Prisma Electronics HPM4+PYR2 User manual

RACING INSTRUMENTS
Get Ahead...
Part number : HPM4+PYR2
MADE IN ITALY
REFERENCE MANUAL 01
T3:123°C
01
0
01
Bar
Multifunctions instrument
TIRE PRESSURE GAUGE
+
TIRE PYROMETER

1 - Power ON
Press button
Auto Power off after 2,5 minutes if inactivity.
To Power off manually , press and hold the
ON/OFF button.
2 - The display shows the test number [ 01 ] :
Measure and set the pressure of the tire shown on the
display. When the pressure is set, press MEM button
to save it
MEM
3 - The display shows the saved pressure value and the next tire to measure
1.65
Repeat the procedure for the other tires.
4 - The display shows all the saved pressures value - COLD TIRES PRESSURE
1.50 1.50
1.65
PRESSURE GAUGE MODE
OFF
ON
MENU

1.65
5 - Repeat the same procedure for the HOT TIRES PRESSURE
1.50 1.50
1.65
1.70 1.65
1.85 1.80
+0.20 +0.15
+0.15+0.20
For a new Test press
MEM
TIRE TEMPERATURE MODE
MODE
Press for TIRE TEMPERATURES MODE
AIR Press to save AIR temperture.The display show A : XX°C
TRACK Press to save TRACK temperature.The display show T : YY°C
MEM MEM Press to save tire temperatures. The display show
T1 to T12 temperatures value

01 : Test number
MODE
Press to return PRESSURE MODE
A : 23°C --> AIR temperature
T : 26°C --> TRACK temperature
01 --> Test number
T3 : 123°C --> Last saved temp
123°C --> Temperature

CONFIGURE - RESET - READ MEMORY ------ Press
The display shows all the Menu and which buttons need to press .
RESET DATA READ SAVED PRESSURES CONFIGURE
MODE MEM
+
PRESSURE SHOOT ® FUNCTION
This function is used to save the HOT tire pressures without pressing MEM button.
PRESSURE DIFFERENCE FUNCTION
This function is used to show the difference from COLD and HOT tire pressures on
the display.
Follow the instructions shown on the display.
DISPLAY BACKLIGHT FUNCTION
With the light sensor the instrument set automatically the backlight of the display. It
can reduce the battery life.
LANGUAGE MENU
ENGLISH - FRENCH - ITALIAN language menu available
OFF
ON
MENU

MADE IN ITALY
www.prismaelectronics.com
For Technical support visit
