PowerWatch 2 Series User manual

USER
MANUAL

1
TABLE OF CONTENTS
Keys 2
Initial Setup 4
Power Off and Factory Reset 6
Navigating from the Home Screen 8
Read Notications 9
Status Widgets 11
Start an Activity 14
Thermoelectric Power 17
Charging the Battery 18
Regulatory Statements 20
E-Label 23
User Manual Series 2

3
User Manual Series 2 PW07
BACK
Go back to the
previous screen.
SELECT
Select options.
2
KEYS
Alternate Key FunctionsKey Functions
Enter Widgets Mode from the home screen.
Turn the watch on and o from the menu.
Enter Activity Mode from the home screen.
Hold for 3 seconds to turn the backlight on and o.
Hold both buttons for 7 seconds to turn on the
watch for the first time.
Enter Notification Mode from the home screen.
Notification
Airplane Mode On /
Bluetooth Mode O
Do Not Disturb Mode
GPS Signal Strength
Status Icons
UP
Scroll up through the
widgets, data screens,
options, and settings.
DOWN
Scroll down through
the widgets, data
screens, options, and
settings.

54
User Manual Series 2 PW07
Turn on the Watch
INITIAL SETUP
Press and hold DOWN and BACK for 7 seconds to turn the watch on. This
only applies to turning on the watch for the first time.
When the watch is powered on, it will display the logo splash screen.
Release the buttons when the splash screen appears.
Pair with Smartphone
Only applicable for initial set up. If the watch has been previously paired,
this step will be automatically skipped.
N
25
75
50
N
25
75
50
After the watch is powered on, a screen with a QR code will be displayed.
Scan the QR code using a smartphone and the pairing screen will appear.
4595
N
25
75
50

76
User Manual Series 2 PW07
N
25
75
50
N
25
75
50
N
25
75
50
N
25
75
50
Power off
The watch can be powered o in
two ways:
Soft Power-off
1. Use UP and DOWN to scroll
through the widgets to the
settings menu.
2. Press SELECT to enter the
settings menu.
3. Use DOWN to scroll through
to the “Power O” option.
4. Press SELECT to power o.
Hard (Forced) Power-off
The watch can be powered o in
any state by pressing and holding
buttons DOWN and BACK for 7
seconds.
POWER OFF AND FACTORY RESET
Factory Reset
A factory reset removes all installed
apps, clears custom settings,
and restores the watch to its
factory default settings.
1. Press DOWN to scroll through the
widgets to the settings menu.
2. Press SELECT to enter the
settings menu.
3. Press DOWN to scroll through to
the “Reset” option.
4. Press SELECT to reset.

98
User Manual Series 2 PW07
NAVIGATING FROM THE HOME SCREEN
N
25
75
50
N
25
75
50
READ NOTIFICATIONS
Enter Notication Mode
Push UP to enter the Notification
Mode.
Push UP or DOWN to scroll through
notifications.
Push SELECT to take actions for
each notification.
BACK
Go back to the
previous screen.
SELECT
Start an Activity
Walk, run, cycle, etc.
UP
Read Notications
e.g. Reply to messages
or reminders.
DOWN
Status Widgets
e.g. Steps, heart rate,
sleep, calories, and
settings.

1110
User Manual Series 2 PW07
N
25
75
50
N
25
75
50
Take Actions within Notication Mode
Push BACK to return to the
previous screen.
Push UP or DOWN to scroll through
action options.
Push SELECT to choose an action
option.
N
25
75
50
STATUS WIDGETS
N
25
75
50
Push DOWN to start checking user
status.
Push UP or DOWN to scroll through
widgets.
Push BACK to return to the home
screen.
Push SELECT to check detailed
stats.

1312
User Manual Series 2 PW07
STATUS WIDGETS continued
N
25
75
50
N
25
75
50
Push UP or DOWN to scroll through
detailed stats.
Push BACK to return to status
widgets.
Widget Guide
TIME
HEART RATE
STEPS
SLEEP TRACKER SETTINGS
CALORIES

1514
User Manual Series 2 PW07
N
25
75
50
N
25
75
50
N
25
75
50
Push SELECT to enter
and exit an Activity
Mode.
Push UP or DOWN to
scroll through Activity
Modes.
Push SELECT to enter
an activity.
Enter and Choose an Activity Mode
START AN ACTIVITY
Push SELECT to start and pause an
activity.
Push BACK to return to the
previous mode.
Settings within an Activity Mode
N
25
75
50
N
25
75
50

1716
User Manual Series 2 PW07
N
25
75
50
Push UP or DOWN to scroll through
the parameters.
Push BACK to return to the
previous screen.
Settings within the Activity Mode Continued
N
25
75
50
THERMOELECTRIC POWER
The PowerWatch requires a temperature dierential with the ambient
air to charge its internal battery. It generates more power when the air is
cooler and when your skin is warmer from being active. The chart below
shows how fast the PowerWatch charges its internal battery at dierent
air temperatures.
The PowerWatch charges its battery the fastest when you are active
(walking or running), and when the ambient temperature is below
80°F (26°C). Above 90°F (32°C), the PowerWatch cannot charge its
internal battery.
Air Temperature
Sitting Quickly
60°
Slowly
70°
No
80°
SlowlyQuickly
Very Quickly Quickly
Very Quickly
Very Quickly
Walking
Running

1918
User Manual Series 2 PW07
GPS & Battery Life
GPS should only be used for 30 minutes per day; otherwise, it will slowly
deplete the battery.
The battery can store GPS minutes that are not used one day to roll over
to another day (e.g. if the GPS is not used at all one day, the next day you
can use the GPS for up to an hour).
The solar cell generates up to 1000x more power with direct sunlight than
with dim indoor light.
Solar Power
Matrix oers a thermal charging pad as backup
solution. To use the charging pad:
1. Place the charging pad on a flat surface.
2. Plug it into the power adapter.
3. Plug the adapter into a power outlet.
4. The wireless charging pad contains magnets
that automatically align to the watch when
properly positioned.
LED Indicator
Triple-Blink Yellow Initializing
Solid Green Charging
Solid Yellow Fully charged
Blinking Red Not charging
Caution: Use only PowerWatch-approved chargers, batteries, and
cables. Unapproved chargers or cables can cause damage or make
the battery explode.
Use the supplied wireless charging dock and charger. PowerWatch
cannot be charged properly with a third-party charger.
Connecting the charger improperly may cause serious damage to
the device. Any damage caused by misuse is not covered by the
warranty.
CHARGING THE BATTERY

2120
User Manual Series 2User Manual Series 2 PW07
REG ULATORY STATEME NTS
US
FCC STATEMENT
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
NOTE 1: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet
on a circuit dierent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
NOTE 2: Any changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user’s authority to
operate the equipment.
CANADA
IC STATEMENT
Model Name/Product Market Name: PowerWatch
Series 2
This device complies with Industry Canada
licence-exempt RSS standard(s): Operation is
subject to the following Two conditions:(1) this
device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
Nom du modèle / Nom du produit du marché:
PowerWatch Series 2
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
CHINA
a) Manufacturer’s name: Matrix Industries Inc.
b) Manufacturer’s name & address: Matrix
Industries Inc. 1455 Adams Drive, Suite 1190 Menlo
Park, CA 94025 USA
c) Model Name/Product Market Name:
PowerWatch Series 2
EU
1. Safety
a) Product Type: Short range device
b) Software version: PowerWatch 2 Android App
v3.00.00; PowerWatch 2 IOS App v3.00.00
c) Number of equipment and key component
in the DOC is 2: PowerWatch Series 2 and
TC03(Wireless Thermal Charger)
d) Rated Voltage: 3.85V DC, Battery Type:
Lithium-ion Polymer (3.85V, 350mAh)
e) Model Name/Product Market Name:
PowerWatch Series 2
f) Made in China
g) Operation Temperature: -10oC to 45oC max
h) 20 ATM
i) Manufacturer’s name: Matrix Industries Inc.
j) Manufacturer’s name & address: Matrix
Industries Inc. 1455 Adams Drive, Suite 1190 Menlo
Park, CA 94025 USA
k) Importer Name: Matrix Industries Inc. Address
is: Nijverheidsweg 27, 3274 KJ Heinenoord
0186-612267, The Netherlands .VAT number is
NL825573026B01.
2. RF & EMC
CE-RED Requirement
1) Accessory: wireless charging pad model name:
TC03. Operation freq.: 150KHz. Operation power:
2.5W. Operation voltage: 5V
Maximum transmit power of WPT is -5dBuA/
m@10m.
2) Frequency band(s) = 2402-2480MHzlable
3) Maximum radio frequency power transmitted
in the frequency band(s) = 4dBm or 2.5mW
5) Declaration of Conformity Inserts:
Hereby, Matrix Industries Inc, declares that the
radio equipment type [designation of type of
radio equipment] is in
compliance with Directive 2014/53/EU. The
full text of the EU declaration of conformity is
available at the followinginternetaddress: www.
powerwatch.com/declaration.pdf
7) This equipment may be operated in:
RUNNINGMODE STOPWATCH SYNCDATATOYOURSMARTPHONE AUTOSLEEPTRACKING NOTIFICATIONS
The PowerWatch X can track each run you take.
1. Press MODE until Running Mode screen appears.
2. Press SET to cycle through Start, Stop and Reset.
1. Press MODE until Stop Watch screen appears.
2. Press SET to cycle through Start, Stop and Reset
1. While under the Watch Settings menu, SCROLL until
the Mobile screen appears.
2. Press SET to sync.
See https://store.powerwatch.com/pages/f-a-q for more details. Display may update slowly, but Stop Watch result is accurate.See https://store.powerwatch.com/pages/f-a-q for more details.
The PowerWatch X automatically senses when you sleep
and wake.
1. Press MODE until Daily Activity screen appears.
2. Turn SCROLL to read Today’s Sleep data.
Incoming call
Activity goal met
Message received
Alarm ringing
1 1 112 2 22
REGULATORYSTATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the manufacturer responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
EUROPE (EU)
1.Safety:
a) Rated Voltage: 3.8V DC, 105mA
Battery Type: Lithium-ion Polymer (3.8V, 210mAh)
b) Model Name: PowerWatch X
Operation Temperature: 45C max
c)
d) Manufacturer’s name: Matrix Industries Inc
e) Manufacturer name & address: Matrix Industries
Inc. 1455 Adams Drive, Suite 1190 Menlo Park,
CA 94025 USA
f)
CANADA
This device complies with Industry Canada’s licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device
must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes : (1) l’appareil ne doit
pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
JAPAN
CHINA
2. RF & EMC
• Frequency band(s) = 2402-2480MHz
• Maximum radio frequency power transmitted in
the frequency band(s) = -5.58dBm
• Declaration of Conformity Inserts
• Hereby, Matrix Industries Inc, declares that the
radio equipment type is in compliance with Directive
2014/53/EU. The declaration of conformity may be
consulted at www.powerwatch.com/declaration.pdf
• This equipment may be operated in:
Manufacturer’s name: Matrix Industries Inc.
FCC ID: 2ANY2MPW05
SUPPORT
Our Frequently Asked Questions (FAQ) page is lled
with detailed instructions, tips and warranty information:
https://store.powerwatch.com/pages/f-a-q
The Matrix PowerWatch X does not need charging under
normal use, which includes: adjusting the watch so it
stays in direct contact with the user’s wrist; limiting
Bluetooth and backlight activity while the watch is worn
on the user’s wrist; and not activating the watch
unnecessarily or repeatedly when it is not worn on the
user’s wrist. PowerWatch X rmware can be updated
through the app.
One Year Satisfaction Guarantee
See the FAQ and guarantee at
https://store.powerwatch.com/pages/f-a-q.
For questions or problems, contact us at
[email protected]. Thank you!
TAIWAN
a) Manufacturer’s name: Matrix Industries Inc.
b) Manufacturer’s name & address: Matrix
Industries Inc. 1455 Adams Drive, Suite 1190 Menlo
CAUTION
RISK OF EXPLOSION IF BATTERY US REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS

2322
User Manual Series 2User Manual Series 2 PW07
Park, CA 94025 USA
c) Model Name/Product Market Name:
PowerWatch Series 2
低功率電波輻射性電機管理辦法
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、
商號或使用者均不得擅自變更頻率、加大功率或變更原
設計特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通
信；經發現有干擾現象時，應立即停用，並改善至無干
擾時方得繼續使用。前項合法通信，指依電信法規定作
業之無線電通信。低功率射頻電機須忍受合法通信或工
業、科學及醫療用電波輻射性電機設備之干擾。
Low power radio wave radiating motor
management method
Article 12
A low-power RF motor that has passed the type
approval shall not change the frequency, increase
the power or change the original design features
and functions without permission.
Article 14
The use of low-power RF motors shall not
aect flight safety and interfere with legal
communications; if interference is found, it shall
be immediately deactivated and improved until
no interference is required. Legal communication
in the preceding paragraph refers to radio
communication operating in accordance with the
provisions of the Telecommunications Act. Low-
power RF motors must withstand interference
from legitimate communications or radiological
electrical equipment for industrial, scientific, and
medical use
JAPAN INDONESIA
THAILAND
“This telecom device and equipment is conformed
to requirement to NTC”
203-JN1005
RUSSIA VIETNAM
MALAYSIA
INDIA
PHILIPPINES
Please go to the settings menu on the device to view the E-label screen.
E-LABEL
