste equipment and the
disposal of it together with other waste. See the section "DISPOSAL OF USED DEVICES".

5
APPLICATION
The cordless chainsaw with boom (hereinafter referred to as the saw) is designed for pruning trees and shrubs from
ground level.
The saw can be used without the boom extended to the lowest branches or the boom. The device is not intended for
any other applications (e.g. felling trees, cutting walls, plastics or foodstuffs. The saw is intended for home work. It is
not designed for continuous commercial use. The device is intended for use by adults. Each the use deviating from
the one described in this manual is inconsistent with the intended use of the device The user / owner, not the
manufacturer, is responsible for any damage or injury caused by improper use or changes in the design of the device.
As part of continuous improvement of its products, the manufacturer reserves the right to make minor differences in
this manual, which you should pay attention to.
The device may only be repaired and maintained at an authorized service center.
For safety reasons, the device may not be used by children and adolescents under 18 years of age or by people under the
influence of alcohol, drugs or other intoxicants.
If you have not read this manual, please read it carefully before using the device for the first time.
SAFETY RULES
This paragraph deals with basic safety regulations when using cordless saws. Always wear gloves and goggles. It is also recommended to use
other protective equipment such as safety shoes with non-slip soles and a protective helmet. Appropriate protective clothing reduces the risk of
injury from falling branches, and also protects against accidental contact with the chain.
Never touch the network cords or telephone cables. These types of cables are under very high voltage. There is a risk
of electric shock. Keep a distance of 10 m.
ABOUT GENERAL SAFETY INSTRUCTIONSABOUT GENERAL SAFETY INSTRUCTIONS
Before you start working with this device, familiarize yourself thoroughly with all the controls. Practice working with the device and
ask a specialist to explain the function, mode of operation and working techniques. Make sure that in the event of a failure you will be
able to turn off the device immediately. Improper use of the device can lead to serious injuries.

6
The protective device and personal protective equipment are intended to protect your own health and the health of third parties and to guarantee that
the device will function properly.
ABOUT PROTECTION AGAINST ELECTRIC SHOCKABOUT PROTECTION AGAINST ELECTRIC SHOCK
• Note that the mains voltage corresponds to the data on the rating plate.
• If possible, connect the device only to sockets with a residual current circuit breaker with a measuring current not exceeding 30mA.
• Before each use, check the device and the power cord with the plug for damage. Avoid body contact with grounded parts (e.g. metal
fence, metal pole).
• The extension connector must be protected from splashing water, made of rubber or coated with it. Only use extension cords that
are intended for outdoor use and have the appropriate markings. The cord cross section should be at least 1.0 mm 2. Unwind the cord are intended for outdoor use and have the appropriate markings. The cord cross section should be at least 1.0 mm 2. Unwind the cord are intended for outdoor use and have the appropriate markings. The cord cross section should be at least 1.0 mm 2. Unwind the cord
completely from the drum before using it. Check the cable for damage.
• Route the cable away from the work area and remember to be behind the person operating the device.
• Use the strain relief provided for this purpose to attach the extension cable.
• Damaged cables, connectors, plugs and non-compliant connecting cables must not be used. If the power cord is damaged or cut,
immediately remove the plug from the socket.
• Do not use the device if the switch cannot be turned on or off. Damaged switches must be replaced at a customer service center.
• Do not overload the device. Work only within the specified power range. Do not use low power machines for heavy work. Use your
device only for its intended purpose.
ABOUT GENERAL SAFETY REGULATIONS FOR POWER TOOLS Workplace ABOUT GENERAL SAFETY REGULATIONS FOR POWER TOOLS Workplace
• The workplace should be kept clean and well lit. Cluttered and dark work areas can lead to accidents.
• Do not use this tool in potentially explosive atmospheres, such as in the presence of flammable liquids,
gases or liquids. Power tools create sparks which may ignite.
• Keep the power tool out of reach of children and other people. You can lose control of the tool if you distract
you.
• The chain must not be operated by children and young people; the exception is apprentices over 16 years
under supervision. The prohibition also applies to people who are unfamiliar or insufficiently familiar with the
operation of the chainsaw. The operating instructions should always be at hand. The saw should not be
entrusted to overworked or physically inefficient persons.
Electrical safety
• The power tool plug must match the outlet. Do not change the plug in any way. Do not use adapter plugs for
power tools with protective grounding. Unmodified plugs and matching sockets reduce the risk of electric
shock.
•Avoid contact with grounded surfaces such as pipes, radiators, stoves and refrigerators. The risk of electric
shock is greater when the user's body is grounded.
• The device should be protected against rain and moisture. Water entering a power tool will increase the risk
of electric shock.
• Never use the cable for other activities. Never carry a power tool by the cord or use a cord to suspend the
appliance;

7
Also, do not pull the plug out of the socket by pulling the cord. The cable should be protected against high
temperatures and kept away from oil, sharp edges or moving parts of the device. Damaged or entangled
cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord that is also suitable for outdoor use. Use of an
appropriate extension cord (adapted for outdoor use) reduces the risk of electric shock.
• If the power tool cannot be avoided in a humid environment, use a residual current device (RCD). Use of an
RCD reduces the risk of electric shock.
Security of persons
• Exercise caution when working with a power tool, be careful and prudent every step. Do not use a power
tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention when
using a power tool can result in serious injury.
• Wear personal protective equipment and always wear safety glasses. Wearing personal protective
equipment - mask dust, shoes from soles
, hard hat or hearing protection (depending on the type and use of the power tool) - reduces the risk of
injury.
• Avoid unintentional starting of the tool. Before inserting the plug into the socket and / or connecting to the
battery, and before lifting or moving the power tool, make sure that the power tool is switched off. Keeping
your finger on the switch while moving the power tool or plugging in a power tool may result in accidents.
• Before turning on the power tool, remove the setting tools or wrenches. A tool or wrench that is in the
moving parts of the machine can cause injury.
• Avoid unnatural work positions. Take care of stable work position and balance. This way you will be able to
better control your power tool in unforeseen situations.
• Wear appropriate clothing. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
• If it is possible to install dust extraction and trapping devices, make sure that they are connected and used
correctly. Using a dust extraction device can reduce the risk of dust.
Proper service and use of power tools
• Do not overload the device. Only use power tools intended for this purpose. A properly selected power tool
works better and safer in a given performance range.
• Do not use a power tool if the on / off switch is damaged. A power tool that cannot be turned on or off is
dangerous and must be repaired.
•Before adjusting the device, changing accessories or after stopping the work with the tool, pull the plug out of the
socket and / or remove the battery. This precautionary measure prevents the power tool from unintentionally
starting.

8
• Store unused power tools out of the reach of children. Do not share the tool with people who do not know it
or have not read these regulations. Power tools used by inexperienced people are dangerous.
• Proper maintenance of the power tool is necessary. Check that the moving parts of the device are working
properly and are not blocked, whether the parts are not cracked or damaged in a way that would affect the
proper functioning of the power tool. Damaged parts must be repaired before use. Many accidents are
caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. The cutting tool is stuck much less often if it is carefully maintained.
Well-groomed tools are also easier to drive.
• Power tools, accessories, auxiliary tools etc. should be used in accordance with these instructions. The
conditions and type of work performed should be taken into account. Incorrect use of the power tool can
lead to dangerous situations.
Proper service and use of battery tools
• Rechargeable batteries should only be charged with chargers recommended by the manufacturer. There is
a risk of fire if you use a charger that is suitable for charging a certain type of battery in a way that is not
intended.
• Only use the batteries intended for this purpose. Using other batteries may cause injury and fire.
• Keep unused battery away from paper clips, coins, keys, nails, screws or other small metal objects that
could bridge the contacts. Shorting the battery terminals together may cause burns or a fire.
• If used improperly, it is possible for the electrolyte to escape from the battery. Avoid contact with it, and in
case of accidental contact with the electrolyte, wash the affected area with water. If liquid has got into your
eyes, consult a doctor in addition. The electrolyte may cause skin irritation or burns.
IN SAFETY TIPS FOR WORKING WITH CHAINSAWSIN SAFETY TIPS FOR WORKING WITH CHAINSAWS
• Maintain a safe distance between all body parts and the chain saw while the engine is running. Before
starting the saw, make sure that the chain does not touch anything. A moment of carelessness when
operating a chain saw can result in clothing or body parts being caught in the chain.
•When working with a chain saw, always hold the rear handle with your right hand and the front handle with your left hand.
Holding the saw in a different way (vice versa) increases the risk of injury and is not acceptable.
• The power tool should only be operated by the insulated handle, since the chain may come across hidden
electric wires. As a result of chain contact with a live wire, voltage may be transferred to the metal parts of
the power tool, which could cause electric shock.
• Wear safety glasses and hearing protection. It is also recommended to use a protective helmet, hand, leg
and foot protection. Appropriate protective clothing reduces the risk of injury from airborne filings, and also
prevents accidental contact with the saw chain.
• Do not work a chain saw while sitting in a tree. Working with a chain saw in a tree can cause serious injury.

9
• Always maintain a stable position at work. The chain saw may only be used when standing on a stable, safe
and level surface. Slippery or unstable surfaces, such as when working with a ladder, can lead to loss of
balance or loss of control over a chain saw.
• Always remember that when cutting, a taut branch may spring back. If the stress in the fibers releases, the
branch can hit the saw operator and / or "pull" the saw out of control.
• Particular care should be taken when cutting undergrowth and young trees. Thin material can get caught in
the saw chain and hit the operator, or lead to a loss of balance.
• The chain saw may only be moved with the chain locked; hold it by the front handle with the guide pointing
backwards. Always wear a protective cover when transporting and storing the chain saw. Careful handling of
the chain saw reduces the risk of accidental contact with a moving chain.
• Observe the appropriate instructions when lubricating and tensioning the chain, and when changing tooling.
An improperly tensioned or poorly lubricated chain may break or increase the risk of kickback.
• The handles must always be dry, clean and free from oil or grease. Greasy, oil-contaminated handles are
slippery and lose control of the tool.
• Only wood can be cut. The chain saw must not be used for work for which it was not intended. For example:
Do not use a chain saw to cut plastics, masonry or building materials not made of wood. Using the chain in a
way that is not intended may lead to dangerous situations.
•Reasons for rejection and ways to avoid it:
- The recoil phenomenon occurs when the upper part of the bar tip contacts an object or as a result of a
saw chain jamming in the kerf due to bending of the cut wood.
- As a result of the bar tip coming into contact with an object, in some cases there may be a pushing force
exerted by the chain saw backwards, which may cause uncontrolled upward movement of the bar towards
the operator.
- Jamming of the saw chain on the edge of the guide bar may lead to a sudden kickback of the bar towards
the operator.
- Any of these reactions can cause you to lose control of the chain saw and cause serious injury. Do not
rely solely on the built-in security features of the device. The chainsaw user should take various additional
measures to keep work free from accidents and injuries. The kickback is the result of incorrect or incorrect
use of the power tool. It can be avoided by taking the following precautions:
• Hold the chain saw with both hands, the thumb and other fingers of the hand should cover the handles. The
body and arms should be in a stable position to withstand possible recoil. The operator can keep discards
under control by using appropriate measures. Never let the chain saw be turned on.

10
• Do not take an unnatural position when cutting, or cut with the saw at a height above the shoulders. This
avoids unintentional contact with the top of the bar tip and makes it easier to control the saw in unexpected
situations.
• Only use spare parts recommended by the manufacturer (guides and chains). Incorrect guides or chains can
break the chain or cause kickback.
•The saw should be sharpened and maintained according to the manufacturer's instructions. Too shallow depth
stops increase the tendency to recoil.
D ADDITIONAL SAFETY INSTRUCTIONSD ADDITIONAL SAFETY INSTRUCTIONS
• It is recommended that the person who operates the chain saw be trained before the first start by an
experienced specialist in the use of the tool, as well as the use of protective equipment on specific examples
in practice. As an introductory exercise sawing tree trunks on a goat or a special base should be carried out.
• This power tool is not suitable for use by people (including children) who are physically, emotionally or
mentally restricted, or who have insufficient experience and / or insufficient knowledge. An exception is
when they are supervised by a person responsible for their safety and receive instructions from that person
regarding the use of the power tool. Children should be supervised to rule out the possibility of them playing
with a power tool.
• The chain must not be operated by children and young people; the exception is apprentices over 16 who are
under supervision. The prohibition also applies to people who are unfamiliar or insufficiently familiar with the
operation of the chainsaw. The operating instructions should always be at hand. The saw should not be
entrusted to overworked or physically inefficient persons.
• When working with the power tool, hold it firmly in both hands and ensure a stable working position.
Two-hand power tools are safer.
• Before working with the device, make sure that all safety devices, covers and handles are properly attached.
Do not operate devices that have been partially dismantled or devices with unauthorized modifications.
• Wait until the power tool is stationary before putting it away.
• Under no circumstances may you remove the guide cover or modify it in any way! The saw has been
equipped with a guide bar to prevent kickback in situations where the tip of the saw unintentionally touches
the wood being processed.
Tips for optimal battery handling
• Before inserting the battery, make sure that the garden tool is turned off. Placing the battery with the garden
tool turned on can cause accidents.
• Only use Bosch batteries that are intended for the garden tool. Use of a different type of battery can cause
injury and fire.
• Do not open the battery. There is a danger of short circuit. The battery should be protected against high
temperatures, e.g. from constant sunlight, against fire, water and moisture. There is a risk of explosion.

11
• If the battery is damaged or used improperly, gas may be released. Ventilate the room and consult a doctor
in case of complaints. Gases may damage the respiratory tract.
• The battery should only be used in conjunction with the Powermat product for which it was intended. This is
the only way to avoid overloading, which is dangerous to the battery.
• Sharp objects, such as nails or a screwdriver, as well as external forces may damage the battery. The
internal battery may short-circuit and burn, explode or overheat.
• Do not short circuit the battery. There is a danger of explosion.
•The battery must be protected against moisture and water.
• The battery should only be stored at –20 ° C to 50 ° C. Do not leave the battery in the car, e.g. in summer.
• The ventilation openings should be regularly cleaned with a soft, clean and dry brush.
IN SAFETY PRECAUTIONS FOR CHARGERSIN SAFETY PRECAUTIONS FOR CHARGERS
Read all tips and recipes. Errors in following the instructions below may result in electric shock, fire
and / or serious injury.
Keep these instructions carefully. The charger may only be used if it is possible to fully evaluate all
its functions, carry out all operations without restriction or if the relevant instructions have previously
been obtained.
• Under no circumstances may the garden tool be used by children, persons with physical, sensory or
mental limitations, as well as persons with insufficient experience and / or insufficient knowledge, and / or
by persons who have not read these recommendations. Please note that there are no regulations in your
country that limit the age of the user of similar tools.
• Children should be under supervision. Only in this way can it be guaranteed that they will not play with the Children should be under supervision. Only in this way can it be guaranteed that they will not play with the Children should be under supervision. Only in this way can it be guaranteed that they will not play with the
tool.
• Charge only Powermat lithium-ion batteries from the Interermat series InterPulse with an appropriate
fastening system with a capacity of not less than 2Ah. The battery voltage must match the charging voltage
in the charger. Do not recharge disposable batteries. Doing so creates the risk of fire or explosion.
• Protect the charger from rain and moisture. Water entering a charger will increase the risk of electric shock.
• Only Powermat lithium-ion batteries may be charged. The battery voltage must match the battery charging
voltage in the charger. Otherwise there is a risk of fire or explosion.
• Keep the charger clean. Dirt can cause electric shock.
• Each time, check the condition of the charger, cable and plug before use. Do not use the charger if it is
damaged. Do not open the charger yourself. Repairs should only be carried out by qualified service
personnel using original spare parts. Damaged chargers, cables and plugs increase the risk of electric
shock.

12
• Do not use the charger on a flammable surface (e.g. paper, textiles, etc.) or in the vicinity of flammable
substances. There is a risk of fire due to the temperature increase of the charger during the charging
process.
• Do not block the ventilation slots on the charger. The charger may overheat and stop functioning properly.
• To increase operational safety, it is recommended to use a residual current device with a residual current of
no more than 30 mA. The earth leakage circuit breaker must be checked before each use.
TECHNICAL DATA
Model PM-APW-20C
Battery voltage DC 20V
Battery capacity 2Ah
Maximum revolutions 5m / s
No load turnover 2400 / min- 12400 / min- 1
The maximum length of the device 2,4m
Guide length 8 "
Net weight 3,37kg
Weight without battery 3kg
Sound pressure level L pA K = 3 dB (A) Sound pressure level L pA K = 3 dB (A) Sound pressure level L pA K = 3 dB (A) 77,9dB (A)
Sound power level L wA K = 3 dB (A) Sound power level L wA K = 3 dB (A) Sound power level L wA K = 3 dB (A) 87,8dB (A)
Guaranteed sound power level L wAGuaranteed sound power level L wA 91dB (A)
Protection class II

13
DESCRIPTION OF THE DEVICE
No. | Mark No. | Mark
1Cutting chain 2Shield (guide)
3Mounting screw (not shown in the picture) 4Tensioning wheel
5Blocking wheel 6Chain sprocket cover
7Telescopic connector 8Button for adjusting the angle of the cutting unit
9Telescopic rod locking sleeve 10 Telescopic tube 10 Telescopic tube
11 Telescopic collar 11 Telescopic collar 12 Clamp blocking the telescopic tube
13 Foam handle 13 Foam handle 14 Belt clip 14 Belt clip
15 Battery 15 Battery 16 Battery clip (Fig. 10) 16 Battery clip (Fig. 10)
17 Lock against accidental activation 17 Lock against accidental activation 18 On button 18 On button
19 Ergonomic handle twenty Oil filler cap (Fig. 6) twenty Oil filler cap (Fig. 6)
21 Oil level sight glass (Fig. 6) 21 Oil level sight glass (Fig. 6) 22 Shoulder strap 22 Shoulder strap
23 Guide bar cover 23 Guide bar cover 24 Charger
OPERATING THE DEVICE

14

15
M ONTAŻM ONTAŻ
Connecting parts (Fig. 1.)
•Lock the end of the hexagonal aluminum telescopic tube (10) and end of the tube below the saw head (7) until it
stops. When locking both pipes, make sure that the end (10a) of the hexagonal aluminum pipe matches the nut
(7a) at the end of the pipe.
• Fasten both parts with the shaft connector (9).
Mounting the chain bar and chain (Fig. 2-4)
Turn off the device and remove the battery before performing any service.
•Unscrew the locking wheel (5) and remove the sprocket cover (6) (Fig. 2).
• Fold the chain of the chain (1) in a loop so that the angular cutting edges of the chain links are clockwise.
•Place the chain of the chain (1) in the groove of the blade.
• Make sure the tension wheel (4) is in the position shown in the drawing or turn it counterclockwise so that
the drive wheel cover (6) is aligned with the mark on the tension wheel (4). (Fig. 3).
• Refit the cover (6), mount the back of the cover, then the front, make sure the pin is in position. Tighten the
locking wheel slightly (5). Do not tighten the locating wheel (5) completely, tension the chain saw first. (Fig.
4).
Chain tensioning (Fig. 5.)
Turn off the device before performing any service, remove the battery.

16
The chain tension of the chain (1) is important for both the safety of the user and the function of the battery saw. A
correctly tensioned chainsaw will extend the life of the device. The chain tension must be checked before each use of
the battery saw. Always check the chain tension before starting work, after the first cuts, and regularly during
operation, approximately every five cuts. When first started, the new chains can be significantly extended. This is
normal during burglary, and the time between successive adjustments increases quickly.
• Place the product on a suitable flat surface with the chain rack cover (6) facing up.
•Check the chain tension with one hand to lift the chain saw (1) against the weight of the product. The
correct chain tension is obtained when the chain can be raised approx. 2-4 mm from the guide bar (2) in
the middle.
NOTE: The chain tension on new chainsaws should be adjusted after a short period of operation.
Chain lubrication
Always turn off the machine and allow the engine to cool before filling with chain oil. There is a risk of fire if the chain
oil is overfilled.
NOTE: The bar and chain must always be oiled. Failure to comply with this requirement will result in
increased wear on the blade and chain.
A full tank is enough for about 15 minutes of continuous operation. Check the oil level in a timely manner. The
cordless saw is equipped with an automatic oil system. As soon as the engine drives the chain, the oil flows faster to
the guide rail (2). Check the oil level in the oil tank before starting work.
Filling the oil tank (Fig. 6.)
Check the oil level using the oil sight glass (21) and top it up regularly with chain oil.
Attaching / setting the shoulder strap (Fig. 7.)
1. Attach the snap hook (28a) of the shoulder belt (22) to the shoulder belt buckle 1. Attach the snap hook (28a) of the shoulder belt (22) to the shoulder belt buckle
(14).
2. Quick release can cause the buckle (28b) to be pressed onto the shoulder strap (22). 2. Quick release can cause the buckle (28b) to be pressed onto the shoulder strap (22).
ABOUT AdvanABOUT Advan
When working with the device, wear appropriate clothing, work gloves, protective headgear and
hearing protection as well as strong work shoes. Before each use, make sure that the device is in working
order. The power switch and safety switch must not be locked. The engine must be turned off after the
switch is leased again. Do not use the device if the switch is damaged. Adaptation of the telescopic tube
(Fig. 8.)
The telescopic tube (10) can be infinitely adjusted using the telescopic flange (11).
1. Open the clamping lever (12). 1. Open the clamping lever (12).
2. Hold the device, adjust the length of the rod by pressing or pulling on the handle. 2. Hold the device, adjust the length of the rod by pressing or pulling on the handle.
3. Close the clamping lever. 3. Close the clamping lever.
Adaptation of the cutting unit head (Fig. 9)
The saw head can be tilted in 4 positions to cut crooked branches.

17
Press the angle adjustment button (8) and simultaneously tilt the saw head (7). When the button is released, it is locked in the
desired position.
Engine on / off
Make sure you are standing in a stable position with both hands holding the saw away from your body. Before switching the saw on,
make sure that it does not come into contact with other objects.
1. Pull the trigger (18) and press the safety lock button (17). 1. Pull the trigger (18) and press the safety lock button (17).
2. The device will turn off 2. The device will turn off come again after releasing the trigger button
on / off (18).
CUTTING TECHNIQUES
C EARLY SMALL BRANCHESC EARLY SMALL BRANCHES
Set the cut of smaller branches (0-8 cm) from top to bottom as shown in the picture. Pay attention to the possible
branch breaking if you have not rated its size and weight. Be fully aware of falling cut material.
ABOUT BRINGING THE BRANCH ( R YS. 11.) ABOUT BRINGING THE BRANCH ( R YS. 11.) ABOUT BRINGING THE BRANCH ( R YS. 11.) ABOUT BRINGING THE BRANCH ( R YS. 11.) ABOUT BRINGING THE BRANCH ( R YS. 11.)
For large / long branches, it is recommended to saw the parts. This is the only way to securely secure the point of
impact of the material being cut. Stay away from the place where cut branches fell.
C EATING LARGE BRANCHES ( R YS. 12.) C EATING LARGE BRANCHES ( R YS. 12.) C EATING LARGE BRANCHES ( R YS. 12.) C EATING LARGE BRANCHES ( R YS. 12.) C EATING LARGE BRANCHES ( R YS. 12.)
For controlled cutting of larger branches (08-2Ocm), first a relief cut should be made (see cut a). They are made from
below. Cut the incision in the lower third of the branch. Longitudinal cutting (see cut b) is performed again from above,
if possible according to the first cut so that both cuts coincide.
CHARGING AND CHANGING THE BATTERY
IN INDICATORS - CHARGER LEDSIN INDICATORS - CHARGER LEDS
• Connect the charger to a wall socket.
• Solid green: ready to charge
• Solid red: charging
• Solid green: charged
• Solid green and red: faulty battery or charger.
Note: If the battery does not match correctly, disconnect it and confirm that the battery is the correct model for this
charger, as shown in the specifications. Do not charge any other battery or battery that does not match the charger.
1. Frequently monitor the charger and battery while they are connected. 1. Frequently monitor the charger and battery while they are connected.
2. Disconnect the charger and disconnect it from the battery after use. 2. Disconnect the charger and disconnect it from the battery after use.
3. Let the battery cool completely before use.
4. Store the charger and battery in closed rooms out of the reach of children.
NOTE: If the battery is hot after continuous use in a tool, allow it to cool to room temperature before charging. This will
extend the battery life.

18
P DISCONNECTING / DISCONNECTING THE BATTERYP DISCONNECTING / DISCONNECTING THE BATTERY
WARNING: Before making any adjustments, make sure that the tool is turned off.
•Hold the tool with one hand and the battery with the other (15).
• To install: push and slide the battery into the battery port, make sure the release latch on the back of the battery snaps into place
and the battery is secure before you start working.
•To remove the battery: Press the battery release latch and at the same time pull the battery out.
IN BATTERY CHARGE INDICATORIN BATTERY CHARGE INDICATOR
There are battery capacity indicators on the battery (15d), you can check the battery charge status by pressing the button (15a). Before using
the device, press the trigger to check if the battery is sufficiently charged for proper operation.
These 3 LEDs indicate the battery charge status:
• 3 LEDs are on: The battery is fully charged
• 2 LEDs light up: Battery 60% charged
• 1 LED on: Battery almost empty
TRANSPORT
The lithium-ion batteries included in the delivery are subject to hazardous goods regulations. Batteries can be
transported overland by the user without any further conditions.
In the case of shipments by third parties (e.g. transport by air or through a forwarding company) please comply with
the specific packaging requirements and the importance of the goods. In this case, consult a Dangerous Goods
expert when preparing the goods for shipment.
Batteries can only be shipped if the case is undamaged. The exposed contacts should be sealed and the battery
packaged in such a way that it cannot move (slide) in the packaging.
It is also necessary to take into account any national provisions.
MAINTENANCE AND CLEANING
Pull the battery out of the chain saw before carrying out any work on the device.
All work not described in this manual should be carried out by an authorized customer service center. Use only original
parts.
The following steps maintenance should be carried out regularly, to
guarantee long and efficient operation of the device. Keeping the device and ventilation slots clean
guarantees correct and safe operation. Regularly inspect the chain saw for obvious defects such as a
loose or damaged chain, loose connections, and worn or damaged components. Check that the device
covers and safety devices are fully functional and properly installed. In front of

19
all necessary maintenance and repairs should be carried out before starting work with the device.
Note: The oil tank must be emptied before shipping the chain.
IN CHANGING / ROTATING THE CHAIN SAW AND GUIDE CHAININ CHANGING / ROTATING THE CHAIN SAW AND GUIDE CHAIN
Check the saw chain and guide bar as per the instructions in the chapter "Chain tensioning". Replace the worn guide.
Check the sprocket. If it proves to be worn or damaged due to heavy loads, it should be replaced at a service center.
ABOUT CHAIN SHAVINGABOUT CHAIN SHAVING
Do not sharpen the chain yourself unless you have extensive experience in this area. Replace the chain with a
replacement chain or have the chain sharpened professionally at an authorized power tool service center.
K ONE CONTROL OF THE CHAIN LUBRICATIONK ONE CONTROL OF THE CHAIN LUBRICATION
Checking the automatic chain lubrication can be done by switching on the chain saw and pointing the tip towards a
piece of cardboard or paper placed on the floor. Do not touch the floor with a chain. Observe a safety distance of 20
cm. If you notice oil leakage during the test, it means that the automatic lubrication system is working fine. If - despite
the full tank - no traces of oil appear on the paper, contact a Powermat service center.
P RZECHOWYWANIEP RZECHOWYWANIE
The oil must be removed from the tank before storage.
The plastic chain saw housing should be cleaned with a soft brush and a clean cloth. Do not use water, solvents or
polishing agents. Remove all dirt, especially from the engine's ventilation holes.
After a working time of approx. 1-3 hours, remove the guard, guide bar and chain, and then clean them with a brush.
Clean the dirt around the guard, chain wheel and guide bar with a brush. The oil nozzle should be cleaned with a
clean cloth. Make sure that chips and debris are thoroughly removed and there is no danger of clogging oil lines and
the lubrication system.
If the chain saw is to be stored for an extended period of time, clean the chain and guide bar.
Keep the chain saw in a safe, dry place out of the reach of children. Do not place any objects on the power tool.
Please pay attention when parking the saw - it should be in a horizontal position and the oil tank closure must be
facing up.
The chain saw can be stored in the packaging in which it was supplied, but the oil tank must be completely emptied
first.

twenty
Do not make any changes to the power tool. Unacceptable modifications may reduce the safety of the power tool, as
well as increase noise and vibration. Transport
The lithium-ion batteries included in the delivery are subject to hazardous goods regulations. Batteries can be
transported overland by the user without any further conditions. In the case of shipments by third parties (e.g.
transport by air or through a forwarding company) please comply with the specific packaging requirements and the
importance of the goods. In this case, consult a Dangerous Goods expert when preparing the goods for shipment.
Batteries can only be shipped if the case is undamaged. The exposed contacts should be sealed and the battery
packaged in such a way that it cannot move (slide) in the packaging. It is also necessary to take into account any
national provisions.
SERVICE
Electrical tools should be repaired only by qualified personnel using original spare parts. This ensures safe use of the
device. Address:
Powermat service
ul. Obrońców Poczty Gdańskiej 97 42-400
Zawiercie
Tel. [phone], internal 4 e-mail:
[email protected]
WARRANTY
During the warranty period, the buyer is entitled to free repairs resulting from manufacturing defects. The warranty is recognized only if the
product is delivered to the point of sale in complete condition, unassembled, together with the proof of purchase and properly completed
warranty card.
IN EXCLUSIONS OF THE MANUFACTURER'S WARRANTYIN EXCLUSIONS OF THE MANUFACTURER'S WARRANTY
They occur when the device shows damage resulting from natural wear or resulting from improper handling of the equipment (e.g. overloading,
exerting excessive pressure - in particular cracks or fractures of plastic parts and other mechanical damages and defects resulting from such
damage). As well as in the cases below:
•Attempts at arbitrary repairs are found.
•During the warranty period, the device has been subjected to modifications or repairs by unauthorized persons.
• The tool was used in industry or crafts (the tool was made for DIY and is not intended for work).
The warranty does not cover such elements of the tool that may be damaged as a result of natural wear or overload (e.g. chains, discs, handles
and clamps, covers, housing elements and all masking elements.)
