PRIMAVERA Ambiente Operating manual

Ambiente
Aroma Diffuser
Modern Room Fragrance
for a Pleasant Ambience
Important Information
Regarding Usage and Care
Troubleshooting
PROBABLE CAUSE
No water, or very little water
in the water reservoir.
Water reservoir has overflowed.
The operating period of
1 or 2 hours has ended.
Insufficient water at protection
sensor, or ultrasonic transducer
has not been cleaned properly
and is dirty.
The essential oil is of poor
quality.
Relative humidity is too high or
temperature is too low and has
caused the vapor to condense
quickly.
REMEDY
Switch off the diffuser. Fill the reservoir
with water and switch it on again.
Switch off the diffuser.
Pour out the excess water.
Press the power button again to restart
the unit.
Clean them properly as described above.
Try a 100 % natural PRIMAVERA
essential oil or blend in the diffuser.
Increase air temperature slightly or
move the diffuser in a different location.
Cleaning and Maintenance
• Before cleaning, turn the on/off switch on the Aroma Diffuser to off.
Then unplug the plug from the power outlet.
• Empty the water reservoir. Wipe it with a soft, damp cloth.
• Once a week, use a cotton bud to wipe the metal part of
the ultrasonic transducer on the bottom of the water
reservoir with rubbing alcohol. (Fig. 11)
• (Note: do not wipe the case with rubbing alcohol because
it may remove the paint from the case. Use a mild
detergent instead.)
• If the appliance has been in use for 2-3 weeks and no longer produces
mist or only a reduced amount, clean the transducer as described in the
previous step.
• After use, switch off the unit, unplug it from the main power supply and
empty all the water out of the reservoir.
• Dry the appliance thoroughly before putting it into storage.
• Clean the appliance before using it after a long period of storage.
Store in a dry place.
No mist produced or mist intensity is less than before:
PROBABLE CAUSE
The mist has been blown back
onto the diffuser and has con-
densed on its surface.
REMEDY
Place the diffuser in a different position,
away from drafts.
The area around the diffuser, and the surface on which it
is standing, is wet.
Fig.11
PRIMAVERA LIFE GMBH
Naturparadies 1
87466 Oy-Mittelberg
Germany
www.primaveralife.com
Model Number: AI-15908
Operation Mode: 1 hour/2 hours continuous mode,
6 hours interval mode
Water Reservoir Capacity: approximately 100ml
Ultrasonic Frequency: 1.7 MHz
Power Adaptor (Input): AC 100 – 240 V (50/60 Hz)
Power Adaptor (Output): DC 15 V (0.8 A), 9 W
Material: High quality, glazed ceramic and
high quality BPA free plastic
Safety Advice for the Use of Essential Oils and
Fragrance Blends
Please carefully read the instructions provided and the information on
the label of your essential oils and fragrance blends.
05/2020
Disposal
Please do not dispose of this unit in general household waste but
instead take it to a recycling collection point. These collection points are
regulated according to 2002/96/EC and 2006/66/EC, subject to country
and legislation.
We reserve the right to make technical changes to the Aroma Diffuser
and any substantive changes to these instructions without prior
notification.
Disclaimer
We accept no liability for damage resulting from incorrect use of this
product or caused by the use of essential oils.

Dear Customer,
Thank you for deciding to purchase our PRIMAVERA Aroma Diffuser
Ambiente.
To ensure your enjoyment of our Aroma Diffuser, we ask you to please
read these instructions carefully and observe all safety precautions. We
wish you much joy and wonderfully fragrant hours with this modern and
easy-to-use diffuser.
Fragrant greetings from the foothills of the Alps,
Your PRIMAVERA Team
Please pay attention to these Safety and Operating
Instructions for use and filling!
• Place the unit upright in a safe place and on a firm, non-tilting base.
• Unit use indoors only.
• Do not place in water or other liquids.
• If product has been dropped, disconnect the power plug immediately.
• After use, pour out remaining water and pull the power supply plug.
• Store unit in a place inaccessible by children.
• Children or disoriented people may not use the diffuser without proper
supervision.
• Before filling with water, always unplug the power supply plug!
• Do not operate when the water reservoir is empty. Turn off the appliance when
the water reservoir is empty.
•
Never fill the water reservoir directly from the tap. The device could be damaged.
• For the aromatherapy pour 3-5 drops of essential oils into the water.
• Please only use high-quality 100 % pure essential oils. Oils of inferior quality
can damage the equipment.
• Do not use viscous oils. The device can be damaged.
• Place the unit on a level surface so that it cannot tip over.
• Do not open the device during operation because water may spurt out.
• Do not touch the ultrasonic transducer with the device is in operation!
Risk of burns!
• Never fill the water reservoir with alcohol, chemicals or corrosive liquids!
The device could be damaged!
• This appliance is intended for personal use only. It may only be used for the
purposes described herein. Use only as recommended by the manufacturer.
• If you notice any abnormal odors or noise, disconnect the machine immediately
by unplugging the power adapter plug! Repairs should only be carried out by
qualified personnel.
• For damage caused by improper use, no liability is assumed. In case of damage
to the electrical parts, especially when the electrical supply is damaged, the
unit must not be put into operation. Please contact us in this case or have the
device repaired by authorized personnel. Please do not open the device or
electrical parts themselves or make any structural changes. In these cases,
your guarantee and warranty is void.
Commissioning
PRIOR TO USE
• Pull the ceramic top cover upwards as shown in the image. (Fig. 1)
* Remove splash protection from the water reservoir. (Fig. 2)
* Before filling the container, insert the plug at the base of the appliance. (Fig. 3)
* Fill the container to the marked line with water. (Fig. 4)
USING YOUR DIFFUSER
• Do not operate when the water reservoir is empty. Turn off the appliance as
soon as the water reservoir is empty.
• Never fill the water reservoir directly from the tap. Make sure that no water
gets into the vent. The device could be damaged. (Fig. 5/6)
• If the water reservoir accidentally overfilled (water level above the marked line),
pour out the excess water as shown. (Fig. 7)
• Carefully place the splash protection on the unit. (Fig. 8)
• Push down the ceramic top cover at the top of the machine. (Fig. 9)
• For aromatherapy, pour 3-5 drops of essential oil directly into the water.
Never put the oil directly into the ultrasound transducer!
CONNECT THE DEVICE TO POWER SOURCE
• First insert the power jack in the power socket.
Only then plug the power adaptor into the wall
socket.
DISCONNECT THE DEVICE FROM POWER SOURCE
• First disconnect the power adaptor from the wall
socket, than disconnect the power jack from the
power socket.
OPERATE THE UNIT
• Press on / off button one time (for the LIGHT):
The light turns on in the brightest stage.
• Press the button a second time: The lighting dims.
• Press the button a third time: The lighting goes into
effect mode
• Press the button a fourth time or press and hold for
1.5 seconds: The light goes out.
• Pressing the button again, the light comes on again.
(Fig. 10)
• NOTE: With this button, the unit can be used only as
light if desired.
ON / OFF BUTTON DIFFUSION
• Lighting and diffusion can be switched on separately.
• On / Off (Diffusion)
• On / Off button once: The LED indicator lights on the
left; the diffuser operates continuously. The device
automatically turns itself off after 1 hour.
• Press the button a second time. The middle LED
indicator lights up; the diffuser operates continu-
ously. The unit automatically turns off after 2 hours.
• Press the button a third time. The LED indicator
lights on the right; the nebulizer operates in interval
mode and generates 20 seconds of fine mist. After
a pause of 40 seconds this process is repeated auto
matically. The device switches off automatically after
6 hours.
• Press the key a fourth time or hold 1.5 seconds or
longer to stop diffusion. The LED indicator turns off.
NOTE
• The two on / off switches for lighting and diffusion
can be controlled separately.
• If the timer expires or the water water reservoir is
empty, the LED indicator turns off and the diffusion
is stopped.
• For the machine to work optimally, it should be
turned off after 4 hours continuous operation for at
least 30 minutes.
Product Description
1 Nozzle
2Ceramic top cover
3Ultrasonic transducer
4Splash cover
5Water reservoir
6Air outlet
7Main body of unit
8Light and mist button
9Power adaptor
10 Power jack
11 Power socket
Product Features
• Easy to fill, simple to safely operate
• Three selectable diffuser settings (continuous or interval)
• Three selectable light modes
• Mist and light independently adjustable
• Cold diffusion by ultrasonic unit
• Automatic safety shutdown
• Easy to clean
Unit bottom
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.9
Fig.8
Fig.
Fig.
1
1
Fig.10
1
2
3
4
5
6
7
8
9
10
11
Fig.7
Pour out
the water
