CONGRATULATIONS
The Marquee-Lite™PLUS is the finest retrofit messaging center available on the market
today. The Marquee-Lite™Plus (ML+) is designed for ease of use, ease of installation, and
years of trouble free service.
CABINET INSTALLATION
These displays are designed to fit into an 8 foot cabinet. In some cases you may install the
unit(s) in a larger cabinet, but suitable filler panels will need to be fabricated. Your ML+ is
designed to slide into a standard cabinet, with a 2” flange or less. If the ML+ does not take
up the whole cabinet space, a divider bar and filler panel must be fabricated. This is usually
a sign face made of polycarbonate, and is included with most retrofit kits. Please contact
your local sign fabricator if you do not have this solution.
OVERHEATING/CONDENSTATION WARNING
Vents for retrofits is a MUST! Water-proof vents must be installed on the sides of the cabinet
toward the top end. The ML+ can already dissipate heat from its own casing via the built-in
fans, but the cabinet enclosure must allow for that heat to escape as needed.
Vents installation also prevent condensation build-up on the plexi. If the air is cold outside
while the air is warm inside, this will cause the plexi to fog up. The vents help by allowing
fresh air to be circulated. Sign damage from overheating or condensation is not covered
under the warranty.
ELECTRICAL DANGER
Do not allow AC power to be connected inadvertently during installation. Make sure all
connections are correct and secure by reviewing the installation manual before turning ON
the AC power. Do not make modifications while sign is in operation.
BEFORE INSTALLATION
Make sure all the content in this manual is read and understood.
Follow all warnings and instructions indicated in this manual including those marked
on the product.
Make sure installation meets all local and state codes.
Installer will assume all responsibility for installation and structural integrity.
MAINTAINING PRODUCT WARRANTY
Do not open, modify or disassemble any part of the unit. This will void warranty and
may result in electrical shock and/or serious injury.
Water-proof vents must be installed for retrofits.
Retrofits must prevent water from entering the cabinet during wet weather.
Retain manual for future reference.

3
PACKING LIST …………………………………………………………………………………………………… 4 - 5
SIGN CONFIGURATION ………………………………………………………………………………………. 6 - 7
SIGN COMMUNICATION OPTIONS ………………………………………………………………………. 8
SIGN COMMUNICATION …………………………………………………………………………………….. 9 - 12
TEMPERATURE SENSOR INSTALLATION …………………………………………………………….. 13
AC POWER CONNECTION ………………………………………………………………………………….. 14
CUSTOMER SERVICE ………………………………………………………………………………………… 15

4
SIGN
Data Cable (1 per sign)
Temperature Sensor Case
Installation Manual / Software Manual
Wireless Transmitter Kit
REFER TO NEXT PAGE

5
There are 4 types of wireless kits.
350ft Range:
• Version-A: VW320A
• Version-B: VW320B
1000ft Range:
• Version-A: VW321A
• Version-B: VW321B
The kit received will vary based on requested application or release version of product.
Although the kits vary, there are no additional accessories required for the specific kit you received to achieve
functionality. Make sure and note the type received by checking the label on the transceiver.
350 FT. RANGE
TYPE A –VW320A
TYPE B –VW320B
1000 FT. RANGE
TYPE A –VW321A
TYPE B –VW321B
- Wireless USB Transceiver (Computer Side) x 1
- Wireless COM Transceiver (Sign Side) x 1
- USB Cable x 1
- Antenna x 2
- Antenna Mounts x 2
- Power Supply x 1
- Power cable for COM Transceiver x1
- Wireless USB Transceiver (Computer Side) x 1
- Wireless COM Transceiver (Sign Side) x 1
- USB Cable x 1
- Antenna x 2
- Antenna Mounts x 2
- Power cable for COM Transceiver x1
- Wireless USB Transceiver (Computer Side) x 1
- Wireless COM Transceiver (Sign Side) x 1
- USB Cable x 1
- Antenna x 2
- Antenna Mounts x 2
- Power cable for COM Transceiver x1
- Wireless USB Transceiver (Computer Side) x 1
- Wireless COM Transceiver (Sign Side) x 1
- USB Cable x 1
- Antenna x 2
- Antenna Mounts x 2
- Power Supply x 1
- Power cable for COM Transceiver x1

6
The ML+ is designed to operate as a single-sided unit (MASTER ONLY), or as a paired unit in
a double-sided installation (MASTER/ SLAVE).
Whether single-sided or double-sided, one unit will have to be configured as a MASTER.
1) Locate the MASTER INPUT and OUTPUT1 ports on the back, left side of the sign.
2) Using the supplied Data Cable, connect as shown below.
3) Secure the connections by tightening the fasteners or screws.
For Single-Sided installations, proceed to the SIGN COMMUNICATION section.
For DOUBLE-SIDED CONFIGURATIONS, continue on to the next page.
MASTER ML+ (Backside)

7
Now that you have an ML+ configured as a MASTER, let’s make a paired connection for a
double-sided installation.
Any ML+ unit can be configured as MASTER or a SLAVE. It is important to note that the MASTER
will always be the primary signal carrier.
1) Now connect the remaining Data Cable as shown below.
2) Secure all connections by tightening the fasteners or screws.
Remaining ports on the SLAVE unit are not used.
MASTER ML+
SLAVE ML+
Data Cable #1
Data Cable #2

8
There are 2 options readily available to upload messages to the sign. Available options
require use of the Marquee-Lite software.
Create your message, export to USB Drive, then manually connect the USB Drive to the sign and
the sign will be instantly updated.
During installation, make sure the USB Cable is available to the user for access.
Do not leave USB connection exposed to weather environments. Recommended that a secured
access panel be installed for access.
Refer to Software Manual for exporting message to USB Flash Drive.
ML+ (Backside)
RS232 Cable connection for
Wireless communication.
USB Cable connection for
USB Flash Drive.

9
Easily update the sign without leaving your desk!
OVERVIEW
Line-of-site communication
The antenna of the Wireless Transceivers must be in line-of-site with one another for optimal
reception.
Installation Notes
TRANSCEIVER
Do not mount where it will be exposed to weather elements. The transceiver is not weatherproof.
ANTENNA
Antennas from both transceivers must be in line-of-site with one another for optimal reception. It
is ok to expose the ANTENNA portion to weather elements as long as it is upright at all times.
Type BTransceivers
Make sure the DIP Switch settings match for both Type B transceivers working as a pair. Type A
transceivers do not have DIP Switch settings.
Recommended for
optimal wireless
communication.
Wireless communication
will not work.

10
COMPUTER SIDE SETUP
1) Copy and paste the link below to your web browser to securely download the transceiver
driver for the computer:
http://03be17e.netsolhost.com/DOWNLOADS/DRIVERS/CP210x_VCP_Win_XP_S2K3_Vista_7.zip
Wireless driver also supports Windows 8 and 10.
2) Open the folder where the downloaded file has been saved to. The file name will be
CP210x_VCP_Win_XP_S2K3_Vista_7.ZIP.
3) Decompress the file by right-clicking and selecting Extract All.
4) Specify where you would like the files to be extracted and proceed to decompress.
5) When completed, a folder will have been created containing the necessary driver file. Open
the folder and double-click the file, CP210x_VCP_Win_XP_S2K3_Vista_7.EXE, to launch the
installation wizard.
During installation, leave all settings at default and follow the prompts to complete the
installation. Do not proceed to next step until the driver installation has completed.
6) REQUIRED: Reboot your computer.
7) Wireless USB Transceiver connections:
(a) Connect the antenna.
(b) On VW321model (shown below), connect the power adaptor to the power port on the
transceiver and the opposite end to an AC source.
No power adaptor necessary for any VW320models.
(c) Connect the squared side of the USB cable to the USB port on the transceiver.
(d) Connect the opposite end of the USB cable to any available USB port on the computer.
Additionally, on VW321 models, the
power adaptor may match the one
shown below. Please note that the
USB cable for the power adaptor is not
meant for use with a computer USB
port.

11
8) Go to the Device Manager in your Control Panel.
9) Locate “Ports (COM and LPT)” and expand the tree to view the subcategories.
10)Write down the COM PORT number for the transceiver: _______________________
If the Wireless USB Transceiver is connected to a different USB port than the last time, the
COM PORT number will change.
11) Install the antenna mount in a location where the antenna will not be disturbed. Once the
antenna mount is secure, simply slide the antenna base through the fitting.

12
Sign Side Setup
Make the following connections to the Wireless COM Transceiver:
(a) Connect the antenna.
(b) Connect the power jack end of the power cable to the power port on the transceiver.
(c) Now connect the red wire to V+ and the black wire to V- on the sign’s DC power supply.
(d) On Type Atransceiver models, connect the transceiver’s 9 pin connector to the sign’s 9 pin
connector.
On Type Btransceiver models, connect the sign’s 9 pin connector directly to the 9 pin port of
the transceiver.
On the back of the sign there is a serial
cable with a 9 Pin Connector.

13
The temperature sensor is located besides the USB and COM cables.
In a MASTER/SLAVE Configuration, the temperature sensor on the MASTER unit will be the only
temperature sensor that is required to be installed. The temperature sensor on the SLAVE unit
can be tucked away.
1) Install the temperature sensor cage so that it sits below the unit(s).
In a retrofit, the case must reside outside the cabinet below the units. This will require for a hole
to be drilled on the bottom of the cabinet so that the temperature sensor cable can be passed
through. Complete the pass-through by sealing the hole with silicone.
2) Remove the screw from the temperature sensor.
3) Feed the temperature sensor into the temperature case.
4) The temperature sensor will be suspended in the center of the cage by securing it in place
with the screw.
MASTER ML+ (Backside)
Temperature Sensor.

14
Review all previous connections to make sure they are correct and secure before applying power.
Connect the outlet plug (included) to a 110VAC wall outlet or splice the plug and hard wire
directly to a 110VAC power source using wire nuts (not included).
Your Sign is now ready for operation.
Please refer to the
MARQUEE-LITE SOFTWARE MANUAL
for communicating messages to the sign.
AC Power Plug.

15
TECHNICAL SUPPORT (available 24/7)
http://www.pro-lite.com/support
PARTS ONLY - LIMITED WARRANTY
PRO-LITE INC. Warranty to the original consumer that each of its PRO-LITE products and all components therein contained will be free from for five
years from the date of purchase except those items specified herein under. Any warranty hereunder is extended only to the original consumer
purchaser and is not assignable.
Length of Warranty and Coverage
Warranty period will be determined from the date of purchase as indicated by the date on Pro-Lite invoice and will be covered as follows:
LED Lamps: 5 Years
LED Drivers: 5 Years
LED CPU Board: 5 Years
Wireless Receiver: 5 Years
Power Supply: 5 Years (optimal)
Warranty Conditions
In the event of malfunction or other indication of failure attributable directly to a faulty part, PRO-LITE INC. will at its option, repair or replace said
part to whatever extent it shall deem necessary to restore said part to proper operating condition, provided the original purchaser can provide an
original dated receipt of purchase. During the five years after the date of purchase or specifically specified above, all in house labor and materials
will be provided without charge. There shall be no warranty after the expiration of the five years from the date of purchase. All repairs are only
performed in Pro-Lite at 3505D Cadillac Ave. Costa Mesa, CA 92626.
If Pro-Lite decides to replace a part instead of repairing a part, it is Pro-Lite's option to determine if Pro-Lite wants the defective part sent back to
Pro-Lite or dispose the part without sending back to Pro-Lite. If Pro-Lite decides not to have the defective part sent back to Pro-Lite, Pro-Lite will send
the replacement part to the customer and the customer is responsible for the freight.
Units returned for which a Warranty Registration Card has not been submitted or out-of-warranty units returned will be repaired or replaced (at the
option of PRO-LITE INC.) and the customer will be charged for parts and labor.
The customer shall be solely responsible for failure of any PRO-LITE INC. product or component thereof, resulting from accident, abuser
misapplication of the product, and PRO-LITE INC. assume no liability as a consequence of such events under the terms of the Warranty.
Incidental and consequential damages caused by malfunctions, defect, or otherwise and with respect to breach of any express or implied warranty,
are not the responsibility of PRO-LITE INC. and to the extent permitted by law are hereby excluded both for property and, to the extent, of
unconscionable, for personal injury damage. (Some states do not allow the exclusion or limitations of incidental or consequential damages, so the
above may not apply to you.)
The Pro-Lite Customer Service phone number is 800-223-9223.
Returned Goods Authorizations (RMA)
Before returning a product for repair, the customer must call PRO-LITE INC. Customer Service at [phone] for a Return Materials
Authorization Number. This number should be included with the customer’s mailing address
and telephone number when the product is returned. Products should be returned to: PRO-LITE INC., Attention Warranty/Repair, 3505 Cadillac Ave.
Bldg D, Costa Mesa, CA 92626 (postage prepaid). After receiving the RMA, the user shall promptly return the product at the user’s expense to Pro-
Lite, Inc. after receiving instructions as to when and where to ship product. Failure to follow this procedure shall void this warranty. Should the
number of pieces received by Pro-Lite differ from the RMA either +/-, the customer will be notified and adjustments will be made at that time. Pro-
Lite Inc. reserves the right to examine all failed products and reserves the right to be the sole judge as to whether any products are defective and
covered under this warranty.
Freight Cost
Products will be returned to customer after repair or replacement at Pro-Lite’s expense. It is Pro-Lite’s option to choose the carrier and method to
any destination within the United States of America. Should the customer desire some other specific form of conveyance, or be located outside the
border of the U.S. then the customer must bear the cost of return shipment.
