Promag MP2 User manual

8. User Manual.jpg

MP2 Wires Assignment
To configure the MP2 reader you must connect the MP2 to the PC by RS232C interface using our software.
CAUTION:
The crossed out wheeled bin label that can be found on your product indicates that this
product should not be disposed of via the normal household waste stream.
To prevent possible harm to the environment or human health please separate this
product from other waste streams to en-sure that it can be recycled in an
environmentally sound manner.
For more details on available collection facilities please contact your local government
office or the retailer where you purchased this product.
This information only applies to customers in the European Union.
For other countries, please contact your local government to investigate the possibility
of recycling your product.
DOC# TM951322
Color Symbol I/O Description
Red VCC IN Power Input: 12VDC
Black GND IN Power Ground + Singal Ground
Yellow D1 OUT Clock (ABA TK2) ; Data 1 (Wiegand)
Blue D0 OUT Data (ABA TK2) ; Data 0 (Wiegand)
Green CP OUT Card Present (ABA TK2)
White RX IN RS232 RXD (To Host TXD)
Orange TX OUT RS232 TXD (To Host RXD)
Brown Boot IN Reboot (While this line wired with GND at power on,MP2 will enter boot phase.)
- -
- -
MF700KIT is a kit for MP2 to connect with PC. It is an optional accessory for purchasing.
