Prestigio 110 User manual

EN-1
Introduction
Thank you for purchasing Prestigio Portable DVD Player 110, a mobile digital media center. You
have made an excellent choice and we hope you will enjoy all of its exciting features. Please read
through the user manual carefully before using the product, and follow all of the procedures in this
quick guide to fully enjoy all features of the product.
PackageContent
1. Prestigio Portable DVD Player 110 X 1
2. Remote Control (battery included) X 1
3. Audio/Video Cable X 1
4. AC/DC Power Adapter X 1
5. Car Adapter X 1
6. Earphone X 1
7. Car Bag X 1
8. Quick Guide X 1
Product&RemoteControlOverviews
Main Unit
1 DC IN 9V Connects to AC and car adapter.
2 LCD Switch Turns ON/OFF LCD Screen.
3 AUDIO Button Press to select audio language.
4 SETUP Button Press to enter or to exit from system setup menu.
5 MENU Button Press to enter or to exit from root menu.
6 USB/SD Button Press to select media source.
7 STOP/Button Press to stop playback. Press again to stop playback completely.
8 PLAY/PAUSE/
Button
Press once to pause playback and press it again to resume playback.
9 S/TSkips to previous track(UP direction) / Skips to next track(DOWN
direction)
10 W/X Rewind(LEFT direction) / Fast Forward(RIGHT direction)

EN-2
11 OK Button Press to confirm selection.
12 OPEN Button Press to open tray cover.
13 SD Card Slot Receives SD memory card.
14 ON/OFF Switch Slide to turn power ON/OFF.
15 COAX Jack Connects to external amplifier/stereo set.
16 AV IN Jack Connects to external display for audio/video input.
17 AV OUT Jack Connects to external display for audio/video output.
18 Volume Wheel Scroll to adjust volume of the headphone or speaker.
19 Earphone Jack Connects to headphone sets.
20 USB Port Connects to USB device.
Remote Control
1 0-9 Number Button Press to select numbers.
2 USB/SD Button Press to select media source.
3 TITLE Button Press to display title information.
4 AUDIO Button Press to select audio language.
5 SETUP Button Press to enter or to exit from system setup menu.
6 ENTER Button Press to start playback or to confirm selection.
7 ///Press to return/skip to the previous/next list, track, chapter, or scene.
Press to rewind/fast forward during playback at a speed of 2X, 4X, 8X,
16X, or 32X.
Press to point/scroll UP/DOWN /LEFT/RIGHT.
8 Button Press once to pause the playback and press it again to resume
playback.
9 Button Press to stop playback. Press button to resume playback at the
same point. Press button twice to stop playback completely.
10 SLOW Button Press to activate the slow playback function.
11 OSD Button Press to toggle between elapsed and remaining time during playback.
12 SUBTITLE Button Press to select a subtitle language (multi languages subtitle
required). Press again to cancel.
13 MENU Button Press to return to or exit from root menu during playback.
14 A-B Button Press to play a selected segment repeatedly. Press again to cancel.
15 ANGLE Button Press to select camera angles (camera angle adjusting function
required).
16 REPEAT Button Press to select different repeat and shuffle patterns.
17 ZOOM Button Press to cycle through zooming functions.
18 RETURN Button Press to return to the main menu.
19 VOL-/VOL+ Button Press to turn volume down/up.

EN-3
NOTE:
Please follow below diagrams to replace battery:
When using remote control, please make sure
the infrared window on remote control is
aligned with infrared receiving window of the
device. The distance must be within 3 meters.
Please refer to the diagram on the right for
illustration.
Getting Started
Please read through the instructions below before operating Prestigio Portable DVD Player 110
for the first time.
To start disc/USB device/SD card media (DVD, MPEG4, SVCD, VCD, CD, MP3) playback:
1. Connect Prestigio Portable DVD Player 110 to power supply or wall plug via power
adapter provided.
2. Adjust the device to the best viewing position desired.
3. Turn on the device by sliding power switch at the left side of unit to ON position. The source
menu will be displayed on screen:
NOTE:
When selecting media mode, please make USB device or SD/MMC card is properly inserted.
4. Press /button to enter DVD Mode or Media Mode and press ENTER button to confirm
selection.
5. Press OPEN button to open disc tray cover. Place the disc with appropriate file formats in the
disc tray with printing side facing up. Close the disc tray cover.
6. The device will automatically begin media playback process upon closing of disc tray cover.
7. Adjust playback volume by scrolling VOLUME wheel at the left side of device to an
appropriate level before playback.
8. Turn off the device by sliding power switch at the left side of unit to OFF position.
60°
DVD
MEDIA

EN-4
GeneralVideoPlaybackOpeartions
Press once to stop playback; then press to resume playback from the point where you
stopped; press twice to stop playback completely.
zTo pause playback DVD MPEG4 SVCD VCD CD MP3
1. During playback, press to pause. Press it
again to resume playback.
NOTE:
When the device is at idle mode (paused, stopped, no
disc), the device will automatically enter screen
protection mode after 3 minutes. Press any button to
exit.
zTo start title/chapter playback DVD MPEG4 SVCD VCD CD MP3
1. Press MENU button to enter disc main menu.
2. Press directional buttons to select user desired
title/chapter.
3. Press ENTER button to confirm.
NOTE:
This function is only available if the media disc supports
such feature.
zTo fast forward/rewind DVD MPEG4 SVCD VCD CD MP3
1. Press to fast forward at speed of 2X, 4X, 8X,
16X, and 32X in cycle.
2. Press to rewind at speed of 2X, 4X, 8X, 16X,
and 32X in cycle.
zTo repeat DVD MPEG4 SVCD VCD CD MP3
1. During DVD disc playback, Press REPEAT button to cycle through repeating patterns including
Chapter Repeat, Title Repeat, Disc Repeat, and Repeat Off.

EN-5
2. During CD/VCD disc playback, Press REPEAT button to cycle through repeating patterns
including Track Repeat, Disc Repeat, and Repeat Off.
3. During MP3 disc playback, Press REPEAT button to cycle through repeating patterns including
File Repeat, Folder Repeat, and Repeat Off.
zTo repeat a specific segment DVD MPEG4 SVCD VCD CD MP3
1. Press A-B button once to set the starting point A
2. Press it again to designate end point B.
3. The segment from A to B will be played repeatedly.
4. Press the button again to stop A-B repeat function.
zTo adjust display angle DVD MPEG4 SVCD VCD CD MP3
1. Press ANGLE button to adjust display angle.
2. Press number buttons to select a display angle
desired.
3. Press ANGLE button again to resume default
angle playback.
NOTE:
This function is only available if the media disc supports
multi-angle feature.
zTo zoom in/out DVD MPEG4 SVCD VCD CD MP3
1. Press ZOOM button to zoom in/out at factors of
2X, 3X, 4X, 1/2X, 1/3X, 1/4X in cycle.
2. Press /buttons to select a display angle
desired.

EN-6
GeneralImagePlaybackOperations
1. Press MENU button to browse *.jpg files. Press to display image files in thumbnail mode.
Press /to move up/down the directory and /to select image files. To view desired
image files for full screen display, press ENTER to confirm selection.
2. Press /to rotate the image file clockwise/counter-clockwise.
3. Press /to reverse the image files vertically/horizontally.
4. Press OSD button to cycle through various image transition modes:
A From top to bottom I From horizontal center to both sides
B From bottom to top J From vertical center to both sides
C From left side to right side K From top and bottom to center
D From right side to left side L From right and left to center
E From left top to right bottom M From four window top side to bottom side
F From right top to left bottom N From four window left side to right side
G From left bottom to right top O From four edges to center
H From right bottom to left top
5. ∅icon will be displayed when the options are not available at this mode.
GeneralMusicPlaybackOperations
1. Press /button to select desired MP3 file. Press
ENTER button to start playback.
2. Please refer to General Video Playback
Operations section for more detailed function
description.
SystemSetup
1. Press SETUP button to enter setup menu.
2. Press /button to highlight various categories.
Press /button to select options.
3. Press ENTER button to confirm selection. Press 
button to exit.

EN-7
General Setup Page
TV Display:
Adjusts screen display format between Normal/PS,
Normal/LB, and Wide.
Note:
zThis option is determined by the screen ratio from
which DVD disc is recorded.
zPlease select Wide when using a 16:9 TV display.
Angle Mark:
zEnables/Disables the multi-angle function.
zA camera icon will be displayed on the screen when
such function is supported by the media file.
TV Type:
zAdjusts TV type from PAL or NTSC.
zThe default value is set on PAL TV type.
Screen Saver:
zEnables/Disables the screen saver function.
zThe screen saver function will be activated when the
device is idle for more than 3 minutes.
zThe default value is set to ON.
OSD Lang:
zAdjusts the OSD language.
zThe default value is set on ENG.

EN-8
Video Setup Page
Quality:
zAdjusts video output screen options including
Brightness, Contrast, Hue, and Saturation.
zThe default values are 00.
Panel Quality:
zAdjusts device screen options including Brightness,
Contrast, Hue, and Saturation.
zThe default values are 00.
Password Setup Page
Password:
zDefines/Modifies password.
zAll parental control features are password protected.
zThe default values are 8888.
Preference Page
Audio:
zAdjusts to desired audio language of DVD disc.
zThe default language is ENG.
NOTE:
zThe audio languages are provided by DVD disc.
Subtitle:
zEnables/Disables/Adjusts to desired subtitle
language of DVD disc.
zThe default value if OFF.
NOTE:
zThe subtitle languages are provided by DVD disc.

EN-9
Disc Menu:
zAdjusts to desired menu language of DVD disc.
zThe default language is ENG.
NOTE:
zThis function is only available for DVD disc.
Parental:
zLocks up specific segments of DVD contents.
zSets to various parental control levels of DVD disc.
zThe default value is set to ADULT.
Default:
zSelect the option and press ENTER button to restore
all settings to factory values.
ChargingDevice
zThe device battery is made of Lithium Polymer rechargeable batteries. Please fully charge the
battery pack before using for the first time.
zCharging time under normal conditions is approximately 6 hours. A fully charged battery pack
delivers approximately 2 hours of main unit operation. However, operation time varies in
accordance with the files being played.
zA Low Battery sign will be displayed when battery is running low. The battery will be depleted
completely after 10 minutes.
zThe battery can only be recharged when the device is in power off mode. Please turn off the
device before recharging battery. The battery status LED indicator will glow in red while
charging. It turns yellow when the device battery is fully charged.

EN-10
UsingCarBag
Follow the steps below to attach the Prestigio Portable DVD Player 110 onto the car seat
headrests.
1. Open up the car bag included and detach hook-and-loop fasteners.
2. Place the device into the car bags with the base at the deeper side.
3. Put attached bands on left and right sides of the base and screen to fix its positions.
4. Re-attach hook-and-loop fasteners to desired positions.
5. Unbuckle and loosen up the strap on the back of car bag.
6. Insert the strap through the gap on the card seat headrest.
7. Adjust the length of the straps to fit the car seat headrest and buckle up.
ProductSpecifications
Compatible Disc Format DVD±RW/RW, VCD, CD-R/RW, CD-DA,MP3, MPEG4, JPEG
Signal System PAL/NTSC
TFT LCD screen size 10.2 inch
Frequency Response 20Hz～20kHz ±2.5dB
Video Output Output Level: 1.0VP-P, Load: 75Ω, unbalanced
Audio Output Output level: 1.4Vrms, Load: 10KΩ
Audio Signal-to-Noise Rate ≥80dB
Dynamic Range ≥85dB
USB Data Transfer Speed USB1.1
Power Source DC 9~12V
Power Consumption 10W
Operating Temperature 5~40°C
Weight 0.78Kg
Dimensions (L * W * H) 270mm X 200mm X 41mm
Battery Type Lithium Polymer Rechargeable Battery
TechnicalSupportandWarrantyInformation
Please refer to www.prestigio.com for technical support and included warranty card for warranty
information.
Disclaimer
We make every effort to ensure that the information and procedures in this user manual are accurate
and complete. No liability can and will be accepted for any erros or omissions. Prestigio reserves the
right to make any changes without further notice to any products herein.
