Brookstone Retro Clock User manual

Retro Clock
App-driven dock for iPod®
& iPhone®devices
643403_INS_iDesign Retro Alarm Clock Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk
iDESIGN®

1
TABLE OF CONTENTS
CautionsandWarnings....................................................2
LocationsofPartsandControls............................................6
IncludedAccessories......................................................7
Set-UpandOperation.....................................................8
CompatibleiPodandiPhoneModels........................................8
UsingtheApp.............................................................9
UsingLine-In............................................................10
Specifications............................................................11
Troubleshooting..........................................................12
Warranty.................................................................13

CAUTION
• TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
THERE ARE NO SERVICEABLE PARTS INSIDE.
• TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
The lightning flash with arrow-head symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the unit’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the unit.
IMPORTANT SAFETY INSTRUCTIONS
All the safety and operating instructions should be read, adhered to and followed
before the unit is operated.
SAVE THESE INSTRUCTIONS
2
643403_INS_iDesign Retro Alarm Clock Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk

IMPORTANT SAFETY INSTRUCTIONS
All the safety and operating instructions should be read, adhered to and followed
before the unit is operated.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other unit (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades, with one wider than the other. A grounding-
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where it exits from the unit.
11. Only use attachments/accessories specified by the manufacturer.
3

12. Unplug this unit during lightning storms or when unused for long
periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when
the unit has been damaged in any way, including if the power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the unit,
the unit has been exposed to rain or moisture, does not operate normally,
or has been dropped.
Note:
1. The unit shall not be exposed to dripping or splashing liquids.
2. Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the unit from the
power completely, the main plug should be disconnected from the main
socket outlet completely.
WARNING
1. Keep away from children. This is not a toy.
2. Use this unit only for its intended use as described in this manual.
3. Unplug this unit during lightning storms or when unused for long
periods of time.
4. Never drop or insert an object into any opening.
5. Protect the power cord from being walked on or pinched, particularly at plug
outlets, convenience receptacles and the point where it exits the unit.
4
643403_INS_iDesign Retro Alarm Clock Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk

5
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This equipment may not cause harmful interference.
2. This equipment must accept any interference received, including interference
that may cause undesired operation.
Modifications not authorized by the manufacturer may void the user’s authority
to operate this device.

6
643403_INS_iDesign Retro Alarm Clock Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk
1. Clip Dock
2. 30-Pin Connector
3. Speakers (2)
4. Snooze Button
5. Volume —/+
LOCATION OF PARTS AND CONTROLS
Top view
Front view
3
1
2
5
4

LOCATION OF PARTS AND CONTROLS
1. Line-in Jack
2. DC 5V Jack
12
Back view
INCLUDED ACCESSORIES
6 iPod/iPhone Clips
DC Adapter
and Cord
7

8
643403_INS_iDesign Retro Alarm Clock Size:5”Wx4.75”H_Output:100%_Prints:1/1,Blk
SET-UP AND OPERATION
AC POWER
Connect the DC Adapter to a power outlet and
the DC IN on the Retro Clock.
CONNECTING YOUR iPod/iPhone
TO THE RETRO CLOCK
Select the correct iPod/iPhone CLIP for your
iPod/iPhone and slide it securely into the docking
area on the front of the unit (see the example to
the right).
Slide the CLIP down onto the CLIP DOCK.
Slide your iPod/iPhone down through the CLIP and securely on the
30-PIN CONNECTOR.
PLAYING YOUR iPod/iPhone
1. Dock your iPod/iPhone.
2. Adjust the volume using the + or — buttons.
COMPATIBLE iPod/iPhone MODELS
iPod touch
(1st, 2nd and 3rd generation)
iPod classic
iPod nano
(4th and 5th generation)
iPhone 4
iPhone 3GS
iPhone 3G
iPhone

USING THE APP (free download from App StoreSM)
The app includes alarm clock, weather forecast and more.
When you dock your iPod/iPhone in the unit, a pop-up
asking if you’d like to download the free iDesign®Retro Alarm
Clock app will appear.
You may also go directly to the iTunes®App StoreSM
to download the iDesign®Retro Alarm Clock app.
Note: For all compatible iPod/iPhone devices the
OS must be 3.1.2 or later to work with the app.
APP TIPS
SCREENS
Swipe Left/Right to go to:
Double tap on screen to activate a split screen.
Swipe left/right to change screens.
Double tap to return to full screen.
Horizontal orientation will automatically show a split screen.
Touch to access Wall Paper settings.
Touch to customize screen
9
• Home
• Weather
• Photo
• World Time
• Date
• Music
• Alarm
