Powermate PWFT15022 User manual

Look Inside for:
Page
Safety Definitions 1
Important Safety Information 2-4
Safety Decals 5
Specifications 6
Features 6
Assembly 7-8
Engine Preparation 9-10
Operation 11-12
Slope Guide 13
Maintenance 14-19
Technical Service 19
Troubleshooting 20
Warranty 21
08/03/2018 Printed in China A203971
Operator’s Manual
FIELD TRIMMER
150 cc, 4 Cycle
IMPORTANT:
Thank you for purchasing this Powermate® Field Trimmer.
This manual provides complete instructions for safely operating and maintaining your Trimmer. Read and save these
instructions. Refer to this manual each time before using your Trimmer.
Record the following for future reference:
Mfg. Date Code: _________________________________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
Refer to the website for electronic manual and parts book.
www.powermateoutdoor.com
KEEP THIS MANUAL FOR FUTURE REFERENCE
MODEL Nos. PWFT15022
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
CONTAINS LEAD. May be harmful if eaten or chewed. May generate dust containing lead. Wash hands after use. Keep out
of reach of children.
This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
WARNING
WARNING

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 1
Oil Fill Location
Do Not Overfill
Gasoline Fill Location
Start Unit Stop Unit
Engine Stop
PUSH TO PRIME
Push primer 3 times before starting a
cold engine. Important: Do not prime to
restart a warm engine.
This symbol indicates a potential personal injury
hazard. It means:
Attention! Be alert! Your
safety is involved!
Wear eye protection complying with ANSI
Z87.1.
Read operator’s manual before operating this
machine. Failure to follow directions could
result in serious injury.
Disconnect spark plug wire when not in use
or before servicing, cleaning, or performing
maintenance on the unit.
Thrown objects. Remove all rocks, stones,
and foreign objects which could be thrown by
machine.
Engine exhaust contains carbon monoxide,
an odorless and deadly gas. NEVER run unit
indoors or in a poorly ventilated area.
Keep bystanders at a safe distance (15m /50
ft). NEVER use if children are present.
Do NOT touch hot muffler or cylinder. These
parts are extremely hot from operation and
may remain hot for a short time
after operation.
Do NOT trim up and down slopes. Trim
across slopes.
To reduce risk of fire, clean spilled gas and
oil and keep unit free from debris. Gasoline is
extremely flammable. Allow machine to cool a
minimum of 2 minutes before refueling.
Rotating parts can cause serious injury. Keep
hands and feet away.
Safety Definitions
• Save these instructions
Safety Warning Symbols
Control and Operating Symbols
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor/moderate injury.
Indicates a situation which may result in equipment / property damage or may relate to
general safety messages.
The following symbols are used on the product and in this manual to alert the operator of potential safety hazards. Read
them carefully, and understand their meaning.
Safety Alert Symbols
The following symbols may relate to safety and may be found on your trimmer. Carefully read and understand their meaning.
Important Safety Information
NOTICE
15m/50ft

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 2
Important Safety Information
Important Safety Information
• Save all instructions
RESPONSIBILITY OF THE OWNER
1. Carefully read and follow these safety instructions. Failure to do so can result in serious injury.
2. Know your product. Read and understand this manual before use. Compare the illustrations to unit. Learn location
and function of all controls. Thoroughly understanding the unit before use will result in the best performance and safety.
3. Follow all instructions when assembling the unit. If the unit was purchased in assembled condition, the operator
must check the unit carefully to make sure it was assembled according to the instructions in the manual before use.
4. Regularly inspect the trimmer. Make sure parts are not bent, damaged, or loose.
5 Use this equipment for its intended purpose only.
6. Operate the unit only with guards, shields, and other safety items in place and working correctly.
7. Service the unit only with authorized or approved replacement parts.
8. Complete all unit maintenance and adjustments according to the instructions in this manual.
To prevent accidental starting when setting up, transporting, adjusting or making repairs, always disconnect spark plug
wire and put wire where it cannot contact the spark plug.
PREPARATION SAFETY
• Read, understand, and follow all instructions on this machine and in this manual. Be thoroughly familiar with the
controls and the proper use of the trimmer before starting. Know how to stop the engine quickly.
• Familiarize yourself with all the safety and operating decals on this equipment.
• Thoroughly inspect the area where the trimmer is to be used and remove all foreign objects. Your equipment can
propel small objects at high speed causing personal injury or property damage. Stay away from breakable objects,
such as house windows, auto glass, greenhouses, etc.
• Verify that the control lever is working properly. Make sure that the cable is free and that the control lever is not damaged.
• Check that all nuts and bolts are tight and equipment is in good condition. Check mounting hardware on trimmer head
every time you change trimmer line and prior to each use.
OPERATION SAFETY
• Never allow children or young teenagers to operate the trimmer.
WARNING
• Keep area of operation clear of all bystanders, particularly small children and pets.
• Only allow responsible individuals, who are familiar with the instructions, to operate the trimmer.
• Do not operate the trimmer while under the influence of alcohol, drugs, or other medication which can cause
drowsiness or affect your ability to operate this machine safely.
• Do not use this machine if you are mentally or physically unable to operate the machine safely.
• Always wear ANSI compliant safety goggles or safety glasses with side shields when operating trimmer to protect your
eyes from foreign objects, which can be thrown from the unit.
• Wear appropriate clothing such as a long sleeved shirt or jacket. Also wear long trousers or slacks. Do NOT wear
shorts. Do NOT wear loose clothing, which could get caught in this equipment.
• Always wear work gloves and sturdy footwear such as leather work shoes or short boots. These will protect ankles
and shins from small sticks, splinters, and other flying debris, and improve traction.
• It is advisable to wear protective headgear to protect against being struck by small flying particles, or being struck by
low hanging branches, twigs, or other objects, which may be unnoticed to the operator.
WARNING
WARNING

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 3
Important Safety Information (Continued)
• Save all instructions
WARNING
• Do not put hands or feet near or under rotating parts.
• When crossing gravel drives, walks, or roads, stop the unit and wait for the trimmer lines to stop. Exercise extreme
caution. Stay alert for hidden hazards or traffic.
• Exercise caution to avoid slipping or falling. Never operate trimmer in wet grass. Always be sure of your footing;
keep a firm hold on the handle and walk; never run.
• Look behind and use care when backing.
• Never operate the trimmer without good visibility or light.
DANGER
• Do not run the engine indoors or inside a closed area. The exhaust fumes are dangerous, containing CARBON
MONOXIDE, an ODORLESS AND DEADLY GAS.
• If the trimmer should start to vibrate abnormally, stop the engine, disconnect the spark plug wire and prevent it from
touching the spark plug. Check immediately for the cause. Vibration is generally a warning of trouble.
• Watch for holes, ruts, bumps, or other rough ground. Tall grass can hide obstacles.
WARNING
• Frequently clean debris and grass build up from the recoil starter cover holes, under the deck in the trimming
head area, and around the muffler. Using the unit with excessive debris can risk fire. Always use extreme caution when
using the trimmer during dry conditions.
• Do not trim excessively steep slopes (maximum 15 degrees). See the “Slope Guide” in the back of this manual to
check a slope.
• Always trim across the face of slope; never up and down. Exercise extreme caution when changing direction
on slopes. If you are uneasy on a slope, do NOT trim it.
• Do NOT trim near drop-offs, ditches, or embankments. The operator could lose footing or balance.
FUEL SAFETY
WARNING
• Gasoline is extremely flammable, and gasoline vapors can explode if ignited. Handle with Care.
• Use an approved container.
• Check fuel supply before each use, allowing space for expansion as the heat of the engine and/or sun can
cause fuel to expand.
• Fill fuel tank outdoors with extreme care. Never fill fuel tank indoors.
• Never remove gas cap or add fuel with the engine running. Allow engine to cool before refueling.
• Do not smoke while refueling.
• After refueling, replace fuel tank cap securely and wipe up spilled fuel.
• Never store fuel or trimmer with fuel in the tank inside a building where fumes may reach an open flame.
Important Safety Information

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 4
Important Safety Information (Continued)
• Save all instructions
STORAGE SAFETY
• Always refer to the owner’s manual instructions for important details if the trimmer is to be stored for an
extended period.
• Never store the trimmer with fuel in the fuel tank inside a building where ignition sources are present such as
water heaters, space heaters, clothes dryers, etc.
• To reduce fire hazard, keep trimmer free of grass, leaves, or other debris build-up.
• Allow the engine to cool before storing in any enclosure.
REPAIR, MAINTENANCE, AND ADJUSTMENT SAFETY
• After striking a foreign object, stop the engine. Remove the wire from the spark plug and keep the wire away
from the plug to prevent accidental starting. Thoroughly inspect the trimmer for any damage. If damaged, have
the equipment repaired by a trained technician before restarting and operating.
WARNING
• Stop the engine before cleaning, repairing, or inspecting the unit. Make sure all moving parts have stopped. Let
the engine cool, disconnect the spark plug wire and move it away from the spark plug.
• Never attempt to make any adjustments while the engine is running except when specifically recommended by the
manufacturer.
• Keep the trimmer in safe working condition. Check all fasteners at frequent intervals for proper tightness.
• When servicing or repairing the trimmer, do not tip the machine over or up unless specifically instructed to do
so in this Manual. Service and repair procedures can be done with the trimmer in an upright position. Some
procedures will be easier if the machine is lifted on a raised platform or working surface.
• Use only original equipment or authorized replacement parts.
• Never tamper with safety devices. Check their proper operation regularly.
• Do not change the engine governor setting or over-speed engine.
• Clean and replace safety and instruction decals as necessary.
• To guard against engine over-heating, always have engine debris filter mounted and clean.
CHILDREN SAFETY
WARNING
• Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to
the trimmer and the trimming activity.
• Keep children out of the trimming area and under the watchful care of a responsible adult.
• Never assume that children will remain where you last saw them.
• Be alert and turn trimmer off if children enter the area.
• Before and while moving backwards, look behind and down for small children.
• Never allow children to operate the trimmer.
• Use extra care when operating blind corners, shrubs, trees, or other objects that may obscure vision.
Important Safety Information

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 5
Safety Decals
• Save all instructions
This field trimmer has been designed and manufactured to
provide you with the safety and reliability you would expect
from an industry leader in outdoor power equipment
manufacturing.
Although reading this manual and the safety instructions it
contains will provide you with the necessary basic knowledge
to operated this equipment safely and effectively, we have
placed several safety labels on the field trimmer to remind you
of this important information while you are operating the unit.
These important safety labels are illustrated below, and are
shown here to help familiarize you with the location and content
to the safety messages you will see as you perform normal
trimming operations. Please review these labels now. If you
have any questions regarding their meaning or how to comply
with these instructions, reread the complete safety instruction
text on the preceding pages, or contact your local dealer.
Should any of the safety labels become unreadable because
of being worn, faded, or otherwise damaged during the use of
your field trimmer, please contact your local authorized dealer
to order replacement label.
The safety labels are easily applied, and will act as a constant
visual reminder to you and others who may use the equipment.
Following the safety instructions is necessary for safe, effective
operation of your field trimmer.
See “Safety Definitions” section of this manual for
explanations of the safety symbols.

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 6
Specifications
• Save all instructions
1. Control Lever - Release to stop the engine.
2. Recoil Starter Handle - The engine is equipped with an
easy pull recoil starter.
3. Recoil Starter Cover - Covers recoil starter mechanism.
Holes allow air intake to cooling system.
4. Spark Plug/Spark Plug Wire - Provides spark to ignite
air/fuel mixture. The spark plug wire must be moved
away from the spark plug when servicing the unit.
5. Muffler -Location of engine exhaust.
6. Trimmer Guard -Protects the operator from thrown
debris. Blade mounted on guard will automatically cut
trimmer line to correct length if line is too long.
7. Trimmer Line - Rotating cutting element of trimmer.
8. Trimmer Head - Rotates the trimmer lines.
9. Primer Button - Injects fuel directly into the carburetor
for faster starts.
10. Air Filter - Removes debris and contaminates from
intake air, allowing engine to run smoothly with low
exhaust.
Features
UNIT
Unit Weight..........................66 lb. (29.9 kg)
Cutting Swath....................... 22 in. (599 mm)
Cutting Line Diameter. . . . . . . . . . . . . . . . . 0.155 in. (4 mm)
Wheel Diameter ..................... 12 in. (305 mm)
Cutting Height........................1.5 in. (38 mm)
Gasoline Type .....Regular Unleaded – 87 Octane (min.)
Gasoline Capacity . . . . . . . . . . . . . . . . . . . . . . . 1.0 qt. (1 L)
Oil Type (API SG-SL) . . . . . .10W-30 is recommended for all
service temperatures. See page 8 for additional information.
Oil Capacity ......................15-1/2 oz. (450 ml)
Spark Plug Model...................... Torch K7RTC
Spark Plug Gap ................0.024 - 0.031 in. (0.6 -
0.8mm)
ENGINE
Type ................................4 Stroke, OHV
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 cc
Torque Rating .....5.75 ft/lbs gross torque per SAE J1940
Bore Diam. x Stroke.......2.56 x 1.78 in. (65 x 45.2 mm)
Intake Valve Clearance . . . . 0.006-0.008 in. (0.15-0.20 mm)
Exhaust Valve Clearance . . . 0.006-0.008 in. (0.15-0.20 mm)
Full Throttle RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3000
Figure 1
3
4
5
6
7
8
9
10
1
2

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 7
Read and follow the assembly instructions. Do not discard
any parts or materials until the unit is assembled.
References to the right or left side of the trimmer are from
the viewpoint of the operator’s position behind the trimmer.
Do not operate trimmer if it is damaged or not completely
and correctly assembled.
Before doing any assembly or maintenance to the unit,
remove the wire from the spark plug. The following compo-
nents will be found in the carton. Quantities shown in ( ).
Assembly
• Save all instructions
If you need assistance or find any parts missing, CALL
TOLL FREE: 1-800-737-2112.
Wing Nut
Rope Guide
Handle
Recoil Start
Handle
Figure 2
Figure 3
Wheel
Hub Cap
Flange
Nut
Handle
Bolt
Steel
Spacer
Z-hook
Control Lever
Clip retainer
Control cable
Assemble the Handle
NOTE: Refer to Figure 2 when following the steps below
1. Attach upper handle assembly to lower handle by aligning
bolt holes and inserting provided handle bolts through
each side and assembling plastic wing nut.
Assemble the Control Cable to the Control Lever
NOTE: Refer to Figure 3 when following the steps below
After the handle has been assembled, install the control
cable as follows:
1. Insert z-hook into hole in the control lever
(insert from inside to outside).
2. Clip retainer into hole in handle.
3. Secure control cable to handle with cable ties as desired.
4. To attach the recoil starter handle to the rope guide,
engage control lever, pull rope, twist the rope through the
rope guide mounted on the right side of the handle.
Included Parts in the Carton QTY
1 Operator Manual 1
2 Engine Manual 1
3
Start Guide 1
4 Wing Nuts 2
5 Handle Bolts 2
6 Flange Nut 1
7 Hub Cap 2
8 Two Wheels 1
9 Upper Handle 1
10
Trimmer assembly 1
11 Set of 0.155in. (4mm) Trimmer Line 2
12 Cable Ties 2
13 Container of Engine Oil 1
WARNING

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 8
Assemble the Wheel
NOTE: Refer to Figure 2 when following the steps below
1. Place the unit on a level surface.
2. Steel spacer and locknuts are already assembled to each
end of axle.
3. Remove nut, install wheel, reinstall nut and tighten
securely. Repeat on opposite side.
4. Install hub cap by pressing rmly in the center until the cap
snaps into place.
Assembly (Continued)
• Save all instructions
If you need assistance or find any parts missing, CALL
TOLL FREE: 1-800-737-2112.
Figure 4
Flange
Nut
Assemble the Flexible Shield
NOTE: Refer to Figure 4 when following the steps below
1. Align rear hole of exible shield with threaded stud at the
base of the deector shroud.
2. Assemble with ange nut.
WARNING
Do not operate trimmer unless all shields are fully installed.
Assemble Fuel Cap
1. Remove label from top of fuel tank ller neck.
2. Install cap by screwing onto tank.

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 9
NOTICE
Engine shipped without oil. Failure to add oil will result in
serious engine damage.
A bottle of engine oil is included with your Trimmer. Refer to
Figure 5for alternative oil types to use at different tempera-
tures. Always use a high quality detergent oil classified “For
Service, SG, SH, SJ” or higher. Do not use special additives.
Always use recommended oil type. Using dirty oil or incorrect
oil type such as 2-stroke engine oil will shorten engine life.
HOW TO CHECK OIL LEVEL AND FILL TO PROPER LEVEL
WARNING
Before checking oil, make sure engine is off, and spark
plug wire has been disconnected from spark plug.
1. Place trimmer on a level surface.
2. Remove Dipstick and wipe clean with cloth. Refer to
Figure 6 for location of Dipstick.
3. Replace Dipstick and do NOT screw it. Remove and
check oil level.
4. When oil level is full, the oil will be at upper limit on dip
stick. If oil level is near or below the lower limit, oil must
be added. (See Figure 6)
5. Add oil slowly until the oil level reaches the upper limit of
the dipstick. Use a funnel or nozzle to reduce spillage.
Frequently check oil level while filling.
DO NOT OVERFILL. DO NOT UNDERFILL. Running
engine at improper oil level will seriously damage engine.
6. Replace and tighten dipstick.
7. Clean up any spilled oil.
Engine Preparation
• Save all instructions
Engine Oil
A
Figure 6
Upper Limit
Lower Limit
Figure 5
SAE
TEMP 100° F
40° C
-20
-20-30 -10
0
0
20
2010
40 60 80
30
Ambient Service Temperature
SAE 10W-30
SAE 30
NOTICE

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 10
WARNING
• Gasoline is extremely ammable and vapors can
explode if ignited. Handle with care.
Use fresh, clean, regular-unleaded gasoline with a
minimum of 87 Octane. Do NOT use leaded gasoline,
gasohol, methanol, or diesel fuel. Do NOT mix oil with
gasoline. Do NOT allow gasoline to become contaminated
with dust, water, or debris.
Using incorrect fuel type or contaminated fuel will cause
serious engine damage.
NOTE: Fuel tank capacity is approximately 1.06 qt. US (1.0 L).
HOW TO FILL ENGINE WITH FUEL
WARNING
• Turn engine off and let engine cool for several minutes
before removing the fuel cap or adding fuel.
• Never fill fuel tank indoors.
• Do not smoke while adding fuel.
1. Clean surface around fuel tank cap to prevent
contaminations. Refer to Figure 7 for location of fuel cap.
2. Loosen fuel cap slowly to remove.
3. Pour fuel into the tank. Use care to avoid spillage.
WARNING
Do NOT OVERFILL fuel. Allow space for the fuel to expand
due to heat from engine and/or sun.
4. Before replacing the fuel cap, inspect and clean the fuel
cap seal.
5. Replace the fuel cap and securely hand-tighten.
6. Clean up any spilled fuel.
Fuel
B
Engine Preparation (Continued)
• Save all instructions
Fuel Tank Cap Figure 7
Oil Fill Cap/Dipstick
NOTICE

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 11
WARNING
Debris thrown from Trimmer can cause severe eye
damage. Always wear ANSI compliant safety glasses
or eye shields when operating trimmer. If you wear
eyeglasses, put an OSHA certified Wide Vision Safety
Mask over your eyeglasses.
Before starting Trimmer, clean debris from holes in the
recoil starter cover.
1. Review ALL steps in the “BEFORE STARTING THE
ENGINE” section.
2. Push the Primer Bulb 3 times, waiting 2 seconds
between each push. (See Figure 8)
NOTE: Not required when re-starting a warm engine.
WARNING
Before starting engine, read operator’s manual. Become
familiar with location and function of all controls. Know how
to stop the engine quickly.
Before attempting to start the engine, review the
following steps:
1. Unit has been assembled according to all
assembly instructions.
2. Unit has been inspected for any damaged or
missing components.
3. No parts are remaining in the carton.
4. Engine oil is at proper level.
5. Fresh, clean, regular-unleaded gasoline has been
added to fuel tank.
6. Spark plug wire is connected to spark plug.
7. Trimmer has been moved to desired location.
8. Trimmer is on level surface.
Operation
• Save all instructions
Before Starting the Engine
A
How to Start the Engine
B
WARNING
Keep all bystanders, especially CHILDREN, away
during operation.
IMPORTANT: This unit’s engine exhaust system is equipped
with a spark-arresting muffler. Tampering with or removing
the spark-arrestor violates section 4442 of the California
Public Resources Code as well as other applicable state
and federal law.
DANGER
Never run engine indoors or in a poorly ventilated area.
Engine exhaust contains Carbon Monoxide, an ODORLESS
and DEADLY gas.
Figure 8
Primer
Button
NOTICE

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 12
3. Firmly grip the Trimmer handle with your left hand,
engaging engine control lever. (See Figure 9)
4. Firmly grip the Recoil Starter Handle with your right hand.
(See Figure 9)
5. Pull the recoil starter slowly, until you feel tension in the
starter rope. Then quickly pull the recoil starter handle to
start engine. DO NOT allow the starter rope to snap back.
Let the starter rope slowly rewind as you hold the recoil
starter handle.
6. If engine fails to start after three pulls, push the primer
button two times and again pull the recoil starter handle.
7. If engine fails to start after 5 or 6 more tries, see the
instructions in the “Troubleshooting Chart”.
WARNING
Keep hands, feet, hair, and loose clothing away from any
moving parts. Avoid touching muffler and surrounding
areas. Temperatures can exceed 150° F. Keep all safety
devices and shields in place.
Operation (Continued)
• Save all instructions
Figure 9
Recoil Starter
Handle
How to Start the Engine
B
How to Stop the Engine
C
1. Release the control lever.
CAUTION
Trimmer line will continue to rotate for several seconds after releasing the control lever. Use Caution.
WARNING
Debris such as sticks, gravel, and rocks can be thrown with
sufcient force to cause personal injury or property damage.
• Frequently clean debris and grass build up from the
recoil starter cover holes, under the deck in the trimming
head area, and around the mufer. Using the unit with
excessive debris can risk re. Always use extreme
caution when using the trimmer during dry conditions.
• If the trimmer lines become too short, it will take longer
to complete this job. If the trimmer lines are worn to less
than half their original length, change to a new trimmer
line. See “How to Replace the Trimmer Line” in the
Maintenance section.
• Do not trim on excessively steep slopes. See Slope
Guide. If a slope is difcult to stand on, do not trim it. Do
not trim on slopes when the ground is slippery or wet.
Trim across the face of a slope, not up and down.
• Trimmer head contact to concrete, asphalt and harder
surfaces may create premature wear.
• For best results and longer lasting line, soak the trimmer
line in a pail of water for 24 hours prior to use. A moist
line will be more exible than a dry, brittle line.
• Let the ends of the trimming line do the cutting. This is
easily done by moving slowly through very thick or heavy
weeds.
Trimming Tips
D

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 13
SLOPE GUIDE SIGHT AND HOLD THIS GUIDE LEVEL WITH A VERTICAL TREE, A CORNER OF A STRUCTURE, A POWER LINE POLE, OR A FENCE. Operate a trimmer across the face of slopes, never up or down slopes. Use this guide and do not trim on a slope greater than 15 degrees. A 10-degree slope is a hill that increases in height at approximately 1.7 feet in 10 feet. A 15-degree slope is a hill that increases in height at approximately 2.5 feet in 10 feet.
WARNING! Use extreme care at all times and avoid sudden turns or maneuvers. Follow other instructions in this manual for safety in trimming on slopes. Operate a trimmer across the face of slopes, never up or down slopes. Use extra care when operating on or near slopes and obstructions.
19
F-050204L
15 Degrees
10 Degrees
Operate a trimmer across the face of slopes, never up or down slopes.
FOLD ALONG DOTTED LINE
15 DEGREES

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 14
PERIODIC MAINTENANCE SCHEDULE TABLE
CAUTION
IMPORTANT NOTES about Maintenance schedule
1. Change Trimmer Lines when they are half original length.
2. Frequently clean grass from:
a. Holes in recoil starter cover
b. Under deck in the trimmer head area
c. Around mufer
3. Re-check fastener tightness after the rst 2 hours of
initial use.
4. Clean air lter every 10 hours. Clean more often if
operating under dusty conditions.
5. Change engine oil after rst 5-8 hours of initial use
6. Change oil every 25 hours if operating under heavy load
or in high temperatures
Maintenance
• Save all instructions
WARNING
Before performing any maintenance, turn engine off and remove the wire from the spark plug to prevent accidental
starting and serious injury.
IMPORTANT: The warranty on this Trimmer does not cover items that have been subjected to operator abuse or negligence.
To receive full value from the warranty, the operator must maintain the trimmer as instructed in this manual, and only use
genuine replacement parts. The following table lists required periodic maintenance.
Service Records-
Fill in dates as you complete regular
service
Before
Each Use
After
Every
10 Hours
of Use
After Every
25 Hours
of
Use
After Every
50 Hours of
Use
After Every
100 Hour
of Use
Before
Each
Season
Before
Storage
See
Note
Below
Check Engine Oil Level,
Fill to Proper Level √ √
Check Trimmer Lines and
Replace if Necessary √ √
1
Clean Debris From Unit √ √ √
2
Check Fasteners for Tightness √ √
3
Check Fuel Line
Replace if Necessary √ √
Lubricate Moving Parts √ √ √
Check Spark Plug
Replace if Necessary √ √
Check Drive Belt
Replace if Necessary √ √
Clean Air Filter, Replace if very Dirty √ √
4
Change Engine Oil √ √ √
5, 6
Replace Spark Plug √
Clean Combustion Deposits from
cylinder, piston, and valves √
WARNING
Use only GENUINE replacement parts. Other parts may
damage the unit or result in injury.

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 15
Maintenance (Continued)
• Save all instructions
How to Change the Oil
NOTE: Refer to Figure 7 when following the steps below:
1. Stop the engine and allow it to cool.
2. Disconnect spark plug wire from the spark plug.
3. Remove oil dipstick. (See Figure 7)
4. Tilt engine and allow all of oil to drain into a collection pan.
IMPORTANT: Used oil is a hazardous waste. Place oil in a sealed container and take to your local recycling center. Do NOT
discard with household waste.
5. To re-fill engine with oil, see engine preparation section “How to Check Oil and Fill to Proper Level”.
How to Clean the Air Filter
A dirty air filter will restrict air intake. Periodic maintenance
of the air filter will help improve engine performance and
reduce emissions.
WARNING
Never clean air filter with gasoline or an easy ignited solvent
because it may create a fire hazard.
1. Remove the air filter cover, and carefully remove the filter
element. (See Figure 10)
2. Clean all parts. Clean filter element by gently tapping it
on a flat surface. Replace if very dirty.
3. Reinstall the filter element and air filter cover. Figure 10
Filter Element
Air Filter Cover

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 16
Maintenance (Continued)
• Save all instructions
How to Replace the Trimmer Lines
When the trimmer line becomes worn to half the original
length, replace the trimmer line. For the best performance,
use a heavy gauge 0.155 in. [4 mm] trimmer line.
1. Stop the engine. Wait for all moving parts to stop.
Disconnect the wire from the spark plug.
2. Remove the worn trimmer line from line retainer.
3. Cut the length of the trimmer line to 21.5 in. [546 mm].
Use the length guide; located on the shield to make sure
the trimmer line is the correct length. (See Figure 11)
NOTE: Do not allow the length of the lines to vary more than
one inch. Make sure the trimmer head is balanced and does
not vibrate.
IMPORTANT: To extend the life of the trimmer line, keep the
trimmer line moist. If not kept moist, the nylon trimmer line
will become dry and brittle. Keep extra trimmer line in a can
of water. The line will then stay exible and easy to change.
A exible line will also last much longer.
Figure 11
Figure 12
Figure 13
Figure 14

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 17
How to Check the Spark Plug
Spark Plug Model: Torch K7RTC
CAUTION
Only use the recommended spark plug or a spark plug with
the same temperature range. Using an improper spark plug,
an incorrect spark plug gap, or a dirty/fouled spark plug can
reduce engine performance and cause damage.
1. Stop engine and allow it to cool.
2. Remove spark plug wire from spark plug.
3. Remove the spark plug with a size 16mm (5/8 inch) deep
well socket.
4. Visually inspect the spark plug for cracks or damage.
If cracked, replace spark plug.
5. Clean carbon deposits. If excessive carbon build up,
replace spark plug.
6. Check that the gap of the spark plug is 0.024 - 0.031 in.
(0.6 - 0.8mm). (Figure 15)
7. Re-insert the spark plug and tighten to 12 foot-pounds
(16 Nm).
8. Reattach spark plug wire to spark plug. Figure 15
0.024 - 0.031 in.
(0.6 - 0.8mm)
Maintenance (Continued)
• Save all instructions

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 18
How to Replace the Drive Belt
WARNING
Before you remove the drive belt, disconnect the wire from
the spark plug.
1. Remove the four fasteners that holds the plastic belt guard
to the trimmer housing. (See Figure 16)
2. Remove the plastic belt guard.
3. Remove the ange nut and washer that holds the forward
drive pulley onto the trimmer head. (See Figure 16)
4. Pull straight up on the forward drive pulley to remove
from the spindle head shaft.
5. Remove the ange nut holding the idler pulley to the idler
bracket. (See Figure 17)
6. Remove the drive belt from the unit.
IMPORTANT: Only use a replacement belt from the
manufacturer. To order spare parts,
call us at: 1-800-737-2112
7. To assemble the drive belt, reverse the above steps.
8. The torque specs are
• 50-70 inch-pounds [5.7-8.0 Nm] for the belt guard.
• 27-33 foot-pounds [36.6-44.7 Nm] for the drive pulley
mounting nut.
9. Check the routing of the drive belt. Make sure the drive
belt is inside of all belt guides and that the belt is not
twisted. (See Figure 17)
IMPORTANT: Test the drive system. Start the engine and
assure that the spindle head is turning freely.
Maintenance (Continued)
• Save all instructions
Figure 16
Drive
Belt
Forward
Drive Pulley
Engine Drive
Pulley
Belt Guard
Figure 17
Forward
Drive Pulley
Idler
Bracket
Idler
Pulley

Questions? Call Toll Free at 1-800-737-2112 Copyright © 2018 MAT Engine Technologies, LLC
EN - 19
Maintenance (Continued)
• Save all instructions
How to Prepare for Storage
WARNING
Never store the trimmer indoors with fuel in the fuel tank.
Never store in an enclosed, poorly ventilated area where
fumes could reach an open ame, a spark or a pilot light as
on a furnace, water heater or clothes dryer. Allow engine to
cool before storing unit.
Do not remove gasoline while inside a building, near a re,
or while you smoke. Gasoline fumes can cause an
explosion or a re.
NOTE: A yearly checkup or tune-up at an authorized service
center will make sure that the trimmer will provide maximum
performance for the next season.
When the trimmer is put in storage for thirty days or more,
the following steps should be followed to make sure the
Trimmer is in good condition the next season. To prevent
fuel gum deposits and corrosion in the unit’s carburetor and
fuel system, it is highly recommended to use a fuel additive/
stabilizer formulated for ethanol fuels.. Follow the stabilizer
manufacturer’s instructions. Run the engine for at least 5
minutes after adding stabilizer.
1. Let the engine run until it is out of gasoline. Remove
carburetor screw from bowl and drain fuel. Tilt the unit
slightly to remove all fuel. Replace screw.
You may have further questions about assembling, operating, or maintaining this Trimmer. If so, you can contact our
Technical Service Department at 1-800-737-2112 (English only).
You may also write to:
METL - CORRESPONDENCE ONLY
ATTN: Technical Service – METL
213 Industrial Drive
Jackson, TN 38301
Technical Service
When contacting the Technical Service Department, have ready:
• Your Name
• Your Address
• Your Phone Number
• Model Number of Product
• Date of Purchase (include copy of receipt for written requests)
• Date Code on Unit
If you need assistance or have any questions, CALL
TOLL FREE: 1-800-737-2112.
WARNING
Do NOT attach spark plug wire to spark plug when
storing unit.
4. Clean Trimmer. Remove all dirt, leaves, debris, grease,
etc. from the Trimmer – including cylinder cooling ns,
recoil starter cover holes, under fuel tank, and
under mufer.
5. Check the trimmer for worn or damaged parts. Have
damaged parts replaced if necessary.
6. Tighten any loose hardware.
7. Apply lubrication as directed in Maintenance section.
8. Put the unit in a building that has good ventilation.
2. Change the oil by following instructions under “How to
Change the Engine Oil” section.
3. Remove the spark plug from the cylinder. Pour one
ounce of oil into the cylinder. Slowly pull the
recoil-start grip so that the oil will protect the cylinder
Install a spark plug in the cylinder. Pull recoil slowly
until resistance is felt. This will close the cylinder valves.
