PowerPac PPIN1129 User manual

Model: PPIN1129
220746-12
CERAMIC
SOLE-PLATE
TEMPERATURE
CONTROL
1.4KG

LIST OF COMPONENTS
1.
2.
3.
4.
5.
360 Swivel Cord
Indicator Light
Handle
Steam Button
Temperature Regulating Knob
6.
7.
8.
9.
10.
Water Filler
Button groove
Soleplate (Non-stick)
Water Tank (+ Window) (180 ml)
Heel Rest
PARTS & DESCRIPTION
7 8 9 10
34
1
2
5
6
1

ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation, use and
maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read all instructions before using the appliance.
The Appliance
This appliance must be used only for the purpose it was expressly designed – for ironing
fabrics on an ironing board; any use NOT complying with the instructions contained in the
manual is considered inappropriate and dangerous. The manufacturer is NOT responsible for
possible damages caused by the inappropriate and/or unreasonable use.
The Water Tank in the appliance is designed for heating water only. DO NOT put other liquids
into it. Different liquids have different boiling points, with volatile liquids having boiling points
lower than 100°C, the boiling point of water.
The installation/assembly of the appliance will be made in accordance with the indications of
the manufacturer. A wrong procedure may cause damages to persons, animals or objects, for
which the manufacturer cannot be considered responsible.
Before use, check the integrity of the appliance and power cable. DO NOT operate the
appliance when its housing is damaged or if the appliance have has been dropped. In case you
are not sure, contact a qualified person. If the power cable is damaged, it must be replaced by
the manufacturer or its service agent or a qualified technician in order to avoid a shock hazard.
Before powering the appliance make sure the rating (voltage and frequency) corresponding
to the grid and the socket is suitable for the plug of the appliance, and that the wall socket is
properly grounded.
Avoid the use of adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the electrical
parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote control
appliances which are not specified in this manual.
Only use original components & accessories provided by the manufacturer. Any non-original
component or accessory NOT recommended by the manufacturer may cause injuries to
persons or damage to the appliance.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out of the reach
of children or disabled persons since they represent potential sources of danger.
Location
This appliance is NOT suitable to be used or stored near heat sources (open flame, ovens,
heaters, stoves, etc.) and/or in an explosive environment (in the presence of flammable
substances such as gas, vapour, mist or dust, in atmospheric conditions when, after ignition,
the combustion is spread in the air). Items containing these substances should never be
placed in the appliance, and never be used to clean the appliance in order to avert the risk of
fire or explosion.
The appliance should be placed on an ironing board, which is covered by fabric made
specifically for that purpose. When using the appliance, the surface that the appliance is
placed upon as well the surface immediately above (e.g. a wooden cabinet above the
appliance), may become very hot. The appliance should NOT be placed on a surface or in the
vicinity of objects which can be damaged by heat, such as carpets or plastics. DO NOT locate
multiple portable socket outlets or power supplies in the vicinity of the appliance.
WARNINGS
2

13.
14.
15.
16.
17.
18.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it can be
damaged easily. Avoid placing heavy objects on the cable. Be especially vigilant in preventing
the hot Soleplate from coming to rest on the power cable. The cable must NOT be placed
under carpets, or covered with throw rugs, runners or similar. Arrange the cable away from
the high traffic area, and where it will NOT be tripped over. DO NOT pull or carry the appliance
by the cable.
DO NOT use or store the appliance outdoors. Store and use the appliance only indoors, or in
any case, protected from weathering such as rain, direct radiation of the sun and dust.
Operation
If you are using the appliance for the first time, you should:
a.
b.
c.
DO NOT:
•
•
•
•
•
During operation, DO NOT touch the appliance with wet body parts, and it is recommended
to have between you and the standing surface, an isolating element (for example, wearing
shoes with rubber soles).
During the period of operation, high temperature steam may escape from the container.
To avoid scalding:
•
•
•
•
•
•
•
•
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let any liquid
flow into the internal casing of the appliance to prevent electric shock. In case of accidental
fall in water, DO NOT try to take it out, but first of all switch the appliance off.
Clean the exterior parts of the appliance thoroughly with a damp cloth. DO NOT use metal
scouring pads.
Place and use the appliance upright on a horizontal, stable, dry and heat-resistant surface.
Damage to the appliance may occur if it is placed on an incline or decline.
(First use)
• Clean the iron by ironing an old rag, as oil or grease from the manufacture and assembly
of the components may be present, which could cause discolouration of fabric. The oil or
grease should be burnt off after a short while, and some smoke may be emitted.
This is normal.
• Fill the Water Tank with water before using the Spraying button & the Burst Steam button.
Ensure that the exterior of the iron is completely dry before use.
• Make sure to remove any label or protective sheet which may prevent its proper functioning.
cover the appliance during functioning;
obstruct totally nor partially the Soleplate;
insert objects or body parts inside the protection cover of the appliance;
place the appliance and heat it by any other means, e.g. in a microwave, oven or on a frying
pan filled with water and placed directly on a gas stove, as the plastic components can be
deformed as a result;
leave the appliance unsupervised during operation.
ensure that the iron is correctly positioned while being used;
DO NOT fill the Water Tank with hot water;
DO NOT fill water beyond the maximum volume indicated;
DO NOT iron or steam fabrics while they are still attached to the body;
DO NOT touch any part of the iron except the Handle, Steam Button and Temperature
Regulating Knob when the iron is hot;
note that water inside the Water Tank might be very hot during operation, and for some
time after the appliance have stopped operating;
DO NOT press the Steam Button too forcefully;
one’s hands and face should be angled away from the Water Filler & Soleplate.
3

19.
20.
21.
22.
23.
24.
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let any liquid
flow into the internal casing of the appliance to prevent electric shock. In case of accidental
fall in water, DO NOT try to take it out, but first of all switch the appliance off.
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible, with the
support of a qualified person.
If smoke is observed coming out of the appliance, unplug the power cable immediately.
This appliance is NOT intended for commercial use but to be used in households and similar
applications, such as:
• Staff kitchen areas in shops, offices and other working environments;
• By clients in dormitories hotels, motels and other residential environments;
• Bed and breakfast type environment.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall NOT play with the appliance. Cleaning and
user maintenance shall NOT be made by children unless they are older than 8 and supervised.
Keep the appliance and its cable out of reach of children less than 8 years old.
Save these instructions.
4

Sort your clothes according to the nature of the fabrics. Chemical fibres which are synthetics
should not encounter high temperatures while Natural fibres which includes (silk, wool, cotton
and linen) can withstand progressively higher temperatures.
How to fill the iron with water
1.
2.
3.
4.
Using as a DRY IRON
1.
2.
3.
4.
5.
6.
Switch off the iron and unplug the power cable from the electric mains.
Set the Temperature Regulating Knob to the ‘0’ position and the Steam Button locked in the
DOWN position.
Position the iron vertically resting on the Heel Rest on a horizontal, stable and heat-resistant
surface. Use a clean measuring cup and pour water into the Water Filler to the‘MAX’ line of
the Water Tank.
DO NOT overfill or use water containing additives, scented water, mineral water, etc. Use only
tap water or distilled water.
The water level can be observed through the transparent part of the Water Tank. During the
course of operation, refill the tank (following the procedure outlined in steps 1 – 3) if the
water level becomes low.
Set the Temperature Regulating Knob to 0 and the Steam Button locked in the DOWN position.
Position the iron vertically resting on the Heel Rest on a horizontal, stable and heat-resistant
surface.
Plug the power cable into the electric socket and switch it ON.
Set the Temperature Regulating Knob to the appropriate setting (up to 4) for your fabric. The
Indicator Light comes on. The process of preheating the iron has commenced.
Wait for the Indicator Light to go off, indicating that the selected temperature has been
reached and you can start ironing fabrics which require low temperature ironing. The light
will cycle on an off during ironing.
When you are ready to proceed with fabrics which require progressively higher temperatures,
select a higher temperature setting, position the iron vertically 90 The Indicator Light comes
on. Wait for the Indicator Light to go off, and you can start ironing fabrics which require
higher temperature ironing.
Temperature Regulating dial to adjust temperature according to fabric
HOW TO USE
Temperature Fabric
Acrylic, Spandex (Lycra or Elastane), Lyocell1
Acetate, Nylon, Microfibre,2
Cashmere, Lace, Polyester, Satin, Silk3
Polyester, Synthetic blends (e.g. Cotton Blends),
Viscose or Rayon
4
Wool5
Cotton6
Linen, Corduroy7
STEAM FUNCTION
0 1
ACRYLIC
2
NYLON
3
SILK
4
POLYESTER
5
WOOL
6
COTTON
7
LINEN
5

7.
Using as a STEAM IRON
1.
2.
3.
4.
5.
6.
7.
8.
Always iron clothes which require lower temperatures first, and work your way to higher
temperatures. Never the other way around as thermally-sensitive fabrics will be ruined by
higher temperatures. In addition, the iron gets hot faster than it cools.
Ensure that the water is filled to the ‘MAX’line of the Water Tank.
Set the Temperature Regulating Knob to the ‘0’ position.
Position the iron vertically resting on the Heel Rest on a horizontal, stable and heat-resistant
surface.
Plug the power cable into the electric socket and switch it ON.
Set the Temperature Regulating Knob between 5 – 7 and the Steam Button unlocked in the
UP position. The Indicator Light comes on. The process of preheating the iron has commenced.
Wait for the Indicator Light to go off, indicating that the selected temperature has been
reached and you can start ironing fabrics which require lower temperature ironing. The light
will cycle on an off during ironing.
When you are ready to proceed with fabrics which require progressively higher temperatures,
select a higher temperature setting, position the iron vertically 90 The Indicator Light comes
on. Wait for the Indicator Light to go off, and you can start ironing fabrics which require higher
temperature ironing.
Always iron clothes which require lower temperatures first, and work your way to higher
temperatures. Never the other way around as thermally-sensitive fabrics will be ruined by
higher temperatures. In addition, the iron gets hot faster than it cools.
Note: the iron gives off steam continuously only if held horizontally with the Steam Button
unlocked in the UP position. You can stop the continuous flow of steam by placing the iron in
a vertical position, by moving the control dial to 0 or having the Steam Button locked in the
DOWN position.. You can only use steam at the highest temperatures (5 – 7, otherwise water
may drip onto the plate.
6

1.
2.
3.
4.
5.
6.
Once you have finished ironing, place iron on the Heel Rest, turn temperature selector to OFF
and unplug the iron. Set the Temperature Regulating Knob to 0 and the Steam Button locked
in the DOWN position
Wait until the iron has cooled down completely.
Pour out the remaining water after use by pointing the tip of the iron downwards and
inverting the iron. DO NOT store the iron with water still inside the Water Tank.
Wipe the exterior of the iron using a soft, damp cloth or sponge. Remove stubborn spots with
a cloth moistened with mild liquid detergent. DO NOT use abrasive scouring pads or powders.
Never let steam iron cleaners come into contact with the working parts of the iron.
Soleplate: Starch and other residues may be easily removed from the Soleplate with a damp
cloth with a vinegar-water solution.
To avoid scratching the finishing, never use a metallic pad to clean the Soleplate, and never
place the iron horizontally over a rough surface.
If synthetic fabrics are ironed at too high temperatures, not only is the fabric usually ruined
but the Soleplate is often covered with the melted remains of the synthetic fabric.
The best way to remove synthetic fabric residue from the Soleplate is to heat the iron and to
iron over an old cotton rag repeatedly.
Store the iron in a vertical position.
HOW TO CLEAN
Anti-Drip Function
Below a certain temperature (Temperature setting 5 on the Temperature Regulator knob), the
anti-drip function cuts off the flow of water to the Soleplate and stops the water from dripping
out of the appliance.
Overheat Safety Protection
In the case where the installed thermostat malfunctions, the power supply will stop
automatically to prevent the steam iron from overheating. In this case, the steam iron has to be
repaired by the service point.
SAFETY FEATURES
7

This appliance, along with all other electronic appliances, should, when it is no longer capable of
functioning, be disposed with the least possible environmental damage according to the local
regulations in your area. In most cases you can discard the appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside so that
children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
Warranty Conditions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
This warranty provides against defective materials and manufacturing faults throughout for
two years from the date of purchase of the appliance. The warranty on the Compressor is 10
years subject to the same conditions as above.
This warranty also does not cover normal wear and tear, replacement of consumable
materials and accessories, and the cost of maintenance of the appliance.
This warranty does not cover the repair or replacement of part/s damaged by misuse,
accidents, negligence, alterations, or modifications in any way, or repairs done by any repair
organisation without the prior consent of PowerPac Electrical Pte Ltd.
Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045.
A transport fee will be charged for personal doorstep service.
The original purchaser of the appliance must furnish proof of purchase to our Service Centre
with the email or number as registered during submission of warranty when this appliance is
sent for repair/service. Failure to do so may delay the receipt of said repair/service by the
customer.
Under no circumstances whatsoever shall the serial number be erased, defaced or altered by
the customer and/or his representatives, or the dealer and/or his agents. Failure to ensure
this shall invalidate the warranty.
This warranty is deemed to be void if the defect is cause by the attack of household pests,
fire, lightning, natural disasters, pollution, abnormal voltage or the usage of generators.
This warranty is valid in Singapore only.
This warranty will be honoured subject to the customer’s registration of the warranty
inclusive of original invoice or valid purchase receipt. Failure to present these documents will
result in denial of service. However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair the appliance but impose
a labour charge, as well as the costs of the replacement parts, to be borne solely by the
customer.
Please refer to the attached picture for the location of one of our appliance’s serial number,
as an example.
Please complete the on-line registration warranty form available
on our website. There is no further requirement to send us any
hard copy as part of our efforts to save the environment.
In accordance with the terms and conditions of this limited
warranty as stated above, PowerPac Electrical Pte Ltd, at its
expense shall provide free services for the appliance within the
warranty period from its date of purchase from our Authorised
dealers.
WARRANTY
E-Register scan
8

PPIN1129
MODEL
220-240V ~ 50/60Hz
VOLTAGE
1200W
POWER
SPECIFICATION
9
