TRENDnet TEW-664UB User manual

The 300Mbps Dual Band Wireless N USB Adapter (model TEW-664UB)
automatically connects your laptop or desktop computer wirelessly with
supercharged speed and reliability to a 2.4GHz and 5GHz wireless
network. Experience up to 12x the speed and 4x the coverage of a wireless
g connection*. Dual Band wireless n technology uses additional wireless
channels, reduces wireless interference and optimizes performance in the
most challenging environments.
Setup is a breeze with Wi-Fi Protected Setup technology. Advanced
wireless encryption protects your valuable data. The latest in MIMO
antenna technology ensures the fastest communication speeds that
wireless n technology provides. Stream HD media, download files, play
games and talk online with 300Mbps dual band wireless n technology.
** Maximum wireless signal rates are referenced from IEEE 802.11
theoretical specifications. Actual data throughput and coverage will cary
depending on interference, network traffic, building materials and other
conditions.
TEW-664UB(V1.0R)
TEW-664UB
rev:01.20.2009
• Wi-Fi compliant with IEEE 802.11n standard
• Backwards compatible with IEEE 802.11g, IEEE 802.11b and IEEE 802.11a devices
• Supports Ad-Hoc (Client-Client) and Infrastructure (AP-Client) Mode
• Supports Multiple Input Multiple Output (MIMO) technology
• Maximum reliability, throughput and connectivity with automatic data rate switching
• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
• Low interference and high susceptibility optimize performance
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported
• Compatible with Windows 2000/XP/Vista and Mac OS X 10.3/4/5 operating systems
• Easy user setup and intuitive diagnostics utilities
• Coverage of up to 50 meters indoor, 100 meters outdoor *
• 3-year limited warranty
FEATURES
wireless
300Mbps Dual Band Wireless N USB Adapter

Supported OS
Dimensions (LxWxH)
Weight
Humidity
Channel
• IEEE 802.11a, IEEE 802.11b, IEEE 802.11g and IEEE 802.11n (draft 2.0)
• Windows 2000/XP(32/64-bit)/Vista (32/64-bit)
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• 80 x 27 x 12mm (3.1 x 1 x 0.5in)
• 20g (0.7oz)
• 802.11a: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
• 802.11a: -69dBm at 300Mbps
• 802.11b/g/n: 1~11 (FCC), 1~13 (ETSI)
• 802.11a: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC), 36, 40, 44, 48 (ETSI)
Encryption
Interface
Hardware
SPECIFICATIONS
• USB 2.0
LED Indicator
• Receive mode: 300mA (max) ; Transmit mode : 450mA (max)
Power Consumption
• 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK
• 802.11n: up to 300Mbps
TEW-664UB(V1.0R)
300Mbps Dual Band Wireless N USB Adapter
• Activity
Standards
Temperature • Operating: 0° ~ 40° C (32° ~ 104° F); Storage: -10° ~ 65° C (14° ~ 149° F)
• FCC, CE
• 802.11n: 2.412 ~ 2.484 GHz
• 5% ~ 95% max (non-condensing)
Certification
Frequency
Data Rate (auto fallback)
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
Output Power • 802.11a: 10dBm (typical)
• 802.11b: 16dBm (typical)
• 802.11n: 13dBm (typical)
Receiving Sensitivity • 802.11b: -86dBm at 11Mbps
• 802.11a: -70dBm at 54Mbps
• Built-in 2 on board antennas
Antenna
Wireless
• 802.11a: 5.150GHz ~ 5.350GHz / 5.725GHz ~ 5.825GHz (FCC)
5.150GHz ~5.350GHz / 5.470GHz ~ 5.725GHz (ETSI)
• 802.11g: 13dBm (typical)
• 802.11g: -71dBm at 54Mbps
• 802.11n: -66dBm at 300Mbps
TEW-664UB
rev:01.20.2009

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
• CD-ROM (Utility and Driver)
• TEW-664UB
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
TEW-670APB
TEW-672GR 300Mbps Dual Band Wireless N Gigabit Router
300Mbps Dual Band Wireless N Access Point
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• USB cable (14.5cm / 5.7in.)
TEW-664UB(V1.0R)
300Mbps Dual Band Wireless N USB Adapter
300Mbps Dual Band
Wireless N Gigabit Router
(TEW-673GR)
Notebook with
Wireless N PC Card
(TEW-641PC)
Cable/DSL
Modem
Workstation with
Wireless N PCI Adapter
(TEW-643PI)
Workstation with 300Mbps Dual Band
Wireless N USB Adapter
(TEW-664UB)
5Ghz wireless n 2.4Ghz Wireless n
