Promag TR510 User manual

TR510 EXPRESS Time Recorder
V1.5-0

Attention! Firmware Management mode (FMM)
The TR510 has two different modes of operation. Normal mode provides
regular device functionality. Firmware Management mode (FMM) is provided for
internal firmware checkup and upgrades (see Section 5).
The Normal mode is entered by powering the TR510 up while not pressing
the IN button. Switching the TR510 on while holding the IN button or both IN and
OUT buttons down forces the unit into the FMM. The FMM mode of operation
cannot be exited other than by switching the TR510 off and back on again.
Contents
Attention! Firmware Management mode (FMM) ..................................................2
Contents...............................................................................................................2
1. Installing the TR510.........................................................................................3
2. Using the TR510..............................................................................................8
3. Communications protocol ..............................................................................10
4. Registers........................................................................................................27
5. Firmware Management mode........................................................................40
6. Test mode......................................................................................................43
Appendix A. Possible Errors ..............................................................................45
Appendix B. Interface connector pin assignment...............................................45
Appendix C. Specifications................................................................................46
Appendix D. Ordering Information......................................................................46

1. Installing the TR510
DC Jack Comm. Port Magnetic/ barcode
head on this side
IN button & LED
OUT button & LED
Wall-mount and desktop operation
The TR510 can be used either as a wall-mount (default, see Figure above)
or desktop device. Machine needs to be rotated 180 degrees when used on a
desk. For this reason, the TR510 comes with two different LED plates (with their
artworks rotated 180 degrees with respect to each other). Machine’s LED can
also display time and other data in a “normal” (wall-mount), or desktop fashion.
There is an orientation setting provided that allows you to select display mode
(see Section 4).
PC interface
The TR510 supports two different interfaces: RS232 for single-terminal
communications, and RS485 for multi-terminal communications. Only one
TR510 can be attached to the PC’s serial port using the RS232 interface. Up to
32 units can be interconnected using the multi-terminal RS485
communications.`
RS232 arrangement is simple: just plug the RS232 cable (supplied) into the
TR510 and connect the other side to the PC’s serial port.
Using RS485 requires a special adaptor- CON485 (must be purchased
separately). CON485 is a “smart” RS232ÆRS485 converter that allows for
higher data transfer rates between the PC and TR510s.
3

TR510 User’s Manual
The RS485 network is of “bus” type- all TR510s are connected in parallel on
a so-called twisted pair bus. The most suitable cable for the bus is the one
normally used for Ethernet communications (twisted pair Cat. III or V). You only
need to use one twisted pair of wires inside the cable.
Note: depending on the cable type, up to 4 twisted pairs may be available, it
doesn’t matter which one you use, just make sure that you are using both wires
of the same wire pair.
To connect the TR510 to the twisted pair bus, cut the RS232 cable supplied
with each TR510 and locate 2 wires inside: Orange and Green. Attach each wire
to one of the wires on the twisted pair bus. Mind the polarity! Orange and Green
wires cannot be switched. It is recommended that you keep the length of each
“bus stem” (i.e. the cable that is used to attach a certain TR510 to the bus) as
short as possible, ideally under 10 cm (see the drawing below).
120
<10cm
485-
Orange
CON485
485- Orange
#4
#3
485+
Green
485+ Green
One side of the bus must be attached to the CON485: Orange connects to
pin #3, Green connects to pin #4.
Another side of the twisted pair bus must be properly terminated. This is
especially important for long buses. Standard termination resistor value is 120
Ohm.
Before testing the network, make sure that all Terminals and the CON485
are powered and that the CON485’s baudrate selector is in the 19200 position
(selector must be set prior to powering the CON485 up).
TR510’s interface connector pin assignment can be found in Appendix B.
Understanding machine numbers
For single-terminal RS232 communications, you needn’t specify your
TR510’s machine number.
For multi-terminal RS485 communications you must make sure that all
Terminals on the network have unique machines numbers. Machine number is a
4

TR510 User’s Manual
network address that uniquely identifies the Terminal on the network. Having
two different Terminals on the network set up to the same machine number will
result in the inability to communicate with both Terminals.
Machine number can be in the 0 to 255 range (00-FF Hex). 0 is a universal
machine number- any Terminal responds to it regardless of this Terminal’s
actual machine number setting. Machine number of 0 can be used for RS232
communications- you only have a single Terminal in this case, so you can
address it with the universal number.
For multi-terminal RS485 communications, you’ll need to assign a unique
(and non-zero!) machine number to each Terminal on the network.
Assigning machine numbers
The TR510 offers a fast and convenient way of assigning machine numbers
in the range from 0 to 10. To assign a new machine number:
• Power the Terminal down (unplug the power cord)
• Press and hold the OUT button
• Power the Terminal up while continuing to hold down the OUT button
• After 2-3 seconds, the Terminal will beep and display its current
machine number, for example:
• While still keeping the OUT button pressed, push the IN button
(several times if necessary) to change the machine number to the
desired value
• When the desired machine number is displayed, release the OUT
button- the Terminal will resume normal operation
This method allows you to set the numbers in the 0-10 range only (which
would actually cover most of the actual installation requirements). If you need to
set the machine number to, say, 25, then you will have to follow this procedure:
• Connect the TR510 to the PC using the RS232 cable
• Launch the TR510 Control Center software and select the Terminal #0
(i.e. use the universal machine number to address the Terminal)
• Use the “Set M#” button to set the new machine number for this
Terminal
• Unplug the RS232 cable and put the Terminal back on the RS485
network.
5

TR510 User’s Manual
Note: machine number is displayed briefly at the Terminal power-up (even if
you don’t push the OUT button).
Bell relay
The TR510 features a built-in bell relay. The relay is capable of controlling a
low-power external bell. There are two modes for bell schedule, one is Everyday
mode another is Week mode. Only one table in Everyday mode, a daily bell
schedule of up to 32 different bell times can be defined in Everyday mode.
Seven bell schedule tables can be defined from Sunday to Saturday in Week
mode, and each table also has up to 32 different bell times can be defined.
N.C.
N.O.
C
Relay connector is located under the metal back plate. Figure above shows
connector position and pin assignment. Both Normally Closed (N.C.) and
Normally Opened (N.O.) contacts are provided.
Locking event selection (IN or OUT)
By default, the TR510 allows the User to choose the desired event (IN or
OUT) prior to reading the ID-card. There is a setting provided that allows event
selection to be fixed either at IN or OUT (see Section 4). This arrangement may
be desirable in case several TR510s are used, with some machines installed at
the entrance and serving for registering IN events, and some machines installed
at the exit and serving for OUT registration only. Fixing the event prevents the
User from choosing an alternative event at the moment of reading ID-card.
There is another setting provided that allows event selection automatically to
be set either at IN or OUT depends on a pre-scheduled event table. The pre-
scheduled event table features up to 32 entries. There are two fields of each
6

TR510 User’s Manual
pre-scheduled event table entry: ‘time’ field and corresponding event mode
‘IN/OUT’ field. When time up to the scheduled time, the TR510 will automatically
switch event selection at IN or OUT by your setting in pre-scheduled event table.
7

2. Using the TR510
Clocking in and out
To register an event (IN or OUT), push the appropriate button and read your
ID-card. For the TR510R (RFID version), the card is read by bringing it close to
the reader (< 8 cm). For the TR510M, TR510B, and TR510F (Magnetic, Visible
Barcode and IR Barcode respectively), the card is read by swiping it in either
direction along the reader slot. For the machine orientation shown on figure of
page 3, magnetic (barcode) stripe of the ID-card must face downwards.
Note 1: the TR510 can be programmed to fix event selection to IN or OUT
only- in this case event selection won’t work!
Note 2: for automatically activation at IN or OUT event, the TR510 provides a
pre-scheduled event table for user to arrange time and event for activation IN or
OUT in a scheduled time; in this mode, user can directly register ID-card in a
scheduled event, or register an event by manually push the appropriate button;
in this way, TR510 will go back to scheduled event (IN or OUT) when finish the
card reading. If user does not has his ID-card to be read after press a button,
TR510 will automatically go back to scheduled event after 5 seconds Time-out.
The last four digits of the ID-cards ID-code are displayed on the LED when
the ID-card is read. “Err” is displayed and meanwhile beeps three times in case
of read error:
Memory full status
When the database memory is full, new records cannot be added. Reading
an ID-card will produce a long beep and a “FULL” message:
Error conditions
The TR510 can detect and notify you of a number of different error conditions.
Please refer to Appendix A for complete list of all possible errors.
Normal operation of the TR510 is suspended upon encountering an error
condition other than “card read error”. New records cannot be added to the
8

TR510 User’s Manual
database in this situation. Communications with the TR510 from the PC side is
still possible, however. This gives you an opportunity to access the TR510
online and attempt to correct the problem.
9

TR510 User’s Manual
3. Communications protocol
The TR510 communications protocol is based on the GNET protocol
specification. Communications parameters are 19200-8-N-1.
Communications between the TR510 and the PC takes place in the form of
commands sent by the PC and replies from the TR510. Commands and replies
are packets of data. Each packet begins with an STX (02H) character and ends
with CR (0DH) character. Selected commands and replies include a checksum
field as an additional safety measure. All characters between the STX and the
CR characters must be in the 20H...7FH range.
The STX character of a command packet is followed by a one-character
command code. The STX character of a reply packet is followed by a one-
character reply code. Both command and reply packets may contain some
relevant data after the command (reply) character:
STX C1 C2 CR
02H Cmd/Rpl
code Data (if any) Checksum* 0DH
*Checksum field is not included into certain commands and replies
All available commands are described later in this Section. Of reply codes,
only two are possible: ‘A’ (completed successfully) and ‘N’ (some error was
encountered). Depending on the command given to the TR510, reply packets
with reply code ‘A’ may contain some data (as shown on the Figure above).
Reply packets with the reply code ‘N’ always contain a 2-digit error code that can
be used to analyze the source of a problem.
The checksum is an 8-bit sum of all characters between the STX and CR,
represented as a 2-character HEX string. For an example packet below, the
checksum is calculated as follows. The data part of the packet is “A1XYZ”. The
sum of these character codes is: 41H+31H+58H+59H+5AH=17DH. Eight least
significant bits contain 7DH. The string representation of this value is “7D” (i.e. 2
ASCII characters- ‘7’ and ‘D’).
STX A 1 X Y Z 7 D CR
02H 41H 31H 58H 59H 5AH 37H 44H 0DH
Packet portion the checksum is calculated on Checksum
10

TR510 User’s Manual
Table below lists all possible error codes:
04 Illegal (invalid) command (command code or data is wrong)
06 Record number is out of range (requested record doesn’t exist)
07 Command failed (hardware problem or invalid internal data)
08 Log (data) memory is full (this message reply in Extended mode)
09 Access has been denied (terminal is not in Extended mode)
Summarized below are all supported commands. Command characters are
found in the “CC” column, their corresponding ASCII codes- in “Hex”. “CS” lists
commands that require the checksum in the command packet (“C”) or reply
packet (“R”). “Error code” column lists errors that may result from each
command execution:
CS Errors
C.
C. Hex Description CR467
‘D’ 44H Select designated terminal Note 1
‘I’ 49H Set new machine number ++
‘Y’ 59H Get machine number +
‘S’ 53H Set date/time ++
‘T’ 54H Get date/time +
‘V’ 56H Get firmware version
‘R’ 52H Initialize the terminal
‘C’ 43H Set group-1 registers (see group-1 table) ++
‘B’ 42H Get group-1 registers (see group-1 table) ++ +
‘N’ 4EH Get number of records ++
‘G’ 47H Get specified record ++++
‘E’ 45H Initialize the database
‘M’ 4DH Prepare for database recovery
‘P’ 50H Set group-2 registers (see group-2 table) ++
‘Q’ 51H Get group-2 registers (see group-2 table) ++ +
‘J’ 4AH Set group-3 registers (see group-3 table) ++
‘K’ 4BH Get group-3 registers (see group-3 table) ++ +
‘Z’ 5AH Perform self-test** Note 2
Note 1. D-command never returns error message even if the data supplied in the
command packet is incorrect. Invalid command packet makes it impossible to determine
11

TR510 User’s Manual
which terminal is being addressed and, therefore, which one should reply with an error
code.
Note 2. Self-test takes place on the next power-up, not immediately.
The TR510 have 3 group registers. Group-1 is for accessing registers for
“LED mode”, “bell duration”, “32 entries of bell table times field (Everyday
mode)”, “32 entries of bell table enable/disable field (Everyday mode)”, “event
lock mode”, “Relay function”, “event table times field (32 entries)”, “event table
enable/disable field (32 entries)”, and “bell table mode (Everyday or Week)”,
“Daylight Saving Time”, “Enable/Disable Daylight Saving Time function”, “Door
lock duration”, “Prefix to match”, “From Character”, “Number of characters”.
Group-2 is for accessing registers of “7x32 entries for bell table times field
(Week mode, from Sunday to Saturday)”. Group-3 is for accessing registers of
“7x32 entries of bell table enable/disable field (Week mode, from Sunday to
Saturday)”.
Extended command-set (for Real-time access function):
Summarized below are all supported extended commands using in
extended mode. Command characters are found in the “CC” column (all
extended commands are lower case), their corresponding ASCII codes- in “Hex”.
“CS” lists commands that require the checksum in the command packet (“C”) or
reply packet (“R”). “Error code” column lists errors that may result from each
command execution:
CS Errors
C.
C. Hex Description CR479
‘i’ 69H Log into Extended mode
‘o’ 6FH Log out from Extended mode
‘s’ 73H Get current login status
‘n’ 6EH Terminal sends captured-data to Host +
‘r’ 72H Host requires Terminal to resend
captured data +++
‘a’ 61H Host acknowledges that data has
received successfully +
12

TR510 User’s Manual
‘d’ 64H Host sends “4 digits” message to display ++
‘l’ 6CH Host sends the “Relay activation”
duration. (The command ‘l’ is lower case
of ‘L’)
++
‘p’ 70H Set punch times ++
‘u’ 75H Get punch times +
Follows is the detailed command description. Command and reply packets
are shown without STX, Checksum and CR characters.
Select designated terminal (‘D’, 44H)
Possible error codes: none
Command DNN
Reply ANN,TR510
NN is a machine (terminal) number in Hex form (00H-FFH), 00H is a
“universal” number (see below for details).
‘D’ is a special command. It is used to select a particular TR510 terminal. All
terminals power up in a “deselected” state. Each terminal ignores all incoming
commands until it receives the D-command whose machine number is either
equal to the machine number of this terminal, or 00. After that, the terminal
switches into “selected” state and responds to all subsequent commands until
new D-command with a different machine number is issued. Thus, the D-
command should always be used to initiate communications between the host
and the designated TR510.
Note: the TR510 never returns any error codes in reply to this command.
This holds true for both “illegal command” error and “Command failed” error. The
former is not responded to, because when there is some discrepancy in the
format of the D-command issued by the Host (which can only be in the Machine
Number field), no particular terminal can be “sure” that it is being addressed.
Therefore, no terminal on the network assumes responsibility for sending a reply.
“Command failed” situation can only arise because of incorrect machine number
setting value in the TR510 memory. In this case, the terminal will be unable to
compare its internal machine number with the one supplied in the D-command.
Hence, the Terminal will not be able to make sure that it is being addressed.
13

TR510 User’s Manual
Since 00 is a universal machine number, it works with any terminal. Use it
only when you have a single terminal connected to the host. Universal machine
number also comes handy during initial terminal setup (to assign a unique
machine number to the terminal prior to placing it on a multi-terminal network).
The terminal replies with its actual machine number even if you address it
using 00. The only exception is when the terminal is unable to retrieve its own
machine number due to some internal malfunction. Reply will contain 00 instead
of an actual machine number in this case.
Set new machine number (‘I’, 49H)
Possible error codes: 04, 07
Command INN
Reply A
NN- machine number in Hex form (00H-FFH), 00 should never be used on a
multi-terminal network because this is a universal number (see D-command
description for details).
This command is used to assign a new machine number to the terminal.
Machine numbers provide a way to distinguish between the terminals on a multi-
terminal network. See D-command description for more details.
Get machine number (‘Y’, 59H)
Possible error codes: 07
Command Y
Reply ANN
NN- machine number in Hex form (00H-FFH)
This command is used to retrieve the terminal’s machine number. Machine
numbers provide a way to distinguish between the terminals on a multi-terminal
network. See D-command description for more details.
Set date/time (‘S’, 53H)
14

TR510 User’s Manual
Possible error codes: 04, 07
Command SYYYYMMDDhhmmss
Reply A
YYYY-year, MM- month, DD-date, hh-hour, mm-minutes, ss- seconds
This command is used to set the TR510’s internal clock. Date/time supplied
must be valid. Incorrect data (like 31st of February) will be rejected (error 04).
Get date/time (‘T’, 54H)
Possible error codes: 07
Command T
Reply AYYYYMMDDhhmmss
YYYY-year, MM- month, DD-date, hh-hour, mm-minutes, ss- seconds
This command is used to get the TR510’s current date and time.
Get firmware version (‘V’, 56H)
Possible error codes: none
Command V
Reply Aversion_string
Version_string length is guaranteed to not exceed 61 character, all character
codes are guaranteed to be in the 20H…7FH range
This command can be used to verify the TR510’s internal firmware version.
Although version string can be any ASCII string, the following format is adopted:
“VX.XX cc…….c”, where “VX.XX” is a version number (i.e. “V1.81”) and
“cc…c” is a comment string. Comment string is separated from the version
number by a single space character. Version number will never have any
spaces in it.
Initialize the terminal (‘R’, 52H)
15

TR510 User’s Manual
Possible error codes: none
Command R
Reply A
This command is used to initialize the TR510. Initialization takes place on
the next power-up, not immediately. Upon initialization, all setting values are
restored to their factory defaults. TR510’s internal date and time are also
checked and, if contained garbage, initialized to 1999/01/01 and 00:00:00
respectively. The database data is not be erased, this must be done using the E-
command.
Note: It will take 25 seconds to restore all factory defaults when turn power-
up at first time for TR510 after received ‘R’ command, in the meanwhile LED will
display “INIT”; please wait for this initialization procedure to complete:
Set group-1 registers (‘C’, 43H)
Possible error codes: 04, 07
Command CRR,reg_data
Reply A
RR- register number (group 1) in Hex form (00…FFH), reg_data is the data
for the register to be set
This command is used to set one of the TR510 “group-1 registers”.
Registers are actually functioning parameters (Settings). Complete description
of all available registers can be found in Section 4.
Get group-1 registers (‘B’, 42H)
Possible error codes: 04, 07
Command BRR
Reply Areg_datacc
RR- register number (group 1) in Hex form (00H…FFH), reg_data is the data
16

TR510 User’s Manual
stored in the register, cc- checksum
This command is used to retrieve the data contained in the designated
“group-1 register”. Registers are actually functioning parameters (settings).
Complete description of all available registers can be found in Section 4.
Set group-2 registers (‘P’, 50H)
Possible error codes: 04, 07
Command PRR,reg_data
Reply A
RR- register number (group 2) in Hex form (00…FFH), reg_data is the data
for the register to be set
This command is used to set one of the TR510 “group-2 registers”.
Registers are actually functioning parameters (Settings) with respect to access
bell table ‘time’ field (7x32 entries) from Sunday to Saturday. Complete
description of all available registers can be found in Section 4.
Get group-2 registers (‘Q’, 51H)
Possible error codes: 04, 07
Command QRR
Reply Areg_datacc
RR- register number (group 2) in Hex form (00H…FFH), reg_data is the data
stored in the register, cc- checksum
This command is used to retrieve the data contained in the designated
“group-2 registers”. Registers are actually functioning parameters (settings) with
respect to access bell table ‘time’ field (7x32 entries) from Sunday to Saturday.
Complete description of all available registers can be found in Section 4.
Set group-3 registers (‘J’, 4AH)
17

TR510 User’s Manual
Possible error codes: 04, 07
Command JRR,reg_data
Reply A
RR- register number (group 3) in Hex form (00…FFH), reg_data is the data
for the register to be set
This command is used to set one of the TR510 “group-3 registers”.
Registers are actually functioning parameters (Settings) with respect to access
bell table ‘enable/disable’ field (7x32 entries) from Sunday to Saturday.
Complete description of all available registers can be found in Section 4.
Get group-3 registers (‘K’, 4BH)
Possible error codes: 04, 07
Command KRR
Reply Areg_datacc
RR- register number (group 3) in Hex form (00H…FFH), reg_data is the data
stored in the register, cc- checksum
This command is used to retrieve the data contained in the designated
“group-3 registers”. Registers are actually functioning parameters (settings) with
respect to access bell table ‘enable/disable’ field (7x32 entries) from Sunday to
Saturday. Complete description of all available registers can be found in Section
4.
Get number of records (‘N’, 4EH)
Possible error codes: 07
Command N
Reply ANNNNcc
NNNN- number of records in Hex form; cc- checksum
This command can be used to retrieve the number of records currently found
in the database. Leading zeroes are not omitted, so reply string length is always
the same.
18

TR510 User’s Manual
Get specified record (‘G’, 47H)
Possible error codes: 04, 06, 07
Command GNNNN
Reply ANNNN,ccc…c,E,YYYY/MM/DD,hh:mm:sscc
NNNN- record number (starting from 0000) in Hex form, ccc…c- ID-code, E-
event (0: OUT, 1: IN), YYYY- year, MM-month, DD-date, hh-hour, mm- minute,
ss- second, cc- checksum
This command is used to retrieve the database record with a specified
number. Record number must be supplied in Hex format, leading zeroes must
be preserved or error 04 will be returned. Record numbers start from 0000.
Specifying record number beyond N-1 (where N is the number of records in the
database returned by the N-command) will cause error 06.
When use this command to retrieve database, TR510 will automatically lock
itself, this means it will reject card reading until database stop retrieving, then
user’s card can be read again; in the meantime, LED will display ‘busy’ as
following:
This auto-lock function prevent data is deleted inadvertently for some
application. Some application Polling database use command ‘N’ to get number
of records then use command ‘G’ to retrieve the records, at last use command
‘E’ to erase database. But during retrieve the records some user card’s may be
read into database again, think of this, user’s application does not know these
cards have read into database, application retrieves records but does not
include these new read-in records, when it erases database, these new read-in
records will be erased as well, this will cause lose data. Now the new auto-lock
function will prevent data was deleted inadvertently; when application stops
database retrieving, TR510 will wait 3 seconds for receiving command ‘E’, if ‘E’
command has received, TR510 erases database then unlock itself, user’s card
can be read again; or until 3 seconds Time-out TR510 still has not received ‘E’
command, however it will unlock itself but does not erase database.
19

TR510 User’s Manual
Returned data string contains the record number, ID-code of the ID-card that
was used to create this record, event code (i.e. which button was pressed), and
the date and time of record creation.
The TR510 verifies all database records before sending them out to the PC.
This is done because the FLASH memory may actually contain a garbage data.
There is a special M-command that lets you initialize the database in such a way
that it appears to be 100% full (you can “recover” entire database memory
contents then). Naturally, some database records may turn out to contain invalid
data.
Database record validity is verified on a field-by-field basis. Should the field
turn out to be invalid, its contents are substituted for a “safe” default data:
• ID-code. If ID-code turns out to contain illegal characters (i.e. with
codes outside of 20H-7FH range), then these characters are
substituted for “_”. If ID-code length is outside of valid margins* then
entire ID-code is substituted for the following code: “0000000000” (ten
‘0’ characters)
• Date. If the date is invalid (i.e. December, 32nd) then default date
(1999/01/01) is used
• Time. If the time is invalid (i.e. 24:00:00) then default time is used
• Event. if Event code exceeds 1, then this field is substituted for “0”.
*Note: for JIS-II code, the valid length of ID-code is “1<= margin <=69”; for
Track1 code, the valid length of ID-code is “1<= margin <=76”; for Track2 code,
the valid length of ID-code is “1<= margin <=37”.
Initialize the database (‘E’, 45H)
Possible error codes: none
Command E
Reply A
Executing this commands initializes the database. This command can be
used to delete all database data and restore the database functionality in case
of database malfunction.
E-command doesn’t really delete the data itself- just some internal database
housekeeping is initialized. The data can still be (partially) recovered using an
20
