Progress PBD34103B User manual

PBD34103B
PBD34103X
User Manual
Benutzerinformation
Oven
Backofen

CONTENTS
Safety information 2
Safety instructions 3
Installation 7
Product description 8
Control panel 8
Before first use 9
Daily use 10
Clock functions 12
Using the accessories 13
Additional functions 14
Hints and tips 14
Care and cleaning 26
Troubleshooting 29
Energy efficiency 29
Subject to change without notice.
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information:
www.progress-hausgeraete.de/support
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
2 Progress

•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
•Always use oven gloves to remove or put in accessories or
ovenware.
•Before carrying out any maintenance, disconnect the
appliance from the power supply.
•WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of electric
shock.
•Do not use the appliance before installing it in the built-in
structure.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch the
surface, which may result in shattering of the glass.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an electrical
hazard.
•To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
Progress 3

• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from other
appliances and units.
• Before mounting the appliance, check if
the oven door opens without restraint. If
not the oven has to be lifted.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power supply.
Cabinet minimum
height (Cabinet un‐
der the worktop mini‐
mum height)
590 (600) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of
the appliance
594 mm
Height of the back of
the appliance
576 mm
Width of the front of
the appliance
595 mm
Width of the back of
the appliance
559 mm
Depth of the appli‐
ance
569 mm
Built in depth of the
appliance
548 mm
Depth with open
door
1022 mm
Ventilation opening
minimum size. Open‐
ing placed on the
bottom rear side
560x20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 4x25 mm
Electrical connection
WARNING! Risk of fire and
electric shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche
below the appliance, especially when it
operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
4 Progress

• This appliance is supplied with a main
plug and a main cable.
Cable types applicable for installation or
replacement for Europe:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-
F, H05 V2V2-F (T90), H05 BB-F
For the section of the cable refer to the
total power on the rating plate. You can
also refer to the table:
Total power (W) Section of the ca‐
ble (mm²)
maximum 1380 3 x 0.75
maximum 2300 3 x 1
maximum 3680 3 x 1.5
The earth cord (green / yellow cable) must
be 2 cm longer than phase and neutral
cables (blue and brown cables).
Use
WARNING! Risk of injury,
burns and electric shock or
explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is in
operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
WARNING! Risk of damage to
the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put aluminium foil directly on
the bottom of cavity of the
appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance
of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance operates. Heat and moisture
can build up behind a closed furniture
panel and cause subsequent damage
to the appliance, the housing unit or the
floor. Do not close the furniture panel
until the appliance has cooled down
completely after use.
Care and cleaning
WARNING! Risk of injury, fire,
or damage to the appliance.
Progress 5

• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instructions on its packaging.
Internal lighting
WARNING! Risk of electric
shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational status
of the appliance. They are not intended
to be used in other applications and are
not suitable for household room
illumination.
• Use only lamps with the same
specifications.
Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming trapped
in the appliance.
6 Progress

INSTALLATION
WARNING! Refer to Safety
chapters.
Building in
18
594
589
114
21548
595+-1
min. 550
20
600
min. 560
5
1
60
20
80
520
60
198
523
min. 550
20
595+-1
18
590
min. 560
594
589
114
21548
1
5
70
60 520
60
20
198
523
(*mm)
Progress 7

Securing the oven to the cabinet
PRODUCT DESCRIPTION
General overview
8
7
12 9
10
11
5
4
1
2
3
331 64 52
1Control panel
2Knob for the heating functions
3Power lamp / symbol
4Display
5Control knob (for the temperature)
6Temperature indicator / symbol
7Heating element
8Lamp
9Fan
10 Cavity embossment - Aqua cleaning
container
11 Shelf support, removable
12 Shelf positions
Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Combi pan
For cakes and biscuits. To bake and
roast or as a pan to collect fat.
CONTROL PANEL
Retractable knobs
To use the appliance press the knob. The
knob comes out.
8 Progress

Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
Display
A B
A. Clock functions
B. Timer
BEFORE FIRST USE
WARNING! Refer to Safety
chapters.
Before first use
The oven can emit an odour and smoke during preheating. Make sure that the room is
ventilated.
Step 1 Step 2 Step 3
Set the clock Clean the oven Preheat the empty oven
1. Press: .
2. , - press to set the
hour. Press: .
3. , - press to set the
minutes. Press: .
1. Remove all accessories
and removable shelf
supports from the oven.
2. Clean the oven and the
accessories with a soft
cloth, warm water and a
mild detergent.
1. Set the maximum tem‐
perature for the function:
.
Time: 1 h.
2. Set the maximum tem‐
perature for the function:
.
Time: 15 min.
3. Set the maximum tem‐
perature for the function:
.
Time: 15 min.
Progress 9

Turn off the oven and wait until it is cold. Place the accessories and the removable shelf sup‐
ports in the oven.
DAILY USE
WARNING! Refer to Safety
chapters.
How to set: Heating function
Step 1 Turn the knob for the heating
functions to select a heating
function.
Step 2 Turn the control knob to select
the temperature.
Step 3 When the cooking ends, turn
the knobs to the off position to
turn off the oven.
Setting the function: True Fan Cooking PLUS
WARNING! Risk of burns and damage to the appliance.
Step 1 Make sure that the oven is cold.
Step 2 Fill the cavity embossment with
tap water.
The maximum capacity of
the cavity embossment is 250
ml. Do not refill the cavity em‐
bossment during cooking or
when the oven is hot.
Step 3 Set the function: .
Step 4 Turn the control knob for the temperature to set temperature.
Step 5 Preheat the empty oven for 10 min to create humidity.
Step 6 Put food in the oven.
Refer to "Hints and tips" chapter. Do not open the oven door during cooking.
Step 7 Turn the knob for the heating functions to the off position to turn off the oven.
Step 8 After the function ends, carefully open the door. Released humidity can cause
burns.
Step 9 Make sure that the oven is cold. Remove the remaining water from the cavity em‐
bossment.
10 Progress

Heating functions
Heating
function
Application
Off position
The oven is off.
Light
To turn on the lamp.
True Fan
Cooking
PLUS / Aqua
Clean
To add humidity during
the cooking. To get the
right colour and crispy
crust during baking. To
give more juiciness dur‐
ing reheating.
Refer to "Care and clean‐
ing" chapter for more in‐
formation about: Aqua
Clean.
Moist Fan
Baking
This function is designed
to save energy during
cooking. When you use
this function, the temper‐
ature in the cavity may
differ from the set tem‐
perature. The heating
power may be reduced.
For more information re‐
fer to "Daily Use" chap‐
ter, Notes on: Moist Fan
Baking.
Bottom Heat
To bake cakes with
crispy bottom and to pre‐
serve food.
True Fan
Cooking
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20 -
40 °C lower than for Con‐
ventional Cooking.
Heating
function
Application
Turbo Grilling
To roast large meat joints
or poultry with bones on
one shelf position. To
make gratins and to
brown.
Fast Grilling
To grill thin pieces of
food in large quantities
and to toast bread.
Pizza Func‐
tion
To bake pizza. To make
intensive browning and a
crispy bottom.
Conventional
Cooking
To bake and roast food
on one shelf position.
Notes on: Moist Fan Baking
This function was used to comply with the
energy efficiency class and ecodesign
requirements according to EU 65/2014
and EU 66/2014. Tests according to EN
60350-1.
The oven door should be closed during
cooking so that the function is not
interrupted and the oven operates with the
highest energy efficiency possible.
For the cooking instructions refer to "Hints
and tips" chapter, Moist Fan Baking. For
general energy saving recommendations
refer to "Energy Efficiency" chapter,
Energy Saving.
Progress 11

CLOCK FUNCTIONS
Clock functions
Clock function Application
Time of Day
To set, change or check the time of day.
Duration
To set how long the oven works.
Minute Minder
To set a countdown. This function has no effect on the opera‐
tion of the oven. You can set this function at any time, also
when the oven is off.
How to set: Clock functions
How to change: Time of Day
- flashes when you connect the oven to the electrical supply, when there was a power cut
or when the timer is not set.
Step 1 - press repeatedly. - starts to flash.
Step 2 , - press to set the time.
After approximately 5 sec., the flashing stops and the display shows the time.
- press repeatedly to change the time of day. - starts to flash.
How to set: Duration
Step 1 Set an oven function and the temperature.
Step 2 - press repeatedly. - starts to flash.
Step 3 , - press to set the duration.
The display shows: .
- flashes when the set time ends. The signal sounds and the oven turns off.
Step 4 Press any button to stop the signal.
Step 5 Turn the knobs to the off position.
How to set: Minute Minder
Step 1 - press repeatedly. - starts to flash.
12 Progress

How to set: Minute Minder
Step 2 , - press to set the time.
The function starts automatically after 5 sec.
When the set time ends, the signal sounds.
Step 3 Press any button to stop the signal.
Step 4 Turn the knobs to the off position.
How to cancel: Clock functions
Step 1 - press repeatedly until the clock function symbol starts to flash.
Step 2 Press and hold: .
The clock function turns off after few seconds.
USING THE ACCESSORIES
WARNING! Refer to Safety
chapters.
Inserting accessories
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Progress 13

Deep pan:
Push the tray between the guide bars of
the shelf support.
Wire shelf, Deep pan:
Push the tray between the guide bars of
the shelf support and the wire shelf on
the guide bars above.
ADDITIONAL FUNCTIONS
Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
Safety thermostat
Incorrect operation of the oven or
defective components can cause
dangerous overheating. To prevent this,
the oven has a safety thermostat which
interrupts the power supply. The oven
turns on again automatically when the
temperature drops.
HINTS AND TIPS
Refer to Safety chapters.
Cooking recommendations
The oven has five shelf positions.
Count the shelf positions from the bottom
of the oven floor.
Your oven may bake or roast differently to
the oven you had before. The below
tables provide you with the standard
settings for temperature, cooking time and
shelf position.
If you cannot find the settings for a special
recipe, look for the similar one.
The oven has a special system which
circulates the air and constantly recycles
the steam. With this system you can cook
in a steamy environment and keep the
food soft inside and crusty outside. It
decreases the cooking time and energy
consumption.
14 Progress

Baking cakes
Do not open the oven door before 3/4 of
the set cooking time is up.
If you use two baking trays at the same
time, keep one empty level between them.
Cooking meat and fish
Use a deep pan for very fatty food to
prevent the oven from stains that can be
permanent.
Leave the meat for approximately 15
minutes before carving so that the juice
does not seep out.
To prevent too much smoke in the oven
during roasting, add some water into the
deep pan. To prevent the smoke
condensation, add water each time after it
dries up.
Cooking times
Cooking times depend on the type of food,
its consistency, and volume.
Initially, monitor the performance when
you cook. Find the best settings (heat
setting, cooking time, etc.) for your
cookware, recipes and quantities when
you use this appliance.
True Fan Cooking PLUS
Use the second shelf position.
Use a baking tray.
CAKES / PASTRIES / BREADS
(ml) (°C) (min)
Cookies / Scones / Croissants 100 150 -
180
10 - 20
Focaccia 100 200 -
210
10 - 20
Pizza 100 230 10 - 20
Bread rolls 100 200 20 - 25
Bread 100 180 35 - 40
Plum cake / Apple pie / Cinnamon rolls, baked in a
cake mould
100 - 150 160 -
180
30 - 60
Use 150 ml of water unless specified otherwise.
FROZEN READY MEALS
(°C) (min)
Pizza 200 - 210 10 - 20
Croissants 170 - 180 15 - 25
Lasagne, use 200 ml 180 - 200 35 - 50
Use 100 ml of water.
Set the temperature to 110 °C.
Progress 15

FOOD REGENERATION
(min)
Bread rolls 10 - 20
Bread 15 - 25
Focaccia 15 - 25
Meat 15 - 25
Pasta 15 - 25
Pizza 15 - 25
Rice 15 - 25
Vegetables 15 - 25
Use 200 ml of water.
Use a glass baking dish.
ROASTING
(°C) (min)
Roast beef 200 50 - 60
Chicken 210 60 - 80
Roast pork 180 65 - 80
Baking and roasting
CAKES
Conventional
Cooking
True Fan Cooking
(min)
(°C) (°C)
Whisked rec‐
ipes
170 2 160 3 (2 and 4) 45 - 60 Cake
mould
Shortbread
dough
170 2 160 3 (2 and 4) 20 - 30 Cake
mould
Buttermilk
cheesecake
170 1 165 2 60 - 80 Cake
mould, Ø
26 cm
Strudel 175 3 150 2 60 - 80 Baking
tray
16 Progress

CAKES
Conventional
Cooking
True Fan Cooking
(min)
(°C) (°C)
Jam tart 170 2 165 2 30 - 40 Cake
mould, Ø
26 cm
Christmas
cake, preheat
the empty
oven
160 2 150 2 90 -
120
Cake
mould, Ø
20 cm
Plum cake,
preheat the
empty oven
175 1 160 2 50 - 60 Bread tin
Muffins 170 3 140 -
150
3 20 - 30 Baking
tray
Muffins, two
levels
- - 140 -
150
2 and 4 25 - 35 Baking
tray
Muffins, three
levels
- - 140 -
150
1, 3 and 5 30 - 45 Baking
tray
Biscuits 140 3 140 -
150
3 30 - 35 Baking
tray
Biscuits, two
levels
- - 140 -
150
2 and 4 35 - 40 Baking
tray
Biscuits,
three levels
- - 140 -
150
1, 3 and 5 35 - 45 Baking
tray
Meringues 120 3 120 3 80 -
100
Baking
tray
Meringues,
two levels,
preheat the
empty oven
- - 120 2 and 4 80 -
100
Baking
tray
Buns, pre‐
heat the
empty oven
190 3 190 3 12 - 20 Baking
tray
Eclairs 190 3 170 3 25 - 35 Baking
tray
Eclairs, two
levels
- - 170 2 and 4 35 - 45 Baking
tray
Progress 17

CAKES
Conventional
Cooking
True Fan Cooking
(min)
(°C) (°C)
Plate tarts 180 2 170 2 45 - 70 Cake
mould, Ø
20 cm
Rich fruit
cake
160 1 150 2 110 -
120
Cake
mould, Ø
24 cm
Preheat the empty oven.
BREAD
AND PIZZA
Conventional Cook‐
ing
True Fan Cooking
(min)
(°C) (°C)
White bread, 1 -
2 pieces, 0.5 kg
each
190 1 190 1 60 - 70 -
Rye bread, pre‐
heating is not
needed
190 1 180 1 30 - 45 Bread tin
Bread rolls, 6 - 8
rolls
190 2 180 2 (2
and 4)
25 - 40 Baking
tray
Pizza 230 - 250 1 230 - 250 1 10 - 20 Enamel‐
led tray
Scones 200 3 190 3 10 - 20 Baking
tray
Preheat the empty oven.
Use the cake mould.
FLANS
Conventional Cooking True Fan Cooking
(min)
(°C) (°C)
Pasta flan, preheating is
not needed
200 2 180 2 40 - 50
18 Progress

FLANS
Conventional Cooking True Fan Cooking
(min)
(°C) (°C)
Vegetable flan, preheat‐
ing is not needed
200 2 175 2 45 - 60
Quiches 180 1 180 1 50 - 60
Lasagne 180 - 190 2 180 - 190 2 25 - 40
Cannelloni 180 - 190 2 180 - 190 2 25 - 40
Use the second shelf position.
Use the wire shelf.
MEAT
Conventional
Cooking
True Fan
Cooking
(min)
(°C) (°C)
Beef 200 190 50 - 70
Pork 180 180 90 - 120
Veal 190 175 90 - 120
English roast beef, rare 210 200 50 - 60
English roast beef, medium 210 200 60 - 70
English roast beef, well done 210 200 70 - 75
MEAT
Conventional
Cooking
True Fan Cooking
(min)
(°C) (°C)
Pork shoulder, with rind 180 2 170 2 120 - 150
Pork shin, 2 pieces 180 2 160 2 100 - 120
Leg of lamb 190 2 175 2 110 - 130
Whole chicken 220 2 200 2 70 - 85
Whole turkey 180 2 160 2 210 - 240
Whole duck 175 2 220 2 120 - 150
Progress 19

MEAT
Conventional
Cooking
True Fan Cooking
(min)
(°C) (°C)
Whole goose 175 2 160 1 150 - 200
Rabbit, cut in pieces 190 2 175 2 60 - 80
Hare, cut in pieces 190 2 175 2 150 - 200
Whole pheasant 190 2 175 2 90 - 120
Use the second shelf position.
FISH
Conventional
Cooking
True Fan Cook‐
ing
(min)
(°C) (°C)
Trout / Sea bream, 3 - 4 fish 190 175 40 - 55
Tuna / Salmon, 4 - 6 fillets 190 175 35 - 60
Grill
Preheat the empty oven.
Use the fourth shelf position.
Grill with the maximum temperature setting.
GRILL
(kg) (min)
1st side
(min)
2nd side
Fillet steaks, 4 pieces 0.8 12 - 15 12 - 14
Beef steak, 4 pieces 0.6 10 - 12 6 - 8
Sausages, 8 - 12 - 15 10 - 12
Pork chops, 4 pieces 0.6 12 - 16 12 - 14
Chicken, half, 2 1 30 - 35 25 - 30
Kebabs, 4 - 10 - 15 10 - 12
Chicken breast, 4 pieces 0.4 12 - 15 12 - 14
Burgers, 6 0.6 20 - 30 -
20 Progress
