Pro2 HDMI2SP User manual

Operating Instructions
4
Operating Instructions
1x2 HDMI Splitter
Supports resolution 4Kx2K@60Hz(YUV 4:2:0) HDCP, EDID
Model: HDMI2SP
Operating Instructions
Notice
The information in this document is subject to change without notice. Every effort has
been made in the preparationof this document to ensure accuracy of the contents, but
all statements, information, and recommendations in this document do not constitute
the warranty of any kind, express or implied.
Features
Simultaneously displays an UItra Hi-Def source on up to two UItra HD displays.
Supports resolutions up to UItra HD 4Kx2K(3840x2160@60Hz YUV 4:2:0 ) and
1080p Full HD.
Supports four kinds of EDID handling abilities: mixed EDID, copy EDID, default
1080p output, default 4Kx2K output.
Supports 36 bit Deep Color.
Supports LPCM 7.1, Dolby TrueHD, Dolby digital Plus, and DTS-HD Master
Audio.
Supports HDMI input/output cable 10 to 15 meters at 1080p/8-bit resolution.
HDCP Compliant.
Support 3D.
Package Contents
1 x HDMI Splitter
1 x 5V/1A DC Adapter
1 x User Manual
1

Operating Instructions
SPECIFICATIONS
Operating Temperature Range -5 to +35℃(+23 to +95℉)
Operating Humidity Range
5 to 90%RH (No Condensation)
Bandwidth frequency
10.2Gbps
Input ports 1xHDMI(female)
Output ports 2xHDMI outputs(female)
Resolution outputs up to 4Kx2K(3840x2160@60Hz YUV 4:2:0)
Dimensions(LxWxH) 75x68x25.2mm
Power consumption 1W(MAX)
Transmission Distance 15m(Maximum)over standard HDMI cable/26AWG
Net Weight 128g
PANEL DESCRIPTIONS
①HDMI output ports
②HDMI output ports
③Indicator of HDMI output
④Power input
⑤Indicator of power input
⑥HDMI input port
⑦DIP switch for EDID choosing
00: Mixed EDID, 11: Copy EDID,
10: Default 1080p output, 01: Default 4Kx2K output
2
Operating Instructions
EDID Introduction:
00: Mixed EDID: always follow the lowest resolution
of the displays connected to output 2 in order to support all displays show the source.
11: Copy EDID: output 1 is prior port
a. When output 1 is connected to one display, another display which connected to
output 2 will follow the Resolution of output 1.
b. When output 1 is disconnected, output 2 will output 1080p only.
10: Default 1080p output: output a default 1080p source, in this case all outputs will
display 1080p if they support resolution 1080p and above.
01: Default 4Kx2K output: output a default 4Kx2K source, in this case all outputs will
display 4Kx2K if they support resolution 4Kx2K and above.
Please restart the splitter when change EDID mode!
Connecting and operating
1) Connect the HDMI input source to input port of HDMI splitter.
2) Connect the HDMI splitter output ports to the displays.
3) Power up splitter, source and displays.
Connection Diagram
3
4K TV1 4K TV2
prior port
