Physical to Logical Port Assignment
2 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Table of Contents
1 Introduction 4
1.1 Document Purpose 4
1.2 Intended Audience 4
2 Logical Port Label Assignment 5
2.1 LoadMaster LM-X1 5
2.2 LoadMaster LM-X3 6
2.3 LoadMaster LM-X15 8
2.4 LoadMaster LM-X15-MT 10
2.5 LoadMaster LM-X25 13
2.6 LoadMaster LM-X25-MT 15
2.7 LoadMaster LM-X40 18
2.8 LoadMaster LM-X40-MT 21
2.9 LoadMaster LM 8020-FIPS 23
2.10 LoadMaster LM-8020 and LM-8020M 27
2.11 LoadMaster LM-8000 and 8010-MT 30
2.12 LoadMaster LM-5600 and LM-5610 34
2.13 LoadMaster LM-4000 36
2.14 LoadMaster LM-3400 38
2.15 LoadMaster LM-3000 40
Last Updated Date 42
Physical to Logical Port Assignment
3 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

1 Introduction
There are a variety of hardware LoadMaster models to choose from. For details on each, consult the
Kemp website: www.kemptechnologies.com.
The physical network ports and their logical assignment varies between models depending on the
underlying hardware platform used.
1.1 Document Purpose
This document outlines the total number of Ethernet and Small Form-factor Pluggable (SFP+) ports
on each hardware LoadMaster. Because the physical port labels on each LoadMaster model may
vary, this document shows the factory default logical port label assignment.
1.2 Intended Audience
This document is intended to be read by anyone who is interested in finding out the logical port
label assignment when installing a hardware LoadMaster.
Physical to Logical Port Assignment
1 Introduction
4 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

2 Logical Port Label
Assignment
Refer to the sections below for details on the logical port label assignment.
2.1 LoadMaster LM-X1
Port Location - Front Panel
Item
No. Item Description Notes
1. PWR LED Indicates the power
status of the system
LED – Blue Power on
LED – Off Power off
HDD LED Indicates the status of the Hard Disk Drive
(HDD)
LED – Yellow flashing Indicates read/write
activity of the HDD
LED – Off Indicates no activity of
HDD
2. Reset button Reset LoadMaster GPIO software button
3. RJ-45 type
console port
Used to connect console devices with RJ45
connection
Physical to Logical Port Assignment
2 Logical Port Label Assignment
5 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

4. USB 3.0 Ports (2) Allows to connect USB 3.0/2.0/1.1 devices to
the system
5.
1 Gb copper
ethernet ports
(4)
4 x 1 Gb copper ports used to connect LAN
network devices with LED indicators
Logical Assignment
Port 0:3 map to
ETH0:ETH3
Activity LED – Yellow blinking Indicates data activity
Activity LED - Off Indicates no data
activity
Link LED – Green Indicates data 1 Gb
and 10/100 Mb
Link LED – Off Indicates no link
Port Location - Rear Panel
Item No. Item Description
6. VGA port Used to connect an analog VGA monitor
7. Power supply 250W AC power supply
2.2 LoadMaster LM-X3
Port Location - Front Panel
Physical to Logical Port Assignment
2 Logical Port Label Assignment
6 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Item
No. Item Description Notes
1.
PB2 LED
PB1 LED
Not used by LoadMaster OS (LMOS)
Indicates the LAN bypass
BP1 and BP2 LED – On Bypass enabled
BP1 and BP2 LED – Off Bypass disabled
PWR LED Indicates the power status of the system
LED – Green Power on
LED – Off Power off
HDD LED Indicates the status of the Hard Disk Drive
(HDD)
LED – Yellow flashing Indicates read/write
activity of the HDD
LED – Off Indicates no activity
of HDD
2. Reset button Reset LoadMaster GPIO software button
3. RJ-45/Micro USB
type console port
Used to connect console devices with
RJ45/Micro USB type connection
4. USB 3.0 Ports (2) Allows to connect USB 3.0/2.0/1.1 devices to
the system
5. 1 Gb copper
ethernet ports (8)
8 x 1 Gb copper ports used to connect LAN
network devices with LED indicators
Logical Assignment
Port 0:7 map to
ETH0:ETH7
Physical to Logical Port Assignment
2 Logical Port Label Assignment
7 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

ACT LED – Yellow blinking Indicates data activity
ACT LED - Off Indicates no data
activity
LINK LED – Green Indicates data 1 Gb
and 10/100 Mb
LINK LED – Off Indicates no link
Port Location - Rear Panel
Item No. Item Description
6. VGA port Used to connect an analog VGA monitor
7. Power switch Press to power-on or power-off the system
8. USB 3.0 ports (2) Allows you to connect USB 3.0/2.0/1.1 devices to the system
9. Power supply 250 W AC power supply
2.3 LoadMaster LM-X15
Port Location - Front Panel
Item Item Description Notes
Physical to Logical Port Assignment
2 Logical Port Label Assignment
8 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

No.
1. RAID (Dual HDD) Built-in hardware RAID controller,
supporting RAID 0
Disk mirroring - replicating
of data to two or more
disks. Good choice for
applications requiring high
performance and high
availability
2. PB2 LED
PB1 LED
*Not used by LMOS
Indicates the LAN bypass
BP1 and BP2 LED – On Bypass enabled
BP1 and BP2 LED – Off Bypass disabled
PWR LED Indicates the power status of the
system
LED – Green Power ON
LED – Off Power Off
HDD LED Indicates the status of the Hard Disk
Drive (HDD)
LED – Yellow flashing Indicates read/write
activity of the HDD
LED – Off Indicates no activity of
HDD
3. Reset button Reset LoadMaster
4. RJ-45/Micro USB type
console port
Used to connect console devices
with RJ45/Micro USB type
connection
5. USB 3.0 ports (2) Allows you to connect USB
3.0/2.0/1.1 devices to the system
6. 1 Gb copper ethernet
ports (16)
16 x 1 Gb copper ports used to
connect LAN network devices with
LED indicators
Logical Assignment
Port 0:15 map to
ETH0:ETH15
Physical to Logical Port Assignment
2 Logical Port Label Assignment
9 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

ACT LED – Yellow blinking Indicates data activity
ACT LED - Off Indicates no data activity
LINK LED – Green Indicates data 1 Gb and
10/100 Mb
LINK LED – Off Indicates no link
7. 10 Gb SFP+ ports (4)
4 x 10 Gbps supporting fiber optic
and direct-attach copper (DAC)
cables.
Logical Assignment
Port 16:19 map to
ETH16:ETH19
Activity LED Off - no network activity
Blinking - network activity
Link LED Off - no link (cable
disconnected)
Continuously illuminated –
link
Port Location - Rear Panel
No Item Description
8. VGA port Used to connect an analog VGA monitor
9. Power switch Press to power-on or power-off the system
10. Dual power supply 220 W AC by 1 and common redundant power supply (CPRS)
2.4 LoadMaster LM-X15-MT
Port Location - Front Panel
Physical to Logical Port Assignment
2 Logical Port Label Assignment
10 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Item
No. Item Description Notes
1. RAID (Dual HDD) Built-in hardware RAID controller,
supporting RAID 0
Disk mirroring -
replicating of data to
two or more disks.
Good choice for
applications requiring
high performance and
high availability
2. PB2 LED
PB1 LED
*Not used by LMOS
Indicates the status of the LAN bypass
BP1 and BP2 LED – On Bypass enabled
BP1 and BP2 LED – Off Bypass disabled
PWR LED Indicates the power status of the
system
LED – Green Power on
LED – Off Power off
HDD LED Indicates the status of the HDD
LED - Yellow flashing Indicates read/write
activity of the HDD
LED - Off Indicates no activity of
HDD
3. Reset button Reset LoadMaster GPIO software button
4. RJ-45/Micro USB type
console port
Used to connect console devices with
RJ45/Micro USB type connection
Physical to Logical Port Assignment
2 Logical Port Label Assignment
11 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

5. USB 3.0 ports (2) Allows you to connect USB 3.0/2.0/1.1
devices to the system
6. 1 Gb copper ethernet
ports (16)
16 x 1 Gb copper ports used to
connect LAN network devices with LED
indicators
Logical Assignment
Port 0:15 map to
ETH0:ETH15
ACT LED – Yellow blinking Indicates data activity
ACT LED - Off Indicates no data
activity
LINK LED – Green Indicates data 1 Gb
and 10/100 Mb
LINK LED – Off Indicates no link
7. 10 Gb SFP+ ports (4) 4 x 10 Gbps supporting fiber optic and
direct-attach copper (DAC) cables
Logical Assignment
Port 16:19 map to
ETH16:ETH19
Activity LED Off - no network
activity
Blinking - network
activity
Link LED Off - no link (cable
disconnected)
Continuously
illuminated - link
Port Location - Rear Panel
Item No. Item Description
8. VGA port Used to connect an analog VGA monitor
Physical to Logical Port Assignment
2 Logical Port Label Assignment
12 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

9. Power switch Press to power-on or power-off the system
10. Dual power supply 220 W AC by 1 and common redundant power supply (CPRS)
2.5 LoadMaster LM-X25
Port Location - Front Panel
Item
No. Item Description Notes
1. RAID (Dual HDD) Built-in hardware RAID controller,
supporting RAID 0.
Disk mirroring -
replicating of data to
two or more disks.
Good choice for
applications
requiring high
performance and
high availability
2. ERR LED Error LED - LED red
Indicates if the
system is
experiencing an error
during operation
STBY LED Standby LED – LED orange
Indicates if the
system is in sleep
mode (system idle for
too long)
Physical to Logical Port Assignment
2 Logical Port Label Assignment
13 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

HDD LED Indicates the status of the HDD Indicates read/write
activity of the HDD
LED – Yellow flashing Indicates no activity
of HDD
LED – Off
PWR LED Indicates the power status of the system
LED – Green Power on
LED - Off Power off
3. RJ-45 console port Used to connect console devices with
RJ45 type connection
4. USB 3.0 ports (2) Allows you to connect USB 3.0/2.0/1.1
devices to the system
5. 1 Gb copper ethernet
ports (2)
2 x 1 Gb copper ports used to connect
network devices with LED indicators
Logical Assignment
Port 0:1 map to
ETH0:ETH1
Activity LED – Yellow blinking Indicates data
activity
Activity LED - Off Indicates no data
activity
Link LED – Green Indicates data 1 Gb
and 10/100 Mb
Link LED – Off Indicates no link
6. Reset button Reset LoadMaster GPIO software button
7. 10 Gb SFP+ ports (12) 12 x 10 Gbps supporting fiber optic and
direct-attach copper (DAC) cables
Logical Assignment
Port 2:13 map to
ETH2:ETH13
Activity LED Off - no network
activity
Blinking - network
activity
Physical to Logical Port Assignment
2 Logical Port Label Assignment
14 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Link LED Off - no link (cable
disconnected)
Continuously
illuminated – link
Port Location - Real Panel
Item No. Item Description
8. VGA port Used to connect an analog VGA monitor
9. Power switch Press to power-on or power-off the system
10. Dual power supply 700 W AC x1 and a common redundant power supply (CRPS)
11. USB 3.0 ports Allows you to connect USB 3.0/2.0/1.1 devices to the system
2.6 LoadMaster LM-X25-MT
Port Location - Front Panel
Physical to Logical Port Assignment
2 Logical Port Label Assignment
15 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Item
No. Item Description Notes
1. RAID (Dual HDD) Built-in hardware RAID controller,
supporting RAID 0
Disk mirroring -
replicating of data to
two or more disks.
Good choice for
applications
requiring high
performance and
high availability
2. ERR LED Error LED - LED red
Indicates if the
system is
experiencing an error
during operation
STBY LED Standby LED – LED orange
Indicates if the
system is in sleep
mode (system idle for
too long)
HDD LED Indicates the status of the HDD
LED – Yellow flashing Indicates read/write
activity of the HDD
LED – Off Indicates no activity
of HDD
PWR LED Indicates the power status of the
Physical to Logical Port Assignment
2 Logical Port Label Assignment
16 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

system
LED – Green Power on
LED – Off Power off
3. RJ-45 console port Used to connect console devices with
RJ45 type connection
4. USB 3.0 ports (2) Allows you to connect USB 3.0/2.0/1.1
devices to the system
5. 1 Gb copper ethernet ports
(2)
2 x 1 Gb copper ports used to connect
network devices with LED indicators
Logical Assignment
Port 0:1 map to
ETH0:ETH1
Activity LED – Yellow blinking Indicates data
activity
Activity LED - Off Indicates no data
activity
Link LED – Green Indicates data 1 Gb
and 10/100 Mb
Link LED – Off Indicates no link
6. Reset button Reset LoadMaster GPIO software button
7. 10 Gb SFP+ ports (12) 12 x 10 Gbps supporting fiber optic
and direct-attach copper (DAC) cables
Logical Assignment
Port 2:13 map to
ETH2:ETH13
Activity LED Off - no network
activity
Blinking - network
activity
Link LED Off - no link (cable
disconnected)
Continuously
illuminated - link
Port Location - Real Panel
Physical to Logical Port Assignment
2 Logical Port Label Assignment
17 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

Item No. Item Description
8. VGA port Used to connect an analog VGA monitor
9. Power switch Press to power-on or power-off the system
10. Dual power supply 700 W AC x1 and a common redundant power supply (CRPS)
11. 3.0 USB ports Allows you to connect USB 3.0/2.0/1.1 devices to the system
2.7 LoadMaster LM-X40
Port Location - Front Panel
Item
No. Item Description Notes
1. RAID (Dual HDD) Built-in hardware RAID controller,
supporting RAID 0
Disk mirroring -
replicating of data to
Physical to Logical Port Assignment
2 Logical Port Label Assignment
18 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

two or more disks.
Good choice for
applications requiring
high performance and
high availability
2. ERR LED Error LED - LED red
Indicates if the system
is experiencing an
error during operation
STBY LED Standby LED – LED orange
Indicates if the system
is in sleep mode
(system idle for too
long)
HDD LED Indicates the status of the HDD Indicates read/write
activity of the HDD
LED – Yellow flashing Indicates no activity of
HDD
LED – Off
PWR LED Indicates the power status of the
system
LED - Green Power on
LED - Off Power off
3. RJ-45 console port Used to connect console devices with
RJ45 type connection
4. USB 3.0 ports (2) Allows you to connect USB 3.0/2.0/1.1
devices to the system
5. 1 Gb copper ethernet
ports (2)
2 x 1 Gb copper ports used to connect
network devices with LED indicators
Logical Assignment
Port 0:1 map to
ETH0:ETH1
Activity LED – Yellow blinking Indicates data activity
Activity LED - Off Indicates no data
activity
Activity LED – Green Indicates data 1 Gb
Physical to Logical Port Assignment
2 Logical Port Label Assignment
19 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.

and 10/100 Mb
LINK LED – Off Indicates no link
6. Reset button Reset LoadMaster GPIO software button
7. 10 Gb SFP+ ports (12) 12 x 10 Gb supporting fiber optic and
direct-attach copper (DAC) cables
Logical Assignment
Port 2:13 map to
ETH2:ETH13
Activity LED Off - No network
activity
Blinking - network
activity
Link LED Off - no link (cable
disconnected)
Continuously
illuminated - link
Port Location - Real Panel
Item No. Item Description
8. VGA port Used to connect an analog VGA monitor
9. Power switch Press to power-on or power-off the system
10. Dual power supply 700 W AC x1 and a common redundant power supply (CRPS)
11. 3.0 USB ports Allows you to connect USB 3.0/2.0/1.1 devices to the system
Physical to Logical Port Assignment
2 Logical Port Label Assignment
20 © 2022 Progress Software Corporation and/or one of its subsidiaries or affiliates. All rights reserved.
