User’s manual PMA-1000

2
To be able to make full use of
this phone, a SIM card must be
inserted (not included). Without
this SIM card, most functions
of this phone are unavailable.
This manual assumes you’ve
already installed the SIM card
according to the installation
guide.
• Chapter 1 contains an over-
view of the contents of the
packaging. p.4
• Chapter 2 explains various
terms with regards to your
mobile phone. p.5
•Chapter 3 described the basic
operation of this phone. p.15

3
• Chapter 4 provides informa-
tion regarding the use of the
included battery. p.29
• Chapter 5 describes the
operation of the basic func-
tions of the phone. p.33
• Chapter 6 explains the use
and setup of all functions
available in the menu. p.51
• Chapter 7 contains safety
precautions to be followed
when using this phone. p.115
• Chapter 8 lists the specific -
tions of the device. p.125
• Chapter 9 provides a detailed
table of contents. p.126

4
1 CONTENTS OF THE
PACKAGING
• Mobile phone
• Battery
• Power adaptor
• User’s manual
• Starting guide
• USB cable
We may remotely improve the
functions of this device.
Because we’re continuously
working on making the operation
easier, you might notice small
differences between this manual
and the latest software version.
Always visit our website for the
latest version (see the back).

5
2 CONCEPTS
Provider:
‘Provider’ is another name for
‘Telephone Company’.
The documentation accompa-
nying the SIM or the SIM card
itself will show through which
provider you’re calling.
SIM card:
A SIM (‘Subscriber Identity Mod-
ule’) is a small card containing a
chip. The number is programmed
in this chip and it also allows you
to store several numbers and
messages, so you can take this
information with you when you
install the SIM card into another
phone.

6
SIM cards are provider-specific.
Ask your provider for a regular
size SIM card. The smaller Mini
SIM and Micro SIM variants will
not fit in this phone
SIM-LOCK-free:
This phone is SIM-LOCK-
FREE. This means the phone
is not bound to SIM cards of a
certain provider, allowing you to
choose any desired telephone
company.
PIN code / PUK code:
Each SIM can be secured using
a PIN. This PIN code helps you
to prevent unauthorised per-
sons from using your phone.

7
In most cases, the documen-
tation accompanying the SIM
card will show a PIN set by
default. You can change this
PIN yourself.
After you’ve entered an incor-
rect PIN for up to three times,
the SIM card will be locked.
You then need the PUK code
of the SIM card to unlock the
card again. Also the PUK code
is usually mentioned in the
documentation your supplier
provided with the SIM card. If
this information is not available,
please contact the help desk of
your supplier.

8
9
Prepaid or subscription:
This determines how you pay
for your phone bill. In short:
using the prepaid option, you’re
paying beforehand, in the case
of a subscription, you’re paying
afterwards.
This payment method is linked
to your SIM. Ask the help desk
of your provider about all of
your options.
Voicemail:
Voicemail is an answering
machine at the telephone ex-
change of the provider. It allows
callers to leave you a message
when you can’t or won’t answer
their call.

9
Ask the help desk of your pro-
vider about all of your options.
Car kit:
A car kit allows you to make
phone calls in your car keeping
your hands free for driving. Ask
the supplier of your car kit abut
connection options. You can of
course also connect a headset
in your car.
Headset:
A headset is a small ear phone
with a microphone attached to
a bracket or wire. It allows you
to make calls or listen to music
without holding the phone to
your ear.

10
This phone is suitable for head-
sets with a 4-pin 3.5mm con-
nector.
Warning: Using ear-
phones or headphones
for long periods of
time at high volume can lead
to permanent hearing damage.
To protect your hearing, please
keep the following in mind:
Increase the volume starting at
the minimum up to a comfort-
able level. Don’t listen for long
periods of time at high volumes.
Never increase the volume to
ignore or outdo environmental
noise. Decrease the volume
when you can’t hear the people
around you.

11
Mobile data:
Mobile data (cellular data) is a
method to use the internet via the
mobile phone. If this function is
not automatically set, please ask
your provider for these settings or
for releasing the use of internet.
Attention: if you don’t agree to
a data subscription, this mobile
data can lead to high costs.
WiFi:
This standard in wireless internet
is a method for your phone to
connect to the internet. It allows
you to login to your local wireless
modem and then use the internet
functions of this phone at no ad-
ditional costs.

12
GPS:
Using this function, it’s possible
to determine the location of the
phone. By scanning for contact
through satellites, the position
of the phone can be accurately
determined. Amongst others, this
function can be used for naviga-
tion. Inside buildings and in small
streets, contact with the satellites
can be affected, causing this
function to be inaccurate or to be
unavailable.
AGPS:
Using this function, it’s possible
to determine the location of the
phone. By establishing a con-
nection with the antennas of
your network, the position of the
phone can be determined with
an accuracy of 1300 meters.

13
Amongst others, it can help with
navigation when no satellites can
be found (e.g. inside buildings).
This function works via the in-
ternet service (mobile data). Ask
your provider for its costs.
Apps:
Apps are computer programs
especially written for smart-
phones and tablets. All func-
tions on this phone work via
Apps. You can also use the
Google Play™ store to install
additional Apps and further
expand the functionality of this
phone.

14
Bluetooth®(Optional)
Bluetooth® wireless technology
is a standard to wirelessly con-
nect two devices at a short dis-
tance. This way you could e.g.
exchange files between phones
or you can equip the phone with
a wireless, Bluetooth-enabled
headset.
The Bluetooth® word mark and logos are regis-
tered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks is under license.

15
3 BASIC OPERATION
This phone is provided with
four physical buttons, three
touch-sensitive buttons and a
touch-screen you can use for
the majority of the functions by
simply touching or dragging the
screen.
On the adjacent page,
you’ll find an overview of all
possibilities this phone has to
offer. The next page will explain
these in more detail.

16
Camera
Speakers for conversations
Light sensor
USB port for charging or PC
Volume button
Touch-sensitive buttons
Display
Power
button

17
USB port:
On the left side of the phone
you’ll find a port for connecting
the included cable. The other
side of this cable fits into
an adaptor for charging the
phone or into a computer for
exchanging files
Camera
SOS button
Speaker
Headset
output

18
Speaker for conversations:
This speaker is only used while
having telephone conversa-
tions.
Camera:
This camera comes equipped
with two cameras – one of
these is located on the screen
side and can be used for video
conferences, photos of yourself
and sometimes for games you
can play via the internet.
At the rear of the phone you’ll
find the second camera. This
one is meant for making photos
and videos, which is why it has
a higher picture quality. See
also page 73.

19
Light sensor:
The light sensor of this phone
is used to save battery power.
By monitoring how much en-
vironmental light is available
this sensor adjusts the bright-
ness of the screen, ensuring a
longer battery operating time.
For more information about this
automatic light adjustment, see
also page 87.
Power button:
Press this button to turn on the
phone.
When the phone is switched on,
briefly press this button to turn th
display off or on.
Press and hold the button and an
option will appear to completely
turn off the phone.

20
Display:
This colour screen is touch-
sensitive. You can operate
this phone by simply touching
the screen. By tapping (also
called ‘touching’) the screen or
by swiping (often called ‘drag-
ging’), you can adjust and use
most of the functions of this
phone.
