Nokia N86 8MP User manual

Nokia N86 8MP User Guide

© 2009 Nokia. All rights reserved.
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-484 product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/
declaration_of_conformity/.
Nokia, Nokia Connecting People, Nseries, N86, N-Gage, Nokia Original Accessories logo, and Ovi are trademarks or registered trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document
without prior notice.
This product includes software licensed from Symbian Software Ltd ©1998-2009. Symbian and Symbian OS are trademarks of Symbian Ltd.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4
video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional,
internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia. Nokia
does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user support,
functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE
ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Reverse engineering of software in the device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on Nokia's
representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of Nokia's licensors.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and availability
of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require
you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part
15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's
authority to operate this equipment.
EN

Contents
Safety.................................................................10
About your device....................................................................11
Network services.....................................................................11
Shared memory.......................................................................12
ActiveSync.................................................................................12
Magnets and magnetic fields.................................................12
Get started..........................................................13
Keys and parts (front and top)...............................................13
Keys and parts (back and sides).............................................14
Short slide keys........................................................................14
Kickstand..................................................................................14
Insert SIM card and battery ...................................................15
Memory card............................................................................15
Insert the memory card.......................................................16
Remove the memory card....................................................16
Switch the device on and off..................................................16
Charge the battery...................................................................17
Headset.....................................................................................18
Attach wrist strap....................................................................18
Antenna locations....................................................................19
Find help............................................................20
In-device help..........................................................................20
Support.....................................................................................20
Additional applications...........................................................21
Update device software..........................................................21
Software updates using your PC.........................................21
Software updates over the air.............................................21
Settings.....................................................................................22
Access codes.............................................................................22
Prolong battery life.................................................................23
Free memory............................................................................24
Your device.........................................................25
Phone setup.............................................................................25
Nokia Switch............................................................................25
Transfer content...................................................................25
Synchronise, retrieve, or send content...............................26
Display indicators....................................................................27
Shortcuts..................................................................................28
Mobile Search...........................................................................28
Volume and loudspeaker control...........................................29
Offline profile...........................................................................29
Fast downloading....................................................................30
Ovi......................................................................31
About Ovi Store........................................................................31
Ovi Files.....................................................................................31
Camera...............................................................33
About the camera....................................................................33
Activate the camera................................................................33
Image capture..........................................................................33
Still image camera indicators..............................................33
Active toolbar........................................................................34

Capture images.....................................................................35
Location information............................................................35
Panorama mode...................................................................36
After capturing an image.....................................................36
Flash.......................................................................................37
Scenes....................................................................................37
Capture images in a sequence.............................................38
You in the picture—self-timer.............................................38
Tips on taking good photographs......................................39
Video recording.......................................................................39
Video capture indicators......................................................39
Record videos........................................................................40
After recording a video........................................................41
Camera settings.......................................................................41
Still image camera settings.................................................41
Colour and lighting settings................................................42
Video settings.......................................................................43
Photos................................................................44
About Photos............................................................................44
View images and videos.........................................................44
View and edit file details........................................................45
Organise images and videos..................................................45
Active toolbar...........................................................................45
Albums......................................................................................46
Tags...........................................................................................46
Slide show................................................................................46
TV-out mode............................................................................47
Edit images...............................................................................48
Image editor..........................................................................48
Crop image............................................................................48
Reduce red-eye.....................................................................48
Useful shortcuts....................................................................49
Edit videos................................................................................49
Gallery................................................................50
About Gallery............................................................................50
Main view.................................................................................50
Sound clips...............................................................................50
Streaming links........................................................................51
Presentations...........................................................................51
Connectivity.......................................................52
Wireless LAN ............................................................................52
About WLAN...........................................................................52
WLAN connections................................................................52
See WLAN availability...........................................................53
WLAN wizard ........................................................................53
Connection manager...............................................................53
Active data connections.......................................................53
Available WLANs....................................................................54
Bluetooth..................................................................................54
About Bluetooth....................................................................54
Send and receive data with Bluetooth...............................55
Pair devices............................................................................56
Block devices.........................................................................57
Security tips...........................................................................57
Data cable.................................................................................57
PC connections.........................................................................58
Sync...........................................................................................58
Browser..............................................................59
About Browser.........................................................................59
Browse the web.......................................................................59

Browser toolbar.......................................................................60
Navigate pages........................................................................60
Web feeds and blogs...............................................................60
Widgets.....................................................................................61
Content search.........................................................................61
Download and purchase items..............................................61
Bookmarks...............................................................................62
Empty the cache.......................................................................62
End the connection..................................................................62
Connection security.................................................................63
Web settings............................................................................63
Music..................................................................65
FM radio....................................................................................65
Listen to the radio................................................................65
Saved stations.......................................................................65
FM radio settings..................................................................66
Nokia Music Store....................................................................66
Nokia Internet Radio...............................................................66
Listen to internet radio stations.........................................67
Favourite stations.................................................................67
Search for stations................................................................67
Station directory...................................................................68
Internet radio settings.........................................................68
Nokia Podcasting.....................................................................68
Podcasting settings..............................................................69
Search podcasts....................................................................69
Directories.............................................................................70
Downloads.............................................................................71
Play and manage podcasts..................................................71
Music player..............................................................................72
Play a song or a podcast episode........................................72
Playlists..................................................................................73
Podcasts.................................................................................73
Home network with music player.......................................74
Transfer music from PC........................................................74
FM transmitter.........................................................................74
About the FM transmitter.....................................................74
Play a song using FM transmitter........................................75
FM transmitter settings........................................................75
Positioning (GPS)................................................76
About GPS.................................................................................76
Assisted GPS (A-GPS)................................................................76
Hold your device correctly......................................................77
Tips on creating a GPS connection.........................................77
Position requests.....................................................................78
Landmarks ...............................................................................78
GPS data....................................................................................79
Route guidance.....................................................................79
Retrieve position information.............................................79
Trip meter..............................................................................80
Nokia Maps.........................................................81
About Maps...............................................................................81
Network positioning...............................................................81
Compass....................................................................................82
Move on a map.........................................................................82
Display indicators....................................................................83
Find locations...........................................................................83
Plan a route..............................................................................83
Save and send locations..........................................................84
View your saved items............................................................84
Navigate to the destination...................................................84

Walk to your destination........................................................85
Drive to your destination........................................................85
Traffic and safety.....................................................................86
Maps settings...........................................................................87
Internet settings......................................................................87
Navigation settings.................................................................87
Route settings..........................................................................88
Map settings.............................................................................88
Update maps............................................................................89
Nokia Map Loader....................................................................89
Home network...................................................90
About home network..............................................................90
Important security information.............................................91
Settings for home network....................................................91
Activate sharing and define content.....................................92
View and share media files....................................................92
Copy media files.......................................................................93
Home synchronisation............................................................93
Synchronise media files.......................................................93
Synchronisation settings......................................................94
Define incoming files............................................................94
Define outgoing files............................................................94
Nokia Video Centre.............................................96
View and download video clips.............................................96
Video feeds...............................................................................97
My videos..................................................................................97
Transfer videos from your PC.................................................98
Video centre settings..............................................................98
N-Gage..............................................................100
About N-Gage.........................................................................100
N-Gage views.........................................................................100
Get started..............................................................................101
Create a player name.........................................................101
Start a game........................................................................101
Track your progress............................................................102
Play with friends.................................................................102
Play and manage games.......................................................102
Edit profile details.................................................................102
Connect with other players..................................................103
Find and add friends..........................................................103
View friend information....................................................103
Sort the friends list.............................................................103
Rate a player.......................................................................104
Send messages....................................................................104
N-Gage settings.....................................................................104
Messaging........................................................105
Messaging main view............................................................105
Write text...............................................................................105
Traditional text input.........................................................106
Predictive text input...........................................................106
Tips on text input...............................................................106
Change the writing language............................................107
Edit text and lists................................................................107
Write and send messages.....................................................107
Messaging inbox....................................................................108
Receive messages...............................................................108
Multimedia messages.........................................................109
Data, settings, and web service messages.......................109
Message reader......................................................................109
E-mail......................................................................................110

Set up your e-mail..............................................................110
Send e-mail.........................................................................110
Add attachments................................................................111
Read e-mail.........................................................................111
Download attachments......................................................111
Reply to a meeting request...............................................111
Search for e-mail messages...............................................112
Delete e-mails.....................................................................112
Switch between e-mail folders.........................................112
Disconnect from the mailbox............................................112
Set on an out-of-office reply..............................................112
General e-mail settings......................................................112
View messages on a SIM card...............................................113
Messaging settings................................................................113
Text message settings.......................................................113
Multimedia message settings...........................................114
E-mail settings....................................................................114
Manage mailboxes...........................................................114
Connection settings.........................................................115
User settings.....................................................................115
Retrieval settings.............................................................116
Automatic retrieval settings...........................................116
Web service message settings..........................................117
Cell broadcast settings.......................................................117
Other settings.....................................................................117
Make calls.........................................................118
Voice calls ..............................................................................118
Options during a call.............................................................118
Voice mail ..............................................................................119
Answer or decline a call........................................................119
Make a conference call..........................................................120
Speed dial a phone number ................................................120
Call waiting............................................................................120
Voice dialling.........................................................................121
Make a video call...................................................................121
During a video call.................................................................122
Answer or decline a video call.............................................123
Video sharing.........................................................................123
Video sharing requirements..............................................123
Video sharing settings.......................................................124
Share live video or video clips...........................................124
Accept an invitation...........................................................125
Log..........................................................................................126
Recent calls..........................................................................126
Call duration........................................................................126
Packet data..........................................................................126
Monitor all communication events...................................126
Internet calls....................................................128
About internet calls...............................................................128
Activate internet calls...........................................................128
Make internet calls ...............................................................128
Blocked contacts....................................................................129
Manage internet call services...............................................129
Internet call settings.............................................................129
Contacts (phonebook)......................................130
Save and edit names and numbers.....................................130
Manage names and numbers...............................................130
Default numbers and addresses..........................................130
Ringing tones, images, and call text for contacts..............131
Copy contacts.........................................................................131
SIM services............................................................................131

SIM contacts........................................................................131
Fixed dialling.......................................................................132
Manage contact groups........................................................132
Personalise your device...................................133
Change the look of your device............................................133
Audio themes.........................................................................133
Set tones.................................................................................134
3-D tones................................................................................134
Modify the standby mode.....................................................135
Modify the main menu..........................................................136
Time management...........................................137
Clock........................................................................................137
Alarm clock..........................................................................137
World clock..........................................................................137
Clock settings......................................................................137
Calendar..................................................................................138
Calendar views....................................................................138
Create a calendar entry......................................................138
Manage calendar entries....................................................138
Office................................................................140
File manager..........................................................................140
About File manager............................................................140
Find and organise files.......................................................140
Manage a memory card.....................................................140
Back up files to a memory card.........................................140
Format mass memory........................................................141
About Quickoffice..................................................................141
Currency converter................................................................141
Calculator................................................................................142
Make calculations...............................................................142
Save calculations................................................................142
Zip manager...........................................................................142
Notes ......................................................................................142
Adobe Reader.........................................................................143
Applications.....................................................144
RealPlayer...............................................................................144
Play video clips....................................................................144
Stream content over the air..............................................144
RealPlayer settings.............................................................144
Application manager.............................................................145
Install applications.............................................................145
Remove applications and software..................................147
Application manager settings...........................................147
Recorder.................................................................................147
Speech....................................................................................148
Licences..................................................................................148
Settings............................................................150
General settings.....................................................................150
Personalisation settings....................................................150
Accessories settings...........................................................151
Slide handling settings......................................................152
Sensor settings and display rotation................................152
Security settings.................................................................152
Phone and SIM..................................................................152
Certificate management.................................................153
Security module...............................................................154
Restore original settings....................................................154
Positioning settings...........................................................154
Phone settings.......................................................................155

Call settings.........................................................................155
Call divert.............................................................................156
Call barring..........................................................................156
Network settings................................................................157
Connection settings...............................................................157
Data connections and access points.................................157
Access points.......................................................................158
Create a new access point...............................................158
Create access point groups.............................................159
Packet data access points...............................................159
WLAN internet access points..........................................160
Packet data settings...........................................................161
Wireless LAN settings.........................................................161
SIP settings..........................................................................161
Configurations....................................................................162
Access point name control.................................................162
Application settings..............................................................162
Remote configuration...........................................................162
Troubleshooting..............................................164
Green tips.........................................................168
Save energy............................................................................168
Recycle....................................................................................168
Save paper..............................................................................168
Learn more.............................................................................168
Accessories.......................................................169
Battery..............................................................171
Battery and charger information.........................................171
Nokia battery authentication guidelines............................172
Authenticate hologram......................................................172
Taking care of your device...............................173
Recycle....................................................................................174
Additional safety information.........................175
Small children........................................................................175
Operating environment........................................................175
Medical devices......................................................................175
Implanted medical devices................................................175
Hearing aids........................................................................176
Vehicles...................................................................................176
Potentially explosive environments....................................176
Emergency calls.....................................................................177
Certification information (SAR)............................................177
Index................................................................179

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel, chemicals,
or blasting areas.
GLASS PARTS
The front cover of the device is made of glass. This
glass can break if the device is dropped on a hard
surface or receives a substantial impact. If the glass
breaks, do not touch the glass parts of the device
or attempt to remove the broken glass from the
device. Stop using the device until the glass is
replaced by qualified service personnel.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Note: The surface of this device does not contain
nickel in the platings. The surface of this device contains
stainless steel.
© 2009 Nokia. All rights reserved.10

About your device
The wireless device described in this guide is approved for
use on the (E)GSM 850, 900, 1800,1900, and UMTS 900, 1900,
2100 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and
respect local customs, privacy and legitimate rights of others,
including copyrights.
Copyright protection may prevent some images, music, and
other content from being copied, modified, or transferred.
Your device supports several methods of connectivity. Like
computers, your device may be exposed to viruses and other
harmful content. Exercise caution with messages,
connectivity requests, browsing, and downloads. Only install
and use services and other software from trustworthy
sources that offer adequate security and protection against
harmful software, such as applications that are Symbian
Signed or have passed the Java Verified™ testing. Consider
installing antivirus and other security software on your
device and any connected computer.
Important: Your device can only support one antivirus
application. Having more than one application with antivirus
functionality could affect performance and operation or
cause the device to stop functioning.
Your device may have preinstalled bookmarks and links for
third-party internet sites. You may also access other third-
party sites through your device. Third-party sites are not
affiliated with Nokia, and Nokia does not endorse or assume
liability for them. If you choose to access such sites, you
should take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do not
switch the device on when wireless device use may cause
interference or danger.
The office applications support common features of Microsoft
Word, PowerPoint, and Excel (Microsoft Office 2000, XP, and
2003). Not all file formats can be viewed or modified.
Remember to make back-up copies or keep a written record
of all important information stored in your device.
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
The images in this guide may differ from your device display.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make specific
arrangements with your service provider to use them.
© 2009 Nokia. All rights reserved. 11

Network services involve transmission of data. Check with
your service provider for details about fees in your home
network and when roaming on other networks. Your service
provider can explain what charges will apply. Some networks
may have limitations that affect how you can use some
features of this device requiring network support such as
support for specific technologies like WAP 2.0 protocols (HTTP
and SSL) that run on TCP/IP protocols and language-
dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu names,
menu order, and icons.
Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may reduce
the memory available for the remaining features. If your
device displays a message that the memory is full, delete
some of the information stored in the shared memory.
During extended operation such as an active video call and
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the device
is not working properly, take it to the nearest authorised
service facility.
ActiveSync
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia
device and the authorised Microsoft Exchange server.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
© 2009 Nokia. All rights reserved.12

Get started
Keys and parts (front and top)
1— Light sensor
2— Selection keys
3— Call key
4— Menu key
5— Numeric keypad
6— Microphone
7— Scroll and selection key
8— Clear key C
9— End key
10 — Earpiece
11 — Secondary camera
1— Power key
2— Nokia AV Connector (3.5 mm)
3— Micro USB connector
© 2009 Nokia. All rights reserved. 13

Keys and parts (back and sides)
1— Stereo speaker
2— Volume/Zoom key
3— Capture key
4— Stereo speaker
5— Flash and video light
6— Lens cover
7— Main camera
8— Key lock switch
Short slide keys
Short slide keys act as media, zoom, or gaming keys
depending on the application. Short slide keys also enable
multitasking, for example, if you are browsing the
internet with the Music player application in the
background, you can control the player with the Play/
Pause key.
1— Forward/Zoom in key
2— Play/Pause key and gaming key
3— Stop key and gaming key
4— Rewind/Zoom out key
Kickstand
You can use the kickstand, for example, when you view
images or video clips.
© 2009 Nokia. All rights reserved.14

Open the kickstand at the
back of the device, and
place the device on a level
surface. When you open the
kickstand, the Photos
application is opened
automatically.
To modify the kickstand
settings, select Menu >
Tools > Settings and
General >
Personalisation >
Kickstand.
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
1. With the back of the device
facing you, remove the back
cover by lifting it from the
bottom end of the device.
2. Insert the SIM card into the card
holder. Ensure that the bevelled
corner on the card is facing right,
and that the contact area on the
card is facing down.
3. Insert the battery.
4. To replace the cover, press the
cover down until the cover locks
into place.
Memory card
Use only compatible microSD cards approved
by Nokia for use with this device. Nokia uses
approved industry standards for memory
cards, but some brands may not be fully compatible with
© 2009 Nokia. All rights reserved. 15

this device. Incompatible cards may damage the card and
the device and corrupt data stored on the card.
Insert the memory card
A memory card may be already inserted in the device. If
not, do the following:
1. With the back o f the device f acing you, lift up the cover.
2. Insert a compatible memory card in the slot. Ensure
that the contact area on the card is facing down and
towards the slot.
3. Push the card in. You can
hear a click when the
card locks into place.
4. Close the back cover.
Ensure that the cover is
properly closed.
Remove the memory card
Important: Do not remove the memory card
during an operation when the card is being accessed.
Doing so may damage the memory card and the device,
and corrupt data stored on the card.
1. Before you remove the card, press the power key, and
select Remove memory card. All applications are
closed.
2. When Removing memory card will close all open
applications. Remove anyway? is displayed, select
Yes.
3. When Remove memory card and press 'OK' is
displayed, remove the back cover of the device.
4. Press the memory card to release it from the slot.
5. Pull out the memory card. If the device is switched on,
select OK.
6. Replace the back cover. Ensure that the cover is
properly closed.
Switch the device on and off
To switch on the device:
1. Press and hold the power key.
© 2009 Nokia. All rights reserved.16

2. If the device asks for a PIN code or
lock code, enter it, and select OK. The
preset lock code is 12345. If you
forget the code and your device is
locked, your device will require
service and additional charges may
apply. For more information, contact
a Nokia Care point or your device
dealer.
To switch off the device, press the power key briefly, and
select Switch off!.
Charge the battery
Your battery has been partially charged at the factory.
There may not be a need to charge the battery in advance.
If the device indicates a low charge, do the following:
Regular charging
1. Connect the charger to a wall outlet.
2. Connect the charger to the device.
The charging indicator light next to
the USB connector is lit when the
battery is being charged.
3. When the device indicates a full
charge, disconnect the charger from
the device, then from the wall outlet.
You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging. If the
battery is completely discharged, it may
take several minutes before the
charging indicator appears on the display or before any
calls can be made.
Tip: Disconnect the charger from the wall outlet
when the charger is not in use. A charger that is
connected to the outlet consumes power even
when it is not connected to the device.
USB charging
You can use USB charging when a wall outlet is not
available. With USB charging, you can also transfer data
while charging the device.
1. Connect a compatible USB device to your device using
a compatible USB cable.
© 2009 Nokia. All rights reserved. 17

The efficiency of USB charging varies significantly. In
some cases, it may take a very long time for charging
to start and the device to start functioning.
2. If your device is switched on, you can select from the
available USB mode options on the display of the
device.
During extended operation such as an active video call
and high speed data connection, the device may feel
warm. In most cases, this condition is normal. If you
suspect the device is not working properly, take it to the
nearest authorised service facility.
Headset
You can connect a compatible headset or compatible
headphones to your device. You may need to select the
cable mode.
Some headsets come in two parts, a remote control unit
and headphones. A remote control unit has a microphone
and keys to answer or end a phone call, adjust the volume,
and play music or video files. To use the headphones with
a remote control unit, connect the unit to the Nokia AV
Connector in the device, then connect the headphones to
the unit.
Warning: When you use the
headset, your ability to hear outside
sounds may be affected. Do not use the
headset where it can endanger your
safety.
Do not connect products that create an
output signal as this may cause damage
to the device. Do not connect any
voltage source to the Nokia AV
Connector.
When connecting any external device or
any headset, other than those approved
by Nokia for use with this device, to the Nokia AV
Connector, pay special attention to volume levels.
Attach wrist strap
1. Open the back cover.
2. Thread a wrist strap, and
tighten it.
3. Close the back cover.
© 2009 Nokia. All rights reserved.18
