Pressalit Care R8574572 User manual

R8574572/R8575572
R8584572/R8585572
R8594572/R8595572
Adult changing table –Operation and maintenance manual en
Skifteleje til voksne –Brugs- og vedligeholdelsesvejledning dk
Wechselliege für Erwachsene –Gebrauchs- und Pegeanleitung de
Table de change pour adulte –Manuel d’utilisation et d’entretien fr
Aankleedtafels –Gebruiks- en onderhoudshandleiding nl
Skötbord til vuxna –Bruks- och underhållsanvisning sv
Stellebord –Bruks- og vedlikeholdsveiledning no
Cambiador -Instrucciones de uso y mantenimiento es
成人换洗台 - 操作和维护手册 中文
– ar

English ................................................................. 3
Dansk ................................................................. 23
Deutsch ............................................................... 42
Français ............................................................... 61
Nederlands ............................................................ 80
Svenska................................................................ 99
Norsk................................................................. 118
Español............................................................... 137
中文 ............................................................156
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
en The guarantee covers faults or defects in material or manufacture within a period of 3 years.
Products are subject to minor technical modifications and design deviations. E. & O.E.
dk Garantien dækker i 3 år fra fakturadato for materiale- og fabrikationsfejl. Der
tages forbehold for trykfejl, tekniske ændringer og modelafvigelser.
de Die Garantie gilt für drei Jahre ab Rechnungsdatum für Material- und Herstellungs-
fehler. Druckfehler, technische Änderungen und Modellabweichungen vorbehalten.
fr La garantie couvre les vices de fabrication et de matériaux pour une durée de 3 ans à partir de
la date de facturation. Sous réserve de modifications techniques et d’erreurs d’impression.
nl De garantie is tot 3 jaar na factuurdatum geldig voor materiaal- en fabricagefouten.
Onder voorbehoud van drukfouten, technische wijzigingen en modelafwijkingen.
sv Garantin gäller i 3 år från fakturadatum för material- och fabrikationsfel. Med
reservation för tryckfel, tekniska ändringar och modellavvikelser.
no Garantien gjelder i 3 år fra fakturadato for material- og fabrikasjonsfeil. Med
forbehold for trykkfeil, tekniske endringer og modellforskjeller.
es La garantía cubre fallos de material o fabricación durante los tres años posterio-
res a partir de la fecha de factura. Mantenemos reservas en caso de problemas de
presión, modificaciones técnicas y variaciones de modelo.
中文 保修涵盖 3 年内出现的材料或制造故障或缺陷。产品的技术和设计可能稍微发生变
化，恕不另行通知。
ar قورﻓو ﺔﯾﻧﻓ تﻼﯾدﻌﺗﻟ ﺔﺿرﻋ تﺎﺟﺗﻧﻣﻟا .ماوﻋأ 3 ةرﺗﻔﻟ ﻊﯾﻧﺻﺗﻟا وأ داوﻣﻟا ﻲﻓ بوﯾﻌﻟا وأ ءﺎطﺧﻷا نﺎﻣﺿﻟا ﻲطﻐﯾ
.ةﺎﻧﺛﺗﺳﻣ وﮭﺳﻟاو ﺄطﺧﻟا تﻻﺎﺣ .مﯾﻣﺻﺗﻟا ﻲﻓ ﺔﻔﯾﻔط

3
en
Symbols used in this manual.....................................4
Specific safety ..................................................4
General safety ..................................................5
Product label...................................................6
Intended use ...................................................8
Intended operator profile ...................................8
Intended user profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating environment.....................................8
Versions .......................................................9
Accessories ....................................................9
Operating instructions .........................................10
Folding down R8574/R8584/R8594 .........................10
Height adjustment ........................................11
Folding down R8575/R8585/R8595 .........................12
Height adjustment ........................................13
Optional control box ......................................13
The safety rail ............................................14
Cleaning......................................................15
Disinfection...................................................15
Maintenance..................................................16
Service inspection ........................................16
Service kit.....................................................18
Trouble-shooting ..............................................19
Dimensions, mm ..............................................20
Dimensions, inch..............................................20
Technical data.................................................21
Disposal and recycling .........................................22
Original instructions
Content
Mounting instruction
A mounting instruction is included with the product. It can also
be downloaded from www.pressalitcare.com.
Operational signage
An operational signage is included with this product. It can also
be downloaded from www.pressalitcare.com.

4
en
Symbols used in this manual
The following symbols are used in this manual as well as the associated
documentation supplied with the product.
!WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
!CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
IMPORTANT
IMPORTANT indicates important information about handling and use of
the product.
NOTICE
NOTICE is used to address practices not related to personal safety.
Hand injury
warning
Electricity or potentially
dangerous voltage
Other specific warning
Specific safety
!CAUTION
• Never leave a person lying on the bench without supervision.
• Always be careful when moving a person to and from the bench.

5
en
!CAUTION
• Please comply with these instructions to avoid the product becoming
damaged or destroyed.
• Do not perform repairs, disassembly, or assembly operations,
extensions, re-adjustments or modifications to this product. These
must be carried out by Pressalit or by persons authorized by Pressalit
only.
• Never allow children to operate this product unless under supervision.
The product is not intended for play.
• Never use the product if it is defective or damaged. Do not use a
defective product before it has been repaired.
General safety
!WARNING
• Read and understand the manual completely before use. Keep the
manual close to the unit.
• Comply with this manual to avoid accidents involving serious personal
injury.
• Never use or handle this product in other ways than are specified in
this manual, as this can put your safety at risk and cause damage to the
product.
• Make sure that everyone who is to install or use the product and its
systems has the necessary information and access to this manual.
NOTICE
• The information in this manual is based on correct fitting of the
product in accordance with our Assembly instruction.
• Pressalit cannot be held liable if the product is used in any way which
differs from that described in the guide.
• We reserve the right to amend this manual without prior notice.

6
en
⑩ ⑪ ⑫ ⑬ ⑭
⑮
⑯
⑰
⑱
⑲
①
②
③
④
⑤ ⑥ ⑦ ⑧ ⑨
2
min
18
min
Pressalit A/S, Pressalitvej 1 DK-8680 Ry
[phone], www.pressalit.com
REF
YYYY-MM-DD XXX V
XX-XX Hz
IPXX
XX WRZZZZYYYXXX-X
xxx kg
xxx lbs
xxx kg
xxx lbs
xxx kg
xxx lbs
(01)0XXXXXXXXXXXXX(10)YYMMDD
①Article number
②Production date
③Maximum user weight
④Consult manual for use
⑤Safe working load
⑥Mains voltage
⑦Frequency
Product label

7
en
⑧Maximum power consumption
⑨IP class
⑩Name and address of manufacturer
⑪Consult manual for use
⑫Consult the manual for important cautionary information such as
warnings and precautions.
⑬Duty cycle. The motor on height-adjustable products can be used
for a maximum of 2 minutes of continuous operation, followed by
18 minutes pause.
⑭Type B applied part Part of the product in normal use necessarily
comes into physical contact with the patient to perform its function
The product complies with requirements of IEC 60601-1 to provide
protection against electric shock.
⑮GS1-128 barcode
⑯Product weight
⑰Do not dispose as unsorted municipal waste. The product should
be collected separately and returned to the designated recycling
service.
⑱This product does not contain any of the hazardous substances
mentioned in the Council Directive 2011/65/EC on RoHS.
⑲This product is CE-marked in accordance with the European
Medical Device Directive 93/42/EEC, including amendments
incorporated in Directive 2007/47/EEC. It also complies with all
relevant requirements in the Council Directive 2006/42/EC (of 17
May 2006) on machinery and with Council Directive 2011/65/EC
(of 8 June 2011) on RoHS. A declaration of conformity can be found
at www.pressalitcare.com.

8
en
The product label 1is placed on
the wall mount.
1
NOTICE
If the product is installed in an atmosphere heavy in salt or chloride, the
warranty of the changing table will be reduced from the normal 3 years to
1 year.
Salt and chloride have a corrosive effect on the products components and
will cause a decrease in the life expectancy of the product. The damaging
effects can, however, be reduced if the product is showered with tap water
on a daily basis.
Intended use
This product is intended for people who
• need to get changed on a changing table
• are above the usual changing table age
• are caregivers and need a customized work position
• need to use a changing table in combination with person lifts
Intended operator profile
The product is to be used by personnel trained in health care.
Intended user profile
The product can be used by adults whose weight does not exceed the
maximum load of 200 kg / 440 lbs.
Operating environment
For indoor use, such as a bathroom or wash room. The product is intended to
be used at room temperature, in private homes, nursing homes and hospitals
under normal working conditions.

9
en
Versions
R8574572/R8584572/R8594572 R8575572/R8585572/R8595572
Version Power plug type
R8584572 (Standard)
R8585572 (Standard)
230V
R8594572 (US)
R8595572 (US)
120V
R8574572 (AUS)
R8575572 (AUS)
230V
Accessories
R8574
R8584
R8594
R8487: Mattress R8485: Safety hook
R8575
R8585
R8595
R8487: Mattress R8489: Control box

10
en
Operating instructions
Folding down R8574/R8584/R8594
7 kg
15 lbs 1
1
Take care to avoid injury to
hands when in the vicinity of
closing mechanical parts ①.
Support the table using your hand or
body when folding it down, to avoid the
risk of damage.
The built-in gas cylinders make it easy
to fold the table up against the wall after
use. Be sure to fold the safety rail away
first.

11
en
Make sure that there are no
objects under the changing table
when adjusting the height.
The height adjustment can also be controlled by the wired
remote control unit.
Height adjustment
When the changing able is installed at the correct height, it can be adjusted
between 300 and 1000 mm (11.81 and 39.37 inches) above the floor.
The height adjustment is done by pressing the buttons on the frame.
Press and hold the Up button to raise the bench, and press and hold the
Down button to lower the bench.
The movement stops when the button is released.

12
en
The table folds up and down electrically
On the wired remote control for this model, there are two
additional buttons that control the fold-up function.
Press and hold the fold up button ② to fold the table up, and
press and hold the fold down button ③ to fold the table down.
The movement stops when the button is released.
1
1
2 3
Folding down R8575/R8585/R8595
Take care to avoid injury to
hands when in the vicinity of
closing mechanical parts ①.

13
en
Height adjustment
When the changing table is installed at the recommended height, it can be
adjusted between 300 and 1000 mm (11.81 and 39.37 inches) above the floor.
The height adjustment is done by pressing the buttons on the frame.
The height adjustment and the fold-up
function can also be controlled by the
optional wall-mounted control box.
Make sure that there are no
objects under the changing table
when adjusting the height.
Optional control box
Press and hold the Up button to raise
the bench, and press and hold the
Down button to lower the bench.
The movement stops when the button
is released.
The height adjustment can also be controlled by the wired
remote control unit.

14
en
1
The safety rail
To pull the safety rail
up: Release the lock ① and
pull the safety rail from the
underside of the table, and
swing it upwards. The safety
rail will automatically lock
into position.
To fold the safety rail
away: Release the lock ①
and swing the safety rail
down to the underside of
the table. The safety rail
will automatically lock into
position.

15
en
Cleaning
Clean the changing table after each use. Use ordinary soapy water. Rinse off
with fresh water and dry with a soft cloth.
IMPORTANT
• Do not use an autoclave or other type of steam cleaner.
• Avoid aggressive cleaning agents containing acids or chloride.
• Never spray the table directly with a high pressure cleaner.
• Avoid use of aggressive, abrasive, corrosive or chloride-based cleaning or
disinfecting products.
Disinfection
When using the changing table for multiple patients, it is necessary to both
clean and disinfect it between uses on different patients to prevent the risk of
cross infection.
A list of suitable cleaning agents and disinfectants can be found at
www.pressalitcare.com
!CAUTION
Always read the material safety data sheet (MSDS) and supplied
instructions of the cleaning, disinfecting or de-scaling agent and comply
with instructions for safe use, dilution, rinsing, drying, handling and
storage of the agent.

16
en
Maintenance
Expected service life of the changing table is 10 years, provided that
maintenance is carried out as described below:
It is recommended on a weekly basis to run the motors on the product to their
maximum positions by raising the bench to its full height, and then lowering
it to its lowest position, so that the internal parts are lubricated.
It is recommended that service inspection is done once a year.
Service inspection
1
1
2
2
Check the hinges ①on the bench and the safety rail ②. Tighten if necessary.

17
en
1
1
1
1
Remove the upper and lower retaining
screws ① on the lift unit cover and
carefully remove the cover.
• Check the wall brackets ② and
tighten if necessary.
• Oil moving parts, especially the
sliding brackets ③.
2
2
2
5
6
4
3
3
Disconnect mains before
removing the covers.
• Check all electrical connections to the control box ④.
• Check the chain wheel ⑤for wear.
• Oil the chain ⑥.
• Put the unit cover back again and tighten the retaining screws.

18
en
Service kit
Expected service life of the nursing bench is 10 years for institutional use.
However it must be expected that some of the internal wear and tear parts
must be replaced after approximately 3 years.
The service kits T5256 and T5268 with the replacement parts must be
purchased at Pressalit A/S or your local dealer.

19
en
Contact Pressalit Care or your dealer if the problem cannot be remedied.
Do not attempt to repair the product yourself, as this will invalidate the
guarantee.
Trouble-shooting
Symptom Cause Action
The changing table
does not stay in
upright position.
One or more gas
cylinders are
defective.
Contact Pressalit A/S or
your local dealer.
The product will not
work, even though
the remote control is
used correctly.
Fault in power supply. Check that all wires and
plugs are intact and
correctly connected.
Contact Pressalit A/S or
your local dealer.
The changing table
runs up and down
unevenly.
The sliding brackets
are not properly
lubricated.
Oil the sliding brackets
as described under
的“Maintenance”
The table top is not
level.
Adjustment screws
too high or too low.
Adjust the adjustment
screws ①.
1

20
en
Dimensions, mm
Dimensions, inch
1829
115
813
995 10
1005
750
1180
242
72
4⁄
32
39⁄
⁄
39⁄
29⁄
46⁄
9⁄
