Prima PRCEH104 User manual

BUILT-IN CERAMIC HOB
INSTALLATION AND OPERATION MANUAL
Please read the instruction manual carefully before operating your new hob.
PRCEH104
PRCEH106
Cod：0070303280
Dear Owner: Thank you for purchasing our cooktop which is designed to give you many years of
cooking pleasure. Before using your new appliance please read the user's manual carefully and keep it
in a safe place for future reference.
THIS APPLIANCE MUST BE INSTALLED ONLY BY A QUALIFIED PERSON IN INSTRUCTIONS
PROVIDED. THE MANUFACTURER DECLINE ALL RESPONSIBILITY FOR IMPROPER INSTALLA-
TION WHICH MAY HARM PERSONS AND ANIMALS OR CAUSE DAMAGE TO PROPERTY. THE
APPLIANCE MUST BE USED ONLY FOR THE PURPOSE FOR WHICH IT WAS EXPRESSLY
DESIGNED. ANY OTHER USE (e.g. HEATING ROOMS) IS CONSIDERED TO BE IMPROPER AND
MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE RESULTING FROM
IMPROPER AND IRRESPONSIBLE USE.
A duplicate data label and wiring diagram are contained in this booklet.Please attach these labels to an
accessible and near by surface for easy reference. The Manufacturer shall not be held responsible for
any innaccuracies in this handbook due to printing or transcription errors,also the designs in the figures
are purely indicative. The Manufacturer also reserves the right to make any modifications to the
products as may be considered necessary or useful also in the interests of the user, without
jeopardizing the main functional and safety features of the products themselves.
Use
Directions and suggestions for using
1.Do not touch the built-in ceramic hob with wet hands or feet.
2.Do not operate the built-in ceramic hob when you are barefoot.
3.Do not let young children operate the built-in ceramic hob.
4.Please disconnect the power supply before you do any maintenance and cleaning.
5.When the built-in ceramic hob is working, the temperature of the hob and the ambient temperature
become higher, so please do not touch it and keep the children away from it.
6.A steam cleaner must not be used for cleaning the appliance.
7.The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
8.The built-in ceramic hob must be built into a heat resistant cabinet. Some smoking may occur when
first used. Leave on for a short period to burn off excess sealant.
Operation of the top with the heating area
An appropriately selected pan saves energy. A pan should have a thick, flat base with a diameter equal
to the plate diameter as in that case heat is transferred most efficiently.
Advice on the use of cooking tops. To save energy and to prolong the life of the ceramic tops, we
advise using pans with flat bottom and with a diameter no less than the diameter of the tops. Care must
be taken that fluids do not spill on the ceramic plates. Never leave the tops on without pans on them or
with empty pans and never use the tops to heat plates. Switch on the elements after having set the
pans on them. Once switched off, the elements remain warm for a while, do not touch. Switch off the
heating element before removing the pans. • Select the cooking zone (fig. 2) and heat level (fig. 3).
•Press the timer button (fig. 5), and then use the up and down buttons to set the countdown time.
•Each time the timer up/down button is pressed, the timer display will increase or
decrease in 1 minute increments.
Safety cut-off
• If one or more of the cooking zones are accidentally left on, a safety cut-off will activate
after a certain period of time. The length of time depends on the set power level for that
zone. The table on the right gives the time limits for each power level.
• If more than one zone is operating when one of the zones reaches its safety cut-off
point, only the zone that has reached its safety cut-off point will switch off.
fig.1
fig.2
fig.3
fig.4
fig.5
Touch control For PRCEH106
• All operations are performed by means of the touch controls on the control panel.
• Each touch control has a corresponding visual display (indicator light).
•You will hear a beep each time a touch is registered.
Switching on the ceramic hob
• Press the ON/OFF button (fig. 1) to switch on the appliance.
• The hob will beep once and all cooking zone indicators will light up briefly, indicating that
the hob has entered stand-by mode .
Notice: Take the next step within one minute, otherwise the controller will automatically
shut down.
Switching on a cooking zone and setting a power level
• Press the cooking zone select button (fig. 2) for the zone you want to use.
• Select the heat level required (1-9) by using the up and down buttons (fig. 3). By holding
down either of these buttons, the value on the heat level display will adjust up or down.
Note: when the power displayed 0, press the down button, the power will set to 9.
Switching off the ceramic hob
1. Press the ON/OFF button, the hob will switch off. It is possible to turn the hob off at any
time by pressing the ON/OFF button.
2. Press the up or down buttons to 0, then hob will switch off.
After a zone is switched off, the corresponding heat level display will show a flashing letter “H” .
This means that the temperature of the zone is above 60°C and is therefore still high enough
to cause injury.
•When the temperature of the zone falls below 60°C the letter “H” will go out. It is still
possible to burn yourself on a hob zone, even when its temperature has dropped below 60°C.
IMPORTANT: The residual heat indicator will disappear if the mains supply to the product is cut.
Locking the ceramic hob
To lock the ceramic hob, press the safety lock button (fig. 4) while the appliance is
switched on. With the safety lock activated, all buttons on the control panel will be
disabled, except the ON/OFF button. To disable the safety lock feature, press the safety
lock button again. You are then able to adjust the heat level of any zone on the hob.
Timer
If touch-controlled, your hob has a timer which you can set (from 1 to 99 minutes) for each
cooking zone. At the end of the countdown period, a buzzer will sound and the relevant
cooking zone will be switched off.
PRCEH106
SAFETY WARNING
1. Please check the built-in ceramic hob's integrity after opening the package. If
there are any problems please refer to the supplier.
2. Do not throw the package materials (plastic bag, foam, nails, package etc) in a
place where children can easily access. Please dispose of packaging in an
environmentally friendly manner.
3. Do not change the wiring under any circumstances.
4. Dispose of the appliance in an environmentally friendly manner.
5. If the supply cord is damaged,it must be replaced by the manufacturer its service
agent or similarly qualified persons in order to avoid a hazard.
6. Children and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge should be supervised to ensure appliance is used
safely.
7. Children should be supervised to ensure that they do not play with the
appliance.Cleaning and user maintenance shall not be made by children without
supervision.
8. Do not stare at the hob elements when the appliance is working.
9. Accessible parts may become hot during use. To avoid burns young children
should be kept away
10. 
If the surface is cracked, switch off the appliance to avoid the
possibility of electric shock, for hob surfaces of glass-ceramic or similar material
which protect live parts
11.Shall state a steam cleaner is not be used.
12.Metallic objects such as knives, forks, spoons and lids should not be placed on
the hob surface since they can get hot.
13.  The surface temperature exceeds 95°C.To avoid a hazard,under
bench access must be restricted.Refer to the installation instructions.
14. The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements.Children shall be kept away
unless continuously supervised.
15.The appliance is not intended to be operated by means of an external timer or
separate remote-control system.
16. 
Unattended cooking on a hob with fat or oil can be dangerous and
may result in fire. NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire blanket.
17. 
Danger of fire: do not store items on the cooking surfaces.
18.  The cooking process has to be supervised. A short term cooking
process has to be supervised continuously.
19. Use only hob guards designed by the manufacturer of the cooking
appliance or indicated by the manufacturer of the appliance in the instructions for
use as suitable or hob guards incorporated in the appliance. The use of
inappropriate guards can cause accidents.
Switch Knob
Heating area
(Φ180mm)
Heating area
(Φ180mm)
Heating area
(Φ180mm)
Heating area
(Φ180mm) Heating area
(Φ145mm) Heating area
(Φ145mm)
Heating area
(Φ145mm)
Heating area
(Φ145mm)
PRCEH104 For PRCEH104, according to your needs, the tops can be adjusted by turning the knobs either
clockwise or anti-clockwise to 9 positions besides the 0 position (off). The positions marked by the
higher numerical index match the maximum output of heat (see table).
When using rapid tops, a thermostat automatically reduces the power when the selected temperature
is reached and the top operates intermittently to reach a constant cooking temperature. The pilot light
set in the control is a signal that the electric elements are switched on. The level of heat can be
adjusted gradually by turning the appropriate knob to the right or left. Switching on the element
results in an orange signal light illuminating on the control panel.
0
1-2
3-4
5-6
7-8
9
Switch off
MIN.Warming up
Stewing vegetables, Slow cooking
Slow frying
Grilling meat, fish
MAX.Fast heating up, Fast cooking, Frying
1-2
3-4
5
5
6
Time limit
(hours)
4
1.56-9
Power
level
1
23

Technical Data
WARNING
Close the cable clamp after making the
electrical connection. Close the terminal
board cover by twisting it down.
Scraper for cleaning the hob
PRCEH106PRCEH104
Utensils
Use pans with flat bottoms. Uneven or thin bottoms will waste energy and are slow to cook.
Use pans slightly larger than the hotplates. Smaller pans will waste energy.
Do not use oversized pans. More than 50mm overhang can overheat cooktop components and can
cause fine cracks in the enamel hob which will trap dirt.
Use only dry utensils. Do not place wet or steamy parts (eg.lids) on the hotplates.
Use
Do not use pots and pans that are unsteady and likely to rock or overbalance.
Do not operate the cooktop tor an extended time without utensil on the hotplate.
Good Bad
(recessed base) (convex base) (undersize) (oversize) (moisture on hotplate) (no utensil)
Bad Bad Bad Bad Bad
The manufacturer refuses all responsibility if the standards in force are not respected
.
TECHNICAL INFORMATION FOR INSTALLATION PERSONNEL:
This appliance must be installed only by authorised personnel and in accordance with the regulations
of authorities. The wall and bench surfaces must be capable of sustaining temperatures
of 95 degrees Celsius. All laminates, fixing adhesives and surfacing materials should be certified
suitable for this temperature. Do not install it in ( curtains etc).
Athe , cut square hole in and hob.
Inserting and fixing the hob
Before inserting the hob into the work , place the adhesive seal “s”
around the underside edge the hob. It is important to fix this gasket
evenly, without gaps or overlapping to prevent liquids from seeping
nderneath the hob.
Place the gasket around the bottom edge of the hobs as shown in
the illust ation overleaf.
Place the hob in the installation opening and push it down so that
the hob is resting f mly on the cabinet.
Secure the hob in position using the fixing brackets supplied.
Secure the hob to the underside of the worktop using the fixings provided. Screw one end of the
bracket into the pre-drilled holes in the underside of the hob. The other end of the bracket should be
located underneath the worktop to secure the hob in position.
Note 1:
The minimum height of any adjacent units (including light pelmets) is 450mm, unless they are
manufactured from a material resistant to fire (steel, ceramic tiles for example).
Note 2:
No overhanging surface hood exhaust system are permitted within 750mm above burner
tops.
Note 3: Leave 50 mm clearance between the base of the appliance and a combustib e
surface. Never leave the packing components (plastic bags, nails, foamed polystyrene, etc) within
reach of the children they are a source of danger.
The hob has a special seal which prevents liquid from entering the cabinet Follow these instructions
in order to correctly apply this
Seal:
Detach the seals from their backing, so that the transparent protection still adheres to the seal itself.
Turn the hob and correctly position seal under the edge of the hob itself, so that the outer part
of the seal perfectly matches the outer edge of the hob. Evenly and securely fix the seal to the hob,
pressing it firmly in place.
CLEANING AND MAINTENANCE
-Do not use cleaning products containing abrasive materials for the cleaning and maintenance of the
glass front panel.
-When cleaning do not use cleaning agents with a strong abrasive effect, eg. scouring powders
containing an abrasive, abrasive compounds, abrasive stones, pumice stones, wire brushes .
The scratch the hob surface, causing irreversible damage.
-Large spillages that are firmly stuck to the hob can be removed by a special scraper (not included with
hob); but be careful not to damage the ceramic hob frame when doing this.
Caution!
The sharp blade should always be protected by adjusting the cover (just push it with you thumb).
Injuries are possible so be careful when using this instrument keep out of reach of children.
Appropriate cleaning or washing products are recommended, eg. .
Alternatively a solution of warm water with a little washing up liquid or cleaning products for stainless
steel sinks can be used.
Malfunction
Hob doesn't work
Eliminating guide
•Check the connection
•heck the fuse limit
There is some smoke
when it is working
•It is normal the first time you use
•Clean the around the electric hob .
The wire is damaged •contact the Prima service department to change the parts.
Symbol Value
Model identification
Type of hob
Number of electric cooking
zones and/or areas
Heating technology (induction
cooking zones and cooking
areas, radiant cooking zones,
solid plates)
For circular cooking zones or
area: diameter of useful surface
area per electric heated cooking
zone, rounded to the
nearest 5 mm
For non-circular cooking zones or
areas: length and width of useful
surface area per electric heated
cooking zone or area, rounded to
the nearest 5 mm
Energy consumption per cooking
zone or area calculated per kg
Energy consumption for the
hob calculated per kg
Ø
L, W
--
--
--
--
ECelectric cooking
ECelectric hob
Built-in hob
4
Big ring: 18,0 cm
N/A
Small ring: 14.5 cm
Big ring: 194
Small ring: 187
Unit
cm
cm
Wh/kg
Wh/kg
Radiant cooking
zones
Built-in hob
4
Big ring: 18,0 cm
N/A
Small ring: 14.5 cm
Radiant cooking
zones
189
≥600
450
580
560
490
510
Recommended installation
Wood block
TERMINAL BOARD
Erp
200
50min
200
MALFUNCTION ELIMINATION
This appliance is labelled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic
Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible harm to
the environment and to human health which might otherwise be caused if disposed of in the wrong way.
The symbol on the product indicates that it may not be treated as normal household waste.
It should be taken to a collection point for the recycling of electrical and electronic goods.
This appliance requires specialist waste disposal. For further information regarding the treatment, recovery and
recycling of this product, please contact your local council, household waste disposal service or the shop where you
purchased the product.
For more detailed information about treatment, recovery and recycling of this product, please contact your local local
council, household waste disposal service or the shop where you purchased the product.
Model Power Supply Power(W) Size (mm)
knobs (104)
Bui t-in Hole Size
(mm)
AC220-240V
50Hz
1800W(180mm) 580X510X 560(L)X490(W)
1200W (145mm)
PRCEH104
1800W(180mm) 580X510X52 560(L)X490(W)
1200W (145mm)
PRCEH106
• If the cable is damaged or to be replaced, the operation must be carried out the by a service agent or a suitably
qualified professional.
• If the appliance is being connected directly to the mains, an omnipolar circuit breaker must be installed with a minimum
opening of 3mm between contacts.
•The installer must ensure that the correct electrical connection has been made and that it is compliant with all
applicable standards and safety regulations.
•The cable must not be bent or compressed.
•The cable must be checked regularly and replaced by authorised technicians only.
46
Big ring: 182
Small ring: 195
187
bracket
OR
screw
screw hold
S
Worktop
Screw
Screw
Fixing bracket
Hob
Ventilation slot ≥30mm
50mm MIN. Heat outlet
15mm MIN.
Cleaning
Turn off the mains to the equipment before carrying out any maintenance and wait for it cool down. We
advise using lukewarm water and detergents to clean enameled elements.Never use abrasive products.
Rinse the glass worktop with water and dry using a soft cloth. Use sponges or a moist cloth to clean the
tops, and remember that water in excess can damage the electric elements. Clean tough stains using
non abrasive detergents, or warm vinegar.
Clean the electric tops using a moist cloth, then lightly oil the the top when it is still warm.
Only licensed repairers should service the appliance.
Installation
Electrical connect ppliances with three-pole cable are set up for operation with alternating current
at the voltage and frequency indicated on the rating plate Look at the connection wiring diagram. The
earth conductor is yellow/green. The connection to the electricity supply must be made by a qualified
person and following regulations. When the appliance is to be installed above a built-in
oven, the two appliances must be connected separately. The supply cable must be positioned so that
no p t can reach a temperature 50°C higher than ambient temperature. Also check that the supply
system has an effective earth connection and corresponds to the standards in force and that the
breaker can be reached easily the appliance is installed.
Fitting guidelines
The voltage rating of the hob heating elements is 220-240V. Appliances with three-pole cable are set
up for operation current at the voltage and frequency indicated on the rating plate Look at the
connection wiring diagram. The earth conductor is yellow/green. The connection to the electricity
supply must be made by a qualified person and follow regulations. When the appliance is to
be installed above a built-in oven,the two ap liances must be connected separately, to make it easier to
take the appliances out and electrical safety.
4
5
6
7
CONNECTION DIAGRAM
Caution! Voltage of heating
elements 220-240V Caution! In the event
of any connection the safety Wire
must be connected to the E terminal.
Recommended type of
connection lead
L1 N1 N2L2
E L N
L1 N1 N2L2
