PowerPac PPIN1200 User manual


This appliance has many functions such as temperature regulating, water sprays,
steam bursts, dry ironing, steam ironing, self-cleaning, etc. It is light, easy to handle,
attractively-designed, uses less electricity due to its high energy efficiency, and
provides an enjoyable ironing experience.
LIST OF COMPONENTS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
360° Swivel cord
Handle
Indicator light
Spray button
Steam regulating knob
Temperature regulating dial
Water tank
Water filler cover
Spraying mouth
Soleplate
PARTS & DESCRIPTION
1. 360° Swivel cord
2. Handle
3. Indicator light
4. Spray button
5. Steam regulating knob
6. Temperature regulating
dial
7. Water tank
8. Water filler cover
9. Spraying
mouth
10. Soleplate
1

ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed – for
ironing fabrics on an ironing board; any use NOT complying with the instructions
contained in the manual is considered inappropriate and dangerous. The
manufacturer is NOT responsible for possible damages caused by the inappropriate
and/or unreasonable use.
The Water tank in the iron is designed for heating water only. DO NOT put other
liquids into it. Different liquids have different boiling points, with volatile liquids
having boiling points lower than 100°C, the boiling point of water.
This appliance is NOT suitable to be used in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air). Items
containing these substances should never be placed in the iron, and never be used
to clean the iron in order to avert the risk of fire or explosion.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Before use, check the integrity of the appliance and power cable. In case you are
not sure, contact a qualified person. If the supply cord is damaged, it must be
replaced by the manufacturer or its service agent or a qualified technician in order
to avoid a shock hazard.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
WARNINGS
2

12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Any accessories NOT recommended by the manufacturer may cause injuries to
persons. During use and storage, the appliance must be kept at a safe distance from
heat sources (open flame, ovens, heaters, stoves, etc.) or any flammable and/or
potentially explosive substances.
If you are using the appliance for the first time, you should:
a. Clean the exterior of the iron with water & detergent with a non-abrasive sponge.
DO NOT use metal scouring pads.
b. Fill the Water tank with water before steam ironing. Ensure that the exterior of the
iron is completely dry before use.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
• cover the appliance during functioning;
• obstruct totally nor partially the Spraying mouth;
• insert objects or body parts inside the protection cover of the appliance;
• leave the appliance unsupervised during operation.
Plug and unplug the power cable with dry hands and hold it firmly. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug it
or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the proper command on the control panel.
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock. In
case of accidental fall in water, DO NOT try to take it out, but first of all unplug
immediately the power cable from the socket.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily.
Always remember to unplug the power cable of the appliance if it is NOT used for a
long period, before storing, cleaning or performing any maintenance operation.
Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
The appliance shall only be placed on an ironing board when in use. It should NOT
be placed on a surface or in the vicinity of objects which can be damaged by heat,
such as carpets or plastics. When using the iron, the surface that the oven is placed
upon may become very hot.
3

22.
23.
24.
25.
26.
27.
28.
During the period of operation, high temperature steam may be emitted. To avoid
scalding:
• ensure that the iron is correctly positioned while being used;
• DO NOT fill with the Water tank with hot water;
• DO NOT fill water beyond the maximum volume indicated;
• DO NOT iron or steam fabrics while they are still attached to the body;
• DO NOT touch any part of the iron except the handle when the iron is hot;
• one’s hands and face should be angled away from the Soleplate & Spraying mouth.
Switch off the iron and unplug the socket from the electric mains when not in use
and before filling, emptying and cleaning the iron.
If smoke is observed coming out of the iron, unplug the power cable immediately.
This appliance is intended to be used in households and similar applications,
such as:
• Staff kitchen areas in shops, offices and other working environments;
• Farm houses;
• By clients in hotels, motels and other residential environments;
• Bed and breakfast type environment
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cord out of reach of children less than 8 years.
Save these instructions.
4

How to fill the iron with water
1.
2.
3.
4.
Switch off the iron and unplug the socket from the electric mains.
Set the Steam Regulating knob to the ‘0’ position.
Open the Water filler cover, turn the iron vertically 90° with its base resting on a
horizontal, stable and heat-resistant surface. Fill the Water tank with water to the
‘max’ line of the tank. Close the Water filler cover.
DO NOT overfill or use water containing additives, scented water, mineral water, etc.
Use only tap water or distilled water.
The water level can be observed through the transparent part of the tank. During
the course of operation, refill the tank if the water level becomes low.
Temperature control
1.
2.
3.
4.
5.
6.
7.
Sort your clothes according to the nature of the fabrics:
• Chemical fibre / synthetic
•• Natural fibre / silk / wool
••• Natural fibre / cotton / linen
Heat setting markings on the adjustable control dial of this iron matches those of
the International Textile Care Labelling Code Garments (e.g. Nylon, Acetates,
Acrilan, Courtelle, Orlon, Triacetates, Tricel) marked with 1 dot recommendation
should be ironed at the lower temperature range. Garments (e.g. Wool, Polyester
mixtures, Polyester / Cotton, Linen, Cotton, Rayon, Rayon mixtures, Rayon / Linen)
which are suitable for ironing at 2 & 3 dot settings usually require steam pressing.
Select the lowest temperature first with the Temperature regulating dial.
Position the iron vertically 90° with its base resting on a horizontal, stable and
heat-resistant surface.
Plug the socket attached to the power cable to the electric mains and switch it ON.
The Indicator light comes on. The process of preheating the iron has commenced.
Wait for the Indicator light to go off, indicating that the selected temperature has
been reached and you can start ironing fabrics which require low temperature
ironing.
When you are ready to proceed with fabrics which require progressively higher
temperatures, select a higher temperature setting, position the iron vertically 90°
(step 3). The Indicator light comes on. Wait for the Indicator light to go off, and
you can start ironing fabrics which require higher temperature ironing.
Always iron clothes which require lower temperatures first, and work your way to
higher temperatures. Never the other way around as thermall y-sensitive fabrics
will be ruined by higher temperatures. In addition, the iron gets hot faster than it
cools.
HOW TO USE
5

How to use the spray
1.
2.
3.
4.
During ironing, the spray feature is useful in removing stubborn wrinkles or where
extra dampness prior to ironing is needed.
Before spraying water, check the label on each fabric as certain fabrics may be
stained due to the presence of water which is then converted into steam by the iron.
Simply pump the Spray button when a spray is needed.
This feature can be used both with steam ironing or dry ironing.
How to use as dry iron
1.
2.
3.
4.
5.
6.
Switch off the iron and unplug the socket from the electric mains.
Open the Water filler cover and pour out the remaining water after use by inverting
the iron after the iron has cooled. Close the Water fill er cover.
Set the Temperature regulating dial to‘min’ position.
Position the iron vertically 90° with its base resting on a horizontal, stable and
heat-resistant surface.
Plug the socket attached to the power cable to the electric mains and switch it ON.
The process of preheating the iron has commenced.
Once the indicator light goes out, the iron can be used as a dry iron.
How to empty the iron of water
1.
2.
Switch off the iron and unplug the socket from the electric mains.
Open the Water filler cover and pour out the remaining water after use by inverting
the iron after the iron has cooled. Close the Water filler cover.
How to use as steam iron
1.
2.
3.
4.
5.
6.
Switch off the iron and unplug the socket from the electric mains.
Set the Temperature regulating dial to‘steam’position. Steam ironing is only
possible when the iron is set to the highest temperature, otherwise water would
leak from the Soleplate.
Position the iron vertically 90° with its base resting on a horizontal, stable and
heat-resistant surface.
Plug the socket attached to the power cable to the electric mains and switch it ON.
The process of preheating the iron has commenced.
Once the indicator light goes out, the iron can be used as a steam iron.
Turn the Steam regulating knob to the required setting for different types of fabric
as the ironing proceeds.
6

After each use
1.
2.
3.
4.
Switch off the iron and unplug the socket from the electric mains.
Open the Water filler cover and pour out the remaining water after use by inverting
the iron after the iron has cooled. Close the Water filler cover. DO NOT store the iron
with water remaining in the Water tank.
Wait until the iron has cooled down completely before storing the appliance
vertically with its base resting on a horizontal and stable surface.
Remember to always protect the Soleplate from scratches, corrosions and stains.
How to use the burst of steam
1.
2.
3.
4.
5.
During ironing, the burst of steam feature provides additional steam for removing
stubborn wrinkles.
Before spraying steam, check the label on each fabric as certain fabrics may be
stained due to the presence of steam.
Simply pump the Burst steam button several times to prime the surge system
before pressing the button when a burst of steam is needed.
Wait a few seconds, then repeat step 3 for more steam. For optimal steam, do not
apply more than three successive times after the indicator light goes off.
This feature can be used both with steam ironing or dry ironing.
7

1.
2.
3.
4.
Switch off the iron and unplug the socket from the electric mains when not in use
and before filling, emptying and cleaning the iron.
Wait until the iron has cooled down completely.
Wipe the exterior of the iron using a soft, damp cloth or sponge. Remove stubborn
spots with a cloth moistened with mild liquid detergent. DO NOT use abrasive
scouring pads or powders. Never let steam iron cleaners come into contact with the
working parts of the iron.
Soleplate: Starch and other residues may be easily removed from the Soleplate with
a damp cloth with a vinegar-water solution. To avoid scratching the finishing, never
use a metallic pad to clean the Soleplate, and never place the iron horizontally over
a rough surface. If synthetic fabrics are ironed at too high temperatures, not only is
the fabric usually ruined but the Soleplate is often covered with the melted remains
of the synthetic fabric. The best way to remove synthetic fabric residue from the
Soleplate is to heat the iron and to iron over an old cotton rag repeatedly.
How to use the Self-cleaning feature
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Switch off the iron and unplug the socket from the electric mains.
Set the Steam Regulating knob to the ‘max’ position.
Open the Water filler cover, turn the iron vertically 90° with its base resting on a
horizontal, stable and heat-resistant surface (it is preferable that this surface be
covered with an old piece of cloth). Half fill the Water tank with water.
The water level can be observed through the transparent part of the tank.
Plug the socket attached to the power cable to the electric mains and switch it ON.
Once the indicator light goes out, unplug the socket from the electric mains.
Maintaining the iron in the same vertical position, bring the iron over to the sink.
Rotate the iron to a horizontal position, with the iron below the rim of the sink.
Press down the Self-clean button and don’t let go. As boiling water and steam are
released from the holes in the Soleplate, move the iron forwards and backwards
until the Water tank is empty.
Release the Self-clean button.
Plug the socket attached to the power cable to the electric mains and switch it ON.
With the Steam Regulating knob at the‘max’ position, as the iron heats up, the
remaining water inside the steam chamber will now vaporise and leave the iron
through the Soleplate.
This self-cleaning process should be conducted once a month or more frequently
depending on usage.
HOW TO CLEAN
In the case where the installed thermostat malfunctions, the power supply will stop
automatically to prevent the steam iron from overheating. In this case, the steam iron
has to be repaired by the service point.
AUTOMATIC ELECTRICITY CUT-OFF FOR SAFETY
8

This appliance, along with all other electronic appliances, should, when it is no longer capable of
functioning, be disposed with the least possible environmental damage according to the local
regulations in your area. In most cases you can discard the appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside so that
children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
Warranty Conditions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
This warranty provides against defective materials and manufacturing faults throughout for
two years from the date of purchase of the appliance. The warranty on the Compressor is 10
years subject to the same conditions as above.
This warranty also does not cover normal wear and tear, replacement of consumable
materials and accessories, and the cost of maintenance of the appliance.
This warranty does not cover the repair or replacement of part/s damaged by misuse,
accidents, negligence, alterations, or modifications in any way, or repairs done by any repair
organisation without the prior consent of PowerPac Electrical Pte Ltd.
Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045.
A transport fee will be charged for personal doorstep service.
The original purchaser of the appliance must furnish proof of purchase to our Service Centre
with the email or number as registered during submission of warranty when this appliance is
sent for repair/service. Failure to do so may delay the receipt of said repair/service by the
customer.
Under no circumstances whatsoever shall the serial number be erased, defaced or altered by
the customer and/or his representatives, or the dealer and/or his agents. Failure to ensure
this shall invalidate the warranty.
This warranty is deemed to be void if the defect is cause by the attack of household pests,
fire, lightning, natural disasters, pollution, abnormal voltage or the usage of generators.
This warranty is valid in Singapore only.
This warranty will be honoured subject to the customer’s registration of the warranty
inclusive of original invoice or valid purchase receipt. Failure to present these documents will
result in denial of service. However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair the appliance but impose
a labour charge, as well as the costs of the replacement parts, to be borne solely by the
customer.
Please refer to the attached picture for the location of one of our appliance’s serial number,
as an example.
Please complete the on-line registration warranty form available
on our website. There is no further requirement to send us any
hard copy as part of our efforts to save the environment.
In accordance with the terms and conditions of this limited
warranty as stated above, PowerPac Electrical Pte Ltd, at its
expense shall provide free services for the appliance within the
warranty period from its date of purchase from our Authorised
dealers.
WARRANTY
E-Register scan
9

PPIN1200
MODEL
220-240V ~ 50/60Hz
VOLTAGE
1600W
POWER
SPECIFICATION
Table of contents
Other PowerPac Iron manuals
