Dear Customer,
Please carefully read this manualbefore using the
dishwasher, itwill help you to use and maintain the
dishwasher properly.
Pass it on to anysubsequent owner of the appliance.
This manual containssections on safety Instructions,
Operating Instructions, InstallationInstructions and
Troubleshooting Tips, etc.
Read this Manual
Before Calling for Service
Keep it to refer to it at a later date.
If you can not solve the problems by yourself ,
please ask forthe help of professional technicians.
1) Safety Information..........................................11) Safety Information..........................................1
2) Quick operation guide..................................... 22) Quick operation guide..................................... 2
Loading the baskets according to En50242Loading the baskets according to En50242
Dishwasher Features.................................... ...3
4) Prior usingfor the firsttime...............................44) Prior usingfor the firsttime...............................4
AWater Softener...........................................4
5) Loading theDishwasher Basket........................95) Loading theDishwasher Basket........................9
7) Maintenance andcleaning..............................137) Maintenance andcleaning..............................13
Filtering System.............................................13
Caring for the Dishwasher...............................14
BLoading the Salt into the Softener.................5
CFill the RinseAid Dispenser.........................5
DFunction of Detergent .................................6
6) Starting awashing programme........................116) Starting awashing programme........................11
Wash Cycle Table...........................................11
Turning on the Appliance................................11
Change the Programme..................................12
At the end of the Wash Cycle...........................12
8) Installation instruction....................................158) Installation instruction....................................15
Positioning theAppliance...............................15
Water Connection..........................................16
About Power Connection................................15
Start of dishwasher........................................17
9) TroubleshootingTips......................................189) TroubleshootingTips......................................18
Before calling for service.................................18
Error codes...................................................19
Technicalinformation.....................................20
3) Operation Instruction.......................................33) Operation Instruction.......................................3
Control Panel...................................................3
Recommengation...........................................9
For washing inthe dishwasher the
folliwing cutlery/dishes..................................9
Attention before or after loading the
Dishwasher Baskets......................................9
Removing the Dishes................................. ...9
The Method Loading Normal Dishware......... ...10
The manufacturer,following a policyof constant
development and updating of the product, may
make modifications withoutgiving prior notice.
This user manualshall also begot from the
manufacturer or responsible vendor.

1-11-1
This appliance is for household use only.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
For EN60335-1
This appliance is not intended for use by persons(including children )with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
For IEC60335-1
This appliance is for indoor use only, for household use only. To protect
against the risk of electrical shock, do not immerse the unit, cord or plug in
water or other liquid.
Please unplug before cleaning and maintenance the appliance .Use a soft
cloth moisten with mild soap, and then use a dry cloth to wipe it again .
1.IMPORTANT SAFETY INFORMATION1.IMPORTANT SAFETY INFORMATION
When using your dishwasher,
follow the precautions listed below:
WARNING!WARNING!
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of a malfunction or breakdown,
earthing will r e d u c e the r i s k o f anelectric s h o c k b y p r o v i d i n g a p a t h o f l e a s t
resistance o f e l e c t r i c c u r r e n t . T h i s appliance is e q u i p p e d w i t h a c o r d h a v i n g
an equipment-earthing conductor and a earthing plug.
The plug must be plugged into an appropriate outlet that is installed and
earthed in accordance with all local codes and ordinances.
Improper connection of the equipment-earthing conductor can result
in the risk of an electric shock. Check with a qualified electrician or service
representative if you are in doubt whether the appliance is properly earthed.
Do not modify the plug provided with the appliance; If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.

1-21-2
Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
Do not operate your dishwasher unless all enclosure panels are properly in place.
Open the door very carefully if the dishwasher is operating, there is a risk of water
squirting out.
Do not place any heavy objects on or stand on the door when it is open. The
appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door seal;
2) Warning: Knives and other utensils with sharp points must be loaded in the
basket with their points down or placed in a horizontal position.
Check that the detergent powder is empty after completion of the wash cycle.
Do not wash plastic items unless they are markeddishwasher safe or the
equivalent. For plastic items n check the manufacturer's
ot so marked,
recommendations.
Use only detergent and rinse additives designed for a n a u t o m a t i c dishwasher.
Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
Children should be supervised to ensure that they do not play with the appliance.
The door should not be left open, since this could increase the risk of tripping.
If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
During installation, the power supply must not be excessively or dangerously
bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using new hose sets and
that old hose-sets should not be reused.
The maximum number of place settings to be washed is 10.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.

Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international
abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging material could be dangerous for children!
For disposing of package and the appliance please go to a
recycling centre. Therefore cut off the power supply cable
and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper
and should be disposed in the waste paper collection for
recycling.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
For more detailed information about recycling of this
product, please contact your local city office and your
household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.
WARNING!WARNING!
1-31-3
DisposalDisposal

22
2.Quick operation guide2.Quick operation guide
For detailed operating method read the corresponding content on the instruction manual.
Compartment A:Compartment A:
With each wash cycle.
Compartment B:B:
For programmes with pre-wash only.
(Follow the user instructions!)
Mechanical indicator C.Mechanical indicator C.
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
T urn on the water tap and press the Start/Pause button. The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot andmore susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Close the door, Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )
If the appliance is switched
off during a wash cycle.
Open the doorcarefully.
Hot steam mayescape
when the dooris opened!
WARNING!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance
Press the On/Off button to switch on the appliance, Open the door.
1.Press the start/pause button to stop the machine.
2.Open the door.
3.Add the forgotten dishes.
4.Close the door, then press the start/pause button, the dishwasher will
start running again.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button then press the program button for more than 3 seconds to cancel the
running programme.
3. Select a new programme.
4. Restart the dishwasher.
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the Power button.
Since the appliance is standing by, it will power off automaticly after 30 minutes without any operation.
C
A
B

33
3.Operation Instruction3.Operation Instruction
Dishwasher FeaturesDishwasher Features
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANTIMPORTANT
Control PanelControl Panel
1---Power button and indicator: to switch On/Off the
appliance.and to show when the power on.
3---Delay button andindicators: to showthe delay time
(3h/6h/9h)
5---Start /Pause Button:To start theselected
washing program orpause the washing program
when the machineis working.
4---Half load functions Button: To select Half load
functions. (With this Half load function you can
only use it when you have only about or less than
6 place settingdish wave, andyou will seeless
water and energyconsumption , canonly be used with
Intensive, Normal, ECO,Glassand 90 min .)
6---Salt and rinse aid warning lights: To show
when the salt container or dispenser need to be
refilled.
2---Program button andindicators : topress the button
to select a wash program,and the indicator to show
which wash program you have chose.
.
7---Attention:
Child lock function: press delay button and Half
load functions Buttonsimultaneously to lock
the program.
1122334455
66
77
33
2277
1144
1
2
3
4
5
7
611
Back View
8
Front view
Lower basket
Salt container
Dispenser
Cup shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipeUpper basket
Cutlery rack
1
Inner pipe
5
6
7
8
9
10
11
3
2
4
910

WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will
form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
4.Prior using for the first time4.Prior using for the first time
44
A. Water SoftenerA. Water Softener
NOTE:NOTE:
If your model does not have any water softener, you may skip this section.
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kg dishwasher salt andthen full fillthe salt container with water
C. Fill the rinse aid dispenser
D. Fill in detergent
The water softener must be set manually, using the water hardness dial.
The water softener is designedto remove minerals and salts fromthe water,which would have
a detrimental or adverse effect on the operation of the appliance.
The higher thecontent of these minerals and salts, the harder your wateris.
The softener shouldbe adjusted accordingto the hardnessof the waterin your area.Yourlocal Water Authority
can advise you on the hardness of the water in your area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
the water used.This is intended to optimiseand customise thelevel o fsalt consumption.
Contact your local water board for information on the hardness of your water supply.
Please follow the steps below for adjustment in salt consumption.

Clark: Britishdegree

fH: French degree

DH: German degree
Note:1Note:1 dH=1.25 Clarke=1.78 fH=0.178mmol/l
  
1
Note:2Note:2
Themanufactory setting: H3(EN50242)
1. Switch on the appliance;
2. Press theStart/Pause button formore than 5seconds to start the water
softener set model within 60seconds after the appliance was
switched on;
3. Press theStart/Pause button toselect the properset according to
your local environment, the sets will change in the following
sequence: H1->H2->H3->H4->H5->H6;
4. Press the On/Off button or no operation for 5seconds to endthe set up model.
dH
mmol/l
0~90~5 0~0.94 0
10-20
6-11 1.0-2.0
9
21-30
12-17 2.1-3.0 12
20
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
SelectorPosition
Salt con sumption
(gram/cycle)
18-22 31-40 22-28 3.1-4.0
41-60
23-34 4.1-6.0 30
60
29-42
35-55 61-98 43-69 6.1-9.8
H1
H2
H3
H4
H5
H6

1. The salt container mustonly be refilled when the saltwarning light inthe control panelcomes on.
Depending on how well the saltdissolves, the saltwarning light maystill be oneven though the
salt container is filled.
If there is no salt warninglight in thecontrol panel (forsome Models),you canestimate when to fill
the salt into the softener bythe cycles thatthe dishwasher hasrun.
2. If thereare spills ofthe salt, a soak or arapid program shouldbe run toremove the excessive salt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and should be filled as explained
in the following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specifically designed for the use in a dishwasher, especially table salt, will
damage the water softener. Incase of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
55
B. Loading the Salt Into the SoftenerB. Loading the Salt Into the Softener
NOTE:NOTE:
1122
Full fill the salt container with water,It is normal for a small amount of water to come out of the
salt container.
11
22
A After the lower basket has been removed, unscrew and remove the cap from the salt container.
BPlace the end of the funnel (supplied) into the hole and introduce about 1.5kg of dishwasher salt.
C
D After filling the container , screw the cap tightly back clockwise.
E The salt warning light will stop being after the salt container has been filled with salt.
FImmediately after filling the salt into the salt container, a washing program should be started (We suggest to use a short
program). Otherwise the filter system, pump or other important parts of the machine may be damaged
by salty water. This is out of warranty.
OpenOpen

66
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
AdjustingRinse AidDispenser
The rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 ful l
1 / 2 ful l
1 / 4 full - Should refill to eliminate spotting
Empty
Adjust lever
(Rinse)
Adjust lever
(Rinse)
Whento Refill theRinse AidDispenser
If there is no rinse-aidwarning light inthe control panel,you can estimatethe amount fromthe colour
of the opticallevel indicator C located next tothe cap. When the rinse-aid containeris full, the whole
indicator will bedark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
NOTE:NOTE:
NOTE:NOTE:
" "
MAXMAX
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can
leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse AidDispenser
Functionof Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
C. Fill the Rinse Aid DispenserC. Fill the Rinse Aid Dispenser
C (Rinse-Aid indicator)

77
Based on theirchemical composition, detergents can be splitin two basictypes:
Detergent tablets ofdifferent brands dissolve at different speeds. For this reasonsome Detergent tabletscannot
dissolve and develop their full cleaning power during short programs. Therefore please use long programs when using
detergent tablets, to ensure thecomplete removal of detergent residuals.
The dispenser mustbe refilled before the start ofeach wash cyclefollowing the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergentswith caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is withoutphosphate. Thus the water softener function of
phosphate is notgiven. In this case werecommend to fillsalt in thesalt container evenwhen
the hardness ofwater is only 6 dH. If detergents without phosphate areused in thecase of hardwater
often white spotsappear on dishesand glasses. Inthis case pleaseadd more detergentto reach
better results. Detergentswithout chlorine doonly bleach alittle. Strong andcoloured spots willnot
be removed completely. In this case please choose a programwith a highertemperature.
Detergents
There are 3sorts of detergents
1.With phosphate and with chlorine
2.With phosphate andwithout chlorine
3.Without phosphate and without chlorine
Proper Use of Detergent
Use only detergentspecifically made forthe use indishwashers. Keep yourdetergent fresh anddry.
Don't put powdereddetergent into thedispenser until you'reready to washdishes.
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.
D. Function of DetergentD. Function of Detergent
Attention!

88
You find information about the amount of detergent for the single programme on the last page.
Please aware, thataccording to thelevel soiling and the specific hardnessof water differences are possible.
Please observe themanufacturer's recommendations onthe detergent packaging.
NOTE:NOTE:
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
WARNING!WARNING!
Amount of Detergent to Use
Fill the detergentdispenser with detergent.
The marking indicates the dosing levels , as
illustrated on theright:
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose inthe pre-wash detergent chamber. This detergent willtake effect during the pre-wash phase.
For main wash detergent
For pre-wash detergent
A
B
Fill in Detergent
AABB

5.Loading the Dishwasher Baskets5.Loading the Dishwasher Baskets
For washing in the dishwasher the following cutlery/dishesFor washing in the dishwasher the following cutlery/dishes
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or copperitems
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types ofglasses can become
dull after a large number of washes
Silver and aluminumparts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch.
Load large itemswhich are mostdifficult to clean into thelower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in theupper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow itemssuch as cups, glasses, pans etc.With the openingfacing downwards sothat
water cannot collect in the container or a deep base.
RecommendationRecommendation
Consider buying utensilswhich are identifiedas dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from thedetergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets andcutlery baskets mayvary from yourmodel.)
Scrape off any large amountsof leftover food. Soften remnants of burntfood in pans.
It is not necessary to rinse the dishes under running water.
Place objects inthe dishwasher infollowing way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items,or ones with recesses, should beloaded aslant sothat water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensilsare placed in the way that the sprayarms can rotate freely duringwashing.
NOTE:NOTE:
Very smallitems should not be washed inthe dishwasher asthey could easily fall out ofthe basket.
Attention before or after loading the Dishwasher BasketsAttention before or after loading the Dishwasher Baskets
Toprevent water dripping from the upper basket intothe lower basket,we recommend thatyou
empty the lowerbasket first and then the upperbasket.
Removing the DishesRemoving the Dishes
99

Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be remindedthat:
The Bottom Basket features folding spikes so that larger ormore pots andpans can beloaded.
The Method Loading Normal DishwareThe Method Loading Normal Dishware
Folding Spikes of Lower Basket
Lower positionLower position Upper positionUpper position
WheelsWheels
Cutlery BasketCutlery Basket
IN IN
Cutlery should be placed in the cutlery rack separately
from each other in the appropriate positions, and do
make sure the utensils do not nest together, this may
cause bad performance.
For a top quality cleaning, place the silverware in the basket
making sure that:
For a top quality cleaning, place the silverware in the basket
making sure that:
They do not nest together.They do not nest together.
Silverware is placed with the male face up.Silverware is placed with the male face up.
Long utensils in the middle.Long utensils in the middle.
The upper basketis designed tohold more delicate
and lighter dishware such as glasses, coffee and
tea cups and saucers, as well as plates, small bowls
and shallow pans(as long as they are nottoo dirty).
Position the dishes and cookware so that they will
not get moved by the spray of water.
Loading the Upper BasketLoading the Upper Basket
We suggest that you place large itemsand the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and
bowls, as shownin the figure below. It is preferable to
place serving dishesand lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Loading the Lower BasketLoading the Lower Basket
Adjusting the Upper Basket Folding back the cup shelives
The height ofthe upper basket can be adjustedin order to
create more space for large utensils both for the upper
/lower basket. The height of the upper basket can be
adjusted by placing the wheels on different height of the
rails. Long items, serving cutlery, salad servers and knives
should be placedon the shelfso that they do notobstruct
the rotation ofthe spray arms..
For better stacking of potsand pans,
the spikes can be folded down as
show in thepicture right.
For better stacking of potsand pans,
the spikes can be folded down as
show in thepicture right.
1010

6.Starting a washing program6.Starting a washing program
Turning On the ApplianceTurning On the Appliance
NOTE:NOTE:
*EN 50242 : This programme is the test cycle. The information forcomparability test
in accordance with EN 50242, as follows:
Capacity: 10 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
PI:0.49w;Po:0.45w
Wash Cycle TableWash Cycle Table
NOTE:NOTE:
Means: need to fill rinse into the Rinse-Aid Dispenser.
( )
Detergent
pre/main
Detergent
pre/main
Cycle Selection
Information
Cycle Selection
Information
ProgramProgram
Intensive
Normal
Running
time(min)
Running
time(min)
Water
(L)
Water
(L)
Energy
(Kwh)
Energy
(Kwh)
Rinse
Aid
Rinse
Aid
Description
o f Cycle
Description
o f Cycle
90 min
Glass
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
on soiling.
For normally soiled loads,
such as pots, plates,glasses
and lightly soiled pans.
For lightly soiled crockery
and glass
For lightly soiled loads that
do not need excellent drying
efficiency.
Prewash(45 )
Wash (55 )
Rinse
Rinse (65 )
Drying
165
1.4 16.5
Prewash 50
Wash 60
Rinse
Rinse
Rinse70
Drying
175
1.1
Prewash
Wash (45 )
Rinse(65 )
Drying
190
0.74 9
Wash(65 )
Rinse
Rinse (65 )
Drying
90 11. 5
1.15
Pre-wash
wash(40 )
Rinse
Rinse(60 )
Dry
125
0.75
13.5
(*EN5 0242)
This is standard programme, it is
suitable to clean normally soiled
tableware and it is the most efficient
programme in terms of its combined
energy and water consumption for
that type of tableware.
Starting a cyclewash
Draw out thelower and upperbasket, load the dishes and push them back.
It is commendedto load thelower basket first, then the upperone (see the section entitled
Loading the Dishwasher ).
Pour in thedetergent (see thesection entitled Salt, Detergent and Rinse Aid ).
Insert the pluginto the socket.The power supply is 220-240VAC /50 HZ, thespecification
of the socketis 10A 250VAC. Make sure that the water supplyis turned onto full pressure.
Close the door, press the On/Off button, and the On/Off light willturn on.
Turn the program button ,the wash programwill be changed as follows direction:
ECO->Glass->90 min->Rapid->Intensive->Normal;
If a program is selected, theresponse light willlight. Then press the Start/Pausebutton, the
dishwasher begins tostart.
1
2
3
4
5
Rapid
Ashorter wash for lightly soiled
loads and quick wash.
Wash (45 )
Rinse (50 )
Rinse (55 )
30
0.7
10
20g
(1piece)
3/22g
(1piece)
3/22g
(1piece)
3/22g
(1piece)
3/22g
(1piece)
25g
13
1111

1212
When the workingcycle has finished, the buzzer ofthe dishwasher willsound for 8 seconds, then stop.Turn off
the appliance usingthe Power switch button, shut off the water supply andopen the doorof the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
The program light is on but is not blinking, only in this case the programme has ended.
1.Switch off the dishwasherby pressing theOn/Off button.
2.Turn off the water tap!
Open the door carefully.
Hot dishes aresensitive to knocks.The dishes should therefore be allowed to cooldown around 15minutes
before removing from the appliance.
Open the dishwasher'sdoor, leaveit ajar andwait a fewminutes before removingthe dishes. Inthis way they
will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lowerbasket first andthen the upper one. This will avoid waterdripping from theupper Basket onto
the dishes in the lower one.
Change the Program...Change the Program...
Forgot to Add a Dish?Forgot to Add a Dish?
If you open the door during a wash cycle , the machine will pause. The program light will
stop blinking and the buzzer will mooing every minute unless you close the door . After
you close the door ,the machine will keep on working after 10 seconds.
NOTE:NOTE:
At the End of the Wash CycleAt the End of the Wash Cycle
Premise:
A cyclethat is underwaycan only be modified if ithas only beenrunning for ashort time. Otherwise, the
detergent may have already been released, and the appliance may have already drained the wash water.
If this is the case,the detergent dispenser must be refilled(see the section entitled " Loadingthe
Detergent " ).
Press the Start/Pausebutton , the machine will be in standbystate, press the program button morethan
3s then you can change the program to the desired cycle setting (see the section entitled " Starting a wash
cycle. . ." ).
1
22
WARNING!WARNING!
It is dangerous to open the door when washing,
because the hot water may scald you.
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
6
Press the Start/Pause Button to stop the washing.
Press the Start/Pause Button, the dishwasher will run
after 10 seconds.

The filter preventslarger remnants of food or otherobjects from gettinginside the pump.
The residues may block the filter, in this case they must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Food and soil particles trapped in this filter are pulverized by a
special jet on the lower spray arm and washed down to drain.
Larger items, suchas pieces ofbones or glass, that could block
the drain aretrapped in the coarse filter. To remove theitems
caught by thefilter, gently squeeze the tapon the topof this
filter and liftout.
This filter holds soil and food residues in the sump area and
prevents it from being deposited on the dishes during wash cycle.
Main filter 1
Coarse filter 2
Fine filter 3
2
3
1
Filter assembly
The filter efficiently removes food particles from the wash water, allowing it to be recycledduring the cycle.
For best performanceand results, the filter must becleaned regularly. For thisreason, it is a good ideato
remove the largerfood particles trapped in the filterafter each washcycle by rinsingthe semicircular filterand
cup under runningwater. Toremove the filter device, pull thecup handle inthe upward direction.
WARNING!WARNING!
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and damage dishes and utensils.


1
2
Step 1 Turn the filter in anti-clockwisedirection,
Step 2 lift the filterassy up
7.Maintenance and Cleaning7.Maintenance and Cleaning
Filtering SystemFiltering System
NOTE:NOTE:
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
1313
OpenOpen

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, usea good appliancepolish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect AgainstFreezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain thewater from the inlet pipe and water valve.(Use a panto gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove thefilter at the bottom of the tub and usea sponge to soak up waterin the sump.
please take frostprotection measures onthe dishwasher inwinter. Everytime after washing cycles,
please operate as follows
Caring for the DishwasherCaring for the Dishwasher
Cleaning the Filter
Cleaning the Door
Toclean the coarse filter and thefine filter, use a cleaningbrush. Reassemble thefilter parts as shown inthe figures
on the lastpage and reinsert the entire assemblyin the dishwasher, positioning itin its seatand pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted and the performance of the dishwasher could be decreased.
WARNING!WARNING!
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
WARNING!WARNING!
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.


Cleaning the Spray Arms
NOTE:NOTE:
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessaryto clean thespray arms regularly for hard
water chemicals willclog the sprayarm jets and bearings.
- Inspect the filters for blocking after every time the dishwasher has beenused.
- By unscrewing the coarsefilter, youcan remove thefilter system. Remove any food remnantsand
clean the filters under running water.
Remarks:
The entire filter assembly should be cleaned once a week.
NOTE:NOTE:
To remove the lower spray arm, pull out the spray arm upward.
Toremove the upper spray arm, hold the nut, rotate the arm
clockwise to removeit.
Wash the arms in soapyand warm waterand use asoft brush to
clean the jets. Replace them after rinsing them thoroughly.
1414
OpenOpen

It is recommend that you run awash cycle withthe
dishwasher empty andthen remove the plug fromthe
socket, turn off the water supply and leave the doorof
the appliance slightlyopen. This will help thedoor
seals to last longer andprevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of thefactors that causeodours to formin the
dishwasher is foodthat remains trappedin the seals.
Periodic cleaning witha damp sponge will prevent this
from occurring.
Before cleaning orperforming maintenance, always
remove the plugfrom the socket.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Only use a cloth with warm soapy water.
Toremove spots or stains from thesurface of the
interior, use a cloth dampened with water an a little
vinegar, or a cleaning product made specifically for
dishwashers.
Remove the Plug
No Solvents or Abrasive Cleaning
Moving the Appliance
Seals
How to Keep Your Dishwasher in Shape
After every wash,turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
After Every Wash When not in Use for a LongTime
1515
Electrical Requirements
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into an electrical socket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate for the plug , replace the socket, rather than using a adaptors or the like as
they could cause overheating and burns.
Electrical Connection
Insure proper ground
exists before use
Please look at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp, time delay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
Position the appliancein the desiredlocation. The back should restagainst the wall behind it, andthe sides,
along the adjacentcabinets or walls. The dishwasher is equippedwith water supply and drainhoses that can
be positioned eitherto the right or the left sides to facilitate proper installation.
Levelling the Appliance
Once the appliance is positioned for levelling, the height of the dishwasher
may be altered via adjustment of the screwing level of the feet. In any case,
the appliance should not be inclined more than 2 .
Positioning the AppliancePositioning the Appliance
About Power ConnectionAbout Power Connection
WARNING!WARNING!
For personal safety:
Do not use an extension cord or an adapter plug with this appliance.
Do not, under any circumstances, cut or remove the earthing connection
from the power cord.


8.Installation instruction8.Installation instruction

1616
Cold Water Connection
Connect the coldwater supply hose to a threaded3/4(inch) connector andmake sure
that it isfastened tightly in place.
If the waterpipes are new or have notbeen used foran extended periodof time, let the
water run tomake sure that the water isclear. This precaution is needed to avoidthe
risk of thewater inlet to be blocked anddamage the appliance.
Please close the hydrant after using.
WARNING!WARNING!
Water ConnectionWater Connection
Drain hose Connection
Insert the drainhose into adrain pipe witha minimum diameterof 40mm, orlet it runinto the sink,making sure to
avoid bending orcrimping it. The top of the hose mustbe less than1000mm.
MAX 1000mm
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
1000mm.
40mm
B
PLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, BPLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, B
