PROPOINT 8843625 User manual

V1.0 8843625
Please read and understand all instructions before use. Retain this manual for future
reference.
NEEDLE SCALER

AIR

8843625 Air Needle Scaler V1.0
2 For technical questions call 1-800-665-8685
SPECIFICATIONS
Air Consumption @ 90 PSI 4.75 CFM
Stroke Length 1-5/8 in.
Impact Rate 4,600 BPM
Max. Pressure 90 PSI
Air Inlet 1/4 in.
Recommended Air Hose Size 3/8 in.
Exhaust Style Front
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this manual. A notice is
an alert that there is a possibility of property damage, injury or death if certain
instructions are not followed.
DANGER! This notice indicates an immediate and specific hazard that will
result in severe personal injury or death if the proper precautions
are not taken.
WARNING! This notice indicates a specific hazard or unsafe practice that could
result in severe personal injury or death if the proper precautions
are not taken.
CAUTION! This notice indicates a potentially hazardous situation that may result
in minor or moderate injury if proper practices are not taken.
NOTICE! This notice indicates that a specific hazard or unsafe practice will
result in equipment or property damage, but not personal injury.

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 3
INTRODUCTION
The Air Needle Scaler removes rust, scale, weld flux, cement and other surface
residues for surface preparation applications. The needle scaler has 19 high wear
resistant steel needles, a heat treated barrel and piston for extended tool life. The
linear design fits into narrow spaces.
SAFETY
WARNING! Read and understand all instructions before using this tool. The
operator must follow basic precautions to reduce the risk of personal injury
and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or inspection and
maintenance instructions.
WORK AREA
1. Operate in a safe work environment. Keep your work area clean, well-lit and
free of distractions.
2. Keep anyone not wearing the appropriate safety equipment away from the
work area.
3. Store tools properly in a safe and dry location. Keep tools out of the reach
of children.
4. Do not install or use in the presence of flammable gases, dust or liquids.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by the
Canadian Standards Association (CSA) or American National Standards
Institute (ANSI).
PERSONAL PROTECTIVE EQUIPMENT
1. Always wear impact safety goggles that provide front and side protection for
the eyes. Eye protection equipment should comply with CSA Z94.3-07 or ANSI
Z87.1 standards based on the type of work performed.
2. The tool may contain high pressure. Use safety glasses and gloves for
protection during operation. Keep hands clear of the exposed rubber
portions of the hose.
3. Wear the appropriate type of full-face shield in addition to safety googles, as
the work can create chips, abrasive or particulate matter.
4. Wear gloves that provide protection based on the work materials or to reduce
the effects of tool vibration.

8843625 Air Needle Scaler V1.0
4 For technical questions call 1-800-665-8685
5. Wear protective clothing designed for the work environment and tool.
6. Non-skid footwear is recommended to maintain footing and balance in the
work environment.
7. Wear a NIOSH approved respirator when working on materials that produce
hazardous fumes, dust or particulate matter.
8. This tool can cause hearing damage. Wear hearing protection gear with an
appropriate Noise Reduction Rating to withstand the decibel levels.
PERSONAL PRECAUTIONS
Control the tool, personal movement and the work environment to avoid personal
injury or damage to the tool.
1. Do not operate any tool when tired or under the influence of drugs, alcohol or
medications.
2. Avoid wearing clothes or jewelry that can become entangled with the moving
parts of a tool. Keep long hair covered or bound.
3. Do not overreach when operating the tool. Proper footing and balance enables
better control in unexpected situations.
4. Support the workpiece or clamp it to a stable platform. Holding the workpiece
by hand or against your body may lead to personal injury.
5. Securely hold this tool using both hands. Using a tool with only one hand can
result in loss of control.
6. Keep your fingers away from the trigger/switch while carrying the tool, attaching
an air hose or an accessory. Lock the trigger/switch safety if available.
7. Avoid unintentional starts. Be sure that the regulator/throttle switch is in the
neutral or OFF position when not in use and before connecting it to any air
source.
8. Never point the air stream or tool at any point of your body, other people or
animals. Debris and dust ejected at high speed can cause an injury.
9. Serious injury or death may occur from inhaling compressed air. The air
stream may contain carbon monoxide, toxic vapors or solid particles. Never
inhale compressed air directly from the pump or air tool.
SPECIFIC SAFETY PRECAUTIONS
WARNING! DO NOT let comfort or familiarity with product (gained from
repeated use) replace strict adherence to the tool safety rules. If you use
this tool unsafely or incorrectly, you can suffer serious personal injury.

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 5
1. Use the correct tool for the job. This tool was designed for a specific function.
Do not modify or alter this tool or use it for an unintended purpose.
2 Avoid unintentional starts. Be sure that the throttle/ignition switch is in neutral
or OFF position when not in use and before connecting it to any air source. Do
not carry the tool with fingers near or on the lever.
AIR TOOL PRECAUTIONS
1. Use only clean and dry compressed air as a power source. Contaminated or
moist air will gradually damage the tool.
2. Install an in-line shutoff valve or regulator to allow immediate control over the
air supply in an emergency, even if a hose is ruptured.
3. Discontinue tool use if it does not work properly or air is leaking. Tag or mark
the tool as ‘defective’ or ‘out of service’ until repaired.
4. Check the manufacturer’s maximum pressure rating for air tools and
accessories. Compressor outlet pressure must be regulated to never
exceed the maximum pressure rating of the tool (see Specifications).
Exceeding the maximum PSI rating can create a bursting hazard, causing
injury and property damage.
5. Attach all accessories properly to the tool before connecting the air supply. A
loose accessory may detach or break during operation.
6. Never use oxygen, combustible gas or any other bottled gas as a power
source. Any power source other than an air compressor could cause an
explosion and serious personal injury.
7. Turn OFF the valve and discharge any remaining air pressure after each use
or before adjusting the tool.
8. Do not leave the air tool unattended with its compressed air supply on. Turn
off the compressed air supply and bleed the air tool of any remaining
compressed air before leaving the air tool unattended.
9. Serious injury may occur from loose debris being propelled at high speeds
from the compressed air stream. Always wear OSHA approved safety glasses
to protect the eyes during operation of the air compressor.
10. Always turn off the air compressor and drain tank pressure completely before
attempting maintenance or attaching air tools. Release pressure slowly from
the system.
11. Serious injury or death may occur from inhaling compressed air. The air
stream may contain carbon monoxide, toxic vapors or solid particles. Never
inhale compressed air directly from the pump or air tool.

8843625 Air Needle Scaler V1.0
6 For technical questions call 1-800-665-8685
POWER TOOL PRECAUTIONS
1. Do not use any power tool with a malfunctioning power switch or control. A
power tool that fails to respond to the controls is dangerous and can
cause an injury. A qualified technician must repair and verify the power
tool is operating correctly, before it can be used.
2. Disconnect the power source before installing or servicing the tool.
3. Never force the tool. Excessive pressure could break the tool, resulting
in damage to your workpiece or serious personal injury. Excessive
pressure is the cause if your tool runs smoothly under no load, but
roughly under load.
4. Keep hands and fingers away from the work area. Any part of body
contacting the tool’s working parts could cause an injury.
5. Only use accessories that are specifically designed for use with the tool.
Ensure the accessory is tightly installed.
6. Only use an accessory that exceeds the No Load Speed rating (see
Specifications).
7. Before using the tool on a workpiece, test the tool by running it at the
highest no load speed for at least 30 seconds in a safe position. Stop
immediately if there is any abnormal vibration or wobbling. Check the tool
to determine the cause.
8. Never touch the tool accessory or workpiece during or immediately after
use. They may be hot and could inflict a burn injury.
9. Never use a tool with a cracked or worn tool accessory. Change the tool
accessory before using it.
10. Do not place the tool down until the tool’s accessory has stopped moving.
The accessory may catch the surface of work material and wrench itself
free, causing injury to the user or others in the work area.
AIR HOSE PRECAUTIONS
1. Inspect the tool's air hose for cracks, fraying or other faults before each use.
Discontinue use if the air hose is damaged or hissing is heard from the air
hose or couplers. Replace the defective air hose.
2. Do not allow people, mobile equipment or vehicles to pass over the
unprotected air hose. Position the air hose away from high traffic areas, in a
reinforced conduit or place planks on both sides of the air hose to create a
protective trench.

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 7
3. Prevent damage to the air hose by observing the following:
a. Never carry the tool by the air hose.
b. Keep the air hose behind the tool and out of the tool's work path.
c. Keep the air hose away from heat, oil, sharp edges or moving parts.
d. Do not wrap the air hose around the tool as sharp edges may pierce or
crack the air hose. Gently coil the hose and either hang on a hook or
fasten with a device to keep hose together when storing.
4. A damaged or disconnected air hose under pressure may whip around and
inflict personal injury or damage the work area. Secure the compressor's air
hose to a fixed or permanent structure with clamps or cable ties.
COMPRESSOR/TANK PRECAUTIONS
DANGER! Do not use an air tank beyond its expiration date. A tank rupture
or explosion may kill or cause a serious injury to yourself or a bystander.
Disable and discard the air tank according to the your municipality by-laws.
1. Never drill into, weld, patch or modify the air tank. Immediately replace the
tank or compressor if an air leak develops. The leak may lead to a rupture.
2. Never make adjustments to the components that control tank pressure.
Serious injury or death may occur if modifications are made to the pressure
switch, safety relief valve or other components that control the tank pressure.
3. Check operation of the pressure relief valve on a regular basis and never
operate without a factory approved pressure relief valve. Do not make
alterations to the factory operating pressure settings.
VIBRATION PRECAUTIONS
1. This tool vibrates during use. Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury. Take frequent breaks when
using the tool.
2. If you feel any medical symptoms related to vibrations (such as tingling,
numbness, and white or blue fingers), seek medical attention as soon as
possible.
3. Wear suitable gloves to reduce the effects of vibration.
4. DO NOT use this tool before consulting a physician if one of the following
applies:
a. Pregnant
b. Impaired blood circulation to the hands
c. Past hand injuries
d. Nervous system disorders
e. Diabetes
f. Raynaud's Disease

8843625 Air Needle Scaler V1.0
8 For technical questions call 1-800-665-8685
UNPACKING
WARNING! Do not operate the tool if any part is missing. Replace the missing
part before operating. Failure to do so could result in a malfunction and
personal injury.
Remove the parts and accessories from the packaging and inspect for damage. Make
sure that all items in the parts list are included.
Contents: • Needle Scaler Body • Needle Holder • Needle Tube and Spring
• 19 Needles • Air Inlet Cap
ASSEMBLY & INSTALLATION
Numbered references in parenthesis (#1) refer to the included Parts List.
INSTALL AIR COUPLER PLUG
Prepare a standard 1/4 in. NPT male air coupler plug (sold separately) for use with
your tool.
1. Wrap the external threads of the male coupler plug with sealant tape.
a. Wrap tape in a clockwise direction so it will not unravel.
b. Do not tape all the threads. Leave several leading threads unwrapped for
easier alignment.
2. Screw the coupler plug into the tool's air inlet and tighten with a wrench until snug.
3. Run the compressor at a low volume and check the connection for air leaks. Do
not use the tool until all air leaks are repaired or the faulty component is replaced.
IMPORTANT! Vibration may cause failure if a quick coupler is connected directly
to the air tool. To overcome this, connect a leader hose to the tool. A quick
coupler may then be used to connect the leader hose to the air line hose.
ASSEMBLING THE NEEDLE HOLDER
1. Insert the needles (Fig. 1-4) through the holes of the needle holder (Fig. 1-3).
Each needle’s head should fit snugly into
the holder when inserted through the
correct side.
2. Slide the spring (Fig. 1-2) over the needles.
3. Slide the needle assembly into the needle
tube (Fig. 1-1) until the spring rests against
the front of the tube. Push any wayward
needles down into the holder.
Fig. 1

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 9
4. Place the needle driver (Fig. 1-5) against the needle holder and align the tab
(Fig. 1-6) with the slot in the needle tube. Push the needle tube onto the main
body (#1) until the tab reaches one of the notches. Rotate the needle tube to lock
the tab into the notch.
OPERATION
PRESSURE DROP
Apply the air consumption and pressure rate numbers to the tool’s air inlet, not the
compressor’s outlet. Calculate the pressure drop for your air supply set-up and
increase the compressor outlet pressure to compensate. Make sure you do not exceed
the maximum pressure for any part of your air supply system.
Installing a pressure gauge at the tool inlet is the best way to measure the air pressure
and adjust the compressor’s output.
TOOL OPERATION
1. Select the amount of force the needles will apply to the workpiece. Each notch
closer to the front reduces the stroke length and force.
2. Grip the tool with both hands. Place one hand on the needle tube (#29) and the
other hand on the main body (#1).
3. Press the lever (#9) to operate. Make sure the needles are not touching any
surface when you turn on the tool.
4. Place the vibrating needles on the work surface at an angle between 60º and
70º. Move the needle scaler around in the area from which you wish to
remove the material.
5. Keep only light pressure on the tool while in use. Do not apply heavy pressure as
it may damage the surface area.
6. Do not hold the needle scaler in any one area of the work surface for more than a
few seconds. Longer intervals could damage the surface.
7. If the needle scaler will not remove the material from the surface after a few short
attempts, do not continue. Use another method to remove the material.
CARE & MAINTENANCE
1. Maintain the tool with care. A tool in good condition is efficient, easier to control
and will have fewer problems.
2. Inspect the tool components periodically. Repair or replace damaged or worn
components. Only use identical replacement parts when servicing.

8843625 Air Needle Scaler V1.0
10 For technical questions call 1-800-665-8685
3. Follow instructions for lubricating and changing accessories.
4. Only use accessories intended for use with this tool.
5. Keep the tool handles clean, dry and free from oil/grease at all times.
6. Maintain the tool’s labels and name plates. These carry important information. If
unreadable or missing, contact Princess Auto Ltd. for replacements.
WARNING! Only qualified service personnel should repair the tool. An
improperly repaired tool may present a hazard to the user and/or others.
CLEANING
Keep the tool clean. Wipe the tool with a clean cloth and periodically blow out all areas
with compressed air. If compressed air is not available, use a brush to remove dust
from all areas. Do not use harsh chemicals or solvents to clean the tool.
AIR TOOL LUBRICATION
NOTICE! Only use air tool oil to lubricate the tool. Other lubricants are not
suitable and will damage the tool or cause a malfunction during use.
NOTICE! Never use a penetrating oil to lubricate an air tool. Penetrating oil
acts as a solvent that will dissolve the tool’s grease packing and may damage
the o-rings, causing the tool to seize or malfunction.
1. All air tools have an internal coating of grease to prevent corrosion during
shipping and storage. Remove this grease by adding a generous amount of air
tool oil in the air inlet and then run the tool under no load until the exhaust is clear.
2. Manually add a drop or two of air tool oil into the tool’s male connector before
each use and after every hour of continuous use. The tool will not work properly
without lubrication and parts will wear prematurely.
3. Avoid adding too much air tool oil as this can cause premature power loss and
eventual tool failure. A qualified technician will need to take the tool apart and
clean out the excess oil.
4. Apply a generous amount of air tool oil to the tool before storing it for an extended
period of time (overnight, weekend, etc.). Run the tool for approximately 30
seconds to ensure the oil is evenly distributed throughout the tool. Store it in a
clean and dry location.
STORAGE
When not in use for an extended period, apply a thin coat of lubricant to the steel parts
to avoid rust. Remove the lubricant before using the tool again.

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 11
DISPOSAL
Recycle a tool damaged beyond repair at the appropriate facility.
Contact your local municipality for a list of disposal facilities or by-laws for electronic
devices, batteries, oil or other toxic liquids.
IMPORTANT! DO NOT pollute the environment by allowing uncontrolled
discharge of waste oil.
TROUBLESHOOTING
Visit a Princess Auto Ltd. location for a solution if the tool does not function properly or
parts are missing. If unable to do so, have a qualified technician service the tool.
PROBLEM(S) POSSIBLE CAUSE(S) SUGGESTED SOLUTION(S)
Tool runs at
normal speed,
but loses power
under load.
Motor parts worn. 1. Have a qualified technician
service the tool.
2. Replace tool or parts.
Tool runs slowly.
Air flows slightly
from exhaust.
Motor parts jammed with
dirt particles.
OR
Airflow blocked by dirt.
1. Check air inlet filter for
blockage.
2. Pour air tool lubricating oil
into air inlet as per
lubrication instructions for
clearing shipping grease.
3. Operate tool in short bursts
to clear debris.
4. If tool still jammed, clean
tool and lubricate per
lubrication instructions.
Tool runs slowly.
Air flows slightly
from exhaust.
1. Air regulator in closed
position.
2. Damage or excessive
wearing of internal
parts.
1. Open the air regulator to
desired airflow.
2a. Have a qualified
technician service the
tool.
2b. Replace tool or parts.
Tools will not
run. Air flows
freely from
exhaust.
Damage or excessive
wearing of internal parts.
1. Have a qualified
technician service the
tool.
2. Replace tool or parts.

8843625 Air Needle Scaler V1.0
12 For technical questions call 1-800-665-8685
PROBLEM(S) POSSIBLE CAUSE(S) SUGGESTED SOLUTION(S)
Impact tools will
not run. Air flows
freely from
exhaust.
Piston is jammed. 1. Remove chisel and spring
retainer.
2. Push punch through hole in
the cylinder until resting
against the piston.
3. Sharply strike punch with a
hammer to loosen piston.
4. If still jammed, disassemble
barrel from housing and use
punch to push piston
through the rear of barrel.
5. Clean the barrel and piston.
Remove any rust.
6. Reassemble.
Tool will not shut
off.
1. Throttle valve o-ring
dislodged from inlet
valve seat.
2. Trigger mechanism
jammed or dirty.
1. Replace throttle valve
o-rings.
2. Clean trigger mechanism
and lubricate.
Loss of power or
erratic
performance.
1. Excessive drain on the
air hose. Incorrect size
or type of hose
connectors.
2. Moisture or restriction
in the air hose/tank
3. Air compressor has
insufficient flow.
1. Check the air hose and
confirm the hose fitting is
correct for the inlet bushing.
2. Depressurize system and
drain tank and air hose of
water.
3. Ensure tool is connected to
a compressor with a rate
flow that matches the tool.

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 13
PARTS BREAKDOWN

8843625 Air Needle Scaler V1.0
14 For technical questions call 1-800-665-8685
PARTS LIST
# DESCRIPTION QTY
1
Main Body
1
2 O-Ring 1
3
O-Ring
1
4 Throttle Valve 1
5
Spring Gasket
1
6 Gasket 1
7
Valve Cap
1
8 Pin 1
9
Throttle Lever
1
10 Hose Adaptor 1
11
Locking Ring
1
12 Alignment Shim 1
13
Rear Valve Block
1
14 Pin 2
15 Valve 1
16
Front Valve Block
1
17 Piston 1
18
Barrel Sleeve
1
19 Nose 1
20
Key
1
21 Barrel Assembly 1
22
Driver Retainer
1
23 Retainer Buffer 1
24
Retainer Clip
1
25 Needle Driver 1
26
Needle (19)
1
27 Needle Holder 1
28
Spring
1
29 Needle Tube 1

V1.0 Air Needle Scaler 8843625
Visit www.princessauto.com for more information 15

8843625 Air Needle Scaler V1.0
16 For technical questions call 1-800-665-8685

V1,0 8843625
Vous devez lire et comprendre toutes les instructions avant d'utiliser l'appareil. Conservez ce
manuel afin de pouvoir le consulter plus tard.
DÉROUILLEUR-DÉTARTREUR

PNEUMATIQUE

8843625 Dérouilleur-détartreur pneumatique V1,0
2 En cas de questions techniques, appelez le 1-800-665-8685
SPÉCIFICATIONS
Consommation d'air à 90 lb/po carré 4,75 CFM
Longueur de course 1 5/8 po
Vitesse d'impact 4 600 coups/min
Pression max.
90 lb/carré
Entrée d'air 1/4 po
Taille de tuyau à air recommandée 3/8 po
Type d'échappement Avant
DÉFINITIONS DE DANGER
Veuillez-vous familiariser avec les avis de danger qui sont présentés dans ce manuel.
Un avis est une alerte indiquant qu'il existe un risque de dommage à la propriété, de
blessure ou de décès si on ne respecte pas certaines instructions.
DANGER ! Cet avis indique un risque immédiat et particulier qui entraînera
des blessures corporelles graves ou même la mort si on omet
de prendre les précautions nécessaires.
AVERTISSEMENT ! Cet avis indique un risque particulier ou une pratique non
sécuritaire qui pourrait entraîner des blessures corporelles
graves ou même la mort si on omet de prendre les précautions
nécessaires.
ATTENTION ! Cet avis indique une situation possiblement dangereuse qui peut
entraîner des blessures mineures ou modérées si on ne procède
pas de la façon recommandée.
AVIS ! Cet avis indique un risque particulier ou une pratique non
sécuritaire qui entraînera des dommages au niveau de
l'équipement ou des biens, mais non des blessures corporelles.

V1,0 Dérouilleur-détartreur pneumatique 8843625
Visitez www.princessauto.com pour plus d'informations 3
INTRODUCTION
Le dérouilleur-détartreur pneumatique retire la rouille, la calamine, le flux de soudage,
le ciment et les autres résidus lors de la préparation des surfaces. Le dérouilleur-
détartreur présente 19 pointeaux d’acier très résistants à l’usure, un corps et un piston
thermisés afin de prolonger la durée utile de l’outil. La conception linéaire permet
d’atteindre les endroits exigus.
SÉCURITÉ
AVERTISSEMENT ! Veuillez lire et comprendre toutes les instructions avant
d'utiliser cet outil. L'utilisateur doit respecter les précautions de base lorsqu'il
utilise cet outil afin de réduire le risque de blessure ou de dommage à
l'équipement.
Conservez ce manuel qui contient les avertissements de sécurité, les précautions, les
instructions de fonctionnement ou d'inspection et d'entretien.
AIRE DE TRAVAIL
1. Travaillez dans un environnement de travail sécuritaire. Gardez votre aire de travail
propre, bien éclairée et exempte de toute distraction.
2. Assurez-vous que les personnes qui ne portent pas l'équipement de sécurité
approprié ne se trouvent pas à proximité de l'aire de travail.
3. Rangez les outils correctement dans un lieu sécurisé et sec. Gardez les outils
hors de la portée des enfants.
4. N'installez pas et n'utilisez pas d'outils électriques en présence de gaz, de
poussière ou de liquides inflammables.
SÉCURITÉ PERSONNELLE
AVERTISSEMENT ! Portez de l'équipement de protection personnelle
homologué par l'Association canadienne de normalisation (CSA) ou
l'American National Standards Institute (ANSI).
ÉQUIPEMENT DE PROTECTION PERSONNELLE
1. Portez toujours des lunettes antiprojections qui offrent une protection frontale et
latérale pour les yeux. L'équipement de protection des yeux devrait être conforme
à la norme CSA Z94.3-07 ou ANSI Z87.1 fonction du type de travail effectué.
2. L’outil peut être à haute pression. Portez des lunettes de sécurité et des gants
pour vous protéger au cours de l'opération. Gardez les mains à l'écart des parties
de caoutchouc exposées du tuyau.

8843625 Dérouilleur-détartreur pneumatique V1,0
4 En cas de questions techniques, appelez le 1-800-665-8685
3. Portez un écran facial panoramique de type approprié avec les lunettes de
sécurité puisque cette tâche peut créer des copeaux, des matières abrasives ou
des particules.
4. Portez des gants qui protègent en fonction des matériaux de travail et pour
réduire les effets des vibrations de l'outil.
5. Portez des vêtements de protection conçus pour l'environnement de travail et
pour l'outil.
6. Les chaussures antidérapantes sont recommandées pour maintenir la stabilité et
l'équilibre au sein de l'environnement de travail.
7. Portez un appareil respiratoire approuvé par la NIOSH pour travailler sur des
matériaux qui produisent des émanations dangereuses, de la poussière ou des
particules.
8. Cet outil peut causer des dommages à l'ouïe. Portez un dispositif de protection
anti-bruit présentant une cote de réduction du bruit adéquate en fonction du
niveau de décibels.
PRÉCAUTIONS PERSONNELLES
Gardez le contrôle de l'outil, de vos mouvements et de l'environnement de
travail pour éviter les blessures ou le bris de l'outil.
1. N'utilisez pas l'outil si vous êtes fatigué ou sous l'effet de drogues, d'alcool ou de
médicaments.
2. Évitez de porter des vêtements ou des bijoux pouvant se prendre dans les pièces
mobiles d'un outil. Gardez les cheveux longs recouverts ou attachés.
3. N'utilisez pas l'outil si vous devez étirer les bras pour vous en servir. Une stabilité
et un équilibre appropriés sont nécessaires afin d'avoir un meilleur contrôle en
cas de situations inattendues.
4. Soutenez la pièce à travailler ou fixez-la sur une plate-forme stable. Une pièce à
travailler tenue dans les mains ou appuyée contre votre corps sera instable et
peut entraîner des blessures corporelles.
5. Tenez cet outil solidement à l’aide des deux mains. Un outil tenu d’une seule main
peut causer une perte de contrôle.
6. Gardez vos doigts à bonne distance de la gâchette/commutateur lors du
transport de l’outil ou du branchement d’un tuyau à air ou d’un accessoire.
Engagez le verrou de gâchette/interrupteur, le cas échéant.
7. Évitez les mises en marche involontaires. Assurez-vous que le
régulateur/commutateur est en position neutre ou OFF (arrêt) lorsque l’outil n’est
pas utilisé et avant de le brancher à une source d’air.
