This manual contains sections of Safety
Instructions,Operating Instructions,
Installation Instructions and Troubleshooting
Tips etc. Carefully reading it before using the
dishwasher will help you to use and maintain
the dishwasher properly.
To review the section on Troubleshooting Tips
will help you to solve some common problems
by yourself and not need to ask for the help of
professional technicians.
ControlPanel........................2
DishwasherFeatures................. 2
WashCycleTable.................... 3
WaterSoftener...................... 4
Detergent...........................5
RinseAid...........................6
Loading the Dishwasher Rack . . . . . . . 7,8
Not suitable for the dishwasher
Attheendofthewashcycle............9
FilteringSystem....................10
CaringfortheDishwasher......... 11
TurningOntheAppliance..............3
.
........ 9
..
AboutElectricityconnection..........12
WaterConnection...................13
Technicalinformation................14
Beforecallingforservice.......... 15,16
Error codes........................................16
..................1
The manufacturer, following a policy of constant
development and up-dating of the product, may
make modifications without giving prior notice.
This appliance must be grounded. In the event
of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a
path of least resistance of electric current. This
appliance is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate
outlet that is installed and grounded in accordance
with all local codes and ordinances.
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service representative if you
are in doubt whether the appliance is
properly grounded. Do not modify the plug
provided with the appliance; If it is not fit
for the outlet. Have a proper outlet installed
by a qualified electrician.

1

Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren

Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.

Do not touch the heating element during or
immediately after use.

Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic
items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed
for an automatic dishwasher. Never use soap,
laundry detergent, or hand washing detergent
in your dishwasher.


During installation, the power supply must not
be excessively or dangerously bent or flattened.
The door should not be left in the open position
since this could present a tripping hazards.


Do not tamper with controls.


Do not place any heavy objects of stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Load sharp knives with the handles up to reduce
the risk of cut-type injuries.
3 Warning:Knives and other utensils with sharp points
must be loaded in the basket with their points down
or placed in a horizontal position.
)

When using your dishwasher, you should prevent
plastic item from contacting with heating element.

If the supply cord is damaged, it must be replaced
by the manufacturer or itsservice agentor a
similarly qualified person in order to avoid a
hazard.

Please dispose of packing materials properly.


Use the dishwasher only for its intended function.

Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
This appliance is not intended for use by persons
(including children ) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge ,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Dishwasher detergents are strongly alkaline,they
can be extremely dangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Children should be supervised to ensure that they
do not play with the appliance.
Check that the detergent receptable is empty after
completion of the wash cycle.




Other means for disconnection from the supply must
be incorprated in the fixed wiring with at least 3mm
contact separation in all poles.

The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should
not be reused.

The maximum number of place settings to be washed
is 12.

The maximum permissible inlet water pressure is 1Mpa.

The minimum permissible inlet water pressure is 0.04Mpa.

Do not operate your dishwasher unless all
enclosure panels are properly inplace. Open
thedoorverycarefullyifthedishwasheris
operating, there is a risk of water squirting out.
To get the best performance from your dishwasher,read all operating instructions before using it for the
first time.
2
Upper Basket
Spray Arms
Lower Basket
Water Softener
Detergent Dispenser
Silverware BasketMain Filter
Cup Shelf
5
6
7
8
Rinse Aid Dispenser
Coarse Filter
Drain pipe connector
Inlet pipe connector
9
10
12
11
3
2
14
11 12
12 3 4
5
6
7
89
6 Start / Reset Button: Press this button to start or pause the
dishwasher, the selected program indicating light will blink
when starting.
9 Power Light : To come on when the ON/OFF Button is
Press d down.e
1 Pre-rinse light: Blink during pre-rinse.
2 Wash light: wash.Blink during
3 Rinse light: rinse.Blink during
4 Drying light: drying.Blink during
5 Door Handle: Pull it to open the door.
7 Washing Program Selector: Turn the knob clockwise to
select wash cycles.
NOTE: this model hasa "brokenremember" function, which
means that power supply broken down during washing
will not reset the current washing program. So you can't
cancel a program by cutting off the power. Please
see the section entitled "change a program".
8 ON/OFF Button: To turn ON/OFF the power supply.
10
10 Salt and rinse aid warning lights: To come on when
the softener or dispenser needs to be refilled
Glass Soak
EconomyNormal
Strong
1
2
3
4
5
6
7
8
9
10
If all the lights begin to glimmer, that indicates the machine is out of order, please turn off the main power and water supply
before calling a service.
3
3
4
5
6
7
8
1
Draw out the lower and upper basket, load the dishes and
push them back. It is commended that loading the lower
basket first, then the upper one (see the section entitled
" Loading the Dishwasher " ).
Press the ON/OFF button
Turn the knob located on the right of the control panel in
the clockwise direction until the number or the symbol
for the cycle
Press the button to start the washing.
Start/Reset
When the washing is over, you can shut off the swtich by
pressing on/off button.
With a little force to ensure the door is properly closed.
NOTE: A click could be heard when the door is closed
perfectly.
2
Pour in the detergent(see the section entitled,
"Salt,DetergentandRinseAid").
Insert the plug into the socket.
The power supply is 220-240VAC 50HZ, the specification
ofthesocketis10A250VAC,Makesurethatthewater
supply is turned on to full pressure.
For normally soiled loads,
such as , plates,glasses
and lightly soiled pans.
standard daily cycle.
pots
Pre-wash
-wash
Wash (45 ℃)
Rinse (65 ℃)
Drying
Pre
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
For lightly soiled loads,such
as plates,glasses,bowls and
lightly soiled pans.
To rinse dishes that you
plan to wash later that day.
Normal
Strong
Economy
Soak
5/22 g
5/25 g
22 g
Pre-wash
-wash( 0℃
Wash (60 ℃)
Rinse
Rinse (70 ℃)
Drying
Pre 5 )
Pre-wash
The four program lights shows the state of the dishwasher:
a)All program lights off-----------------stand by
b)One of the program lights on-----------pause
c)One of the program lights blinking------run
Please press the Start/Reset button and last more than
three seconds, this will cancel the current programme.
(NOTE: turning off the appliance by pressing the on/off
button can not cancel the current programme, because
this model has a "broken remember" function.)
Turn around the to select the
desired programme.
Washing Program Selector
Press the Start/Reset button to start washing.
1
2
3
Premise
: A cycle that is underway can only be modified if it
has only been running for a short time. Otherwise, the detergent
may have already been released, and the appliance may have
already drained the wash water. I this case, the detergent
dispenser must be refilled (see the paragraph entitled " Loading
the Detergent " ).
n
NOTE: If you open the door when washing, the machine
will pause. When you close the door and press the
Start/ button, the machine will keep on working after
10 seconds.
Reset
15 g.
Pre-wash
wash (40℃)
Drying
Rinse( 65℃)
For lightly soiled loads, such
as glasses, crystal and fine
china.
Pre-wash
Wash (50 ℃)
Rinse
Rinse (65 ℃)
Drying
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower rack and should be filled as follows:
Unscrew the cap from the salt container.
There is a ring on the container with an arrow on it (see Figure to the side), if
necessary, rotate the ring in the anticlockwise direction from the "-" Setting
toward the "+" sign, based on the hardness of the water being used.It is
recommended that adjustments should be made in accordance with the following
schema:
1
2
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes
and utensils.
The appliances is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the
water.
The dishwasher is designed to allow for adjusting the amount of salt consumed based on the hardness of the water used.
This is intended to optimize and customize the level of salt consumption so that the salt consumption could be set proceed as
follows:
Remove the lower basket and then unscrew and remove the cap from the salt
container.
If you are filling the container for the first time ,fill 2/3 of its volume with water
(around 500ml).
Place the end of the funnel(supplied) into the hole and introduce about 1.2kg of
salt .It is normal for a small amount of water to come out of the salt container
Carefully screw the cap back on.
1
2
4
3
Usually, the salt warning light will be off in 2-6 days after the salt container be
filled with salt.
5
4
If your model have not water softener, you may skip this section.
1.
The salt container must be refilled when the salt warning light in the control panel comes on.
Though the salt container is filled enough, the indicator light may not black out
before the salt fully dissolve.
2.
If there is no salt warning light in the control panel (for some models) , you can judge when to load
the salt into the softener by the cycles that the dishwasher had run (see the following schema ).
If there are spills of the salt, a soak program could be run to wipe them out.
5
If the water isn't too hard, you may also prevent the formation of deposits by adding detergent.
The dispenser must be refilled before the start of each wash cycle following the instructions provided in the" Wash Cycle
Table".Your dishwashers than conventional dishwashers. Generally, only one tablespoon of
detergent is needed for a normal wash load. Also, more heavily soiled items need more detergent. Always add the detergent just
before starting dishwasher, otherwise it could get damp and will not dissolve properly.
use less detergent and rinse aid
To remove hard water spots, try the following:
Run dishes through a normal wash program.
Remove all metal dishware, such as cutlery, pans, etc.,
from the dishwasher.
Do not add detergent.
Pour two cups of vinegar into a bowl and set the bowl face
up on the lower rack of the dishwasher.
Run the dishes through a normal wash program.
If this doesn't work, try the same process with 1 / 4 cup of
citric acid crystals instead of vinegar.
Dishwasher detergent is corrosive! Take care to keep it out
of reach of children.
Use only detergent specifically made for use in dishwashers.
Keep your detergent fresh and dry. Don't put powder detergent
into the dispenser until You're ready to wash dishes.
Detergent
for pre-wash
Detergent
for main wash
Contact your local water board for information on the hardness of your watersupply.
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 - 20 60
39~8022~45 3.9~8 Mid 40 30
>80>45 >8 +60 20
fH
0~10
10~28
28~56
>56
Clark
°Clark: British degree
°fH : French degree
°dH : German degree
Note:1 °dH=1.25 °Clark=1.78 °fH=0.178mmol/l
WATER HARDNESS
Selector Position Salt consumption
(gram/cycle)
Auto nomy
(cycles/1.2kgs)
To open the dispenser, turn the cap to the "open" (left)
arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to
overfill.
Replace the cap by inserting it aligned with "open" arrow
and turning it to the closed (right) arrow.
A measured amount of rinse aid is released during the final rinse. As with detergent, the amount
of rinse aid needed for your dishes depends on the hardness of the water in your area. Too much
rinse aid can result in lather of foaming and cause cloudiness or steaks on your dishes. If the
water in your area is very soft, you may not need rinse aid. If you do,you can dilute the rinse aid
with an equal amount of water.
The rinse aid dispenser has six or four settings. Always start with the dispenser set on " 2 ". If
spots and poor drying are problems, increase the amount of rinse aid dispensed by removing the
dispenserlid and rotating the dial to "3". If the dishes still are not drying properly or are spotted,
adjust thedial to the next higher number until your dishes are spot-free. We suggest you
to set on "4" .(Factory value is "4".)
The rinse aid is released during the final rinse to prevent water
from forming droplets on your dishes that can leave spots and
streaks. It also improves drying by allowing water to "sheet" off
the dishes.
Your dishwashers are designed to use liquid rinse aids. The
rinse aid dispenser is located inside the door next to the
detergent dispenser. To fill the dispenser, open the cap and
pour the rinse aid into the dispenser until the level indicator
turns completely black. The volume of the rinse aid container is
about 140ml.
Be careful not to overfill the dispenser, because this could
cause oversudsing. Wipe away any spills with a damp cloth.
Don't forget to replace the cap before you close the dishwasher
door.
If you have soft water, you may not need rinse aid for it may
cause a white film to develop on your dishes.
If there is no rinse aid warning light in the control panel, you can judge the amount of rinseaid by the following means. The
black dot on the rinse aid dispenser indicates the amount of rinse aid in the dispenser. As the rinse aid diminishes, the size of
the black dot decreases. You should never let the rinse aid get below 1 / 4 full.
As the rinse aid diminishes, the size of the black dot on the rinse
aid level indicator changes, as illustrated below.
Full
3/4full
1/2full
1 / 4 full - Should refill to eliminate spotting
Empty
6
7
The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cup and saucers, as well
as plates, small bowls and shallow pans(as long as they are not too dirty).
Position the dishes and cookware so that they do not get moved by the spray of water.
If required,the height of the upper rack can be adjuested in order to creat more space for large utensils either in the upper rack
or lower rack.
Long items,serving cutlery,salad servers or knives should be placed on the shelf so that they do not obstruct the rotation of the
spray arms. The shelf can be folded back or removed when not required for use.
The upper rack can be adjusted for height by putting wheels of different height into the rails.
Scrape off any large amounts of left-over food. It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way
1.Items such as cups, glasses, pots/pans, etc. are stood upside down.
2.Curve items, or those with recesses, should be at a slant so that water can run off.
3.They are stacked securely and cannot tip over.
4.They do not prevent the spray arms from rotating while washing takes place.
Very small items should not be washed in the dishwasher as they could easily fall out of the racks
Removing the dishes
To prevent water dripping from the upper back onto the dishes in the lower back, we recommend that you empty the lower basket first
and then the upper back..
6
5
5
1
Cups
2
Small serving bowl
3
Large serving bowl
4
Glasses
Saucers
5
6
Dish
Dessert dishes
3
4
1
7
7
4
2
1
1
