Primex 14000 Series Operation manual

XR TIME SYNCHORNIZATION
14000 SERIES TRANSMITTER - EXTERNAL ANTENNA
INSTALLATION & USER GUIDE
Doc Part No.: 14000-EM 082713

Legal Notice
Copyright ©2013 Primex Wireless, Inc. All rights reserved.
U.S. Patents 6,873,573; 7,352,657. Other Patents Pending.
Printed in the USA.
Information in this document is subject to change without notice. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical or otherwise, for any purpose, without the prior written
permission of Primex Wireless.
Contact Primex Wireless
United States Canada United Kingdom
Address 965 Wells Street
Lake Geneva WI 53147
1310 Kerrisdale Blvd.
Unit #4
Newmarket, ON L3Y 8V6
Unit G420 Dean Clough
Halifax, West Yorkshire HX3 5AX
Email [e-mail] [e-mail] [e-mail]
Web www.primexwireless.com www.primexwireless.ca primexwireless.co.uk
Telephone [phone] [phone] 0800-3896996
Fax [phone] [phone] 01422-349462
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide I

CONTENTS
Regulatory Compliance 1
Important Safety Instructions 2
XR Series Time Synchronization System Overview 3
Architecture 3
Precision Timing 3
Synchronization 3
Typical System Setup 3
System Specifications 4
System Components 4
Transmitter Display Specifications 4
GPS Receiver Specifications 5
Installation and Configuration 7
Transmitter and GPS Receiver Location 7
Installation and Configuration Overview 7
Installation Location Guidelines 7
Assemble Ground Plane Omnidirectional Antenna 9
Assemble Antenna Mast 9
Mount the Antenna Mast 9
Route Antenna LMR 400 Coaxial Cable 14
Route GPS Cable 14
Install GPS Receiver 14
Secure Antenna to Mast 15
Connect Cables 15
Ground the Antenna Mast 16
Ground the Transmitter 16
Complete Final Installation and Mounting Requirements 16
Setup the Transmitter 17
Verify System is Operational 19
Transmitter Operation 20
Basic Operation of the Transmitter 20
Daylight Saving Time 20
Time Zone 21
12-Hour or 24-Hour Time 21
Status of GPS Receiver Communication 21
Power Failure 21
Troubleshooting 22
Transmitter Problems 22
Display Does Not Light Up 22
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 2

Display Lights Up, but is Blank or Very Faint 22
Signal Reception Problems 22
Displayed Time/Date is Incorrect 23
Extremely Weak Transmitter Power (About 100 Feet or Less) 23
Weak Signal (Limited Coverage Area) 23
Red LED is Flashing 23
Transmitter Broadcast - System Device Installation Considerations 24
Manual Setting Battery Operated Clocks 24
Automatic Setting Battery Operated Clocks 24
AC Powered Analog Clocks 24
Digital LED Clocks 25
Satellite Transmitter - Receiver Switch (Repeater) 25
Wireless Tone Generator 25
Support 26
Warranty 27
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 3

REGULATORY COMPLIANCE
Federal Communications Commission (FCC) / Industry Canada (IC)
License Requirements
lOperation of the Transmitter requires a FCC/IC operating license, which must be obtained prior to operation.
lFCC licenses must be renewed every 10 years and the IC licenses must be renewed annually.
lAs a service, Primex Wireless will file the license application if the end-user desires it. An end-user that does not want
Primex Wireless to file for the original site license will be required to complete a waiver form, file the required
application, and receive a valid license from the FCC/IC prior to use.If you have any questions or need any assistance,
please contact Primex Wireless at 1-800-537-0464.
lPrimex Wireless requires a copy of the licenses in order to complete the factory presets.
Product Compliance
lThis device complies with Part 90 and Part 15 of the FCC rules and RSS-210 of Industry Canada.
lOperation of this device is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference, including interference that may cause undesired operation.
Changes or modifications to any part of the Primex Wireless System components not expressly
approved by Primex Wireless could void the userʼs FCC/IC authority to operate the equipment.
Radio Frequency (RF)Exposure
To comply with FCC OET65 and Industry Canada RF exposure requirements, the antenna is only to be used or installed in locations
where the following antenna separation guidelines exist when the transmitter is in operation. Distance above roofline is for direct line
of sight only, as illustrated in Figure 1.
Distance Above Roofline: 8.95' (2.72m)
Figure 1: Distance Above Roofline Illustration
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 1

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE INSTALLATION, OPERATION, OR MAINTENANCE OF PRODUCT.
Some of the following information may not apply to your particular product model; however, as with any electronic product, precautions
should be observed during installation, operation, and maintenance.
lNever operate the transmitter without the antenna being properly connected to the transmitter.Operating the
transmitter without an antenna can lead to permanent damage of the transmitter and poses a safety risk.
lDo not touch any of the antennas while broadcasting.
lStandard acceptance procedures must be followed prior to operating this equipment in the proximity of life support
systems.
lDo not operate the transmitter outdoors, in wet areas were there is standing water, or in areas where there is
condensation or the risk of condensation. Use in any of these environments will damage the transmitter and void the
warranty.
lDo not open the transmitter to alter the internal elements in any way. This will void the warranty and could lead to
unsafe conditions, malfunction, and violations of FCC/IC regulations.
lDo not use a metal ladder during installation of the external antenna.
lDuring antenna installation, be sure to wear shoes with rubber soles and heals and wear protective clothing with long
sleeves and rubber gloves.
lDo not install the antenna on a wet or windy day when lighting or thunder is in the area or near power lines. Power lines,
telephone lines, and guy wires look the same. As a precaution please assume any wire can electrocute you.
The installation, maintenance, or removal of an antenna requires qualified, experienced personnel. The installation instructions are
written for such installation personnel.
Antenna systems should be inspected once a year by qualified personnel to verify proper installation, maintenance, and condition of
equipment.
Primex Wireless disclaims any liability or responsibility for the results of improper or unsafe installation practices.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 2

XR SERIES TIME SYNCHRONIZATION SYSTEM OVERVIEW
Architecture
The XR Time Synchronization System has been designed with customization in mind. It provides a scalable solution that offers time
synchronization services for a variety of devices and components. The system ranges from a a single transmitter, GPS Receiver, and a
handful of clocks in a single building, to a campus wide deployment.
Precision Timing
The Global Positioning System (GPS) Receiver draws time information from the U.S. Government Satellites. The GPS Receiver then sends
the time to the transmitter.
Synchronization
Once the transmitter has received its time, from either a GPS Receiver or another transmitter, it sets its internal clock. It then transmits
time information or schedules via a wireless radio signal to the wireless clocks, bells, and other devices in the system. As a result, the
system clocks, bells, and other devices are precisely synchronized to each other and all time, schedules, and events are kept current.
lTime Source: The transmitter has its time synchronized by a GPS Receiver and then broadcasts that time and event
schedules to clocks and other devices. The transmitter operates on channels with 20kHz bandwidths and 72MHz
frequency and is preset to one of the channels licensed by the FCC/IC to minimize interference on these frequencies and
channels.
lTransmit Schedule: The transmitter transmits its synchronized time to the system clocks and devices from the 39th to
the 6th minute of the next hour and changes to a standby mode during the 7th to the 38th minute of the hour (standard
broadcast schedule). During initial power-up, the transmitter broadcasts for 8 consecutive hours. After the 8 hour power-
up period, the transmitter reverts to the standard broadcast schedule.
Typical System Setup
The illustration below represents a typical system setup.
Figure 2: Transmitter - External Antenna Typical System Setup
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 3

SYSTEM SPECIFICATIONS
System Components
lXR 14000 Series Transmitter - External Antenna
l100' (30.48m) LMR 400 coaxial cable
lGelwrap splice enclosure
lPower supply and cable extension
lGrounding clamp
l6 AWG stranded wire
lTerminal lug
lGround Plane Omnidirectional Antenna
Optional Equipment
lGPS Receiver
lGPS Extension Cable
lGPS Receiver Mounting Kit
lGround Plane Omnidirectional Antenna Pole Mounting Kit
lGround Plane Omnidirectional Penetrating Antenna Kit
lGround Plane Omnidirectional Non-Penetrating Antenna Kit
lSatellite Transmitter
Transmitter Specifications
l1 Watt maximum transmission (at transmitter)
l72MHz frequency range
l16 channels available (pre-programmed prior to shipping)
lDaylight Saving Time bypass switch
lTime zone adjustment switch (pre-programmed on 14000-E prior to shipping)
lLCD display for time, date, and signal verification
lDimensions: 16.0”L x 12.0”W x 1.9”D (40.6cm x 30.5cm x 4.8cm)
lPower Supply:
lInput: 120 VAC, 50/60 Hz, 0.4 Amp
lOutput: 9 VDC, 2.0 Amp (6 ft. cord, 1.83m)
lOperating Range: 32°- 158°F (0° - 70°C)
Transmitter Display Specifications
The transmitter has a lighted front display that shows important information.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 4

Figure 3: 14000 Series Transmitter Display
Display Specifications
Table 1: 14000 Transmitter Display Specifications
Component Description
Time Displays the precise time received from the GPS Receiver.
If AM or PM is on the display, then the 12-hour option is selected.
If neither AM nor PM is on the display, then the 24-hour option is selected.
Daylight Saving Time The letters "DT" (Daylight Saving Time) or "ST" (Standard Time) will be displayed
when adjustment for Daylight Saving Time is active.
If neither "DT" nor "ST" is displayed, then switch #3 is in the down position and the
transmitter will not adjust for Daylight Saving Time.
GPS Communication The GPS Communication indicator appears when the transmitter is
communicating with the GPS Receiver.
The parentheses indicate the time signal is being received.
Day/Date Displays the day and date received from the GPS satellite.
Channel Number Displays the channel number (1-16) the transmitter is set to.
Red LED The red LED (Light Emitting Diode) is located on the right side of the front panel of
the transmitter.
The LED flashes on initial setup until a GPS time signal is received or when a
severe GPS Receiver signal problem has occurred and no time data has been
received from the GPS Receiver in 48 hours.
See the Troubleshooting section of this guide for additional information.
GPS Receiver Specifications
The GPS receiver draws time information from the U.S. Government Satellites, providing the system with Coordinated Universal Time
(UTC).
lMounted to rooftop, pole, or window (not a Low-E glass window).
lGPS receiver sends the UTC time to the transmitter via the NMEA 0183 standard protocol.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 5
System Specifications GPS Receiver Specifications

lOptional GPS extension cable. A specially designed low-resistance cable is available to extend the distance between GPS
receiver and transmitter. The maximum total length of the cable cannot exceed 200' (60.96m).
Table 2: GPS Receiver Specifications
Parameter Specification
Cable 10' (3.05m) cable
50', 100',and 200' (15.24m, 30.48m, and 60.69m) extensions available. The maximum total
length of the cable cannot exceed 200' (60.96m).
Dimensions 2.5”W x .75”H (6.35cm x 1.91cm)
Mounting Bracket 3.5”W x 1.4”H x 4.5”D (8.89cm x 3.56cm x 11.43cm)
Included for rooftop or window installation.
Weight 0.75 lb. (.34kg)
Operating Range -32°- 158°F (-30° - 70°C)
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 6
System Specifications GPS Receiver Specifications

INSTALLATION AND CONFIGURATION
Transmitter and GPS Receiver Location
The first step in setting up the transmitter is to determine a suitable location for the transmitter and GPS Receiver. Location is
extremely important to ensure the best operation of the system. You must consider the following:
Installation and Configuration Overview
lReview the Installation Location Guidelines and identify the installation location of the system components.
lInspect system components to verify packaging includes all supplied parts for each system component and verify no
damage has occurred during shipping.
lDo not install or attempt to set the system wireless clocks or devices until the system components are installed and
configured, the transmitter is powered and its time source is configured, and the transmitter is fully operational.
Summary of Installation
Listed below is a summary of the order in which the system and its components are to be installed and configured.
1. Assemble the ground plane omindirectional antenna .
2. Assemble the antenna mast.
3. Route the antenna LMR 400 coaxial cable
4. Route the GPS cable.
5. Install the GPS receiver.
6. Secure the antenna to mast.
7. Ground the antenna mast.
8. Ground the transmitter.
9. Connect the transmitter time source.
10. Establish the transmitter settings and verify connections.
11. Verify the system is operational.
Installation Location Guidelines
When planning the system installation, Primex Wireless recommends taking into consideration the below installation guidelines.
NOTE: Prior to installation and to assure optimum performance of the system, it is recommended a Primex Wireless
Applications Engineer performs a site survey. The site survey includes an analysis and recommendation of the
installation location of the system components and ground plan omnidirectional antenna.
Ground Plane Omnidirectional Antenna Installation Location Guidelines
lIn the event that metal objects extend above the level of the ground plane, the radiation pattern will be distorted.
Radiation through metal objects will be lower than from other directions.
lThe antenna cannot be placed on or directly adjacent to walls or metal structures.
lAntenna is required to be a minimum of 15' (4.57m) clear from the radius of other antennas.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 7

Transmitter Installation Location Guidelines
lTransmitter should be located a minimum of 2 to 3 feet above the floor.
lLocate transmitter within 8 feet from a 120 VAC electrical outlet.
lLocate transmitter within 100' (30.48m) of antenna. The maximum cable length allowed between the antenna and
transmitter is 100' (30.48m) .
lThe transmitted signal from the antenna radiates in a circular and “umbrella” pattern; therefore a central location for the
transmitter where the antenna is at maximum allowable height is recommended to ensure best possible coverage.
lIn multi-story buildings, installation the transmitter on the top floor will often significantly improve coverage to the
lower floors due to the “umbrella” pattern of transmission.
GPS Receiver Installation Location Guidelines
Determine a suitable location for the GPS receiver unit.Location is extremely important to ensure the best operation of the system.
You must consider the following:
lGPS receiver unit requires a "clear view of the sky" to receive a GPS signal 24 hours a day.
lTypical mounting locations of the GPS receiver unit include the inside of a window (not a Low-E glass window), to an
exterior pole or on a rooftop.
lGPS receiver unit should be kept away from large metal objects.
lGPS receiver unit and cable are mounted above any potential standing water, snow depth, leaves or other obstructions
and it protected from weather.
lMaximum total distance of the GPS cable to the transmitter cannot exceed 200' (60.96m).
lIf the GPS cable is located outdoors, the use of a gelwrap splice enclosure is strongly recommend.
Tools and Equipment Required
To install the system and its components, you will need the following tools and equipment.
lHammer drill
l3/4” concrete drill bit, 18” (45.72cm) long
lPenetrating Mount only: 5/8" concrete drill bit, 18” (45.72cm) long
l1/2” wrench
lCaulk for concrete
lPhillips and flat head screwdrivers
l10” (25.4cm) adjustable wrench
lLineman’s pliers
lShears/scissors
lTransmitter shelf (recommended)
lBuilding ground near transmitter
lGround near transmitting antenna
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 8
Installation and Configuration Installation Location Guidelines

Assemble Ground Plane Omnidirectional Antenna
Complete the steps below to assemble the antenna.
1. After removing the antenna from the shipping box, inspect all contents to ensure all parts are on hand and no damaged has
occurred during shipping.
2. Screw the radials (3) into the base of the antenna.
3. Assemble the U-bolt on the base of the antenna. The Mast is to be aligned with the top of the mast channel.
Figure 4: Antenna Assembly
Assemble Antenna Mast
The Antenna Mast has two sections secured by a hex bolt during shipment. The two sections include a 5’ by 1.25” (1.52m by 2.54cm)
rigid galvanized conduit and a 5’ by 1” (1.52m by 3.17cm) rigid galvanized conduit.
NOTE: The Non-penetrating mounting kit only includes the 5’ by 1.25” rigid galvanized conduit section.
Complete the steps below to assemble the antenna mast.
1. Loosen and remove the hex bolt.
2. Remove the 5’ by 1” rigid galvanized conduit section.
3. Insert the 5’ by 1” rigid galvanized conduit section into the 5’ by 1.25” rigid galvanized conduit section in reverse as shipped to
attain a combined antenna mast length of 9' (2.74m).
4. Align the sections' fastening holes and secure sections together using the supplied hex bolt and nuts.
Mount the Antenna Mast
NOTE: Mounting the antenna mast may require two people.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 9
Installation and Configuration Assemble Ground Plane Omnidirectional Antenna

There are three available mounting methods. The method used is dependent upon the mounting kit supplied with the system.
lNon-Penetrating Antenna Kit: See "Install Non-Penetrating Antenna Kit" for detailed mounting instructions.
lPenetrating Antenna Kit: See "Install Penetrating Antenna Kit" for detailed mounting instructions.
lAntenna Pole Mounting Kit: See "Install Pole Mount Kit" for detailed mounting instructions.
Install Non-Penetrating Antenna Kit
The Non-Penetrating Antenna Kit is designed for mounting a ground plane omnidirectional antenna when mounting to the side of a
structure is not practical.The overall footprint of the frame is 29” X 35 ½" (73.66cm x 88.9cm).
Kit Contents
The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless.
Description Qty
5’ by 1.25” (1.52m x 3.17cm) rigid galvanized conduit mast 1
Tripod leg: 27"(2.54cm) each in length 3
34 ¾”(88.26cm) Frame rail (long) 2
28 ¼” (71.75cm) Frame rail (short) 4
Long carriage bolt 1
Short carriage bolt 11
Flat washers 12
Locknuts 12
Installing the Antenna Using the Non-Penetrating Kit
Complete the steps below to mount an antenna using a non-penetrating antenna kit. The assembly is illustrated in For additional
information, see "Non-Penetrating Mount Illustration" located on page 11.
1.1. Verify the kit contents.
2. Assemble the outer frame by laying the 2 long frame rails parallel to each, approximately 30" (76.2cm) apart.
3. Insert a short carriage bolt from the bottom at each frame rail end, pointing skyward (4 total).
4. Connect the 2 long frames rails by placing the 2 short frame rails on top of the 4 protruding bolts to form a rectangle. Make
sure the square holes in the short tail "sides" are directly opposite each other.
5. Place a washer and nut on each of the 4 bolts and finger tighten.
6. Position the tripod within the 4 sided frame.
7. Secure the 3 tripod legs to the inside of the frame by inserting 3 short bolts, from the inside and placing the washer and
nut on the outside of the frame.
8. Drop the bottom of the mast (end with hole) through the top of the tripod collar.
9. Place the remaining 2 short rails parallel to each other, separated by the bottom of the mast.
10. Align the hole at the bottom of the mast, with the 2 square holes in the short frame rail sides.
11. Insert the long bolt and connect the frame rails to the mast.
12. From the underside of the frame, insert the 4 remaining short bolts upward and connect the inner short tails to the frame.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 10
Installation and Configuration Mount the Antenna Mast

13. Tighten all nuts to secure.
14. Next, route the antenna cable. For additional information, see "Route Antenna LMR 400 Coaxial Cable" located on page 14.
Figure 5: Non-Penetrating Mount Illustration
Install Penetrating Antenna Kit
The Penetrating Antenna Kit contains the materials required to mount the antenna to a wooden pole or masonry wall. A 5/8" (1.58cm)
diameter mounting hole is required and the maximum diameter of the pole or wall thickness is 14" (35.56cm).
Kit Contents
The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless.
Description Qty
5’ by 1.25” rigid galvanized conduit section 1
5’ by 1” rigid galvanized conduit insert 1
Antenna mounting clamp 2
1/2" hex head bolt 2
1/2" bolt washer 2
1/2" lock washer 2
1/2" hex nut 2
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 11
Installation and Configuration Mount the Antenna Mast

Mounting Antenna Using Penetrating Antenna Kit
Complete the steps below to mount the antenna using a penetrating antenna kit.
NOTE: The recommended diameter of the pole or the wall thickness should not exceed 14" (35.56cm).
1. Verify the kit contents.
2. Assemble both clamps, as shown in Figure 6, tightening the hex nuts to a torque of approximately 45ft-lbs.
Figure 6: Wall Mount
3. Remove the nut and washer from 14” threaded rod.
4. Drill a 5/8” hole through the top of an exterior wall.
5. Insert the 14” threaded rod through the hole in the wall. If the thickness of the wall is greater then 10”, a longer rod may be
required. Different lengths of rod are available at hardware stores. If a longer threaded rod is needed, please use a 5/8”-11
threads per inch rod.
6. Place the nut and metal plate over the rod.
7. Tighten the square nuts to an approximate torque of approximately 55 ft-lbs.
8. Drill a second 5/8” (1.59cm) hole 2.5’ (0.76m) directly below the first hole.
9. Ensure both clamps are vertically aligned, as shown in Figure 7.
10. Repeat Steps 4 through 6.
11. Connect the LMR 400 cable to the antenna. Be sure the connection is tight.
12. Insert the mast into the clamps.
13. Tighten both clamps evenly and securely.
14. Next, route the antenna cable. For additional information, see "Route Antenna LMR 400 Coaxial Cable" located on page 14.
Figure 7: Aligning Clamps
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 12
Installation and Configuration Mount the Antenna Mast

Install Pole Mount Kit
The Pole Mount kit is designed for the purpose of mounting the ground plane ominidirectional antenna to round or angled tower legs.
The clamps can be used on round tower legs that measure for 1.25" to 3.25" (3.17cm to 8.25cm) OD or on angled tower legs that
measure up to 3" (7.62cm) on a side.
The center section of each clamp is welded to proved mechanical stability and all parts are hot-depped galvanized steel.
Kit Contents
The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless.
Description Qty
5’ by 1.25” rigid galvanized conduit section 1
5’ by 1” rigid galvanized conduit section 1
X style clamp 2
U-clamp 4
1/2" all thread bolt 4
1/2" lock washer 16
1/2" hex nut 16
Mounting Antenna Using Pole Mount Antenna Kit
Complete the steps below to mount the antenna using the pole mount antenna kit.
1. Verify the kit contents.
2. Assemble both clamps, as shown in Figure 8, tightening the hex nuts to an approximate torque of approximately 45 ft-lbs.
3. Tighten half of one clamp two feet below the top of the pole. Use a 3/4” wrench to do this and be sure to tighten the clamps both
evenly and securely.
4. Tighten half of the other clamp, using a 3/4” wrench, a few inches below the top of the pole. Be sure to tighten the clamps both
evenly and securely.
5. Connect the LMR 400 cable to the antenna. Be sure the connection is tight.
6. Insert the mast into the clamps. The bottom of the mast should be a minimum of 2” below the bottom clamp.
7. Tighten all nuts on both clamps using a 3/4” wrench. The final assembly is to resemble Figure 8.
8. Next, route the antenna cable. For additional information, see "Route Antenna LMR 400 Coaxial Cable" located on page 14.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 13
Installation and Configuration Mount the Antenna Mast

Figure 8: Pole Mount
Route Antenna LMR 400 Coaxial Cable
Complete the below steps to route the LMR 400 coaxial cable from the transmitter to the antenna.
1. Drill a 1" (2.54cm) hole through an exterior wall of the building that is in close proximity to the antenna installation location.
2. Rollout the LMR 400 cable to prevent kinks from developing during routing.
3. Route the LMR 400 cable female connector from the transmitter installation area to the outside installation location of the
antenna, leaving enough cable for (2) 1' (0.30m) diameter coils at the base of the antenna mast.
4. Form and secure two 1’ diameter (305mm) loops in the LMR 400 cable at the base of the mast for lightning protection.
5. Connect the LMR 400 cable to the antenna.
Route GPS Cable
Complete the below steps to route and connect the GPS cable to the transmitter.
1. From the outside of the building, route the GPS cable through thea 5/8" 3/4" drilled hole into the building.
Install GPS Receiver
Mounting Kit Contents
The GPS Receiver mounting kit is supplied with the following parts. If any of these items are missing, contact Primex Wireless.
Part Quantity
Mounting bracket 1
LVC and connector 1
M3 x 0.5 x 6mm pan head screws 2
#6 x 3/8 sheet metal screw 3
Suction cups 3
U-bolt with nuts for mounting on 1” (2.54cm) pole 1
Mounting the GPS Receiver
If the system will use GPS as its time source, complete the following installation steps.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 14
Installation and Configuration Route Antenna LMR 400 Coaxial Cable

1. Verify the kit contents.
2. Verify the installation location meets the installation guidelines.
3. Assemble and mount the GPS receiver unit to an inside of a window (not Low-E glass), an outside pole, or rooftop. The mounting
location is required to have a clear view of the sky.
CAUTION: Be sure to follow local building code requirements when attaching the GPS unit to the inside of a window.
Clean the windowpane before using the suctioncups for attachment.
Figure 9: GPS Receiver Installation Components and Illustration
Secure Antenna to Mast
Complete the steps below to secure the antenna to the mast.
1. Attach and fasten the antenna channel side base to the top of the 1” rigid galvanized conduit section.
2. Use a 1/2” wrench to tighten the nuts on both of the U-bolts, both evenly and securely. Tighten the second nut to the first nut, to
ensure it is secure.
Connect Cables
Complete the steps below to connect the GPS and LMR 400 cable to the transmitter.
1. Connect the GPS cable to transmitter "GPS IN" port, located on the rear of the transmitter.
2. Connect the LMR 400 cable to the transmitter "External Antenna" port, located on the rear of the transmitter.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 15
Installation and Configuration Secure Antenna to Mast

Ground the Antenna Mast
Complete the steps below to ground the antenna mast. The National Electrical Code (NEC) requires that every antenna installation be
grounded. Also, many areas have local antenna-grounding codes. Be sure that you are familiar with the grounding and other antenna
regulations in your area.
1. Secure the ground clamp (supplied) around the antenna mast.
2. Insert and tighten the #6 gauge wire (supplied) in the ground clamp. The final assembly should resemble Figure 10.
NOTE: Cut the 50’ wire off at the necessary length. The remainder of the wire will be used to ground the transmitter.
3. Connect the other end of the #6 gauge wire to a verified building/earth ground.
Figure 10: Ground Clamp
Ground the Transmitter
Complete the steps below to ground the transmitter.
1. Connect and tighten the terminal ground lug (supplied) on the transmitter.
2. Insert and tighten #6 gauge wire (supplied) into the transmitter terminal ground lug.
3. Connect other end of wire to a verified building/earth ground source.
Complete Final Installation and Mounting Requirements
1. Weatherproof the antenna connection using gel wrap kit supplied.
2. Secure the GPS cable and LMR 400 cable to building and mast.
3. Leave a drip loop where both cables enter the building to prevent water from entering the building.
4. Use UV resistant zip ties to secure the cables to the mast and building.
NOTE: Do not zip tie the GPS cable to the LMR 400 cable. These two cables must be 2” (5.08cm) apart at all times, with
the exception of the point where they enter into the building.
5. Verify all nuts and bolts in the mounting hardware are secure.
6. Caulk all exterior holes.
7. Secure and tie wrap all indoor cables.
Primex Wireless 14000 Series Transmitter - External Antenna Installation & User Guide 16
Installation and Configuration Ground the Antenna Mast
