Pro Intercom BP1 User manual

BP1
Portable Headset Station
(Beltpack)
The following instruction are for the BP1 Beltpack. The HS2 Fixed Headset Station’s circuitry is identical. Mechanical lay-
out and the manner of connection are different. See HS2 Family page for connector instructions for HS2s.
1. Plug a headset into the XLR type 4-pin socket on the back of the unit. The rear panel connections are detailed on the
next page. In Pro Intercom systems, the phase of the earphone is the reverse of that sometimes used. This was done to
reduce the effect that the headset connector and wiring has on the headset station bridging impedance and ‘Sidetone’
(See #8) adjustment stability. Either standard of headset wiring will work with Pro Intercom headset stations.
2. Plug the standard microphone cable from your power supply or master station into the XLR 3-pin type socket on the
back of the unit.
3. Press the mic. button and partly turn up the ‘Listen level’ control on your unit and others on the same circuit as your-
self.
4. You should now be able to communicate with any of these other outstations.
5. The thumb operated ‘Listen-level’ control regulates the loudness of your headset earphone(s). It has NO effect on the
microphone level, or the volume that others hear.
6. The microphone amplifier gain is factory adjusted to suit most types of headset microphones. It contains a limiter/com-
pressor which compensates for differences in microphone output and voice levels.
7. The flash (signal) push button flashes a light in all outstations connected to your circuit. It is used to attract attention in
the event that a user has removed his/her headset.
8. The screwdriver preset controls the level of your own voice in your headset. This adjustment is called ‘Sidetone’. This is
set at the factory at a level suitable to the majority of the users. This can be altered for personal preference or adjusted for
deep cancellation allowing the headset to be removed and used to monitor.
9. The BP1 is compatible with Clear-Com®and other, lesser-known 200Wunbalanced party-line headset intercom sys-
tems.
Specifications:
Headset Microphone Impedance: 200Wdynamic, 30Wto 1 KWacceptable, or 1.2~1.8kWelectret..
Headset Earphone Impedance: 150-600Wpreferred, 8W- 4 KWacceptable.
Voltage: 24V DC nominal, 18-30V DC acceptable.
Current consumption: 10 mA with speech, 30 mA with signal lamp activated.
Lamp type: 4-segment 20mA LED )
Line bridging impedance: 200Wunbalanced
Sidetone cancellation: 0dB to 55dB
Controls:
Talk: Push on/push off, self indicating switch
Listen level: Thumbwheel operated potentiometer
Signal: Non-latching push button switch.
Sidetone: Screwdriver adjust, recessed potentiometer.
Operating Instructions & Connections
Pro Intercom LLC
PO Box 7035 Algonquin Illinois 60102-7035
Phone: [phone] Orders and Tech support: [phone] Fax: [phone]
[email protected] Skype: intercom4pros
Printed in U.S.A Rev.3_01.13
(Continued on next page)

4-pin Male XLR
Mic. Gnd. è
Mic. +è
ç Ear +
çEar 0
Now you can use headsets with electret
microphones!
Rear (Back) Panel Connections
If you don’t read anything else, please read this!!!
By convention, in order to avoid any confusion with low impedance mi-
crophone jacks, the female jack on intercom equipment is considered
the input, while the male jack is intended to be used to loop onwards to
other stations in the system. Reversing this order will not effect perfor-
mance, but does make it more probable that a reversal of pins 2 and 3
will occur. This is the single most common cause of failure in both
beltpacks and in complete intercom systems. The reversal will apply
24VDC to the communications conductor which will, at a minimum,
cause the signal light system to become erratic and eventually fail,
causing internal damage to the beltpack(s).
To/From System
Onwards to Next Station
Headset
