ProLite Marquee-Lite PLUS 3225 User manual

 Built‐InDataAmplifier
SIGN INSTALLATION MANUAL
Models:3225,4225

INTRODUCTION
CONGRATULATIONS
The Marquee-Lite™ PLUS is the finest retrofit messaging center available on the market
today. It is available in two sizes, a 6 foot (ML3225) or 8 foot (ML4225) unit. The Marquee-
Lite™Plus (ML+) is designed for ease of use, ease of installation, and years of trouble free
service.
These displays are designed to fit in either an 8 or 6 foot cabinet. In some cases you may
install the unit(s) in a larger cabinet, but suitable filler panels will need to be fabricated. Your
ML+ is designed to slide into a standard cabinet, with a 2” flange or less. The finish size is
71.875” and 95.875” respectively. This gives plenty of room to fit in the appropriate
cabinet. If your display does not take up the whole cabinet space, a divider bar and filler
panel must be fabricated. This is usually a sign face made of polycarbonate, and is included
with most retrofit kits. Please contact your local sign fabricator if you do not have this
solution.
OVERHEATING DANGER:
T
he cabinet MUST be equipped with a proper
ventilation system. Without proper ventilation, the sign will overheat,
cause condensation on the components and/or plexi or cause other
damage. This damage will not be covered under the warranty.
The ML+ sign can already dissipate heat from its own casing, but not the
cabinet enclosure that will hold the sign. Vents on the sides toward the top
end of the cabinet enclosure should be installed to allow air to escape.
Make sure proper vent installation techniques are followed to prevent
water from entering through the vents.
READING INSTRUCTIONS
 Retain manual for future reference.
 Follow all warnings and instructions indicated in this manual including those marked
on the product.
BEFORE INSTALLATION
 Do not allow AC power to be connected inadvertently during installation.
BEFORE OPERATION
 Confirm all connections are correct and secure by reviewing manual before power up.
DURING OPERATION
 Do not make modifications while sign is in operation.
MAINTENANCE
 Do not open, modify or disassemble any part of the unit. This will void warranty and
may result in electrical shock and serious injury.
 To maintain warranty, the unit must be installed in a cabinet that protects the back of
the unit from water. Your unit is not designed to repel running water from the back.
Exposure to running water on the back will void the warranty.

TABLE OF CONTENTS
PACKING LIST ………………..……………………………………………………………………………………….. 1
SIGN CONFIGURATION – MASTER ONLY …………………………………………………………………… 2
SIGN CONFIGURATION – MASTER/SLAVE ………………………………………………………………….3
SIGN INSTALLATION & AC POWER CONNECTIONS ………………………………………………………4
TEMPERATURE SENSOR INSTALLATION ………..…………………………………………………………..5 - 6
CUSTOMER SERVICE - WARRANTY …………………………………………………………………………….7

PACKING LIST
SIGN
Remote Temperature Sensor Case
Remote and Installation Manual Data Cable (1 per sign)
Page 1

SIGN CONFIGURATION – MASTER ONLY
The ML+ is designed to operate as an independent unit (MASTER ONLY), or operate two
ML+ units (MASTER/ SLAVE) controlled by a single remote control. Follow the instructions in
this section to operate the ML+ as a MASTER ONLY configuration.
1) Locate the MASTER INPUT and OUTPUT1 ports on the back, left side of the ML+
2) Using the supplied Data Cable, connect as shown below.
3) Secure the connections by tightening the fasteners or screws.
Go to SIGN INSTALLATION section for completion
OR
Continue to next section for MASTER/SLAVE Configuration.
MASTER ML+ (Backside)
Page 2

SIGN CONFIGURATION – MASTER/SLAVE
Follow the instructions in this section to operate two ML+ units as a MASTER/SLAVE
configuration.
NOTE : Any ML+ unit can be configured as MASTER or SLAVE. It is important to
note that the MASTER will always be the primary signal carrier.
1) Configure one ML+ as a MASTER ONLY configuration. Refer to previous section.
2) Now connect the remaining Data Cable as shown below.
NOTE : For ease of installation into a cabinet, Data Cable #2 should be made once
partially installed into its final position in the cabinet.
4) Secure all connections by tightening the fasteners or screws.
5) MASTER/SLAVE Configuration complete!
NOTE : Remaining ports on the SLAVE ML+ unit are not used in a MASTER/SLAVE
configuration.
MASTER ML+
SLAVE ML+
Page 3
Data Cable #1
Data Cable #2

SIGN INSTALLATION & AC POWER CONNECTIONS
SIGN INSTALLATION
1) Slide the unit(s) into your cabinet.
2) Confirm that all Data Cable connections are secure.
3) Finish securing the unit(s) to the cabinet with two self tapping screws (not included),
through the flange.
NOTE : It is recommended that the two self tapping screws are secured on each end
behind the cabinet face retainer, into the narrow extrusion, to hide the screws.
This will eliminate vibration and secure the unit from sliding back and forth, if
the cabinet is slightly larger than the display.
POWER CONNECTIONS
The ML+ boasts ultra efficient power consumption, using less than 3 amps per unit. The
ML+ requires a 110V AC power source to operate.
1) Connect the outlet plug (included) to a 110VAC wall outlet or splice the plug and hard wire
directly to a 110VAC power source using wire nuts (not included).
NOTE : In many cases, existing power can be used, but it is suggested to find the
cleanest AC power source available. It is also recommended that a licensed
electrician perform any wiring modifications needed for custom applications.
Always follow local laws and ordinances.
AC Power Plug
Page 4

TEMPERATURE SENSOR INSTALLATION
Some of the ML+ come equipped with a temperature sensor option that will allow the ML+
to read and display the temperature.
The sensor will be attached next to the power supply on the backside of the ML+.
NOTE : In a MASTER/SLAVE Configuration, the temperature sensor on the MASTER
ML+ will be the only temperature sensor that is required to be installed. The
temperature sensor on the SLAVE ML+ can be tied and tucked away.
INSTALLATION
1) Drill a hole under the cabinet and feed the temperature line through.
2) Feed the temperature line into the temperature sensor case so that it is floating in
the center and lock the line in place.
MASTER ML+ (Backside)
Temp Sensor Case (top view)
Temp Sensor
Locking Nut
Page 5

TEMPERATURE SENSOR INSTALLATION (continued)
3) Mount the temperature sensor on the bottom of the cabinet and tuck the excess line
back up into the cabinet.
NOTE: It is recommended the hole under the cabinet for the temperature line be
sealed with a sealing product such as silicone.
4) Temperature Installation completed!
NOTE: It is recommended the temperature sensor case be used for optimal
temperature reading accuracy. If using the temperature sensor case does not
work for the application, a hole can simply be drilled at the bottom of the
cabinet to allow the sensor to protrude 2” – 3” out. This will protect the sensor
from the sun while allowing a good air stream to read from.
Your ML+ is now ready for operation.
Please refer to the REMOTE KEYBOARD USERS MANUAL
for operation instructions.
Page 6

CUSTOMER SERVICE
TECHNICAL SUPPORT
Available 7:30 am – 4:30pm PST
Phone [phone]
Email: [email protected]
Web: www.pro-lite.com
LIMITED WARRANTY
PRO-LITE INC. Warranty to the original consumer that each of its PRO-LITE products and all components therein contained will be free from defects
in materials and/or workmanship for three years from the date of purchase except those items specified herein under. Any warranty hereunder is
extended only to the original consumer purchaser and is not assignable.
Length of Warranty and Coverage
Warranty period will be determined from the date of purchase as indicated by the date on Pro-Lite invoice and will be covered as follows:
LED Lamps: 3 Years
LED Drivers: 3 Years
LED CPU Board: 3 Years
Wireless Receiver: 3 Years
Power Supply: 3 Years (optimal)
Remote Control: 1 Year
Warranty Conditions
In the event of malfunction or other indication of failure attributable directly to faulty workmanship and/ or material, PRO-LITE INC. will at its option,
repair or replace said products or components to whatever extent it shall deem necessary to restore said product to proper operating condition,
provided the original purchaser can provide an original dated receipt of purchase. During the three years after the date of purchase or specifically
specified above, all in house labor and materials will be provided without charge. There shall be no warranty for either parts or labor after the
expiration of the three years from the date of purchase. PRO-LITE INC. does not warranty remote control, bulbs in combivision of fluorescent board
products.
Units must be returned postage prepaid. It is recommended that the unit be insured when shipped. Units returned for which a Warranty Registration
Card has not been submitted or out-of-warranty units returned will be repaired or replaced (at the option of PRO-LITE INC.) and the customer will be
charged for parts and labor.
The customer shall be solely responsible for failure of any PRO-LITE INC. product or component thereof, resulting from accident, abuser
misapplication of the product, and PRO-LITE INC. assume no liability as a consequence of such events under the terms of the Warranty.
Incidental and consequential damages caused by malfunctions, defect, or otherwise and with respect to breach of any express or implied warranty,
are not the responsibility of PRO-LITE INC. and to the extent permitted by law are hereby excluded both for property and, to the extent, of
unconscionable, for personal injury damage. (Some states do not allow the exclusion or limitations of incidental or consequential damages, so the
above may not apply to you.)
State Law Exceptions
This Warranty gives you specific legal rights and you also have other rights that vary from state to state.
This Warranty is in lieu of all other express warranties which now or hereafter might otherwise arise with respect to this product. ANY AND ALL
IMPLIED WARRANTY OF MERCHANTIBILITY AND FITNESS FOR PARTICULAR USE SHALL HAVE NO GREATER DURATION THAN THE PERIOD THE
EXPRESS WRITTEN WARRRANTY APPLICABLE TO THIS PRODUCT AS SHOWN ABOVE ND SHALL TERMINATE AUTOMATICALLY AT THE EXPIRATION OF
SUCH PERIOD. No action shall be brought for breach of any implied or express warranty after one year subsequent to the expiration of the period of
the express written warranty. (Some states do not allow limitations of how long an implied warranty lasts, so this limitation may not apply to you.)
Returned Goods Authorizations (RMA)
Before returning a product for repair, the customer must call PRO-LITE INC. Customer Service at [phone] for a Return Materials
Authorization Number. This number should be included with the customer’s mailing address and telephone number when the product is returned.
Products should be returned to: PRO-LITE INC., Attention Warranty/Repair, 3505 Cadillac Ave. Bldg D, Costa Mesa, CA 92626 (postage prepaid).
After receiving the RMA, the user shall promptly return the product at the user’s expense to Pro-Lite Co., Inc. after receiving instructions as to when
and where to ship product. Failure to follow this procedure shall void this warranty. Should the number of pieces received by Pro-Lite differ from the
RMA either +/-, the customer will be notified and adjustments will be made at that time. Pro-Lite Co. Inc. reserves the right to examine all failed
products and reserves the right to be the sole judge as to whether any products are defective and covered under this warranty.
Freight Cost
Products will be returned to customer after repair or replacement at Pro-Lite’s expense if the product is purchased within 30 days and Products will
be returned to customer at customer’s expense after 30 days from the date of purchase. In the event Pro-Lite would pay for the freight, it is Pro-
Lite’s option to choose the carrier and method to any destination within the United States of America. Should the customer desire some other
specific form of conveyance, or be located outside the border of the U.S. then the customer must bear the cost of return shipment.
