ProMinent DULCOnvert Manual

DULCOnvert
PROFIBUS® - PROFINET® converter
Installation and configuration manual
These operating instructions are only valid in conjunction with the "Operating instructions for the solenoid metering pump
delta® with controlled solenoid drive optoDrive® DLTa” or the “Operating instructions for the motor-driven metering pump
Sigma/ x Control type SxCb”!
EN
982920 BA PM 008 02/18 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Table of contents
1Prerequisites......................................................................... 3
2 Setting up installation............................................................ 4
2.1 General......................................................................... 4
2.2 Setting up the PROFIBUS® slave address................... 4
2.3 Activating / deactivating PROFIBUS®........................... 4
2.4 PROFINET® settings.................................................... 5
3Special features in active PROFIBUS® mode....................... 7
3.1 General......................................................................... 7
3.2 Displays........................................................................ 7
3.3 LEDs on the PROFIBUS® module................................ 8
3.4 Using the metering monitor........................................... 8
4 Assembly and electrical installation...................................... 9
5 Operation............................................................................ 11
5.1 General....................................................................... 11
5.2 GSDML File................................................................ 11
5.3 Description of the data objects................................... 11
5.4 Cyclic data transmission............................................. 15
5.4.1 Overview of the data objects................................... 15
5.4.2 Configure................................................................. 18
5.5 Extended diagnostics.................................................. 18
6 Technical data on DULCOnvert.......................................... 20
Table of contents
2

1 Prerequisites
The pump must have enhanced PROFIBUS® functionality by
means of a plug-in module. To do this, insert the plug-in module
into the front of the pump (similar to a relay module). The menu
item “PROFIBUS® then appears in the operating menu.
The pump requires a minimum of software version
V01.03.06.00 (delta® DLTa) or V01.01.00.00
(Sigma Control SxCb) and hardware version
V01.04.00.00 for the delta® for the PROFIBUS®
module to work correctly. If it is not working, the
LED on the PROFIBUS® module flashes slowly red
and green.
The pump can then be extended with PROFINET® functionality via
the DULCOnvert converter.
Prerequisites
3

2 Setting up installation
2.1 General
Familiarise yourself with the process:
We describe here how to set up the pump for
PROFIBUS® mode - you will later meet the pump’s
PROFINET® protocol via the DULCOnvert in the
master control system!
For this reason, "PROFIBUS®" is interchangeable
with "PROFINET®” at many points.
The pump with a plug-in PROFIBUS® module is set up in the same
way as a standard pump, with the addition of the bus functionality.
The software interrupts the set-up process in the
event of pauses of longer than 60 s.
2.2 Setting up the PROFIBUS® slave address
1. Connect the disconnected DULCOnvert by its PROFIBUS®
cable to the pump’s PROFIBUS® socket.
2. Press
[P] for 2 seconds on the pump.
3. delta® only: Use the
[arrow keys] to go to „Settings“ and
press [P] .
4. Use the
[arrow keys] to go to „PROFIBUS®“ and press [P] .
5. Use the
[arrow keys] to go to „Address“ and press [P] .
Always enter the PROFIBUS® address “002” as a 3-digit number:
1. Die 1. Use the
[Down] key to go to the 1st digit “0” and press
[P] .
2. Die 2. Use the
[Down] key to go to the 2nd digit “0” and press
[P] .
3. Die 3. Use the
[arrow keys] key to go to the 3rd digit “2” and
press [P] .
2.3 Activating / deactivating PROFIBUS®
„PROFIBUS®“ must be set to „active“ in the operating menu for
the pump to be controlled by the PROFIBUS®:
1. Press [P] for 2 seconds.
2. Use the
[arrow keys] to go to „PROFIBUS®“ and press [P] .
3. Use the
[arrow keys] to go to „active“ or „inactive“ and press
[P] . You’re done!
Setting up installation
4

All external inputs, such as level monitoring, metering monitoring
and external control (pause, contact input, analogue input), will
function while the PROFIBUS® is „active“ . They result in the reac‐
tions that would be expected with the pump without the PRO‐
FIBUS® module being plugged in - see pump operating instruc‐
tions. The pump transmits corresponding information via the
PROFIBUS® to the master (PLC Programmable Logic Controller,
PC etc.).
If the PROFIBUS® is set to
„inactive“ , the settings for the operating
mode previously selected are reloaded.
If the pump is switched to another operating mode, it stops and can
only be restarted using [Stop/Start] .
2.4 PROFINET® settings
1. Connect the DULCOnvert to its supply voltage.
2. Connect the DULCOnvert to your PROFINET® network - see
“Installation” chapter.
3. Select
„Update accessible devices“ in the TIA portal under
„Online accesses“ .
Fig. 1
ðThe default name is
„nl51ndpl“ .
Setting up installation
