PowerPac PPIC831 User manual

Model: PPIC831
190165-24

PARTS & DESCRIPTION
Iron PlateStainless Steel PotDeep-Fry Pan
Usable Pots/Pans
Infrared cooker has no limitation for using any kinds of pan. Such as, Made by metal,
Aluminium, Copper, Ceramic, Glass etc. Bottom of the pan must be plain. The diameter
of the pan should be less than 22 CM.
Enameled
Iron Pot
Iron or Enameled
Iron Pot
Cast Iron Pan Iron Pot
1

The infrared cooker makes use of the far infrared to heat food. It is especially suitable
for modern family cooking. Its main characteristics are as follows:
•
•
•
•
•
•
•
High-tech, far infrared heating: it uses the far infrared portion of the
electromagnetic spectrum, which is entirely safe and poses no danger to health.
It includes many cooking functions, including warming
Any pot can be used, such as iron, aluminium, copper, ceramics, marmite
heat-resistant glass and any heat-resistant utensil can be used as well
Multi-function: micro-computer control, touch control, timer function
Environmentally-friendly: no fire, no smoke and no carbon monoxide
Easy to clean: crystal glass plate
Convenient: intelligent micro-computer control
Safety: numerous protections installed (see below)
FEATURES
•
•
•
•
•
Over-heat protection: if the temperature of cooker surface is over 650 C, the cooker
will be protected automatically
Inner-temperature over-heat protection: when the inner temperature reaches 95C,
the cooker will be protected automatically
High-voltage protection: once voltage is over 275 V, the cooker will be protected
automatically
Low-voltage protection: once voltage is under 95 V, the cooker will be protected
automatically
Constant-temperature over-heat protection: when the temperature of cooker
surface reaches 580 C, it will be on constant temperature protection
SAFETY PROTECTION
2

ATTENTION :
Read this booklet carefully it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
This appliance is NOT suitable to be used in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air).
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the power cable is damaged, it must be replaced
by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
Before use, check the crystal plate (top plate) of the appliance. In case it is damaged
or cracked, it must be replaced by the manufacturer or its service agent.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
Any accessories NOT recommended by the manufacturer may cause injuries to
persons.
WARNINGS
3

13.
14.
15.
16.
17.
18.
During use and storage, the appliance must be kept at a safe distance from heat
sources (open flame, heaters, stoves, etc.) or any flammable and/or potentially
explosive substances.
If you are using the appliance for the first time, you should:
a.
b.
c.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
•
•
•
•
•
•
•
•
•
•
Plug and unplug the power cable with dry hands and hold it firmly. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug it
or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the proper command on the control panel.
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock.
In case of accidental fall in water, DO NOT try to take it out, but first of all unplug
immediately the power cable from the socket.
Place the appliance at a proper distance from objects or surrounding walls making
sure that its functioning will not cause accidental damages. There should be at least
10 cm of free space from the back, left & right sides, and the top of the pot or other
utensil placed on the ceramic cooker.
Clean the ceramic cooker with a dish-washing agent and a damp cloth, and
immediately wipe dry.
Before you switch ON the cooker, add oil, grease or water into the pot first.
Not doing this may lead to burning or scarring of the pot!
Press the Power button after you finish cooking. DO NOT switch the appliance off.
The fan will continue to work until the unit cools down.
cover the appliance during functioning;
obstruct totally nor partially the air inlet & outlet – ensure that the appliance is
least 10 cm from objects or surrounding walls making sure that its functioning
will not cause accidental damages;
insert objects or body parts inside the protection cover of the appliance;
use the appliance near curtains or textiles;
move the appliance while the pot or pan is still on it;
heat an empty pot or pan / overheat an empty pot or pan;
place metallic objects such as knives, forks spoons, lids, etc. or aluminium foil on
the ceramic plate;
place a sheet of paper on the ceramic plate as the paper may get burned and a
fire may start as a result;
touch the crystal plate (top plate) of the appliance when in operation or just after
switching it off as it will still be very hot and may cause scalding;
leave the appliance unsupervised during operation.
4

19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily.
DO NOT switch the appliance off by pressing the switch on the plug attached to the
main electrical supply. Press the Power button after you finish cooking and the
screen will display“_____”. The appliance will stop heating immediately. The fan
does not stop working until the unit cools down.
Always remember to unplug the power cable of the appliance if it is NOT used for a
long period, before storing, cleaning or performing any maintenance operation.
Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
The appliance shall NOT be placed on a surface or in the vicinity of objects which
can be damaged by heat, such as carpets or plastics. When using the ceramic
cooker the surface that the appliance is placed upon may become very hot.
DO NOT touch the surface of the ceramic cooker while it is operating. This is to
prevent scalding. The bottom of the cooker becomes exceedingly hot as the cooker
operates.
If smoke is observed coming out of the appliance, unplug the power cable
immediately. Remove the pot or other utensil placed on the ceramic cooker away
from the cooker.
Before cleaning or storing the appliance, remove the pot or other utensil from the
ceramic cooker. (Caution: The appliance is very hot at this time!) and leave to cool
for at least 30 minutes.
This appliance is intended to be used in households and similar applications,
such as:
• Staff kitchen areas in shops, offices and other working environments;
• Dormitory;
• By clients in hotels, motels and other residential environments;
• Bed and breakfast type environment.
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cable out of reach of children less than 8 years old.
Save these instructions.
5

Note: The actual Control Panel may be different from the image above.
However, the functions and usage remain the same.
The buttons are for adjusting heat levels. There are ten levels in total, from 80˚C to
650˚C. The corresponding power level is from 200 W to 2000 W. The buttons can also
be used to set the timer in pre-set/timer functions as indicated below:
Press the Master ON/OFF button.
Press the Timer button followed by - & + buttons to set the desired time.
The TIMER function works only in Manual mode. The timer can be adjusted
anywhere up to 180 minutes. The cooker will automatically shut off when
the timer expires.
USING YOUR APPLIANCE
6

MANUAL FUNCTION
Pressing the buttons (as shown below) on the Control Panel will light up the LED
display as shown:
REMINDER:
DO NOT switch the appliance off by pressing the switch on the plug attached to the
main electrical supply. Press the Power button after you finish cooking and the screen
will display “_____”. The appliance will stop heating immediately. The fan does not stop
working until the unit cools down.
Button Mode Display
Soup 2000 W
BBQ 550°C
Hot Pot 1800 W
FRY 1800 W
Operation
Power (in W) cannot be adjusted
Auto shut-off after 120 mins
Temperature can be adjusted from 100°C – 650°C
Timer can be adjusted from 1 sec to 3 mins
Power (in W) can be adjusted from 200 W – 2000 W
Timer can be adjusted from 1 sec to 3 mins
Power (in W) can be adjusted from 200 W – 2000 W
Timer can be adjusted from 1 sec to 3 mins
7

PPIC831
MODEL
220-240V ~ 50/60Hz
VOLTAGE
2000W
WATTS(W)
SPECIFICATION
1.
2.
3.
4.
5.
Disconnect plug and wait until the unit has cooled down completely.
Always clean cooking appliances such as pots & pans soon after use. This will
prevent food from sticking to the appliance and reduce the possibility of bacterial
growth. It will also reduce the likelihood of the utensils being stained or discoloured.
The appliance can be cleaned with a dish-washing agent and a damp cloth, and
immediately wiped dry. DO NOT use a scrubbing brush. DO NOT use detergents or
chemicals like benzene, thinner, polishing powder.
Never run water over the unit as malfunctions may occur if water seeps inside the
appliance.
Use a vacuum cleaner to suck up dirt from the air intake and exhaust vent.
CLEANING
8

This appliance, along with all other electronic appliances, should, when it is no longer capable of
functioning, be disposed with the least possible environmental damage according to the local
regulations in your area. In most cases you can discard the appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside so that
children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
Warranty Conditions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
This warranty provides against defective materials and manufacturing faults throughout for
two years from the date of purchase of the appliance. The warranty on the Compressor is 10
years subject to the same conditions as above.
This warranty also does not cover normal wear and tear, replacement of consumable
materials and accessories, and the cost of maintenance of the appliance.
This warranty does not cover the repair or replacement of part/s damaged by misuse,
accidents, negligence, alterations, or modifications in any way, or repairs done by any repair
organisation without the prior consent of PowerPac Electrical Pte Ltd.
Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045.
A transport fee will be charged for personal doorstep service.
The original purchaser of the appliance must furnish proof of purchase to our Service Centre
with the email or number as registered during submission of warranty when this appliance is
sent for repair/service. Failure to do so may delay the receipt of said repair/service by the
customer.
Under no circumstances whatsoever shall the serial number be erased, defaced or altered by
the customer and/or his representatives, or the dealer and/or his agents. Failure to ensure
this shall invalidate the warranty.
This warranty is deemed to be void if the defect is cause by the attack of household pests,
fire, lightning, natural disasters, pollution, abnormal voltage or the usage of generators.
This warranty is valid in Singapore only.
This warranty will be honoured subject to the customer’s registration of the warranty
inclusive of original invoice or valid purchase receipt. Failure to present these documents will
result in denial of service. However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair the appliance but impose
a labour charge, as well as the costs of the replacement parts, to be borne solely by the
customer.
Please refer to the attached picture for the location of one of our appliance’s serial number,
as an example.
Please complete the on-line registration warranty form available
on our website. There is no further requirement to send us any
hard copy as part of our efforts to save the environment.
In accordance with the terms and conditions of this limited
warranty as stated above, PowerPac Electrical Pte Ltd, at its
expense shall provide free services for the appliance within the
warranty period from its date of purchase from our Authorised
dealers.
WARRANTY
E-Register scan
9

Tanah Merah Stn Exit B »» Bus No. 2/9/48(Stop ID: 85091)
»» 5 min (4 stops) »» Bef Changi Fire Stn (Stop ID: 85071)
»» Walk About 6 min, 500m
Simei MRT »» Bus No. 9 (Stop ID: 85079)»» 6 min (3 stops)
»» Flextronic (Stop ID: 96161) »» Walk About 6 min, 500m
Address: 5 Changi South Lane, #03-01 S(486045)
OFFICE / SERVICE CENTER
PowerPac Electrical Pte Ltd Tel: [phone]
E Warranty Registration
E-Register scan
Please complete the on-line registration warranty form below.
There is no further requirement to send us any hard copy as part of
our efforts to save the environment.
In accordance with the terms and conditions of this limited warranty
as stated below, PowerPac Electrical Pte Ltd, at its expense shall
provide free services for the appliance within the warranty period
from its date of purchase from our Authorised dealers.
This warranty will be honoured subject to the customer’s registration
of the warranty inclusive of original invoice or valid purchase receipt.
Failure to present these documents will result in denial of service.
However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair
the appliance but impose a labour charge, as well as the costs of the
replacement parts, to be borne solely by the customer
follow us on
face book
follow us on
tiktok
ITE
Flex
No. 5
ARALOGOS
Changi
Fire Station
Entrance
No.3
Mapletree
No.1
PROLOGIS
Goodrich
Global
85071
(Bus No. 2/9/10/48)
85079
(Bus No.2/9/10/48)
96111 (Bus No. 31 / 118)
Simei Ave
Simei / Tampines
Simpang Bedok
Expo
Upper Changi RD
WE ARE HERE
(LEVEL 3)
Changi S Ln
Kian Ann
SG5
Onn Wah
Product Serial No
Sample
Refer rating label at
bottom of product
