Pro-Form 790t Treadmill User manual

Serial Number
Decal
Model No. PFTL81910.1
Serial No.
Write the serial number in the space
above for reference.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
QUESTIONS?
f you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT T E STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON T E WEB:
www.proformservice.com
USERʼS MANUAL
www.proform.com
Meijer.com

TABLE OF CONTENTS
WARNNGDECALPLACEMENT..............................................................2
MPORTANTPRECAUTONS ................................................................3
BEFOREYOUBEGN ......................................................................5
PART DENTFCATONCHART ..............................................................6
ASSEMBLY...............................................................................7
OPERATONANDADJUSTMENT ............................................................15
HOWTOFOLDANDMOVETHETREADMLL ..................................................24
TROUBLESHOOTNG .....................................................................25
EXERCSEGUDELNES ...................................................................28
PARTLST ..............................................................................30
EXPLODEDDRAWNG ....................................................................32
ORDERNGREPLACEMENTPARTS ..................................................BackCover
LMTEDWARRANTY ..............................................................BackCover
This drawing shows the locations of the
warning decals. If a decal is missing or il-
legible, call the telephone number on the
front cover of this manual and request a
free replacement decal. Apply the decal
in the location shown. Note: The decals
may not be shown at actual size.
WARNING DECAL PLACEMENT
2
PROFORM is a registered trademark of CON P, nc.
Meijer.com

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over age 35 or persons with
pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
3. Use the treadmill only as described.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Place the treadmill on a level surface, with at
least 8 ft. (2.4 m) of clearance behind it and 2
ft. (0.6 m) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
6. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
7. Keep children under age 12 and pets away
from the treadmill at all times.
8. The treadmill should be used only by persons
weighing 325 lbs. (147 kg) or less.
9. Never allow more than one person on the
treadmill at a time.
10. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended
for both men and women. Always wear ath-
letic shoes. Never use the treadmill with bare
feet, wearing only stockings, or in sandals.
11. Plug the power cord into a surge suppressor
(not included), and plug the surge suppressor
into an appropriate outlet (see page 15). To
avoid overloading the circuit, do not plug
other electrical devices, except for low-power
devices such as cell phone chargers, into the
surge suppressor or into an outlet on the
same circuit.
12. Use only a surge suppressor that meets all of
the specifications described on page 15. To
purchase a surge suppressor, see your local
PROFORM dealer, call the telephone number
on the front cover of this manual, or see your
local electronics store.
13. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may slow,
accelerate, or stop unexpectedly, which may
result in a fall and serious injury.
14. Keep the power cord and the surge suppres-
sor away from heated surfaces.
15. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLES OOTING on page 25 if the treadmill is
not working properly.)
16. Read, understand, and test the emergency
stop procedure before using the treadmill (see
OW TO TURN ON T E POWER on page 17).
17. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
18. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
19. The heart rate monitor is not a medical de-
vice. Various factors, including the user's
movement, may affect the accuracy of heart
rate readings. The heart rate monitor is in-
tended only as an exercise aid in determining
heart rate trends in general.
WARNING: To reduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. ICON as-
sumes no responsibility for personal injury or property damage sustained by or through the use of
this product.
IMPORTANT PRECAUTIONS
Meijer.com

4
20. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and press the power switch
into the off position when the treadmill is not
in use. (See the drawing on page 5 for the lo-
cation of the power switch.)
21. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 7, and OW TO FOLD
AND MOVE T E TREADMILL on page 24.)
You must be able to safely lift 45 lbs. (20 kg)
to raise, lower, or move the treadmill.
22. When folding or moving the treadmill, make
sure that the storage latch is holding the
frame securely in the storage position.
23. Never insert any object into any opening on
the treadmill.
24. Inspect and properly tighten all parts of the
treadmill regularly.
25. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorized ser-
vice representative. Servicing other than the
procedures in this manual should be performed
by an authorized service representative only.
26. This treadmill is intended for home use only.
Do not use this treadmill in a commercial,
rental, or institutional setting.
27. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
SAVE T ESE INSTRUCTIONS
Meijer.com

5
Thank you for selecting the revolutionary PROFORM®
790 T treadmill. The 790 T treadmill offers an impres-
sive selection of features designed to make your work-
outs at home more enjoyable and effective. And when
youʼre not exercising, the unique treadmill can be
folded up, requiring less than half the floor space of
other treadmills.
For your benefit, read this manual carefully before
using the treadmill. f you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, please note the product
model number and serial number before contacting us.
The model number and the location of the serial num-
ber decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail
Upright
Tray
Key/Clip
Power Switch
Walking Belt
Platform Cushion
Foot Rail
Power Cord
dler Roller
Adjustment Screws
Console
Heart Rate Monitor
Meijer.com

6
#8 x 3/4" Screw
(2)–8
3/8" Star
Washer (13)–4
3/8" Nut (12)–2
5/16" Star
Washer (11)–4
#10 x 3/4" Screw
(9)–2
3/8" x 2 3/4" Screw (7)–4
3/8" x 1 3/4" Bolt (6)–1 3/8" x 2" Bolt (3)–1
5/16" x 1"
Screw (5)–4
#8 x 1/2" Ground
Screw (10)–1
#8 x 1/2" Screw
(1)–18
5/16" x 1 1/4"
Bolt (4)–2 3/8" x 1 1/4" Screw (8)–4
1/4" x 1/2"
Screw (36)–4
1/4" Star
Washer (35)–6
#10 x 3/4" Flat
Head Screw (112)–2
5/16" Flat
Washer (113)–4
PART IDENTIFICATION C ART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART L ST near the end of this manual. The number following the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see if it is preat-
tached. Extra hardware may be included.
Meijer.com

7
1. Make sure that the power cord is unplugged.
Place a piece of cardboard below the rear of the
Frame (56) to protect the floor or carpet.
Attach the Left Wheel Cap (96) to the Base (94)
with two #8 x 3/4" Screws (2).
Attach the Right Wheel Cap (not shown) to
the right side of the Base (94) in the same
way.
1
96
94
2
56
Cardboard
2. Pull the Upright Wire (81) and the Base Ground
Wire (110) through the indicated hole in the
Base (94).
Attach the Base Ground Wire (110) to the Base
(94) with a #8 x 1/2" Ground Screw (10).
Press the Grommet (77) into the square hole in
the Base (94). 81
2
77
Hole
10
110
94
ASSEMBLY
• To hire a service technician to assemble this
product in your home, call 1-800-445-2480.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish assembly.
• The underside of the walking belt is coated with
high-performance lubricant. After shipping, there
may be some lubricant on top of the walking belt
or on the shipping carton. This is normal. f there
is lubricant on top of the walking belt, wipe it off
with a soft cloth and a mild, non-abrasive cleaner.
• To identify small parts, see page 6.
• Assembly requires the following tools:
the included hex keys
one adjustable wrench
one Phillips screwdriver
scissors
To avoid damaging parts, do not use power tools
for assembly.
Meijer.com

8
4. Hold the Left Upright (89) against the Base
(94). Be careful not to pinch the wires. nsert
two 3/8" x 2 3/4" Screws (7) and two 3/8" x 1
1/4" Screws (8) with two 3/8" Star Washers (13)
into the Left Upright.
Partially tighten the 3/8" x 2 3/4" Screws (7) and
the 3/8" x 1 1/4" Screws (8) until the heads of
the Screws touch the Left Upright (89); do not
fully tighten the Screws yet.
Attach the Right Upright (not shown) in the
same way. Note: There are no wires on the
right side.
89
94
4
8
7
13
13
3. dentify the Left Upright (89), which is marked
“Left.” Have a second person hold the Left
Upright near the Base (94).
See the inset drawing. Tie the wire tie in the
Left Upright (89) securely around the end of the
Upright Wire (81). Then, pull the other end of the
wire tie until the Upright Wire is routed through
the Left Upright.
81
3
81
89
Wire
Tie
Wire
Tie
89
94
81
Meijer.com

9
6. Cut the plastic ties in the Left Handrail (88) and
the Right Handrail (not shown). f necessary,
press the 5/16" Cage Nuts (31) back into place.
dentify the Left Handrail (88) and hold it near
the Left Upright (89). nsert the Upright Wire
(81) through the bracket on the bottom of the
Left Handrail. Pull the Upright Wire out of the
end of the Left Handrail.
88
6
89
31
81
Tie
5. dentify the Left Base Cover (82) and the Right
Base Cover (83). Slide the Left Base Cover onto
the Left Upright (89). Slide the Right Base Cover
onto the Right Upright (90). Do not press the
Base Covers into place yet.
dentify the Left Upright Cover (79) and the
Right Upright Cover (80). Slide the Left Upright
Cover onto the Left Upright (89). Slide the Right
Upright Cover onto the Right Upright (90).
89
82
80
90
79 83
5
Meijer.com

10
8. Set the console assembly face down on a soft
surface to avoid scratching the console assem-
bly. Remove the two indicated Screws (A). Next,
lift off the Crossbar (93). Discard the two
Screws.
93
Console
Assembly
A
8
9. IMPORTANT: To avoid damaging the
Crossbar (93), do not use power tools and
do not overtighten the #10 x 3/4" Screws (9)
or the #10 x 3/4" Flat ead Screws (112).
Orient the Crossbar (93) as shown. Attach the
Crossbar to the Handrails (87, 88) with two #10
x 3/4" Flat Head Screws (112), two #10 x 3/4"
Screws (9), and two 1/4" Star Washers (35) as
shown. Start all four Screws, and then tighten
each of them.
93
88
9
99
87
35
112
112
35
7. Attach the Left Handrail (88) to the Left Upright
(89) with two 5/16" x 1" Screws (5), two 5/16"
Star Washers (11), and a 5/16" x 1 1/4" Bolt (4).
Do not fully tighten the Screws and Bolt yet.
Attach the Right andrail (87) in the same
way.
7
89
88
87
4
5
11
Meijer.com

11
11. Set the console assembly on the Left Handrail
(88) and the Right Handrail (87). Be careful not
to pinch any wires. nsert the excess Upright
Wire (not shown) into the Left Handrail.
Attach the console assembly with six #8 x 1/2"
Screws (1), four 1/4" x 1/2" Screws (36), four
5/16" Flat Washers (113), and four 1/4" Star
Washers (35) as shown. Start all ten Screws,
and then tighten each of them.
See step 7. Fully tighten the four 5/16" x 1"
Screws (5) and the two 5/16" x 1 1/4" Bolts (4).
35 88
1
11
Console
Assembly
1
87
35
36
113
1
113
36
10. With the help of a second person, hold the con-
sole assembly near the Left Handrail (88).
Connect the Upright Wire (81) to the console
wire. See the inset drawing. The connectors
should slide together easily and snap into
place. f they do not, turn one connector and try
again. IF YOU DO NOT CONNECT T E CON-
NECTORS PROPERLY, T E CONSOLE MAY
BECOME DAMAGED W EN YOU TURN ON
T E POWER. Remove the wire tie from the
Upright Wire.
Console
Assembly
Console
Wire
Wire
Tie
88
81
81
Console
Wire
10
Meijer.com

12
14. Hold the Left Upright Cover (79) against the
console assembly. Align the holes in the Left
Upright Cover with the holes in the Left Upright
(89). Attach the Left Upright Cover with three #8
x 1/2" Screws (1).
Attach the Right Upright Cover (80) to the
Right Upright (90) in the same way.
14
89
1
Console
Assembly
79
1
90
1
80
13. Slide the Left Handrail Cover (85) onto the Left
Handrail (88). Slide the Right Handrail Cover
(86) onto the Right Handrail (87). Attach the
Handrail Covers with two #8 x 1/2" Screws (1).
13
85
86
1
1
87
88
12. Firmly tighten the four the 3/8" x 2 3/4" Screws
(7) and the four 3/8" x 1 1/4" Screws (8) (only
one side is shown).
Press the Left Base Cover (82) and the Right
Base Cover (83) onto the Base (94) until they
snap into place.
12
83
8
82
94
7
Meijer.com

13
16. IMPORTANT: See page 15 and plug in the
power cord. Next, see page 17 and turn on
the power.
Then, see page 26 and follow the instruc-
tions under “The incline of the treadmill
does not change correctly.” Note: This will
calibrate the incline.
When the frame stops moving, remove the
key from the console and unplug the power
cord.
16 IMPORTANT:
Make sure to follow all
instructions in this step.
15. Attach the Left Tray (107) and the Right Tray
(108) to the console assembly with four #8 x 1/2"
Screws (1).
107
108
15
Console
Assembly
1
1
1
Meijer.com

14
19. Make sure that all parts are properly tightened before you use the treadmill. f there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
Note: Extra hardware may be included. Keep the included hex keys in a secure place; one of the hex keys is
used to adjust the walking belt (see pages 26 and 27).
18. Attach the Rear Feet (57) to the Frame (56) as
shown with four #8 x 3/4" Screws (2).
Lower the Frame (56) (see HOW TO LOWER
THE TREADM LL FOR USE on page 24).
18
57
2
2
57
56
17. IMPORTANT: Before you begin this step,
make sure that you have read and followed
all the instructions in step 16.
Raise the Frame (56) to the position shown.
ave a second person hold the Frame until
step 18 is completed.
Orient the Storage Latch (53) so that the large
barrel and the latch knob are oriented as shown.
Attach the lower end of the Storage Latch (53) to
the Base (94) with a 3/8" x 2" Bolt (3) and a 3/8"
Nut (12).
Attach the upper end of the Storage Latch (53)
to the bracket on the Frame (56) with a 3/8" x
1 3/4" Bolt (6) and a 3/8" Nut (12).
17
53
Large
Barrel
56
6
Latch
Knob
12 3
94
12
Meijer.com

15
OPERATION AND ADJUSTMENT
OW TO CONNECT T E POWER CORD
Use a Surge Suppressor
Your treadmill, like other electronic equipment, can be
damaged by sudden voltage changes in your homeʼs
power. Voltage surges, spikes, and noise interference
can result from weather conditions or from other appli-
ances being turned on or off. To decrease the risk of
damaging the treadmill, always use a surge sup-
pressor with the treadmill. To purchase a surge
suppressor, see precaution XX on page X.
Use only a surge suppressor that is UL 1449 listed as
a transient voltage surge suppressor (TVSS). The
surge suppressor must have a UL suppressed voltage
rating of 400 volts or less and a minimum surge dissi-
pation of 450 joules. The surge suppressor must also
be electrically rated for 120 volts AC and 15 amps.
There must be a monitoring light on the surge suppres-
sor to indicate whether it is functioning properly.
Failure to use a properly functioning surge sup-
pressor could result in damage to the control sys-
tem of the treadmill and serious injury to users.
Plug in the Power Cord
The treadmill must be grounded. f it should mal-
function or break down, grounding provides a path of
least resistance for electric current to reduce the risk of
electric shock. The treadmill power cord has a plug
with a grounding pin (see drawing 1 on this page).
Plug the power cord into a surge suppressor, and plug
the surge suppressor into an appropriate outlet that is
properly installed and grounded in accordance with all
local codes and ordinances. The outlet must be on a
nominal 120-volt circuit capable of carrying 15 or
more amps. To avoid overloading the circuit, do
not plug other electrical devices, except for low-
power devices such as cell phone chargers, into
the surge suppressor or into an outlet on the same
circuit. IMPORTANT: The treadmill is not compati-
ble with GFCI-equipped outlets and may not be
compatible with AFCI-equipped outlets.
A temporary
adapter may
be used to
connect the
surge sup-
pressor to a 2-
pole recepta-
cle if a prop-
erly grounded
outlet is not
available. The
lug or wire ex-
tending from the adapter must be connected with a
metal screw to a permanent ground such as a properly
grounded outlet box cover. Some 2-pole receptacle
outlet box covers are not grounded. Before using
an adapter, contact a qualified electrician to deter-
mine whether the outlet box cover is grounded. The
temporary adapter should be used only until a
properly grounded outlet can be installed by a
qualified electrician.
DANGER: Improper connection
of the power cord increases the risk of elec-
tric shock. Do not modify the plug—if it will
not fit an outlet, have a proper outlet installed
by a qualified electrician. If you are unsure
whether the treadmill is properly grounded,
contact a qualified electrician.
1
Surge
Suppressor
Grounding Pin
Grounded Outlet
2
Adapter
2-pole Receptacle
Lug
Grounding Pin
Metal
Screw
Meijer.com

16
FEATURES OF T E CONSOLE
The treadmill console offers an impressive array of
features designed to make your workouts more effec-
tive and enjoyable. When you use the manual mode,
you can change the speed and incline of the treadmill
with the touch of a button. As you exercise, the con-
sole will display instant exercise feedback. You can
even measure your heart rate using the handgrip heart
rate monitor.
n addition, the console features sixteen onboard work-
outs—four calorie workouts, four interval workouts,
four speed workouts, and four endurance workouts.
Each workout automatically controls the speed and in-
cline of the treadmill as it guides you through an effec-
tive exercise session.
The console also features an iFit Live mode that en-
ables the treadmill to communicate with your wireless
network through an optional iFit Live module. With the
iFit Live mode, you can download personalized work-
outs, create your own workouts, track your workout re-
sults, race against other runners, and access many
other features. To purchase an iFit Live module at
any time, go to www.iFit.com or call the telephone
number on the front cover of this manual.
You can even listen to your favorite workout music or
audio books with the consoleʼs stereo sound system
while you exercise.
To turn on the power, see page 17. To use the man-
ual mode, see page 17. To use an onboard work-
out, see page 20. To use an iFit Live workout, see
page 21. To use the information mode, see page 22.
To use the stereo sound system, see page 23.
Note: The console can display speed and distance in
either miles or kilometers. To find which unit of mea-
surement is selected, see THE NFORMAT ON MODE
on page 22. For simplicity, all instructions in this sec-
tion refer to miles.
IMPORTANT: If there are sheets of plastic on the
console, remove the plastic. To prevent damage to
the walking platform, wear clean athletic shoes
while using the treadmill. The first time you use the
treadmill, observe the alignment of the walking
belt, and center the walking belt if necessary (see
page 27).
CONSOLE DIAGRAM
Meijer.com

17
OW TO TURN ON T E POWER
IMPORTANT: If the treadmill has been exposed to
cold temperatures, allow it to warm to room tem-
perature before turning on the power. If you do not
do this, you may damage the console displays or
other electrical components.
Plug in the power cord (see
page 15). Next, locate the
power switch on the tread-
mill frame near the power
cord. Press the power
switch into the reset
position.
IMPORTANT: The console features a display demo
mode, designed to be used if the treadmill is dis-
played in a store. If the displays light as soon as
you plug in the power cord and press the power
switch into the reset position, the demo mode is
turned on. To turn off the demo mode, hold down
the Stop button for a few seconds. If the displays
remain lit, see T E INFORMATION MODE on page
22 to turn off the demo mode.
Next, stand on
the foot rails of
the treadmill.
Find the clip at-
tached to the key
and slide the clip
onto the waist-
band of your
clothes. Then, in-
sert the key into
the console. After a moment, the displays will light.
IMPORTANT: In an emergency, the key can be
pulled from the console, causing the walking belt
to slow to a stop. Test the clip by carefully taking a
few steps backward; if the key is not pulled from
the console, adjust the position of the clip.
OW TO USE T E MANUAL MODE
1. Insert the key into the console.
See HOW TO TURN ON THE POWER at the left.
2. Select the manual mode.
f the manual mode is not selected, press the
Manual button on the console.
3. Start the walking belt.
To start the walking belt, press the Start button, the
Speed increase button, or one of the numbered
Quick Speed buttons.
f you press the Start button or the Speed increase
button, the walking belt will begin to move at 1
mph. As you exercise, change the speed of the
walking belt as desired by pressing the Speed in-
crease and decrease buttons. Each time you press
one of the buttons, the speed setting will change by
0.1 mph; if you hold down the button, the speed
setting will change in increments of 0.5 mph. Note:
After you press the button, it may take a moment
for the walking belt to reach the selected speed
setting.
f you press one of the numbered Quick Speed but-
tons, the walking belt will gradually change speed
until it reaches the selected speed setting. To se-
lect a speed setting that includes a decimal—such
as 3.5 mph—press two numbered buttons in suc-
cession. For example, to select a speed setting of
3.5 mph, press the 3 button and then immediately
press the 5 button.
To stop the walking belt, press the Stop button.
The time will begin to flash in the display. To restart
the walking belt, press the Start button or the
Speed increase button.
Reset
Key
Clip
Meijer.com

18
4. Change the incline of the treadmill as desired.
To change the incline of the treadmill, press the
ncline increase or decrease button or one of the
numbered Quick ncline buttons. Each time you
press one of the buttons, the treadmill will gradu-
ally adjust to the selected incline setting.
5. Follow your progress with the displays.
As you walk or run on the treadmill, the display can
show the following workout information:
• The elapsed time
• The distance that you have walked or run
• The workout intensity bar
• The approximate number of calories you have
burned
• The incline level of the treadmill
• The number of vertical feet you have climbed
• The speed of the walking belt
• Your heart rate (see step 6 on page 19)
• The matrix
The matrix offers several display tabs. Press the
increase and decrease button next to the Enter
button until the desired tab is shown.
The ncline tab will show a profile of the incline set-
tings of the workout. A new segment will appear at
the end of each minute. The Speed tab will show a
profile of the speed settings of the workout.
The My Trail tab will show a track that represents
1/4 mile (400 m). As you exercise, the black rec-
tangle will show your progress. The My Trail tab
will also show the number of laps you complete.
The Calorie tab will show the approximate amount
of calories you have burned. The height of each
segment represents the amount of calories burned
during that segment.
As you exercise, the workout intensity level bar will
indicate the approximate intensity level of your
exercise.
Press the Home button to return to the default
menu (see THE NFORMAT ON MODE on page
22 to set the default menu). f necessary, press the
Home button again.
When a wireless iFit Live
module is connected, the
wireless symbol at the top of
the display will show the
strength of your wireless sig-
nal. Four arcs indicate full sig-
nal strength.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Meijer.com

19
6. Measure your heart rate if desired.
Before using
the handgrip
heart rate
monitor, re-
move the
sheets of
plastic from
the metal con-
tacts on the
pulse bar. n
addition,
make sure that your hands are clean.
To measure your heart rate, stand on the foot
rails and hold the pulse bar with your palms on the
metal contacts; avoid moving your hands. When
your pulse is detected, several dashes will appear
and then your heart rate will be shown. For the
most accurate heart rate reading, continue to
hold the contacts for about 15 seconds.
7. When you are finished exercising, remove the
key from the console.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
setting. The incline must be at the lowest set-
ting or you may damage the treadmill when you
fold it to the storage position. Next, remove the
key from the console and put it in a secure place.
When you are finished using the treadmill, press
the power switch into the off position and unplug
the power cord. IMPORTANT: If you do not do
this, the treadmillʼs electrical components may
wear prematurely.
Contacts
Meijer.com

20
OW TO USE AN ONBOARD WORKOUT
1. Insert the key into the console.
See HOW TO TURN ON THE POWER on page 17.
2. Select an onboard workout.
To select an onboard workout, press the Calorie
button, the nterval button, the Speed button, or the
Endure button repeatedly until the desired workout
appears in the display.
When you select an onboard workout, the display
will show the duration, the distance, and the name
of the workout. n addition, a profile of the speed
settings of the workout will appear in the matrix. f
you select a calorie workout, the approximate num-
ber of calories you will burn will appear in the name
of the workout.
3. Start the workout.
Press the Start button or the Speed increase button
to start the workout. A moment after you press the
button, the treadmill will automatically adjust to the
first speed and incline settings of the workout. Hold
the handrails and begin walking.
Each workout is divided into segments. One speed
setting and one incline setting are programmed for
each segment. Note: The same speed setting
and/or incline setting may be programmed for con-
secutive segments.
During the
workout, the
profiles on
the speed
and incline
tabs will
show your
progress.
The flashing segment of the profile represents the
current segment of the workout. The height of the
flashing segment indicates the speed or incline set-
ting for the current segment.
At the end of each segment, a series of tones will
sound and the next segment of the profile will begin
to flash. f a different speed and/or incline setting is
programmed for the next segment, the new speed
and/or incline settings will appear in the display for
a few seconds and the treadmill will automatically
adjust to the new speed and/or incline setting.
The workout will continue in this way until the last
segment of the profile flashes in the display and the
last segment ends. The walking belt will then slow
to a stop.
Note: The calorie goal is an estimate of the
number of calories that you will burn during the
workout. The actual number of calories that you
burn will depend on your weight. In addition, if
you manually change the speed or incline of
the treadmill during the workout, the number of
calories you burn will be affected.
f the speed or incline setting is too high or too low
at any time during the workout, you can manually
override the setting by pressing the Speed or
ncline buttons; however, when the next segment
of the workout begins, the treadmill will auto-
matically adjust to the speed and incline set-
tings for the next segment.
To stop the workout at any time, press the Stop
button. The time will begin to flash in the display.
To resume the workout, press the Start button or
the Speed increase button. The walking belt will
begin to move at 1 mph. When the next segment of
the workout begins, the treadmill will automatically
adjust to the speed and incline settings for the next
segment.
4. Follow your progress with the displays.
See step 5 on page 18. The display will show the
time remaining instead of the elapsed time.
5. Measure your heart rate if desired.
See step 6 on page 19.
6. When you are finished exercising, remove the
key from the console.
See step 7 on page 19.
Current Segment
Meijer.com
