Powerwerx Wouxun DB-16X User manual

Wouxun DB-16X
Dual-Band Two-Way Radio
Instruction Sheet
SUPPLIED IN THE BOX:
• FM Dual-band Transceiver
• Extended life Li-ion battery pack (1700 mAh)
• Dual-band Antenna
• Belt Clip
• Desktop Rapid Charger (charges in 1~3.5 hours)
• Handstrap
INSTALLING THE BATTERY AND ANTENNA
First, match the guides on the bottom of the battery pack with the back side
bottom of the radio. Press on the battery as it will latch as you press downward.
(Press down on each side of the battery to release). Screw in the supplied
antenna into the top of the radio.
TURNING RADIO ON / OFF
Turn the top knob clockwise to turn radio ON. Turn this same knob counter-
clockwise to turn the radio OFF.
SPEAKER VOLUME ADJUSTMENT
Turn the top knob clockwise to adjust the radio volume higher. Turn this same
knob counter-clockwise to adjust the radio volume lower.
CHANNEL SELECTION
Turn the top mounted channel selector to the desired channel. Built-in voice will
announce the channel number as you rotate this knob.
PTT - PUSH TO TALK BUTTON
Press this key to transmit and release to listen.
FLASHLIGHT
Momentary press the bottom side monitor key (short press) to turn ON/OFF
Flashlight feature.
MONITOR KEY
Press and hold the monitor key for 2 seconds to turn ON or OFF the radio
squelch to listen without the tone squelch function.
This Wouxun radio is warranted against failure due to defects in workmanship or
materials for 12 months from the date of purchase from Powerwerx or an authorized
Powerwerx dealer. The included radio battery and battery charger are warranted against
failure due to defects in workmanship or materials for 6 months from the date of purchase
from Powerwerx or an authorized Powerwerx dealer. If purchased from an authorized
Powerwerx dealer the item must be returned with a copy of the original sales receipt
or proof of purchase. Warranty does not include other accessories, antennas or knobs.
Warranty does not cover damage caused by abuse, accident, misuse, improper or
abnormal usage, failure to follow instructions, improper installation, alteration, moisture,
water, lightning, or other incidence of excessive voltage or current. If failure occurs within
this period, return the radio to Powerwerx at your shipping expense with a full explanation,
return address and necessary proof of purchase. The device or accessory will be repaired
or replaced, at our option, without charge, and returned to you at our shipping expense.
Repaired or replaced items are warranted for the remainder of the original warranty
period. Powerwerx shall have no liability or responsibility to customer or any other person
or entity with respect to any liability, loss, or damage.
Revised 4-19-2013
Powerwerx, Inc.
263 N Berry St
Brea, CA 92821
Phone: [phone]
Fax: [phone]
www.powerwerx.com Getting Started
Congratulations on buying the model DB-16X Dual-band radio which is ideal
for resturants, retail, schools and the hospitality industries. This two-way radio
offers many features that can be dealer programmed depending on your
requirements.
DB-16X HANDHELD FEATURES:
• FCC 2013 Narrowband Compliant w/ 2.5 KHz Channel step
• Frequency Range: Dual-band 136-174 / 406-512 MHz
• 16 Channels (pre-programmed w/ 14 UHF & 2 VHF Channels)
• Power Output: VHF: 5W High / 1W Low UHF: 4W High / 1W Low
• 16 Hours of operation: (85% Standby / 10% RX / 5% TX on low power)
• Channel Number and Low Battery Voice Announcement
• Built in Flashlight, VOX Operation
Powerwerx Limited Warranty Policy
4

HI / LOW POWER SELECTION
Press and hold PTT (transmit) button and then momentary press the bottom
side monitor key to select HI / LOW Power. 2 LED ashes is Hi power, 1 ash is
low power. Changing channels puts power selection back to the default.
BATTERY LEVEL (CAPACITY) DISPLAY
Turn the radio OFF. Wait 2 seconds, then turn radio ON.
• Green light ashes (4) times.....Battery is full (80-100%)
• Green light ashes (3) times.....Battery is medium (60-80%)
• Green light ashes (2) times.....Battery is low (40-60%)
• Green light ashes (1) time.......Battery needs recharging (20-40%)
• Red light ashes (4) times.........Battery empty (0-20%) No Tx possible
BATTERY CHARGER OPERATION
Connect to AC power cord into the back of the charging base. Plug in the AC
cord into a standard wall outlet. Place the radio or battery into the charger cup.
Please refer to the battery charger status lights below.
Flashing Red Light.......................... Deep Battery Charging (3 1/2 hours)
Solid Red Light............................... Regular Battery Charging (1/2 to 3 hours)
Green Light..................................... Battery Fully Charged - Ready to use
PRE-PROGRAMMED CHANNELS
Your radio is pre-programmed with (14) UHF & (2) VHF channels. Powerwerx/
Wouxun radios operate on business radio frequencies that are regulated by
the FCC. In order to transmit on these frequencies, you are required to have
a license issued by the FCC. Visit: http://wireless.fcc.gov/services/index.
htm?job=service_home&id=industrial_business
Your dealer can also re-program your radio’s channels with different frequencies
and features as needed.
PRE-PROGRAMMED CHANNELS
Channel 1 464.550 MHz 67.0 Tone 1W Business Ch. CLS-1 (Narrow 2.5 KHz)
Channel 2 467.925 MHz 67.0 Tone 1W Business Ch. CLS-2 (Narrow 2.5 KHz)
Channel 3 467.850 MHz 67.0 Tone 1W Business Ch. CLS-3 (Narrow 2.5 KHz)
Channel 4 467.875 MHz 67.0 Tone 1W Business Ch. CLS-4 (Narrow 2.5 KHz)
Channel 5 469.5125 MHz 77.0 Tone 1W Business Ch. CLS-54 (Narrow 2.5 KHz)
Channel 6 466.3125 MHz 110.9 Tone 1W Business Ch. CLS-45 (Narrow 2.5 KHz)
Channel 7 466.3375 MHz 110.9 Tone 1W Business Ch. CLS-46 (Narrow 2.5 KHz)
Channel 8 466.3625 MHz 110.9 Tone 1W Business Ch. CLS-47 (Narrow 2.5 KHz)
Channel 9 467.7875 MHz 110.9 Tone 1W Business Ch. CLS-48 (Narrow 2.5 KHz
Channel 10 467.8375 MHz 110.9 Tone 4W Business Ch. CLS-49 (Narrow 2.5 KHz)
Channel 11 467.8625 MHz 110.9 Tone 4W Business Ch. CLS-50 (Narrow 2.5 KHz)
Channel 12 467.8875 MHz 110.9 Tone 4W Business Ch. CLS-51 (Narrow 2.5 KHz)
Channel 13 467.9125 MHz 110.9 Tone 4W Business Ch. CLS-52 (Narrow 2.5 KHz)
Channel 14 469.4875 MHz 110.9 Tone 4W Business Ch. CLS-53 (Narrow 2.5 KHz)
Channel 15 154.570 MHz 88.5 Tone 1W VHF Business Ch. (Narrow 2.5 KHz)
Channel 16 154.600 MHz 88.5 Tone 1W VHF Business Ch. (Narrow 2.5 KHz)
A wide variety of optional accessories are available for your DB-16X.
Visit our website to learn more: www.powerwerx.com/wouxun-radios
Channel Selector Power/Volume Switch
Receive Light
Transmit Light
Microphone
Antenna
PTT Push to
Talk) Key
Monitor Key
(Long Press)
Flashlight
(Short Press) Speaker
Radio Diagram
Getting Started (Continued)
Accessory
Jack
Aux Function
Optional Accessories
This VHF/UHF Dual-band handheld is FCC 2013 Narrow band compliant.
Please note the following default TX modulation settings for the
DB-16X.
VHF BAND
136.000-143.995 MHz......Narrow Band (2.5 KHz) TX, Wide or Narrow RX by channel
144.000-148.000 MHz......Amateur Band (5.0 KHz) or Narrow band (2.5 KHz) RX/TX
148.005-174.000 MHz......Narrow Band (2.5 KHz) TX, Wide or Narrow RX by channel
UHF BAND
400.000-429.995 MHz......Narrow Band (2.5 KHz) TX, Wide or Narrow RX by channel
430.000-450.000 MHz......Amateur Band (5.0 KHz) or Narrow band (2.5 KHz) RX/TX
450.005-470.000 MHz......Narrow Band (2.5 KHz) TX, Wide or Narrow RX by channel
470.005-512.000 MHz......Wide Band (5.0 KHz) or Narrow band (2.5 KHz) RX/TX
2 3
