Promax TMC-1000 User manual

TMC-1000
Vacuum Tumbling Machine
Operation Manual
Version 6.9.1
1915 E. Acacia Street, Ontario, CA91761, U.S.A
TEL : [phone]
FAX : [phone]
http://www.promarksvac.com
S/N: QCSIGNATURE:

TABLE OF CONTENTS
1. INSTALLATION …………………………………………………………………... 1
2. MAINTENANCE ………………………………………. …………………………. 1
3. FUNCTIONS OPERATION…….. ………………………………………….. …... 1
4. MACHINE SPECIFICATION……………..……………………………………….2
5. MACHINE OPERATION EXPLAIN…. ……………..…………………………...3
6. FABRICATION ……………………………….………………………………… ..4
6.1 DRUM BODY………………………………………………………….…… 5-6
6.2 MACHINE CASE…………... ………………………………………..……..7-10
6.3 ELECTRICAL BOX ……………………………………………………..11-13

1
1. INSTALLATION
Please check the electric power listed on the vacuum pump and install the vacuum
pump correctly,
ground line must on the floor.
2. MAINTENANCE
A. To ensure vacuum pump works smoothly suggest change the vacuum oil every
500 working hours or every a half year.

B. Check water filter bottle everyday, as soon as the water over a half of the bottle
please cleans it.
3.FUNCTIONSANDOPERATIONS
1 Mix time
2 Barrel speed
3 Vacuum
4 Vacuum pump ON/OFF switch
5 Tumble ON/OFF switch
6 Inch moving tumble forward/Reverse
Cleaning. The tumbler inside must be cleaned everyday after working hours.

2
4. MACHINE SPECIFICATION

3
5.MACHINEOPERATION EXPLAIN.
Check therightpower sourcewiththename plateof themachine. Plug in thepower and
readyto operatethe machine.
Turnonmain powerswitchandset thevalueon control panel. After finishall of the
settingpushdown thesafetybar andpress Start/Pause”buttontostart thefunction.
Safetyfunction will be effectiveand machinewill stopat thesame time whileuser
pull up thesafetybar or gearmotor box duringworkingprocess.
After vacuumtumbling jobfinish,machinewill stopandair ventilationatthe sametime.
As soon as machinefinishair ventilation, openthevacuumcover and useunloading
switchtounload theproduct indrum.
The stopperon thesideof themachineis design toholdthedrumand remain it inthe
sameangleand helpuser toload in theprocessing product. Howto usethe stopper:
A. Pushinthehandlebar of stopper totheholeof thedrumbefore loadinthe
processing product.
B. Pull back the handlebar of stopper fromtheholeof thedrumbeforestart the
machine.
Warning: Thehandle bar of thestoppermust bepulled back beforeuserstart the
machine!!Themachinewill bedamaged if user havenot fulfill it!!

4
6. FABRICATION
6.1 DRUM BODY
6.2 MACHINE CASE 6.3 ELECTRICAL BOX

5
6.1 DRUM BODY
MC1K10000
Drum Body Diagram

6.1-MC1K10P00
NO. PART NO. DESCRIPTION QTY NOTES
1 MC1K201000 Drum tank(TMC1000) 1
2 MC1K202000 Tank cover(TMC1000) 1
3 3114467 Cover gasket 1
4 2740006I2 Fitting 3/4"x1/2" 1
5 2961110 Fitting 3/4"x1P 1
6 29093294 Fitting 316 TYPE F 3/4" 1
6

7
6.2 MACHINE CASE DIAGRAM
Machine Case Diagram
MC1K20000
2
21
16
24
17
20
12
36 26
55 26 36
26
62
26
14
29
57
56
41
33
61
CONNECT-B
60 58
39
22
E
C
34 35 38
CONNECT-A
28
49
28
18
30
25
1
47
28
37
59
40
40
37
19
15
31
23
51
F
F
G
G
5
3
4
6
7
8
10
11
13
50
37
52
53
54
27
43
9
45
44
32
64
63
65
69
66
67
67 68
48
46
42

7.2-MC1K20P00
NO. PART NO. DESCRIPTION QTY NOTES
1 MC1K101000 Frame(TMC1000) 1
2 MC1K102000 Side frame(TMC1000) 1
3 TM5H116000 Electrical protect plate 1
4 MC1K106000 Chain wheel 1
5 MC1K107000 Chain wheel 1
6 MC50109002 Control panel plate 1
7 MC50110001 Control panel bottom plate 1
8 MC50111005 Fixed plate 1
9 2740006I2 Fitting 3/4"x1/2" 1
10 TM3H130021 Window 1
11 MC50129000 Cover plate 1
12 MC1K103000 Cover plate 1
13 MC50122002 Motor fixed plate 1
14 TM3H130011 Control panel cover plate 1
15 D2320020 Hinge 2
16 TM3H190000 Side door 1
17 2712222 Base leg 4
18 2850613 Sensor 1
19 TM3H803000 Panel 1
20 TM3H801000 Electrical box 1
21 2728557 Bearing pillow blockUCP211 1
22 28017051 Switch 1
23 2870077 Switch M22EL-TSF20E30 1
24 27121411 Casters 4" 4
25 29118085 Valve VXZ2242-04-BGR1(AC24V) 1
26 290932570 Nipple 1/2"x30 3
27 TM3H145000 Cover plate 2
28 2705329 Flat washer M16 6
29 2883349 Door lock C408K 2
30 28501030 Reflector 1
31 2883343 Hinge 1
8

7.2-MC1K20P01
NO. PART NO. DESCRIPTION QTY NOTES
32 2815288 Decelerator LM-HMW-80-60-R-1HP 1
33 2701501 Round head screw M6x12(S) 2
34 27004001 Hex head screw M10x20(S) 8
35 2705304 Split lock washer M10(S) 8
36 274000661 Elbow 1/2" 2
37 290932569 Nipple 1/2"x60 3
38 2705189 Flat washer M10(S) 6
39 2728566 Bearing pillow block UCFL211 1
40 2705328 Split lock washer M16(S) 4
41 270020290 Hex head screw M16x45(S) 2
42 2705322 Split lock washer M14(S) 4
43 2814532 Motor 1HP/4P/3ψ230/460V 50/60HZ 1
44 27070094 Nut M14（S）4
45 27136064 Chain RS60(TMC1000) 1
46 27004560 Hex head screw M14x40(S) 4
47 27071103 Nut M16（S）2
48 2705155 Flat washer M14(S) 4
49 2853313 Limit switch TZ-7311 1
50 2909262 Bend 1/2"（S）2
2961071 VACUUM PUMP, BUSCH, 21M3/H, 220V/1PH 1
2961072 VACUUM PUMP, BUSCH, 21M3/H, 110-220V/1PH 1
52 29093291 Fitting TYPE B 3/4" 1
53 TM5H260000 Connection 1/2"（S）1
54 2909238 Fitting 2
55 2940011 Filter bottle 1
56 2705151 Flat washer M6(S) 16
57 2700402 Hex head screw M6x16(S) 16
58 2714251 Chain wheel plate RSC-45-60S 1
59 MC50121000 Fixed mount 1
60 MC50123000 Cover plate 1
61 270020291 Hex head screw M16x35(S) 3
62 29090097 Tee branch valve 1/2"(S) 1
63 2714752 Gasket L=1230 1
64 2832024 Timer 1
65 2851407 Sensor 1
66 29135564 Pressure guage 1
51 OPTION
9

7.2-MC1K20P02
NO. PART NO. DESCRIPTION QTY NOTES
2870187 Button 2
2870479 Button guard 1
28701852 Button 1
2870479 Button guard 1
2896411 Variable resistor 1
2896418 Switch black 1
69
67
68
10

11
6.3 ELECTRICAL DIAGRAM (110V)

12
6.3 ELECTRICAL DIAGRAM (220V)

13
6.3 ELECTRICAL BOX (1ψ)
ITEM PART NO. DESCRIPTION SPECIFICATION Q’TY NOTE
MS1 2810739 Contactor CU-11-B5 (AC24V) 1
MS2~3 2810758 Contactor CU-18-4A 2
TMR1.2.4.6 2832024 Time Relay GE1A-B10HAD24 4
TMR3.5 2833324 Time Relay ANLY AMY-2 30S 2
2833329 Socket Relay PYF08A-E MY2 2
F1~F2 2890048 Fuse 20mm 1A 1
R1~3 2830132 Relay RU4S-C-A24 3
2831106 Socket Relay SY4S-05D 3
OL1~2 2811537 Relay, Overload RHU-10K1(9-12.5A) 1
2811539 Relay, Overload RHU-10K1(15-20A) 1
T1 28960025 Transformer 120VA 110V/0-24V
OF-24V UL 1
