ProLights CONFETTIGUNNER User manual

USER MANUAL
CONFETTIGUNNER
EN
ELEctRic coNfEtti ANd
StREAMER gUNNER

All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be
reproduced in any form or by any means for any commercial use.
In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the
characteristics stated in this instruction manual at any time and without prior notice.
All revisions and updates are available in the ‘manuals’ section on site www.musiclights.it
REV.001-3/15

1
coNfEttigUNNER
Packing content • CONFETTIGUNNER
• Power cable
• User manual
TABLE OF CONTENTS Safety
General instructions
Warnings and installation precautions
General information
1 Introduction
1. 1 Description
1. 2 Technical specications
1. 3 Cannons
1. 4 Operating elements and connections
2 Installation and operation
2. 1 Mounting and operation
3 Maintenance
3. 1 Maintenance and cleaning the unit
3. 2 Fuse replacement
3. 3 Troubleshooting
Warranty
2
2
3
4
4
4
6
7
11
11
11

coNfEttigUNNER
2
WARNING! Before carrying out any operations with the unit, carefully read this instruction
manual and keep it with cure for future reference. It contains important information about
the installation, usage and maintenance of the unit.
SAFETY
The CONFETTIGUNNER has been designed and constructed in such a manner that it can be used safely.
This applies to the use, the circumstances and the regulations as described in this documentation. Read-
ing this documentation and following the instructions are therefore necessary for everyone who is author-
ised to work with the CONFETTIGUNNER.
The CONFETTIGUNNER must be placed and used in surroundings that preferably:
• Have a relative humidity degree of no more than 75%.
• Are reasonably free of dust, corrosive gases and high concentrations of organic vapours.
• Are not situated in the vicinity of a source of vibration.
DISCLAIMERS
Music & Lights excludes liability for unsafe situations, accidents and damage that are the result of:
• Disregard for the warnings or regulations as set out on the CONFETTIGUNNER or in this documenta-
tion.
• Use for other purposes or under other circumstances than those set out in this documentation.
• Alterations to the CONFETTIGUNNER. This also includes the use of replacement parts other than the
original ones.
• Insucient maintenance.
• Unauthorised removal of safety caps and/or safeguards.
• Incompetent operation of the machine.
Music & Lights is not liable for any consequential loss in the event of a CONFETTIGUNNER breakdown.
General instruction
• The products referred to in this manual conform to the European Community Directives and are there-
fore marked with .
• The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.
Never make any modications on the unit not described in this instruction manual, otherwise you will
risk an electric shock.
• Connection of the power adapter must be made to a power supply system tted with ecient earth-
ing (Class I appliance according to standard EN 60598-1). It is, moreover, recommended to protect the
supply lines of the units from indirect contact and/or shorting to earth by using appropriately sized
residual current devices.
• The connection to the main network of electric distribution must be carried out by a qualied electri-
cal installer. Check that the voltage correspond to those for which the unit is designed as given on the
electrical data label.
• This unit is not for home use, only professional applications.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Do not dismantle or modify the xture.
• All work must always be carried out by qualied technical personnel. Contact the nearest sales point for
an inspection or contact the manufacturer directly.
• If the unit is to be put out of operation denitively, take it to a local recycling
plant for a disposal which is not harmful to the environment.
Warnings and installation precautions
• If this device will be operated in any way dierent to the one described in this manual, it may suer
damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like

3
coNfEttigUNNER
short circuit, burns, electric shock, etc.
• Before starting any maintenance work or cleaning the product, cut o power from the main supply.
• Always additionally secure the product with the safety rope. When carrying out any work, always com-
ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country
in which the xture’s being used.
• The operator must be told that he/she may only operate the CONFETTIGUNNER after reading the user
manual.
• Only use the CONFETTIGUNNER if there are no people, animals or other objects in the direction of the
electric cannon within the output distance. The shooting direction is the direction in which the electric
cannon in the CONFETTIGUNNER is pointed. The output distance depends on the content and length
of the electric cannons.
• Make sure that children, unauthorised people and animals do not obtain access to the CONFETTIGUNNER!
• Do not take hold of the CONFETTIGUNNER while it is working or is switched on. Also, when the
CONFETTIGUNNER is not working, the electric cannon may still be lled.
• Safety devices may not be removed or disabled.
• All required safety devices must be in good condition and function properly.
• Ensure sucient lighting of the surroundings.
• Keep the workplace clean.
• Only authorised persons may carry out work with the CONFETTIGUNNER.
GENERAL INFORMATION
Shipments and claims
The goods are sold “ex works” and always travel at the risk and danger of the distributor. Eventual dam-
age will have to be claimed to the freight forwarder. Any claim for broken packs will have to be forwarded
within 8 days from the reception of the goods.
Warranty and returns
The guarantee covers the xture in compliance with existing regulations. You can nd the full version of
the “General Guarantee Conditions” on our web site www.musiclights.it. Please remember to register the
piece of equipment soon after you purchase it, logging on www.musiclights.it. The product can be also
registered lling in and sending the form available on your guarantee certicate. For all purposes, the va-
lidity of the guarantee is endorsed solely on presentation of the guarantee certicate. Music & Lights will
verify the validity of the claim through examination of the defect in relation to proper use and the actual
validity of the guarantee. Music & Lights will eventually provide replacement or repair of the products de-
clining, however, any obligation of compensation for direct or indirect damage resulting from faultiness.

coNfEttigUNNER
4
- 1 - INTRODUCTION
1.1 DESCRIPTION
The CONFETTIGUNNER is a confetti shooting system which has been specially developed to easily shoot
electric cannons from a podium or truss. The CONFETTIGUNNER is splash proof and therefore suitable
for outdoor locations. The CONFETTIGUNNER can be used with electric confetti cannons as well as with
electric streamer cannons.
As the CONFETTIGUNNER can be used in various ways, it is important to read this user manual carefully
from beginning to end before you start operating the machine. Any use other than that described above
excludes your supplier from any liability.
1.2 TECHNICAL SPECIFICATIONS
Electric Confetti and Streamer gunner.
• Voltage: 230 V
• Power: 100 W
• Control: 230V on/o or DMX by using a Switch Pack
• Compatible: EST04, EST08, ECT04, ECT08
• Size (LxWxH): 13x12x16 cm
• Weight: 1,7 kg
1.3 CANNONS
The CONFETTIGUNNER oers the possibility to work with approved electric confetti and streamer can-
nons. The CONFETTIGUNNER is not suitable for cannons other than those described below.
Fig.1
40cm Electric cannon others confetti cannons80cm Electric cannon

5
coNfEttigUNNER
TYPE CANNON CODE CONTENT CANNON LENGTH OUTPUT
ECT04 CONFETTI 40 cm 5 m
EST04 STREAMERS 40 cm 12 m
ECT08 CONFETTI 80 cm 12 m
EST08 STREAMERS 80 cm 20 m
The following types of electric cannons are possible:
All pre-lled cannons are for one-o use only.
DANGER WARNING
Metallic products are heavier and will therefore have a larger output.
The electric cannons contain pressure containers which re o the confetti/streamers under a lot of pres-
sure. Therefore always make sure there is a free shooting range.

coNfEttigUNNER
6
Fig.2
1.4 OPERATING ELEMENTS AND CONNECTIONS
View 1 View 2
1. CANNON SCREW NUT
2. RICHT SCREW NUT
3. CANNON TUBE
4. CANNON CONNECTOR
5. POWER IN mains plug for connection to a
socket via the supplied mains cable. The
support for the mains fuse is located near the
mains plug. Only replace a blown fuse by one
of the same type.
6. POWER OUT
7. LED INDICATOR
1
6
5
47
3
2

7
coNfEttigUNNER
Place the CONFETTIGUNNER on an even, solid
and stable surface and secure it with the notch-
es made for this.
NOTE
Attach the CONFETTIGUNNER to a Base Plate for
an extra stable surface. It is possible to attach 1,
2 or 4 CONFETTIGUNNER to the Base.
If you want to use the CONFETTIGUNNER
while mounted in a truss system, then attach
2 certied truss clamps to the underside
of the CONFETTIGUNNER. Next, place the
CONFETTIGUNNER on the required place in the
truss system and rmly turn the clamp.
The mounting place must be of sucient stabil-
ity and be able to support a weight of 10 times
of the unit’s weight. When carrying out any in-
stallation, always comply scrupulously with all
the regulations (particularly regarding safety)
currently in force in the country in which the x-
ture’s being used.
IMPORTANT
Always additionally secure the projector with
the safety rope from falling down. For this pur-
pose, fasten the safety rope at a suitable posi-
tion so that the maximum fall of the projector
will be 20 cm.
- 2 - INSTALLATION AND OPERATION
2.1 MOUNTING AND OPERATION
CAUTION - The machine can be damaged if you do not follow the procedures carefully.
DANGER WARNING - The CONFETTIGUNNER may only be installed by adults and authorised persons.
Prepare the CONFETTIGUNNER for use as follows:

coNfEttigUNNER
8
Connect a power cable to provide the CONFETTIGUNNER with 230V~ 50/60Hz. You can connect several
CONFETTIGUNNER to each other by using a power loop cable.
NOTE
Only use grounded electricity sockets!
Ensure that the power cable is not connected to the power supply when it is put in the CONFETTIGUNNER.
Test the working of the CONFETTIGUNNER by connecting the power cable to the power supply. As soon
as the blue LED-light above the CONFETTIGUNNER lights up you know that the CONFETTIGUNNER is
properly connected. After testing, make sure that the power cable is no longer directly connected to
the power supply.
During testing, make sure that no electric cannons are connected to the CONFETTIGUNNER.
Place the electric cannon in the cannon holder.
NOTE
The electric cannon can detach itself through
the pressure that is released during the shooting.
Therefore always use a Cannon Clamp to secure
it to the CONFETTIGUNNER. This is especially
important when using it in a truss.
Secure the electric cannon with a screw nut
which is situated on the side of the holder.
NOTE
Never turn the screw nuts tighter than necessary.
This can damage the pressure pattern in the
electric cannon.

9
coNfEttigUNNER
Once the electric cannon has been placed
in the CONFETTIGUNNER it can be adjusted
to the correct shooting direction. Unscrew
the adjustment button on the side of the
CONFETTIGUNNER for setting the holder in the
correct direction.
ATTENTION
Never shoot in the direction of people, animals
or objects. Also consult this manual for the
shooting distance of the various cannons.
Plug in the electric cannon connector in the
right way into the connector on top of the
CONFETTIGUNNER.
This connector has a slot which insures that the
connector can be inserted in only one way.
NOTE
Before plugging in the connector check if the
blue LED is lighting up. If so the cannon will be
shot when u plug the cannon in!
The CONFETTIGUNNER can be operated by means of 230V on/o or DMX. To this end use a DMX
Switchpack.
NOTE
• Make sure that you only shoot when there are no people, animals or objects in the shooting range
of the cannon.
• Make sure that you always have the CONFETTIGUNNER within your sight.

coNfEttigUNNER
10
To switch o the CONFETTIGUNNER, take the following steps:
Make sure that the CONFETTIGUNNER is no longer connected to an electricity source.
Only then remove the power cable.
Removethecannon fromtheCONFETTIGUNNER.

11
coNfEttigUNNER
- 3 - MAINTENANCE
3.1 MAINTENANCE AND CLEANING THE UNIT
To achieve the maximum service life of the CONFETTIGUNNER you must regularly clean the
CONFETTIGUNNER and test if it is working correctly.
Should the CONFETTIGUNNER not work for some reason then please contact an authorized service center.
DANGER WARNING
Do not replace parts yourself; always consult qualied technical personnel if necessary.
3.2 FUSE REPLACEMENT
1. Disconnect this product from the power outlet.
2. Remove the safety cap by a screwdriver.
3. Replace the blown fuse with a fuse of the exact same type and
rating.
4. Install the safety cap, and reconnect power.
3.3 TROUBLESHOOTING
Fuse
Fig.3
Problems Checks and remedies
The machine does not turn on Check if the power cable is properly connected.
A cannon does not work Check if the connector of the cannon is properly connected. If so, exchange the
cannon with another and see if this one works.
Contact an authorized service center in case of technical problems or not reported in the table can not be
resolved by the procedure given in the table.

CERTIFICATO DI GARANZIA GUARANTEE CERTIFICATE
Place Stamp Here
Arancare
Spett.le
Music&Lights S.r.l.
Via Appia Km 136.200
04020 Itri (LT) Italy
"
"
"
Il prodotto è coperto da garanzia in base alle vigenti normative. Sul sito www.musiclights.it è possibile consultare il testo integrale delle “Condizioni Generali di Garanzia”.
Estratto dalle Condizioni Generali di Garanzia • Si prega, dopo l’acquisto, di
procedere alla registrazione del prodotto sul sito www.musiclights.it. In alternativa il prodotto può essere registrato compilando e inviando il modulo riportato sul retro.
• Sono esclusi i guasti causati da
imperizia e da uso non appropriato dell’apparecchio.
• La garanzia non ha più alcun eetto
qualora l’apparecchio sia stato manomesso.
• La garanzia non prevede la
sostituzione dell’apparecchio.
• Sono escluse dalla garanzia le parti
esterne, le lampade, le manopole, gli interruttori e le parti asportabili.
• Le spese di trasporto e i rischi
conseguenti sono a carico del possessore dell’apparecchio.
• A tutti gli eetti la validità della
garanzia è avallata unicamente dalla presentazione del certicato di garanzia.
The guarantee covers the unit in compliance with existing regulations. You can find the full version of the“General Guarantee Conditions” on our web site www.musiclights.it.
Abstract General Guarantee Conditions • Please remember to register the
piece of equipment soon after you purchase it, logging on www.musiclights.it. The product can be also registered lling in and sending the form available on your guarantee certicate.
• Defects caused by inexperience
and incorrect handling of the equipment are excluded.
• The guarantee will no longer be
eective if the equipment has been tampered.
• The guarantee makes no provision
for the replacement of the equipment.
• External parts, lamps, handles,
switches and removable parts are not included in the guarantee.
• Transport costs and subsequent
risks are responsibility of the owner of the equipment.
• For all purposes, the validity of
the guarantee is endorsed solely on presentation of the guarantee certicate.

MODEL / MODELLO SERIAL N° / SERIE N°
Purchased by / Acquistato da SURNAME / COGNOME Dealer’s stamp and signature Timbro e rma del Rivenditore NAME / NOME ADDRESS / VIA N. CITY / CITTA’ Purchasing date Data acquisto FORM TO BE FILLED IN AND MAILED / CEDOLA DA COMPILARE E SPEDIRE FORM TO BE FILLED IN AND KEPT / CEDOLA DA COMPILARE E CONSERVARE
PROV.
ZIP CODE / C.A.P.
MODEL / MODELLO SERIAL N° / SERIE N°
Purchased by / Acquistato da SURNAME / COGNOME Dealer’s stamp and signature Timbro e rma del Rivenditore NAME / NOME ADDRESS / VIA N. CITY / CITTà Purchasing date Data acquisto
PROV.
ZIP CODE / C.A.P.
"
"
"

©2015 Music & Lights S.r.l.PROLIGHTS è un brand di proprietà della Music & Lights S.r.l. PROLIGHTS is a brand of Music & Lights S.r.l.company.
MUSIC & LIGHTS S.r.l.
Via Appia, km 136,200 - 04020 Itri (LT) - ITALY
Phone [phone] - Fax [phone]
www.musiclights.it - email: [email protected]
ISO 9001:2008 Certied Company
