Precision Power E.DZ Programming manual

R
,
Owners Manual
and
Installation Guide

Introduction
Thank you forchoosing PrecisionPower audio equipment. AtPrecisionPower ,we proudly
design and engineerthe world's finestaudio products. Ouraward winning productsutilize
innovative design andtechnology to consistentlydeliverAbsolutely State ofthe Art
performance, sound quality, reliability, and value.This PrecisionPower product reflects our
commitment to offer you unparalleledversatility and qualityfor years ofdependable service
and listening enjoyment.
Dual ZoneConcept
The concept behind E.DZ is the ability toequalize the front stage and rear fillof the vehicle
audio system independently. Thefront stage isthe focalpoint ofyour audio system, requiring
different processing thanthe rearfill. Thefront stageshould appearhigher onthe dash,very
crisp and clear, and aslightly higher amplitudelevel when comparedto the rearfill. The rear
fill does notrequire as extensiveprocessing like thefront stage, asit is notthe focal pointof
the audio system.E.DZ achieves thiswith independent multi-bandequalization of thefront
stage and rearfill audio signals.
Service &Warranty
Cautions
Do notattemptto service PrecisionPower productsyourself.Performingexploratorysurgery
on youraudio equipmentyourself willvoid thewarranty.Many partsof yourPrecisionPower
gear are custom built toour specifications. Ourfactorypartsare not made available to anyone
else nor are they for sale. Our goal is to make sure that your PrecisionPower product will
always sound asgood asthe dayit waspurchased.Contact your authorized PrecisionPower
dealer about obtainingany warranty servicethrough PrecisionPower.
(See Warrantyinside back cover)
High-powered car audio systems may produce sound pressure levels that exceed the
threshold at which hearing loss may result. They may also impair a driver's ability to hear
traffic soundsor emergency vehicles.Use common senseand practice safelistening habits
when listening toor adjusting youraudio system.

Control PanelFunctions
1.Input SelectionSwitch
2.Master Volume Control
3.Subwoofer LevelControl
The Subwoofer LevelControl will increaseor decrease theoutput level ofthe subwoofer pre-amp
output in relationto the MasterVolume Control.
4.Graphic EqualizerControls
The GraphicEqualizer Controlswill increaseor decreasethe levelof itscorresponding frequency,
-18dB or +18dB.Turn theknob counter-clockwise (left)to decrease thelevel, clockwise (right)to
increase the level.
The Mater Volume Control can be used asa primary or secondary volume control for your audio
system. Generally, the source unit volume is set at a moderate level, then utilize the E.DZ's
Master Volume Control. The ring around the Mater Volume Control is a fader, to increase or
decrease the outputlevels between thefront and rearoutputs.
The Input SelectionSwitch controls whichof the twoinputs the E.DZprocesses. Press theswitch
in to accept the audio signal from your source unit through the CD input. Leave the switch out to
accept and processthe audio signalfrom a secondarysource unit orauxiliary device throughthe
AUX inputs.
Features
20dB Headroom SwitchingPower Supply
Built-in Low NoiseBi-FET Op-Amps
2 Selectable BalancedRCA Inputs w/Input Gain
Front, Rear,& Subwoofer RCAOutputs
Four 18dB FrontBands; 125Hz, 500Hz,3.5kHz, 12kHz
Three 18dB RearBands; 50Hz, 600Hz,6.3kHz
Independent Subwoofer LevelControl
Selectable Low-Pass Filter;32Hz, 64Hz, 125Hz
Fader Control
Blue Backlit ControlKnobs

1.CD GainSelector
The CD Gain Selector will increase or decrease the input sensitivity of the CD input. We
suggest if your source unit's pre-amp voltage is 4V or greater, setthe sensitivity switch to
HI. If your source unit's pre-amp voltage is 2V-4V,set the sensitivity switch to MID. If your
source unit's pre-amp voltage is less than 2V,set the sensitivity switch to LOW.
2.Subwoofer FrequencySelector
The Subwoofer Frequency Selector isa built-inlow-pass filter forthe Subwoofer Output.
Generally, thelow-pass filter canbe setto 128Hz, thenthe subwoofer amplifier's low-pass
filter isfine tuned forthe desired response.
TopPanel Functions
3.

4
5 6
7 8
Rear PanelFunctions
1.12V Constant Power Lead (red):This is the main power input for the E.DZ andmust be connected to
a (+)12V constant power supply. DO NOT connect this to a switched 12Vsource or the system may pop
when the key is turned off.
2.Remote Turn-On Input Lead (orange): This is the inputfor turning on theE.DZ and systemamplifiers.
It should be connected to the (+)12V remote turnon output of the system head unit. The E.DZhas a built
in turn off delay to prevent turn-off pops. When the remote turn onsignal fromthe head unit shuts off,
the amplifiers will turn off immediately and theE.DZ will stay on for five seconds before turningoff. This
feature is designed into theE.DZ to eliminate system turn offpops that can occurwhen severalcomponents
turn off at the same time. DO NOTconnect this to a (+)12V constant power supply.
3.Ground (black):Connect this terminal to a quality ground location, preferablythe chassis of the head
unit, which must itself be properly grounded tothe vehicle chassis. It is notrecommended that the factory
radio ground be used for after-market audio components.
4.Sub Out: These arethe pre-amp RCA audio outputs for sending the audio signal to the subwoofer
amplifier.
5.CD Input:These are the pre-amp stereo RCA audio inputs to be connected to the source unit's front
pre-amp outputs.
6.AUX Input:These are the pre-amp stereo RCA audio inputsto be connectedto secondary source unit,
or auxiliary device's pre-amp outputs.
7.Front Output: These are thepre-amp stereo RCA audio outputs for sending the audio signal to the
front speaker amplifier.
8.Rear Output:These are the pre-amp stereo RCAaudio outputs forsending the audio signal to the rear
speaker amplifier. 4.

Installation Instructions
1.Read thismanual carefully andin its entiretybefore installing thisequalizer.
2.Always disconnectthe battery orremove the fusesfor circuits youwill be workingon.
3.Check for clearance of any hazards such as wiring harnesses or heater core before
mounting the equalizerto any panelsin the vehicle.
4.Mount the equalizer in a location that is easy to access and won't be distracting to
vehicle operation whilemaking adjustments.
5.Route all power wires and audio cables away from sharp metal edges that can cause
shorts to ground and any moving parts that can tangle the wires such as heater controls
or wiper motors.
6.Route allpower and signalcables as faras possible fromother vehicle wiringharnesses.
Loom when appropriate.
7.It is recommended that the equalizer be grounded directly to the chassis of the head
unit. The head unit should be grounded at a chassis point (preferably bare or scraped
sheet metal) otherthan the factoryhead unit groundwire or underdash brackets.
8.Use only thesupplied machine screws to mount the equalizer ordamage to the circuitry
could occur.
5.

Initial Settings
1.After completing unit installation, wire, and appropriate audio signal connections, power-up
the source unit,play a familiartrack, and setthe volume levelto approximately 75%.
2.Set allindividual Graphic Equalizer Controls to 0dB. Master Volume Control and Subwoofer
Level Control shouldbe set tominimum, and faderset to even.
3.Pressthe Input Selection Switchto accept theinput signal fromthe source unitor auxiliary
source.
4.Set the CDGain Selector setting appropriate to the pre-amp voltage ofyour source unit.
Most source unitsprovide 2V-4V pre-amppower. Inthis case, setthe CD gainsensitivity to
MID. If your source unit pre-amp voltage is higher, set the CD gain sensitivity to HI; if the
voltage is lower, set the CDgain sensitivity to LOW. We recommend you never set the CD
gain sensitivity to LOWwith a sourceunit that provides ahigher pre-amp voltage. Thiscan
create unwanted levelsof distortion andpossible damage toyour E.DZ.
5.Setthe Subwoofer Frequency Selector switchto thedesired low-pass filter.Generally, the
low-pass filter isset to128Hz, and then thesubwoofer amplifier's low-pass filter isfine tuned
for the desiredresponse.
6.Adjust the Subwoofer Level Control to achieve the desired tonal balance between the front/
rear speakers andthe subwoofer level.
7.Adjust the various individual Graphic Equalizer Controls to increase or decrease the output
level of eachfrequency to achievethe desired responsefor the frontstage and rearfill.
6.
Specifications

end
LIMITED ONE-YEAR CONSUMER WARRANTY
LIMITED TWO-YEAR CONSUMER WARRANTY WITH PURCHASE AND INSTALLATION BY A
PRECISION POWER AUTHORIZED DEALER
Precision Power promises to the original purchaser, to repair or replace this product with a new or
refurbished unit (at Precision Power's sole and absolute discretion) should it prove to be defective in
workmanship or material under normal use, for a period of *two-years from the date of purchase from
the Precision Power authorized dealer,PROVIDED the product was purchased and installed by a
Precision Power authorized dealer. During this *two-year period, there will be no charge for product
repair or replacement, PROVIDED the unit is returned to Precision Power, returnshipping pre-paid,
along with the required proof of installation, the bill of sale or other dated proof of purchase, and the
consumer's contact information.
If the unit is installed by anyone other than a Precision Power authorized dealer, the warranty period will
be 90-days from the date of purchase. This warranty is non-transferable and does not apply to any unit
that has been modified or used in a manner contrary to its intended purpose, and does not cover damage
to the unit caused by installation or removal of the unit. During this 90-day period, there will be no charge
for the repair or replacement PROVIDED the unit is returned to Precision Power, return shipping prepaid,
along with the bill of sale or other dated proof of purchase and the consumer's contact information.
This warranty is void if the product has been damaged by accident or unreasonable use, neglect, improper
service or other causes not arising out of defects in materials or construction. This warranty does not
cover the elimination of externally generated static or noise, or the correction of antenna problems or
weak reception, damage to speakers, accessories, electrical systems, cosmetic damage or damage due
to negligence, misuse, failure to follow operating instructions, accidental spills or customer applied
cleaners, damage due to environmental causes such as floods, airborne fallout, chemicals, salt, hail,
lightning or extreme temperatures, damage due to accidents, road hazards, fire, theft, loss or vandalism,
damage due to improper connection to equipment of another manufacturer, modification of existing
equipment, or Product which has been opened or tampered for any reason. Units which are found to be
damaged by abuse resulting in thermally damaged voice coils are not covered by this warranty but may
be replaced at the absolute and sole discretion of Precision Power. Unit must be returned to Precision
Power, postage pre-paid, with bill of sale or other dated proof of purchase bearing the following
information: consumer's name, telephone number, and address, authorized dealer's name and address,
and product description. Please contact Precision Power warranty office at 800-724-1377 or
[email protected] to obtain a Return Authorization number & address prior to
shipping the product.
Note: This warranty does not cover labor costs for the removal and reinstallation of the unit. IN ORDER
FOR THE TWO-YEAR WARRANTY TO BE VALID, YOUR UNIT MUST BE SHIPPED WITH PROOF OF
INSTALLATION BY A PRECISION POWER AUTHORIZED DEALER. ALL UNITS RECEIVED BY
PRECISION POWER FOR WARRANTY REPAIR WITHOUT PROOF OF PRECISION POWER
AUTHORIZED DEALER INSTALLATION AND PURCHASE WILL BE COVERED BY THE LIMITED
1 YEAR WARRANTY.
BY PURCHASING THIS PRODUCT, ALL WARRANTIES INCLUDING BUT NOT LIMITED TO EXPRESS
WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR
PURPOSE, AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY ARE
EXPRESSLY EXCLUDED TO THE MAXIMUM EXTENT ALLOWED BY LAW, AND PRECISION
POWER NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY
IN CONNECTION WITH THE SALE OF THE PRODUCT. PRECISION POWER HAS ABSOLUTELY NO
LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS
OR INSTALLERS. BY PURCHASING THIS PRODUCT, THE CONSUMER AGREES AND CONSENTS
THAT ALL DISPUTES BETWEEN THE CONSUMERAND PRECISION POWER SHALL BE RESOLVED
IN ACCORDANCE WITH CALIFORNIA LAWS IN LOS ANGELES COUNTY, CALIFORNIA. Some states
do not allow limitation on how long an implied warranty lasts. In such states, the limitation or exclusions of
this Limited Warranty may not apply. Some states do not allow the exclusion or limitation of incidental
or consequential damages. In such states, the exclusion or limitation of this Limited Warranty may not apply
to you. This Limited Warranty gives you specific legal rights, and you may have other rights which vary from
state to state.
