Prochista O2 User manual

Page | 1
Quick Guide
O2 Sensor
For configuring the unit simply login into unit's webpage, by default the unit
boots in static IP mode .The unit's default IP is "172.16.0.1", default Username
and Password is "prochista".
Schematic description
Element
Function/Usage
Main Ethernet (POE)
Main Ethernet jack with POE support.
Secondary Ethernet
Use to connect to another sensor or Ethernet support device.
Input 48VDC
Connect external 48VDC power supply if POE enabled switch is not
available.
Click (<1s)
Reboot system (LED2 & LED4 blinking
simultaneously).
Press >4s and
release
Restore factory setting (LED2 & LED4
blinking one after the other).
LED1
Secondary Ethernet status.
LED2
Steady on after power check complete (about 6s).
LED3
Main Ethernet status.
LED4
Steady on boot sequence/ heart beat flashing while system is
running.
LED4
LED3
LED2
LED1
External 48VDC
input
Secondary
Ethernet
Main Ethernet
(POE)
Reset/
Factory Reset
Bottom view
Top view

Page | 2
Web panel menu description
Main menu
Sub menu
Properties
Overview
Show current value of Oxygen percentage
System Log
Show system logs and events
System Setting
Set local time, hostname and time zone
Password
Setting
Change default password
Upgrade Utility
Upgrade system firmware from binary file (Get it from
prochista.ir)
Reboot
Reboot system
Interfaces
Change IP address and network settings
SNMP Setting
Change SNMP settings, Sensor name, address and
description
Log out
Log out current session
Notice:
oRemove isolation label form both side before use.
oPower jack should be placed upward after installation.
oTo function properly, the unit must be oriented upward. The sensor
should not be placed near a fan or other source of artificial air flow.
Because the concentration of particulates is greatest close to the
floor, for best results the unit should be placed on or close to the
floor.
