Prisma Electronics HPM4+PYR2-IR+STW User manual

RACING INSTRUMENTS
Get Ahead...
Part number : HPM4+PYR2-IR+STW
MADE IN ITALY
REFERENCE MANUAL 01
T3:123°C
01
0
18:31:58 20°C
01
0
.
9
3
Bar
Multifunctions istrument
Tire pressure gauge & Stopwatch

1 - Power ON
Press
MENU
L1
Auto Power OFF after 10 minutes of
inactivity. To force the Power OFF, press
and Hold L1 button
2 - The display show L1 - L2 - L3 - L4
SETUP DEVICE - DELETE DATA - READ DATA
Press and hold L1 button for 2 seconds
MENU
L1
L1 is the DRIVER 1’s START - STOP Button ---> S1 is the Split time button
L2 is the DRIVER 2’s START - STOP Button ---> S2 is the Split time button
L3 is the DRIVER 3’s START - STOP Button ---> S3 is the Split time button
L4 is the DRIVER 4’s START - STOP Button ---> S4 is the split time button
By pressing L1 button the Lap Time Driver 1 starts. - The S1 button is it for the split time.
At the next press of L1 Button ( first Lap ) the display show the current Lap Time.
In the following laps the display show :
Current Lap [ L05 ]
Current Lap Time [ 0:45.96 ]
The time difference with the Best Lap [ +0.58 ]
The Best Lap time [ 0:45.38 ]
The Split times S1 - S2 - S3 - S4 - S5- S6 - S7 - S8 - SS ( SS is the last Split Time )
1 - L05 - 0:45.96 +0.58
|--> SS - 28.50
Best Lap : 45.38
Same procedure for L2 - L3 - L4
STOPWATCH MODE

The display show which buttons to press for each Menu
DELETE DATA READ DATA SET DEVICE
S1 S2
+
Follow the instructions on the display to complete all operations.
BACKLIGHT DISPLAY
The light sensor at the top of the instrument set automatically the display’s backlight
intensity.
MENU LANGUAGE
It is possible to set the menu languages to ITA - FRA - ENG .
Read data
By pressing S2 button, the display shows the current test Lap times.
With S2 - S3 buttons it is possible to read the Lap Split Times.
The + - Buttons is used to scroll the DRIVER 1 -2 - 3 - 4 Lap Times.
To exit to main MENU press
S1
MODE
Press and HOLD for 2 seconds
to switch PRESSURE MODE

1 - Power ON
Press button
Auto Power off after 2,5 minutes if inactivity.
To Power off manually , press and hold the
ON/OFF button.
2 - The display shows the test number [ 01 ] :
Measure and set the pressure of the tire shown on the
display. When the pressure is set, press MEM button
to save it
MEM
3 - The display shows the saved pressure value and the next tire to measure
1.65
Repeat the procedure for the other tires.
4 - The display shows all the saved pressures value - COLD TIRES PRESSURE
1.50 1.50
1.65
MENU
L1
PRESSURE GAUGE MODE

1.65
5 - Repeat the same procedure for the HOT TIRES PRESSURE
1.50 1.50
1.65
1.70 1.65
1.85 1.80
+0.20 +0.15
+0.15+0.20
For a new Test press
MEM
TIRE TEMPERATURE MODE
S1
MODE
Press for TIRE TEMPERATURES MODE
L3
AIR Press to save AIR temperture.The display show A : XX°C
S3
TRACK Press to save TRACK temperature.The display show T : YY°C
L2
MEM
S2
MEM
Press to save tire temperatures. The display show
T1 to T12 temperatures value

01 : Test number
S1
MODE
Press to return PRESSURE MODE

MENU
L1
Switch to STOPWATCH mode
Press for 2 seconds
CONFIGURE - RESET - READ MEMORY ------ Press
The display shows all the Menu and which buttons need to press .
RESET DATA READ SAVED PRESSURES CONFIGURE
MODE MEM
+
PRESSURE SHOOT ® FUNCTION
This function is used to save the HOT tire pressures without pressing MEM button.
PRESSURE DIFFERENCE FUNCTION
This function is used to show the difference from COLD and HOT tire pressures on
the display.
Follow the instructions shown on the display.
DISPLAY BACKLIGHT FUNCTION
With the light sensor the instrument set automatically the backlight of the display. It
can reduce the battery life.
LANGUAGE MENU
ENGLISH - FRENCH - ITALIAN language menu available
MENU
L1

MADE IN ITALY
www.prismaelectronics.com
For Technical support visit
