USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Model No. PFTL31130
Serial No.
CAUTION
Read all precautions and instruc-
tions in t is manual before using
t is equipment. Save t is manual
for future reference.
QUESTIONS?
If you ave questions, or if t ere
are missing or damaged parts,
we will guarantee complete sat-
isfaction t roug direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
T e trained tec nicians on our
Customer Hot Line will provide
immediate assistance, free of
c arge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
Serial Number
Decal

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING and a PART LIST are attached in the center of this manual.
PROFORM is a registered trademark of ICON Health & Fitness, Inc.
2

3
1. It is t e responsibility of t e owner to ensure
t at all users of t is treadmill are adequately
informed of all warnings and precautions.
2. Use t e treadmill only as described.
3. Place t e treadmill on a level surface, wit at
least eig t feet of clearance be ind it and two
feet on eac side. Do not place t e treadmill
on any surface t at blocks air openings. To
protect t e floor or carpet from damage, place
a mat under t e treadmill.
4. Keep t e treadmill indoors, away from mois-
ture and dust. Do not put t e treadmill in a
garage or covered patio, or near water.
5. Do not operate t e treadmill w ere aerosol
products are used or w ere oxygen is being
administered.
6. Keep c ildren under t e age of 12 and pets
away from t e treadmill at all times.
7. T e treadmill s ould be used only by persons
weig ing 250 pounds or less.
8. Never allow more t an one person on t e
treadmill at a time.
9. Wear appropriate exercise clot es w en
using t e treadmill. Do not wear loose clot es
t at could become caug t in t e treadmill.
At letic support clot es are recommended for
bot men and women. Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. W en connecting t e power cord (see page 10),
plug t e power cord into a surge suppressor
(not included) and plug t e surge suppressor
into a grounded circuit capable of carrying 15
or more amps. No ot er appliance s ould be on
t e same circuit. Do not use an extension cord.
11. Use only a single-outlet surge suppressor t at
meets all of t e specifications described on
page 10. To purc ase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-
3651 and order part number 146148.
12. Failure to use a properly functioning surge
suppressor could result in damage to t e con-
trol system of t e treadmill. If t e control sys-
tem is damaged, t e walking belt may c ange
speed or stop unexpectedly, w ic may result
in a fall and serious injury.
13. Keep t e power cord and t e surge suppres-
sor away from eated surfaces.
14. Never move t e walking belt w ile t e power
is turned off. Do not operate t e treadmill if
t e power cord or plug is damaged, or if t e
treadmill is not working properly. (See BE-
FORE YOU BEGIN on page 5 if t e treadmill is
not working properly.)
15. Never start t e treadmill w ile you are stand-
ing on t e walking belt. Always old t e
andrails or upper body arms w ile using t e
treadmill.
16. T e treadmill is capable of ig speeds.
Adjust t e speed in small increments to avoid
sudden jumps in speed.
17. T e pulse sensor is not a medical device.
Various factors, including your movement,
may affect t e accuracy of eart rate readings.
T e sensor is intended only as an exercise aid
in determining eart rate trends in general.
18. Never leave t e treadmill unattended w ile it
is running. Always remove t e key and unplug
t e power cord w en t e treadmill is not in
use.
19. Do not attempt to raise, lower, or move t e
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 13.)
You must be able to safely lift 45 pounds (20
kg) to raise, lower, or move t e treadmill.
20. W en folding or moving t e treadmill, make
sure t at t e storage latc is fully closed.
21. Inspect and properly tig ten all parts of t e
treadmill regularly.
WARNING:To reduce t e risk of burns, fire, electric s ock, or injury to persons, read t e
following important precautions and information before operating t e treadmill.
IMPORTANT PRECAUTIONS

4
T e decals s own ave been placed on
your treadmill. If a decal is missing or illegi-
ble, please call our Customer Service
Department, toll-free, to order a free re-
placement decal (see t e front cover of t is
manual). Apply t e decal in t e location
s own. Note: T e decals are not s own at
actual size.
WARNING:Before beginning t is or any exercise program, consult your p ysician. T is
is especially important for persons over t e age of 35 or persons wit pre-existing ealt problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or t roug t e use of t is product.
SAVE THESE INSTRUCTIONS
22. Never insert any object into any opening.
23. DANGER:Always unplug t e power
cord immediately after use, before cleaning
t e treadmill, and before performing t e
maintenance and adjustment procedures de-
scribed in t is manual. Never remove t e
motor ood unless instructed to do so by an
aut orized service representative. Servicing
ot er t an t e procedures in t is manual
s ould be performed by an aut orized ser-
vice representative only.
24. T is treadmill is intended for in- ome use
only. Do not use t is treadmill in a commer-
cial, rental, or institutional setting.

5
Thank you for selecting the revolutionary PROFORM®
CROSSWALK 330 treadmill. The CROSSWALK 330
treadmill combines advanced technology with innova-
tive design to help you get the most from your exercise
program in the convenience and privacy of your home.
And when you’re not exercising, the unique CROSS-
WALK 330 treadmill can be folded up, requiring less
than half the floor space of other treadmills.
For your benefit, read t is manual carefully before
using t e treadmill. If you have questions after read-
ing this manual, please call our Customer Service
Department toll-free at 1-800-999-375 , Monday
through Friday, a.m. until p.m. Mountain Time (ex-
cluding holidays). To help us assist you, please note
the product model number and serial number before
calling. The model number of the treadmill is
PFTL31130. The serial number can be found on a
decal attached to the treadmill (see the front cover of
this manual for the location).
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail Upright
Storage Latch
Key/Clip
Circuit Breaker
Walking Belt
Cushioned Walking Platform
for maximum exercise comfort
Foot Rail
Power Cord
RIGHT SIDE
Rear Roller
Adjustment Bolts
Console
Bookrack
Water Bottle Holder
(Bottle not included)
Incline Wheel
BACK

ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of
the walking belt or the shipping carton. This is a normal condition and does not affect treadmill performance. If there
is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires t e included allen wrenc es and your own p illips screwdriver ,
adjustable wrenc , wire cutters , and needlenose pliers .
For elp identifying t e assembly ardware, see t e PART IDENTIFICATION CHART below. Note: T e as-
sembly ardware and ot er small parts are packaged in separate part bags. Do not open t e part bags
until instructed to do so.
1/2” Silver Screw
(97)–2
1/4” Star Washer
(111)–8
5/16” Star Washer
(122)–4
3/4” Screw (13)–10
Crossbar Screw
(53)–2
1” Bolt (8)–6 Wheel Nut (38)–2
1/4” Washer
(39)–10
Silver Ground
Screw (104)–1
1/4” x 3” Bolt (102)–4
3/4” Tek Screw (25)–4
5/16” x 3” Bolt (123)–4
Wheel Bolt (36)–2
1. Make sure t at t e power cord is unplugged.
With the help of a second person, carefully tip the tread-
mill onto its left side as shown. Partially fold the Frame
(75) so that the treadmill is more stable. Do not fully
fold t e treadmill until it is completely assembled.
Open part bag A. Attach the four Base Pads (40) to the
bottom of the Base (11) with four 3/4” Tek Screws (25).
Attach a Wheel (37) to the Base (11) with a Wheel Bolt
(3 ) and a Wheel Nut (38) as shown. Do not overtig ten
t e Nut. The Wheel should be able to spin freely.
11
3
37
40
40
38
75
40
40
25
25
25
1
6
25

7
2. Identify the Right Upright ( 2) and the Left Upright (9) by
observing the large round hole near the lower end of the
Right Upright. Make sure that there are two U-Nuts (124)
in the lower end of each Upright. See inset drawing 2a.
Straighten the Wire Harness (21), and feed it into the
lower end of the Right Upright ( 2) and out of the upper
end. Next, slide the slot in the Right Upright onto the in-
dicated Upright Lock Bracket (125) (see drawing 2b).
Slide the Right Upright down until it reaches the Base (11).
Make sure t at t e Wire Harness is not pinc ed.
Attach the Right Upright to the Base with two 5/1 ” x 3”
Bolts (123) and two 5/1 ” Star Washers (122).
With the help of a second person, tip the treadmill onto
its other side. Attach the Left Upright (9) as described
above. (Note: There is not a wire harness on the left
side.) Attach the other Wheel (not shown) to the Base
(11) as described in step 1.
9
2
125
11
Hole
2
21
Slot
123
3. With the help of a second person, raise the Right Upright
( 2) and the Left Upright (not shown) to the vertical posi-
tion. Open part bag B. Identify the Right Handrail (47),
which has a large hole in the left side. Remove any plas-
tic ties from the rectangular bracket on the Right
Handrail. Feed the Wire Harness (21) up into the bracket
and out of the large hole in the left side. (Note: It may be
helpful to use needlenose pliers to pull the Wire Harness
out of the large hole.) Press a Handrail Cap (41) onto the
lower end of the Right Handrail as shown.
Insert the bracket on the Right Handrail (47) into the top
of the Right Upright ( 2) so the Handrail Cap (41) is rest-
ing against the Right Upright. Attach the Right Handrail
and the Handrail Cap with three 1” Bolts (8), three 1/4”
Washers (39), and two 1/4” Star Washers (111) as
shown. Do not tig ten t e Bolts yet.
Attach the Left Handrail (not shown) as described above.
Note: There is not a wire harness on the left side.
4. Set the Crossbar (34) on the brackets on the Handrails
(1, 47). Attach the Crossbar with two Crossbar Screws
(53). Do not tig ten t e Crossbar Screws yet.
Open part bag C. Attach the end of the ground wire to
the small hole in the side of the Right Handrail (47) with a
Silver Ground Screw (104).
Bracket
41
47
2
111
111
21
Ground
Wire
47
104
53
1
53
34
3
4
39
39
39
8
8
8
Large
Hole
9, 2
124
122
11
Side
View
125
2b
2a

8
4
9
Ties
47
5
5. Place the Console Base (4 ) on the Right Handrail (47)
and the Left Handrail (not shown). Attach the Console
Base with four 3/4” Screws (13) (only two Screws are
shown). Do not tig ten t e Screws yet.
Insert the Wire Harness (21) through the two indicated
plastic ties on the Console Base (4 ). Next, insert the
Wire Harness up through the opening beside the Console
Cover (9 ). Make sure that the Console Cover is securely
attached to the Console Base.
See the inset drawing. Look at the top of the Console
Base (4 ). Insert the Wire Harness (21) through the plas-
tic tie on top of the Console Base. 21
21
Tie
4
13
4
10
21
. Hold the Console (10) near the Console Base (4 ).
Touc t e Rig t Handrail (47) to disc arge any static.
See the inset drawing. Find the 3-wire connector on the
end of the Wire Harness (21). Insert the connector into
the red socket beneath the console. T e connector
s ould slide easily into t e socket and snap into
place. If the connector does not slide easily and snap
into place, turn the connector and then insert it. Insert the
5-wire connector into the black socket beneath the con-
sole in the same way.
Insert the excess Wire Harness (21) down through the
opening in the Console Base (4 [see the inset drawing
in step 5]). Securely tig ten t e plastic tie on top of
t e Console Base to prevent t e Wire Harness from
slipping. Then, cut off the end of the plastic tie.
Make sure that the connectors and wires appear as
shown at the right. IF THE CONNECTORS ARE NOT
INSERTED PROPERLY, THE CONSOLE MAY BE
DAMAGED WHEN THE POWER IS TURNED ON.
See drawing a. Press the Book Rack (90) onto the
Console Base (4 ) in the location shown.
Set the Console (10) on the Console Base (4 ). Insert
the excess Wire Harness (21) into the large hole in the
side of the Right Handrail (47). Securely tig ten t e
plastic ties on t e bottom of t e Console Base to
prevent t e Wire Harness from slipping. Then, cut off
the ends of the plastic ties.
Attach the Console (10) to the Console Base (4 ) with four
3/4” Screws (13) and two 1/2” Silver Screws (97). Start all
six Screws before tig tening t em; do not over-
tig ten t e Screws.
13 13
97
47
Ties
4
90
a
5-wire
3-wire
21

9
10.Make sure t at all parts are properly tig tened before you use t e treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place. The large allen wrench is used to adjust the
walking belt (see page 1 ). To protect the floor or carpet, place a mat under the treadmill.
7. See step 3. Firmly tig ten t e 2” Bolts (8).
Lower the Handrails (not shown) to the floor as shown.
Make sure t at t e Frame (75) is centered between
t e Handrails. Firmly tig ten t e 5/16” x 3” Bolts
(123). Raise the Handrails to the vertical position. 75
123
123
7
8. Open part bag D. Attach the Storage Latch (14) to the
Left Upright (9) with two 3/4” Screws (13). Remove the
Latch Knob (10 ) from the Latch Pin (110). Make sure
that the Latch Pin Collar (108) and the Spring (107) are
on the Latch Pin as shown. Insert the Latch Pin into the
Storage Latch (14) and tighten the Latch Knob onto the
Latch Pin.
110
108
107
14
10
9
13
1
8
9. Attach the Left Upper Body Arm (113) to the Left Upright
(9) with two 1/4” x 3” Bolts (102), two 1/4” Washers (39),
and two 1/4” Star Washers (111) as shown. Attach the
Right Upper Body Arm to the Right Upright (not shown)
as described above.
Firmly tig ten all of t e bolts and screws used in as-
sembly steps 3 t roug 7.
113
111
111
39
9
102
9

10
OPERATION AND ADJUSTMENT
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with
PERFORMANT LUBETM, a high-performance lubricant.
IMPORTANT: Never apply silicone spray or ot er
substances to t e walking belt or t e walking plat-
form. Suc substances will deteriorate t e walking
belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease t e possibility of
your treadmill being damaged, always use a surge
suppressor wit your treadmill (see drawing 1 at
t e rig t). To purc ase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-3651
and order part number 146148.
Use only a single-outlet surge suppressor t at is
UL 1449 listed as a transient voltage surge sup-
pressor (TVSS). T e surge suppressor must ave a
UL suppressed voltage rating of 400 volts or less
and a minimum surge dissipation of 450 joules.
T e surge suppressor must be electrically rated
for 120 volts AC and 15 amps. T ere must be a
monitoring lig t on t e surge suppressor to indi-
cate w et er it is functioning properly. Failure to
use a properly functioning surge suppressor could
result in damage to t e control system of t e
treadmill. If t e control system is damaged, t e
walking belt may c ange speed or stop unexpect-
edly, w ic may result in a fall and serious injury.
T is product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug t e power cord into a surge suppressor,
and plug t e surge suppressor into an appropriate
outlet t at is properly installed and grounded in
accordance wit all local codes and ordinances.
Important: T e treadmill is not compatible wit
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if t e outlet box cover is
grounded before using an adapter.
DANGER:Improper connection
of t e equipment-grounding conductor can
result in an increased risk of electric s ock.
C eck wit a qualified electrician or service-
man if you are in doubt as to w et er t e
product is properly grounded. Do not modify
t e plug provided wit t e product—if it will
not fit t e outlet, ave a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin

11
STEP-BY-STEP CONSOLE OPERATION
Before operating the console, make sure that the
power cord is properly plugged in (see page 10). The
reset/off circuit breaker, located on the treadmill frame
near the power cord, should be in the reset position
(see page 15).
Next, stand on the foot rails of the treadmill. Find the
clip attached to the key (see the drawing above), and
slide the clip onto the waistband of your clothes.
Insert the key fully into the console. After a moment,
the displays will light. Test t e clip by carefully tak-
ing a few steps backward until t e key is pulled
from t e console. If t e key is not pulled from t e
console, adjust t e position of t e clip.
Follow the steps below to operate the console.
Insert t e key fully into t e console.
A few seconds after the key is inserted, the dis-
plays will light.
Press t e Start button or t e Speed increase
button to start t e walking belt.
A moment after the button is pressed, the walking
belt will begin to move. Hold the handrails and
begin walking.
As you exercise, change the speed of the walking
belt as desired by pressing the Speed buttons.
Each time a button is pressed, the speed setting
will change by 0.1 mph; if a button is held down,
the speed setting will change in increments of 0.5
mph. Note: T e console can display speed and
distance in eit er miles or kilometers (see
SPEED DISPLAY on page 12). For simplicity, all
instructions in t is section refer to miles.
2
1
CAUTION:Before operating t e
console, read t e following precautions.
• Do not stand on t e walking belt w en turn-
ing on t e power.
• Always wear t e clip (see t e drawing
above) w ile operating t e treadmill.
• Adjust t e speed in small increments to
avoid sudden jumps in speed.
• To reduce t e possibility of electric s ock,
keep t e console dry. Avoid spilling liquids
on t e console and place only a sealed
water bottle in t e water bottle older.
Pulse Sensor
CONSOLE DIAGRAM
Note: If there is a thin sheet of
plastic on the console, remove it.
Displays
Key Clip

12
To stop the walking belt, press the Stop button.
The elapsed time will begin to flash in the
Time/Distance display.
Note: During the first few minutes that the treadmill
is used, inspect the alignment of the walking belt,
and align it if necessary (see page 1 ).
C ange t e incline of t e treadmill as desired.
To change the incline of the treadmill, press either
of the Incline buttons until the desired incline level
is reached.
Follow your progress wit t e t ree displays.
Time/Distance
display—This display
shows the elapsed time
and the distance that
you have walked or run.
The display will change
from one number to the
other every few seconds, as shown by the mode
indicators. When the Stop button is pressed, the
elapsed time will flash.
Fat Calories/Calories/
Pulse display—This
display shows the ap-
proximate numbers of
fat calories and calories
you have burned (see
FAT BURNING on page 17). The display will
change from one number to the other every few
seconds, as shown by the mode indicators. The
display will also show your heart rate when you
use the pulse sensor (see step 5).
Speed display—This
display shows the speed
of the walking belt
Note: The console can
display speed and dis-
tance in either miles or
kilometers. To change
the unit of measure-
ment, hold down the Stop button, insert the key
into the console, and continue to hold the Stop but-
ton for a moment. An “E” for English miles or an
“M” for metric kilometers will appear in the Fat
Calories/Calories/Pulse display. Press the Speed
increase button to change the unit of measure-
ment. When the desired unit of measurement is
selected, remove the key and then reinsert it.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Measure your eart rate if desired.
To measure your
heart rate, stand on
the foot rails and
place your thumb
on the pulse sensor.
Do not press too
ard, or t e circu-
lation in your
t umb will be restricted and your pulse will not
be detected. After a few seconds, the heart-
shaped indicator in the Fat Calories/Calories/
Pulse display will begin to flash, one or two dashes
(– –) will appear, and then your heart rate will be
shown. Hold your thumb on the pulse sensor for
about 15 seconds for the most accurate reading.
If the displayed heart rate appears to be too high
or too low, or if your heart rate is not displayed, lift
your thumb off the pulse sensor for a few seconds.
Then, place your thumb on the pulse sensor as de-
scribed above. Remember to stand still while mea-
suring your heart rate.
W en you are finis ed exercising, remove t e
key.
Step onto the foot rails, press the Stop button, and
remove the key from the console. Keep the key in a
secure place.
6
5
4
3
Mode Indicator

13
HOW TO USE THE UPPER BODY ARMS
As you walk on the treadmill, you can either hold the handrails
or use the upper body arms. To exercise your arms, shoulders,
and back for a total body workout, move the upper body arms
forward and back as you walk on the treadmill.
To vary the intensity of your upper body exercise, the resistance
of the upper body arms can be adjusted. To increase the resis-
tance, turn the resistance knobs clockwise; to decrease the re-
sistance, turn the knobs counterclockwise.
Resistance
Knobs
Upper
Body
Arms
HOW TO FOLD AND MOVE THE TREADMILL
HOW TO FOLD THE TREADMILL FOR STORAGE
Before folding the treadmill, unplug the power cord. CAUTION:
You must be able to safely lift 45 pounds (20 kg) to raise,
lower, or move t e treadmill.
1. Hold the treadmill with your hands in the locations shown at
the right. To decrease t e possibility of injury, bend your
legs and keep your back straig t. As you raise t e tread-
mill, make sure to lift wit your legs rat er t an your
back. Raise the treadmill about halfway to the vertical posi-
tion.
2. Move your right hand to the position shown and hold the
treadmill firmly. Using your left hand, pull the latch knob to
the left and hold it. Raise the treadmill until the latch pin is
aligned with the square hole between the frame and the foot
rail. Slowly release the latch knob so the latch pin is inserted
into the hole. Make sure t at t e frame is securely eld by
t e latc pin.
To protect t e floor or carpet from damage, place a mat
under t e treadmill. Keep t e treadmill out of direct sun-
lig t. Do not leave t e treadmill in t e storage position in
temperatures above 85° Fa ren eit.
Engaged
Frame
Latch Knob

14
HOW TO MOVE THE TREADMILL
Before moving the treadmill, convert the treadmill to the storage
position as described above. Make sure t at t e frame is se-
curely eld by t e latc pin.
1. Hold the upper ends of the handrails. Place one foot on the
base as shown.
2. Tilt the treadmill back until it rolls freely on the front wheels.
Carefully move the treadmill to the desired location. To re-
duce t e risk of injury, use extreme caution w ile mov-
ing t e treadmill. Do not move t e treadmill over an un-
even surface.
3. Place one foot on the base, and carefully lower the treadmill
until it is resting in the storage position.
HOW TO LOWER THE TREADMILL FOR USE
1. Hold the upper end of the treadmill with your right hand as
shown. Using your left hand, pull the latch knob to the left
and hold it. Pivot the treadmill down until the frame is past
the latch pin. Slowly release the latch knob.
2. Hold the treadmill firmly with both hands, and lower the tread-
mill to the floor. Do not drop t e treadmill frame to t e
floor. To decrease t e possibility of injury, bend your
legs and keep your back straig t.
Engaged
Frame
Latch Knob
Base
Front Wheels

15
TROUBLESHOOTING
Most treadmill problems can be solved by following t e steps below. Find t e symptom t at applies, and
follow t e steps listed. If furt er assistance is needed, please call our Customer Service Department toll-
free at 1-800-999-3756, Monday t roug Friday, 6 a.m. until 6 p.m. Mountain Time (excluding olidays).
PROBLEM: T e power does not turn on
SOLUTION: a. Make sure that the power cord is plugged into a surge suppressor, and that the surge suppressor
is plugged into a properly grounded outlet (see page 10). Use only a single-outlet surge suppres-
sor that meets all of the specifications described on page 10. Important: The treadmill is not com-
patible with GFCI-equipped outlets.
b. After the power cord has been plugged in, make sure that the key is fully inserted into the console.
c. Check the reset/off circuit breaker located on the
treadmill frame near the power cord. If the switch
protrudes as shown, the circuit breaker has tripped.
To reset the circuit breaker, wait for five minutes
and then press the switch back in.
PROBLEM: T e power turns off during use
SOLUTION: a. Check the reset/off circuit breaker located on the treadmill frame near the power cord (see the
drawing above). If the circuit breaker has tripped, wait for five minutes and then press the switch
back in.
b. Make sure that the power cord is plugged in. If the power cord is plugged in, unplug it, wait for
five minutes, and then plug it back in.
c. Remove the key from the console. Reinsert the key fully into the console.
d. If the treadmill still will not run, please call our Customer Service Department toll-free.
PROBLEM: T e displays of t e console do not function properly
SOLUTION: a. Remove the key from the console and UNPLUG THE
POWER CORD. Remove the Resistance Knob (115)
from the left upright. Remove the screws from the
hood, and carefully remove the hood.
Locate the Reed Switch (44) and the Magnet (45) on
the left side of the Pulley (50). Turn the Pulley until the
Magnet is aligned with the Reed Switch. Make sure
t at t e gap between t e Magnet and t e Reed
Switc is about 1/8”. If necessary, loosen the Screw
(33) and move the Reed Switch slightly. Retighten the
Screw. Re-attach the hood, and run the treadmill for a
few minutes to check for a correct speed reading.
Reattach the Resistance Knob.
Tripped Reset
c
a
115
45
44
33
Top
View
1/8” 50

16
PROBLEM: T e walking belt slows w en walked on
SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 10.
b. If the walking belt is overtightened, treadmill perfor-
mance may decrease and the walking belt may be-
come damaged. Remove the key and UNPLUG THE
POWER CORD. Using the allen wrench, turn both
rear roller adjustment bolts counterclockwise, 1/4 of a
turn. When the walking belt is properly tightened, you
should be able to lift each side of the walking belt 2 to
3 inches off the walking platform. Be careful to keep
the walking belt centered. Plug in the power cord, in-
sert the key, and run the treadmill for a few minutes.
Repeat until the walking belt is properly tightened.
c. If the walking belt still slows when walked on, call our Customer Service Department toll-free.
PROBLEM: T e walking belt is off-center or slips w en walked on
SOLUTION: a. If the walking belt is off-center, first remove the key
and UNPLUG THE POWER CORD. If t e walking
belt as s ifted to t e left, use the allen wrench to
turn the left rear roller bolt clockwise 1/2 of a turn; if
t e walking belt as s ifted to t e rig t, turn the
bolt counterclockwise 1/2 of a turn. Be careful not to
overtighten the walking belt. Plug in the power cord,
insert the key, and run the treadmill for a few minutes.
Repeat until the walking belt is centered.
b. If the walking belt slips when walked on, first remove
the key and UNPLUG THE POWER CORD. Using
the allen wrench, turn both rear roller bolts clockwise,
1/4 of a turn. When the walking belt is correctly tight-
ened, you should be able to lift each side of the walk-
ing belt 2 to 3 inches off the walking platform. Be
careful to keep the walking belt centered. Plug in the
power cord, insert the key, and carefully walk on the
treadmill for a few minutes. Repeat until the walking
belt is properly tightened.
PROBLEM: ONE OF THE UPPER BODY ARMS SQUEAKS DURING USE
SOLUTION: a. Correcting this problem requires a small amount of
white marine grease, available at most hardware
stores. Turn the Resistance Knob (115) counterclock-
wise until it can be removed. Remove the Resistance
Cone (118) and the Upper Body Arm (113), along with
the Resistance Plate (127), Washer (57), Spring
Washer (11 ), Thrust Washers (7 ), and Thrust
Bearing (117). (Note: If the Resistance Sleeve [119]
or Resistasnce Plate [127] comes out of the
Resistance Bracket [120] or Resistance Cone, press it
back in.) Apply a t in layer of white marine grease to
the outer surface of the Resistance Cone (118).
Reattach all parts in the order shown at the right.
b
a
Rear Roller Adjustment Bolts
2”–3”
b
119
120 113
115
7 11
127 117
a
57
118

17
CONDITIONING GUIDELINES
The following guidelines will help you to plan your ex-
ercise program. For more detailed exercise informa-
tion, obtain a reputable book or consult your physician.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, the key to achieving the
desired results is to exercise with the proper intensity.
The proper intensity level can be found by using your
heart rate as a guide. The chart below shows recom-
mended heart rates for fat burning and aerobic exercise.
To find the proper heart rate for you, first find your age
near the bottom of the chart (ages are rounded off to
the nearest ten years). Next, find the three numbers
above your age. The three numbers define your “train-
ing zone.” The lower two numbers are recommended
heart rates for fat burning; the higher number is the
recommended heart rate for aerobic exercise.
To measure your heart rate during exercise, use the
pulse sensor. If your heart rate is too high or too low,
adjust the speed and incline of the treadmill.
Fat Burning
To burn fat effectively, you must exercise at a relatively
low intensity level for a sustained period of time.
During the first few minutes of exercise, your body
uses easily accessible carbohydrate calories for en-
ergy. Only after the first few minutes does your body
begin to use stored fat calories for energy. If your goal
is to burn fat, adjust the speed and incline of the tread-
mill until your heart rate is near the lowest number in
your training zone.
For maximum fat burning, adjust the speed and incline
of the treadmill until your heart rate is near the middle
number in your training zone.
Aerobic Exercise
If your goal is to strengthen your cardiovascular sys-
tem, your exercise must be “aerobic.” Aerobic exercise
is activity that requires large amounts of oxygen for
prolonged periods of time. This increases the demand
on the heart to pump blood to the muscles, and on the
lungs to oxygenate the blood. For aerobic exercise,
adjust the speed and incline of the treadmill until your
heart rate is near the highest number in your training
zone.
WORKOUT GUIDELINES
Each workout should include the following three parts:
A Warm-up—Start each workout with 5 to 10 minutes
of stretching and light exercise. A proper warm-up in-
creases your body temperature, heart rate and circula-
tion in preparation for exercise.
Training Zone Exercise—After warming up, increase
the intensity of your exercise until your pulse is in your
training zone for 20 to 0 minutes. (During the first few
weeks of your exercise program, do not keep your
pulse in your training zone for longer than 20 minutes.)
Breathe regularly and deeply as you exercise—never
hold your breath.
A Cool-down—Finish each workout with 5 to 10 min-
utes of stretching to cool down. This will increase the
flexibility of your muscles and will help prevent post-
exercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three
workouts each week, with at least one day of rest be-
tween workouts. After a few months, you may com-
plete up to five workouts each week if desired. The key
to success is to make exercise a regular and enjoyable
part of your everyday life.
WARNING:Before beginning t is
or any exercise program, consult your p ysi-
cian. T is is especially important for individu-
als over t e age of 35 or individuals wit pre-
existing ealt problems.
T e pulse sensor is not a medical device.
Various factors, including your movement,
may affect t e accuracy of eart rate readings.
T e sensor is intended only as an exercise aid
in determining eart rate trends in general.

18
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce.
1. Toe Touc Stretc
Stand with your knees bent slightly and slowly bend forward from
your hips. Allow your back and shoulders to relax as you reach
down toward your toes as far as possible. Hold for 15 counts, then
relax. Repeat 3 times. Stretches: Hamstrings, back of knees and
back.
2. Hamstring Stretc
Sit with one leg extended. Bring the sole of the opposite foot to-
ward you and rest it against the inner thigh of your extended leg.
Reach toward your toes as far as possible. Hold for 15 counts, then
relax. Repeat 3 times for each leg. Stretches: Hamstrings, lower
back and groin.
3. Calf/Ac illes Stretc
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your back
foot flat on the floor. Bend your front leg, lean forward and move
your hips toward the wall. Hold for 15 counts, then relax. Repeat 3
times for each leg. To cause further stretching of the achilles ten-
dons, bend your back leg as well. Stretches: Calves, achilles ten-
dons and ankles.
4. Quadriceps Stretc
With one hand against a wall for balance, reach back and grasp
one foot with your other hand. Bring your heel as close to your but-
tocks as possible. Hold for 15 counts, then relax. Repeat 3 times
for each leg. Stretches: Quadriceps and hip muscles.
5. Inner T ig Stretc
Sit with the soles of your feet together and your knees outward.
Pull your feet toward your groin area as far as possible. Hold for 15
counts, then relax. Repeat 3 times. Stretches: Quadriceps and hip
muscles.
1
2
3
4
5

19
NOTES

PART LIST—Model No. PFTL31130 R0903B
Key
No. Qty. Description Key No. Qty. Description Key No. Qty. Description
1 1 Left Handrail
2 1 Key/Clip
3 2 Incline Leg Pivot Bolt
4 1 Cover
5 1 Left Foot Rail
1 Lift Motor
7 1 Rear Roller
8 1” Bolt
9 1 Left Upright
10 1 Console
11 1 Base
12 1 Motor Belt
13 13 3/4” Screw
14 1 Storage Latch
15 2 Frame Spacer
1 7 8” Cable Tie
17 1 Motor Nut
18 1 Pulley/Flywheel/Fan
19 1 Motor
20* 1 Motor/Pulley/
Flywheel/Fan
21 1 Wire Harness
22 4 Belt Guide Screw
23 1 Motor Hood
24 1 Hood Shield
25 11 3/4” Tek Screw
2 1 Controller
27 1 Motor Swivel Bolt
28 1 Motor Tension Nut
29 1 Motor Star Washer
30 1 Motor Tension
Washer
31 2 Motor Tension Bolt
32 1 Incline Stop Bracket
33 8 Belly Pan Screw
34 1 Crossbar
35 4 Cage Nut
3 2 Wheel Bolt
37 2 Wheel
38 Wheel Nut/Lift Nut
39 12 1/4” Washer
40 4 Base Pad
41 2 Handrail Cap
42 1 Lift Pivot Nut
43 1 Reed Switch Clip
44 1 Reed Switch
45 1 Magnet
4 1 Console Base
47 1 Right Handrail
48 4 Platform Screw
49 2 Isolator
50 1 Front Roller/Pulley
51 1 Front Roller Adj. Bolt
52 2 Incline Wheel
53 2 Crossbar Screw
54 1 Power Cord
55 1 Power Cord
Grommet
5 1 Circuit Breaker
57 2 Washer
58 2 Frame Pivot Bolt
59 1 Latch Decal
0 1 Motor Belly Pan
1 2 Cable Tie Clamp
2 1 Right Upright
3 3 Releasable Tie
4 1 Choke
5 2 Belt Guide
Plastic Fastener
7 1 Walking Belt
8 1 Walking Platform
9 1 Belly Pan
70 11 Electronics Screw
71 1 Incline Wire Harness
72 1 Upright Grommet
73 2 Small Screw
74 1 5/32” Allen Wrench
75 1 Frame
7 4 Thrust Washer
77 2 Incline Wheel Bolt
78 1 Power Supply Plate
79 4 Incline Wheel Nut
80 1 Ground Wire
81 2 Hood Screw (Front)
82 1 Incline Leg
83 2 Rear Roller Adj. Bolt
84 1 Left Rear Endcap
85 1 Right Rear Endcap
8 1 Incline Motor Bolt
87 2 Belly Pan Screw
88 1 Power Supply
89 1 Motor Belt Shield
90 1 Bookrack
91 4 Plastic Stand-off
92 1 Warning Decal
93 1 Right Foot Rail
94 1 Front Left Endcap
95 2 Plastic Tie
9 1 Console Cover
97 2 1/2” Silver Screw
98 4 Endcap Screw
99 1 Hole Plug
100 1 Motor Controller Wire
101 1 Allen Wrench
102 2 1/4” x 3” Bolt
103* 1 Latch Assembly
104 2 Silver Ground Screw
105 1 Front Right Endcap
10 1 Latch Knob
107 1 Latch Spring
108 1 Latch Pin Collar
109 1 Pin Clip
110 1 Latch Pin
111 4 1/4” Star Washer
112 2 Foam Grip
113 1 Left Upper Body Arm
114 1 Right Upper Body
Arm
115 2 Resistance Knob
11 2 Spring Washer
117 2 Thrust Bearing
118 2 Resistance Cone
119 2 Resistance Sleeve
120 2 Resistance Bracket
121 2 Resistance Bolt
122 4 5/1 ” Star Washer
123 4 5/1 ” x 3” Bolt
124 4 U-Nut
125 2 Upright Lock Bracket
12 2 Insert Nut
127 2 Resistance Plate
# 1 4” Red Wire, M/F
# 1 4” Blue Wire, 2F
# 1 10” Blue Wire, 2F
# 1 4” White Wire, M/F
# 1 8” White Wire, 2F
# 1 ” White Wire, 2F
# 1 User’s Manual
* Includes all parts shown in the box
# These parts are not illustrated
