Powersmart SF7A501 User manual

INSTRUCTION MANUAL
Electric Blower
Item: PS8216
Model # SF7A501
Have product questions or need technical support? Please feel free to contact us!
Website: www.Amerisuninc.com
Toll free: 1-800-791-9458 M-F 9-5 EST
Email: [email protected]

2

3
CONTENTS
Technical data…...………………………………………………………... 3
General safety rules…….……………………………………………….... 4
Electrical information…………………………………………………….. 6
Symbols………………………………………………………………….. 7
Knowing your blower……. ..…………………………………………… 9
Assembly instruction……………………………………………………… 10
Operating instruction…………………………………………………...... 10
Maintenance.……………………………………………………………… 12
Troubleshooting…………………………………………………………. 12
Exploded view & parts list……………………………………………… 13
Warranty………………………………………………………………… 15
TECHNICAL DATA
7.5A Electric Blower Item: PS8216
Motor: 120V, 60Hz, 7.5A
Blower speed: 186MPH
No-load speed: 15500 RPM
Air volume: 184 CFM
Package dimensions (L x W x H): 14.2 x7.5 x11.8 inches
Weight: 6.27 lb.
Warning! We strongly recommend that this item not be modified and/or used for any application
other than that for which it was designed. If you have any questions relative to its application, do not
use the equipment until you have consulted us and we have advised you.
Contact PowerSmart at [phone] M-F 9am-5pm EST
Thank you for purchasing PowerSmart products. Please register online at
www. Amerisuninc.com.
The information will allow us to track your warranty and update on your unit.
Important: Our company does not provide email or personal information to any third party for any
reason. For any questions check our website or call customer service at [phone].

4
GENERAL SAFETY RULES
Safety is a combination of common sense, staying alert, and knowing how your blower works.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING: Do not operate this unit until you read this instruction manual for safety,
operation and maintenance instructions. Failure to follow all instructions listed below may
result in electric shock, fire, and/or serious personal injury.
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Do not allow children or untrained individuals to use this unit.
Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
Do not handle plug or tool with wet hands.
Never allow children to operate the equipment. Never allow adults to operate the equipment without
proper instruction.
Always wear safety glasses with side shields that comply with ANSI Z87.1. Everyday glasses have
only impact resistant lenses. They are NOT safety glasses. Following this rule will reduce the risk of
eye injury. Use face mask if operation is dusty.
Wear eye protection when operating this product. Secure long hair above shoulder level to prevent
entanglement in moving parts.
Use extra care when cleaning on stairs.
Do not expose to rain, store indoors.
Do not operate in poor lighting.
Keep all parts of your body away from any moving part.
Keep hair, loose clothing, fingers and all body parts away from openings and moving parts.
Wear heavy long pants, boots, and gloves. Avoid loose garments and jewelry that could get caught
in moving parts of the machine or its motor.
Do not force tool. Use the correct tool for your application. The correct tool will do the job better and
safer at the rate for which it is designed.
Do not operate the equipment while barefoot or when wearing sandals or similar lightweight
footwear. Wear protective footwear that will protect your feet and improve your footing on slippery
surfaces.
Secure long hair so it is above shoulder level to prevent entanglement in any moving parts.
Keep firm footing and balance. Do not overreach. Overreaching can result in loss of balance.
Do not allow to be used as a toy. Close attention is necessary when used by or near children.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled with the switch
is dangerous and must be repaired.
Keep all bystanders, children, and pets at least 50 ft. away.

5
Do not operate this unit when you are tired, ill, or under the influence of alcohol, drugs, or
medication.
Keep all parts of your body away from any moving parts and all hot surfaces of the unit.
Do not put any object into openings. Do not use with any opening blocked; keep openings free of
dust, lint, hair, and anything that may reduce air flow.
Check the work area before each use. Remove all objects such as rocks, broken glass, nails, wire, or
string which can be thrown or become entangled in the machine.
Use only identical manufacturer’s replacement parts and accessories. Use of any other parts may
create a hazard or cause product damage.
For household use only.
Disconnect appliance from power source before servicing, cleaning or removing material from the
gardening appliance.
Store idle appliances - When not in use, blower should be stored indoors in a dry, locked place out of
the reach of children.
If the power supply cord is damaged, it must be replaced only by the manufacturer or by an
authorized service center to avoid risk.
Do not point the blower nozzle in the direction of people or pets.
Never run the unit without the proper equipment attached. Always ensure the sweeper tubes are
installed.
Maintain tool with care. Keep fan area clean for best and safest performance. Follow instructions for
proper maintenance. Do not attempt to clear clogs from tool without first disconnect from the
electrical power source.
To reduce the risk of electrical shock, do not expose to rain, do not use on wet surfaces. Store
indoors.
Save these instructions. Refer to them frequently and use them to instruct others who may use this
power tool. If you loan someone this power tool, loan them these instructions also.
To reduce the risk of electric shock – Use outdoor extension cords marked SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJTW-A. or SJTOW-A. These cords are rated for outdoor use and reduce the
risk of electric shock.
CHILD SAFETY
Tragic accidents can occur if the operator is not aware of the presence of children.
Keep children out of the working area and under the watchful care of a responsible adult.
Do not allow children under the age of 14 to operate this blower. Children who are 14 years of age
and older must read and understand the operating instructions and safety rules in this manual and
must be trained and supervised by a parent.
Stay alert and turn the blower off if a child or any other person enters the working area.
Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may
obscure your view of a child who may run into the path of the blower.

6
WARNING:
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
•Lead from lead-based paints,
•Crystalline silica from bricks and cement and other masonry products, and
•Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemical: work in a well-ventilated area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter out microscopic particles.
SAVE THESE INSTRUCTIONS
ELECTRICAL INFORMATION
Guidelines for using extension cords
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one
heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating. The table below shows the correct size to be used
according to cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
Minimum Gauge for Extension Cords (AWG)
(When using 120 V only)
Ampere Rating
Total Length of Cord in feet
More Than
Not More Than
25
50
100
150
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Recommended
Make sure your extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it.
Protect your extension cords from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be
protected with a 15 A time-delayed fuse. Before connecting the motor to the power line, make sure the
switch is in the OFF position and the electric current is rated the same as the current stamped on the motor
nameplate. Running at a lower voltage will damage the motor.
WARNING: Do not expose to rain or use in damp locations.
SYMBOLS

7
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL
NAME
DESIGNATION/EXPLANATION
V
Volts
Voltage
A
Amperes
Current
Hz
Hertz
Frequency (cycles per second)
W
Watts
Power
min
Minutes
Time
Safety Alert
Precautions that involve your safety.
Read the user’s
manual
To reduce the risk of injury, user must read and understand user’s
manual before using this product.
Eye protection
Wear eye protection that is marked to comply with ANSI Z87.1 when
operating this equipment.
Wet conditions
alert
Do not expose to rain or use in damp locations.
Long hair
Failure to keep long hair away from the air inlet could result in personal
injury.
Loose clothing
Failure to keep loose clothing from being drawn into air intake could
result in personal injury.
Keep Bystanders
away
Keep all bystanders at least 50 ft. away.
Blower tubes
Do not operate without tubes in place.
Electric shock
alert
Beware of electric shock hazard.
The following signal words and meanings are intended to explain the levels of risk associated with this
product.

8
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualified service
technician. For service we suggest you return the product to your nearest AUTHORIZED SERVICE
CENTER for repair. When servicing, use only identical replacement parts.
WARNING: To avoid serious personal injury, do not attempt to use this product until you
have read this Owner's Manual thoroughly and understand it completely. If you do not
understand the warnings and instructions in this Owner's Manual, do not use this product. Call
the Toll-free Helpline (1-800-791-9458) for assistance.
WARNING:
The operation of any power tool can result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning power tool operation, always wear
safety goggles or safety glasses with side shields and, when needed, a full face shield. We
recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is marked to comply with ANSI Z87.1.

9
KNOWING YOUR BLOWER
Unpacking
Unpack the blower and all its parts, and compare against the list below. Do not discard the carton or any
packaging materials. Please call 1-800-791-91458 or E-mail us at [email protected] if any parts
are damaged or missing.
Including:
Blower
User manual
Blower tube
ASSEMBLY INSTRUCTIONS
A
Blower small tube
B
Handle
C
E
On/Off trigger switch
Blower big tube
D
F
Power cord
Cord retainer
D
A
B
C
E
ON
OFF
F

10
WARNING! To avoid serious personal injury, read and understand all safety instructions
provided.
WARNING! Do not connect to power supply until assembly is complete. Failure to comply
could result in accidental starting and possible serious personal injury.
WARNING! Before performing any maintenance, make sure the tool is unplugged from the
power supply. Failure to heed this warning could result in serious personal injury.
INSTALLING THE BLOWER TUBE
Slide the small tube (C) over the big tube (B) until the latch on the big tube is inserted into the end
of the opening on the small tube and locks into position (See fig.1)
Align the widest end of the big tube (B) with the front opening on the blower (A). (See fig 2)
OPERATING INSTRUCTIONS
WARNING: Read and thoroughly understand all instructions and safety information before
operating this blower. Failure to do so may cause serious injury or death. Do not allow anyone
to operate this blower who has not read this manual. a blower can be dangerous if assembled or
used improperly. Do not operate this blower if you have doubts or questions concerning safe operation.
Call our customer service department at 1-800-791-9458 to address these concerns.
WARNING: Flying debris can cause serious personal injury to the operator, bystanders or
pets. Keep bystanders and pets at least 50ft away from the area of work and always wear
suitable eye and ear protection, long pants and sturdy shoes or boots while operating the tool.
CONNECTING TO A POWER SOURCE
Fig. 1
C
B
Fig. 2
B
A

11
WARNING: A damaged extension cord can cause electric shock or a fire. Please inspect the
extension cord periodically. The tool must not be used if the cord is damaged in any way.
Replace a damaged extension cord before use.
1. Use a heavy duty extension cord, suitable for outdoor use and so marked. An ordinary duty extension
cord will cause loss of power and may overheat.
2. Keep the extension cord behind you, away from the area of operation.
3. Secure the extension cord to the motor housing using the cord retainer
located at the rear of the blower. Securing the extension cord in this
manner prevents accidental removal of the electrical cord during
operation.(See fig 3)
4. Plug the end of the electrical cord into the receptacle at the back of the
unit.
STARTING/STOPPING THE BLOWER
Connect an outdoor use extension cord to the polarized plug
on the rear of the blower. Follow the instructions for locking
extension cord to cord retainer. (See fig 3)
To start the electric blower, move the ON/OFF switch
to the (l) position. (See fig 4)
To switch off, move the switch to the (0) position. (See fig 4)
WARNING:
The tool runs for approximately 5 seconds after it has been switched off. Let the motor come
to a complete standstill before setting the tool down.
OPERATIONAL GUIDELINES
Hold the blower tube approximately 7” above the ground and turn the switch to the on position to
start. In a sweeping motion, move the blower side-to-side, advancing slowly keeping the leaves,
grass etc. in front of you
Always blow around the outer edges of a debris pile. Never blow directly into the middle of a pile.
Loosen the debris pile using a broom or rake before blowing. If pile is dusty, slightly dampen the pile
to limit airborne dust.
Always wear safety glasses to prevent rocks or solid debris from being blown ricocheting into the
eyes and face which can cause serious injury.
Always work away from solid objects such as large stones, cars and fences.
Be careful around flower beds, the force of the air could damage them.
Fig. 3
Fig. 4
ON
OFF

12
MAINTENANCE
WARNING:
In order to avoid personal injury and the risk of fire and electric shock, disconnect the
appliance from the power supply before adjusting, inspecting, or cleaning the blower.
WARNING:
All repairs, electrical or mechanical, should be attempted only by trained repairmen. Use only
identical replacement parts, any other may create a hazard. If the power plug is worn or
damaged in any way, have it replaced immediately.
CLEANING AND STORAGE
Disconnect the extension cord before performing any maintenance task or storing.
Store the tool, instruction manual and accessories in a secure, dry place. In this way you will always
have the information ready by hand.
Keep the tool’s air intake unclogged and clean at all times.
Remove dust and dirt regularly. Cleaning is best done with a rag or brush.
Never use caustic agents to clean plastic parts.
WARNING:
Do not use cleaning agents to clean the plastic parts of the tool. A mild detergent on a damp
cloth is recommended. Water must never come into contact with the tool.
TROUBLE SHOOTING
The following form lists the common operating system with problem and solutions. Please read the form
carefully and follow it.
WARNING: Always unplug the power cord before performing any adjustments,
maintenance, or repairs to your electric blower.
PROBLEMS
POSSIBLE CAUSES
SOLUTION
Motor fails to start when
Switch is turned on.
1. Power cord is not plugged in or
connection is loose
2. Household circuit breaker is
tripped.
1.Plug in the power cord.
2.Check circuit breaker.
Unit will not blow Blocked tube Clear the blockage.
EXPLODED VIEW & PARTS LIST

13

14
Item Stock# Description Qty
1 PS8216-001 Switch 1
2 PS8216-002 Capacitance 1
3 PS8216-003 Left housing 1
4 PS8216-004 Press plate 1
5 PS8216-005 Screw 4x12 2
6 PS8216-006 Power cord cover 1
7 PS8216-007 Power cord 1
8 PS8216-008 Carbon brush 2
9 PS8216-009 Brush holder 2
10 PS8216-010 Motor holder 1
11
PS8216-011
Connection wire
2
12
PS8216-012
Nut
2
13
PS8216-013
Bearing
2
14 PS8216-014 Stator 1
15 PS8216-015 Stator bolt 4x60 2
16
PS8216-016
Rotor
1
17
PS8216-017
Front holder
1
18 PS8216-018 Impeller part 1
19
PS8216-019
Impeller
1
20 PS8216-020 Nut M8 1
21 PS8216-021 Nut cover 1
22 PS8216-022 Connection wire 1
23 PS8216-023 Connection wire 1
24 PS8216-024 Screw 4x14 13
25
PS8216-025
Right housing
1
26 PS8216-026 Shock pad 2
27 PS8216-027 Small tube 1
28 PS8216-028 Big tube 1
29 PS8216-029 Connection tube 1

15
TWO (2) YEARS LIMITED WARRANTY
PowerSmart®is committed to building tools that are dependable for years. Our warranties are consistent with our
commitment and dedication to quality.
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE.
PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be
free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days
for all Power Smart Products, if the tool is used for professional or commercial use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Two (2) Years Limited
Warranty and, to the extent permitted by law, any warranty or condition implied by law, shall be the repair or
replacement of parts, without charge, which are defective in material or workmanship and which have not been
misused, carelessly handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a
claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to Power
Smart Include a legible copyof the original receipt, which lists the date of purchase (month and year) and the name
of the company purchased from.
THIS LIMITED WARRANTY DOES NOT APPLY TO ANY ACCESSORY ITEMS INCLUDED WITH THE
TOOL SUCH AS CIRCULAR SAW BLADES OTHER RELATED ITEMS OR TO ANY REPLACEMENT
PARTS LISTED UNDER MAINTENANCE.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO TWO (2) YEARS FROM DATE OF
PURCHASE. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE
OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN
CANADA AND FROM COUNTRY TO COUNTRY.
For questions / comments, technical assistance or repair parts –
Please call toll free at: 1-800-791-9458 (M-F 9am – 5pm EST)
Email: [e-mail]
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
