XTR4 II Elliptical Cross Trainer

User Manual

[Revision 1.0 February 2018]

READ THIS MANUAL CAREFULLY BEFORE USE –FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY

DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by

this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

XTR4 II Elliptical Cross Trainer

Safety

Basic precautions, including the following important safety instructions, should always be followed when

using this equipment. Read all instructions before use.

Before beginning any exercise program, consult your physician. This is especially important for

people over 35 years of age or who have pre-existing health problems. Read all instructions before

using any fitness equipment. Do not operate this exercise equipment without properly fitted guards, as the

moving parts can present a risk of serious injury if exposed.

•Use this product for its intended use only as described in this user manual. Do not use attachments not

supplied or recommended by the manufacturer.

•Maximum weight capacity = 100 kg.

•Do not attempt any maintenance or adjustments other than those described in this user manual. Should

any problems arise, discontinue use and consult an authorized service centre or personnel.

•Any information or data provided by the equipment is a guide only and is not to be used as medical data

or scientific evidence.

•Do not use the unit outdoors.

•Keep children and pets away from the equipment while in use.

•Elderly or disabled users should only use the equipment in the presence of an adult who can provide

assistance if required.

•Do not operate where aerosol (spray) products are in use or where adequate oxygen is not available.

•Keep dry –do not operate in wet or moist conditions.

•Keep the unit on a solid, level surface with a minimum safety area clearance of two meters around it. Be

sure the area around the equipment remains clear of any obstructions during use.

•The equipment is for domestic household use only.

•One person only should use the equipment at a time.

•Wear comfortable and suitable clothing when using the equipment. Do not use the equipment barefoot or

in socks. Always wear appropriate, enclosed athletic footwear. Never wear loose or baggy clothing as it

can become caught on the equipment and create a hazard.

•Always hold on to the handrails while using the equipment.

•Do not leave children unsupervised near or on the equipment.

•Children should not be allowed to play or operate the equipment at any time.

•This equipment is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the equipment by a person responsible for their safety.

•Keep hands clear of all moving parts. Never place hands or feet off the handles or pedals while the

equipment is in use.

•Before using the equipment, check that all visible fasteners are sufficiently tightened and secure.

•Handle or move the equipment with due care to avoid personal injury or damage to the equipment.

XTR4 II Elliptical Cross Trainer
E&OE ©2018 Proflex 3
Table of Contents
Safety.............................................................................................................................................2
Parts Identification........................................................................................................................ 4
Assembly.......................................................................................................................................5
Operation....................................................................................................................................... 9
Console and Functions..............................................................................................................9
Setting a Pre-Set Session Time / Distance / Calorie / Pulse....................................................10
Adjusting Resistance...............................................................................................................10
Care, Maintenance and Troubleshooting.................................................................................. 11
Cleaning..................................................................................................................................11
Storage...................................................................................................................................11
Troubleshooting ......................................................................................................................11
Specifications .............................................................................................................................11
Warm-Up and Cool-Down Routine............................................................................................. 12



XTR4 II Elliptical Cross Trainer

Parts Identification

The equipment comes partially assembled. The unit comes with the following parts. Ensure that all parts are

included before assembly.

No.

Description

No.

Description

1

Main Body (includes flywheel and crank)

10

Fasteners / Accessories / Tools:

M8x45 Bolt (4)

M8x15 Button Head Screw (10)

M8x15 Bolt (2)

M6x60 Coach Screw (4)

M8 Washer (4)

M8 Large Washer (2)

M8 Curved Washer 14)

M8 Acorn Nut (4)

M8 Nut (4)

Large Wave Washer (2)

Pedal Bolt (includes wave washer, washer and

nut) (2 - left and right)

Nut Cap (2)

Spanner

Multi-Tool

6 / 8mm Allen Key

2

Front Foot (includes wheels)

3

Rear Foot

4

Centre Brace (includes pedal arm spacers)

5

Pedal Board (2 - left and right)

6

Pedal Arm (2 - left and right)

7

Handlebar (2 - left and right)

8

Stationary Handlebar

9

Console

1

3

4

9

6

2

5

7

10

8

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Assembly

1. Take all parts out of the carton and place them on a firm, flat surface. Remove all packing materials.

Check that all parts have been supplied. Note that some parts may have the necessary fasteners pre-

assembled –these will need to be removed during the assembly process.

2. Attach the front foot (has wheels) (2) and rear foot (3) to the main body (1). Attach each foot using 2 M6

coach screws (4), curved washers (5) and acorn nuts (6). Ensure that the screws are inserted from the

under side of the feet. Tighten (rotate right) the nuts firmly.

3. Bring the centre brace (7) near its location on the main body and connect the wiring in the main body

and centre brace together (A). Do not remove the rubber band holding the wiring at the top of the

centre brace (B) at this stage. Additionally, ensure that the tension adjuster is in the "1" setting (C) –the

tension cable will be at its longest at this setting.

4. Join the tensioning cables in the centre brace and main body together. The "ball" (D) on the end of the

centre brace tensioning cable must sit in the "hook" (E) in the connection bracket on the end of the main

body tensioning cable. Once the cable end is hooked into position, pull the cable collar (F) up and over

the slot (G) at the top of the cable connection bracket.

5. Slide the centre brace down over the main body –ensure that not cables or wiring are pinched or

caught. Secure the two parts together using 4 M8 button head screws (8) and curved washers (9).

Firmly tighten (rotate right) all fasteners using the Allen key.

2

1

3

4

5

6

7

A

B

C

D

G

E

F

D

9

8

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

6. Bring the pedal arms up to the main body in preparation for attachment. Ensure that the pedal arm

marked "R" (10) is on the right-hand side of the main body and the pedal arm marked "L" (11) is on the

left-hand side when standing behind the main body and looking towards the front. On the centre brace

mounting pivots (H) there is a plastic spacer (12), wave washer (13), retaining washer (14), and screw

(15). Remove the retaining washer and screw only. Do not remove any grease / lubricant that may be

on the mounting pivots.

7. Slide each pedal arm sleeve (I) over the mounting pivot –the wave washer should be

in-between the pedal arm sleeve and the plastic spacer. Re-install the retaining

washer and screw, then tighten the screw (rotate right) using the spanner until the

wave washer is starting to compress –do NOT flatten the wave washer as this may

cause binding and unnecessary friction.

It is critical that you follow the pedal arm to crank attachment procedure carefully to ensure

correct assembly. • During assembly, do NOT use excessive force to screw the pedal bolts into the

crank arms –this may indicate misalignment of the bolts or mis-matched threads. If the bolt does not "feel

right" when being screwed in, STOP immediately and check that it is the correct bolt and that it is aligned

properly with the crank arm. Failure to follow the instructions here or take due care may damage the

equipment and void any product warranty.

8. Starting with the right-hand pedal arm, identify

the right-hand pedal bolt assembly (16),

which is identified by having a right-hand

thread (this is the usual type –rotate right /

clockwise to tighten) and the nut (17) having a

light coloured ring (J). The pedal bolt

assembly includes a wave washer (18) and

washer (19). Remove the nut and washer

only from the pedal bolt. Do not remove any

grease / lubricant that may be on the bolt.

9. It is recommended that before actual

assembly, to check that the pedal bolt is

correct by screwing it into the crank arm (K)

several turns –this should require very little

effort. Take extra care when starting the bolt,

as the thread is fine. When you are certain

the bolt is correct, remove it then continue with the assembly procedure.

10. Insert the pedal bolt through the pedal arm sleeve (L). The wave washer should be in-between the

pedal arm sleeve and the head of the pedal bolt. Note that the pedal arm sleeve is able to pivot slightly

on the pedal arm –this allows you to rotate it enough so that the sleeve / bolt is at 90° to the crank arm

10

11

H

14

12

13

15

I

17

16

K

19

18

J

L

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

11. Very carefully begin screwing the pedal bolt into the crank arm (rotate right / clockwise) –it may be

necessary to "wiggle" the pedal arm sleeve a little to avoid possibly jamming the bolt and making it

difficult to turn. If the bolt does not "feel right" when being screwed in, STOP immediately and check that

it is the correct bolt and that it is aligned properly with the crank arm. When the wave washer is just

starting to compress (M), stop screwing the pedal bolt in –do NOT flatten the wave washer as this may

cause binding and unnecessary friction.

12. Insert the washer (19) and nut (17) onto the end of the pedal bolt. Hold the pedal bolt in position using

the Allen key so it does not rotate, then firmly tighten (rotate clockwise) the nut using the spanner.

13. Repeat steps 8 to 12 for the left-hand pedal arm, noting that the pedal bolt and crank arm thread

is left-hand (rotate left / anti-clockwise to tighten) and that the pedal bolt nut has no particular

identifying colour.

14. Attach the pedal boards (20) to the applicable pedal arm. Attach each pedal board using 2 M8x45

screws (21), inserted from the top, and secure from underneath the pedal arm using 2 M8 washers (22)

and M8 nuts (23). Tighten the nuts (rotate right) using the spanner.

15. Bring the stationary handlebar (24) into position against the centre brace so the handlebars are facing

up and towards the rear of the machine, and the brackets are aligned. Ensure that the wiring is not

caught or pinched by the brackets.

16. Attach the stationary handlebar using 2 M8 button head screws (8) and curved washers (9) and tighten

(rotate right) using the Allen key.

M

20

21

22

23

24

8

19

17

Hold in

Position

9

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

17. Lower the right and left handlebars (25 and 26 (not shown)) down over

the tubes at the top-front of the pedal arms. The handlebars should be

positioned so that they extend forward.

18. Attach each handle bar using 2 M8 button head screws (8) and curved

washers (9). Tighten (rotate right) the screws using the Allen key.

19. Remove the pre-assembled screws (N) from the rear of the console (28), then connect the wiring

between the console and centre brace (O) (the cables can be connected one way only). Allow any loose

cable to sit in the centre brace tube.

20. Attach the console to the top of the centre brace using the 2 screws (N) –there are two possible

positions –select the one most comfortable for you. Ensure that the pulse sensor cables are not being

pinched between the brace and console. Connect the pulse sensor cables from the stationary handle

and console (P).

Push the plastic nut caps on to the tops of the fasteners identified by , below (on both sides). When

correctly assembled, the machine should resemble the image below and is ready for use.

Moving

The unit can be tilted onto its front foot wheels for easy moving

and storage. Firmly grasp the stationary handlebar with both

hands. Next, carefully tilt the equipment forward until it rolls freely

on the wheels.

9

28

N

O

N

P

25

8

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Operation

Console and Functions

The equipment features a computerized display that provides you with workout information, such as duration,

speed, distance travelled, pulse etc. The console activates as soon as a key is pressed or the pedals are

moved. When the machine is not being used, the console switches off automatically after 4 minutes.

Control

Description

Display

Shows various information depending on current function. For example, current

speed, used calories, current pulse etc.

Note: When displaying pulse, you must have both hands on the metal sensors on the

stationary handlebar. If no pulse is detected, "P" may be displayed and some functions

are unavailable • To approximately convert calories to kilojoules, multiply the number

of calories by 4.

MODE

Press to switch between available functions. The current function is indicated by

having an arrow shown next to it:

DIST - When in "setting" mode, program a target distance (range = 0 to 999.9 km).

When exercising, shows the current distance travelled for the session.

CAL - When in "setting" mode, program a target calorie amount (range = 10 to 9999

cal). When exercising, shows the current calories used for the session.

ODO - When exercising, shows the current distance travelled for all sessions

combined (returns to zero if the batteries are removed).

PUL - When in "setting" mode, program a target heart rate (range = 80 to 180 bpm).

When exercising, shows your current heart rate.

TIME - When in "setting" mode, program a target session duration (range = 0 to 99

minutes and 59 seconds). When exercising, shows the current time elapsed for the

session.

SCAN - When exercising, automatically steps the display between each function

every 4 seconds.

SET

Press to activate "setting" mode and to increase the current value when setting target

values (for example, time, distance etc).

RESET

When in "setting" mode, press to return the current value to zero "0".

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Setting a Pre-Set Session Time / Distance / Calorie / Pulse

When training to pre-set session values, the console beeps once you have achieved each target value. For

example, setting a time of 5 minutes, distance of 3km, calories used of 50, and pulse of 110 will cause the

console to beep if your pulse reaches 110, beep again if you use 50 calories, beep again if you travel 3km

and beep again after 5 minutes. You can set targets for all values, or whichever ones you want.

1. Press MODE as required until the arrow is shown next to the required function (distance, calories, pulse

or time).

2. Press SET to enter "setting" mode and apply a target value. Press again to increase the value or hold

down to more quickly increase the target value.

3. Press MODE to step to the next function you want to set a target value for, then use SET to enter the

value and so on. Repeat this process as required, then begin your workout.

To cancel the target value and start again, press RESET (any other currently set values will remain

unchanged).

Adjusting Resistance

The resistance of the crank to being rotated can be adjusted.

Increased resistance requires more effort and, therefore, uses more

energy. To adjust crank resistance, rotate the knob on the central

brace –1 = least resistance, 8 = greatest resistance.

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Care, Maintenance and Troubleshooting

Some maintenance activities described may be beyond the scope of some users. For

procedures that you are not comfortable with or have the tools or experience for, have the

unit serviced by a service centre or qualified technician.

Cleaning

The equipment can be cleaned with a soft cloth and mild detergent. Do not use abrasives, solvents or harsh

chemicals. Be careful not to get excessive moisture on the display panel as this may damage it.

After each use, wipe the unit of any sweat, dirt or liquids. Keep the equipment, especially the display

console, out of direct sunlight to prevent damage to the screen.

Storage

Store the equipment in a clean and dry indoor environment. Never leave or use the unit outdoors.

Troubleshooting

The following information may assist in identifying a problem and rectifying it.

Problem

Potential Reason

Correction

Pedals or handles

tight or making

noise.

A. Pedal bolts or retaining

screws too tight.

B. Pivots require lubricating.

A. Loosen fasteners so that wave washers are

not compressed flat. For pedal bolts, hold bolts in

positions when tightening nuts.

B. Disassemble pivots, clean components, then

smear with grease before reassembling.

Console not working.

A. Batteries no longer

serviceable.

B. Connection problem.

C. Console problem.

A. Replace batteries.

B. Check all connections are secure and wiring is

not pinched or damaged. Replace is necessary.

C. Replace console.

When to Call for Help

This equipment is designed with user safety as a priority. In the event of equipment failure, call an authorized

service centre or technician for servicing.

Specifications

Weight Capacity

100kg

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Warm-Up and Cool-Down Routine

The warm-up routine is an important part of any workout. The purpose of warming up is to prepare your body

for exercise and to minimize injuries. Warm up for two to five minutes before aerobic exercising. It should

begin every session to prepare your body for more strenuous exercise by heating up and stretching your

muscles, increasing your circulation and pulse rate, and delivering more oxygen to your muscles.

Always perform a cool-down routine after your workout, repeat these exercises to reduce soreness in tired

muscles. The purpose of cooling down is to return the body to its resting state at the end of each exercise

session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart.

A. Head Roll - Rotate your head to the right for one second, you should feel a stretching sensation up the

left side of your neck. Then rotate your head back for one second, stretching your chin to the ceiling and

letting your mouth open. Rotate your head to the left for one second, then drop your head to your chest

for one second.

B. Shoulder Lift - Lift your right shoulder toward your ear for one second. Then lift your left shoulder up for

one second as you lower your right shoulder.

C. Side Stretch - Open your arms to the side and lift them until they are over your head. Reach your right

arm as far toward the ceiling as you can for one second. Repeat this action with your left arm.

D. Quadricep Stretch - With one hand against a wall for balance, reach behind you and pull your right foot

up. Bring your heel as close to your buttocks as possible. Hold for 15 seconds and repeat with left foot.

E. Inner Thigh Stretch - Sit with the soles of your feet together and your knees pointing outward. Pull your

feet as close to your groin as possible, then gently push your knees toward the floor. Hold for 15 seconds.

F. Toe Touch - Slowly bend forward from your waist, letting your back and shoulders relax as you stretch

toward your toes. Reach as far as you can and hold for 15 seconds.

G. Hamstring Stretch - Extend your right leg. Rest the sole of your left foot against your right inner thigh.

Stretch toward your toe as far as possible. Hold for 15 seconds. Relax and then repeat with left leg.

H. Calf/Achilles Stretch - Lean against a wall with your right leg in front of the left and your arms forward.

Keep your left leg straight and the right foot on the floor; then bend the right leg and lean forward by

moving your hips toward the wall. Hold, then repeat on the other side for 15 seconds.

A

B

C

D

E

F

G

H

PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX PROFLEX

XTR4 II Elliptical Cross Trainer

Some experts believe the incorrect or prolonged use of almost any product could cause

serious injury or death. For information that may reduce your risk of serious injury or

death, consult the points below and additionally, the information available at

www.datastreamserver.com/safety

•Consult all documentation, packaging and product

labelling before use. Note that some products feature

online documentation which should be printed and kept

with the product.

•Check product for loose / broken / damaged / missing

parts, wear or leaks (if applicable) before each use.

Never use a product with loose / broken / damaged /

missing parts, wear or leaks (if applicable).

•Products must be inspected and serviced (if applicable)

by a qualified specialist every 6 months assuming

average residential use by a person of average weight

and strength, above average technical aptitude, on a

property matching average metropolitan specification.

Intended use outside these guidelines could indicate

the product is not suitable for intended use or may

require more regular inspection or servicing.

•Ensure all possible users of the product have

completed an industry recognized training course

before being given access to the product.

•The product has been supplied by a general merchandise retailer that

may not be familiar with your specific application or your description

of the application. Be sure to attain third-party approval for your

application from a qualified specialist before use regardless of prior

assurances by the retailer or its representatives.

•This product is not intended for use where fail-safe operation is

required. As with any product (take an automobile, aircraft, computer

or ball point pen for example), there is always a small chance of

technical issues that needs to be repaired or may require replacement

of the product or a part. If the possibility of such failure and the

associated time it takes to rectify could in any situation inconvenience

the user, business or employee then the product is not suitable for

your requirements. This product is not for use where incorrect

operation or a failure of any kind, including but not limited to a

condition requiring product return, replacement, service by a

technician or replacement of parts could cause a financial loss, loss of

employee time or an inconvenience requiring compensation.

•If this item has been purchased in error after considering the points

above, simply contact the retailer directly for details of their returns

policy, if required.

diagrams or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

Proflex XTR4 II User manual

Popular Elliptical Trainer manuals by other brands
