PROPR LOCK DESK User manual

WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
To help prevent tip-over, read this entire warning.
To further reduce the risk of serious injury and death from tip-overs:
• Never stand on furniture
• Furniture intended for placement on floor
• Do not place items over 300lb on furniture
!
CLEANING + CARE
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive, oil or chemical based cleaners. It is recommended to
use coasters to protect surface from heat and water. Do not
leave spills unattended.
LOCK DESK
QUESTIONS? [e-mail] 718 855 6519 PROPROFFICE.COM
DIMENSIONS
• L30 W18 H29
• L30 W24 H29
• L42 W24 H29
• L42 W30 H29
• L48 W24 H29
• L48 W30 H29
• L60 W24 H29
• L60 W30 H29
• L72 W24 H29
• L72 W30 H29
USER GUIDE

CONTENTS
LOCK DESK
PARTS Qty/Package
1. Work Surface 1
2. Lateral Support 2
3. Horizontal Support 2
4. End Frame 2
5. Corner Bracket 4
6. Trim Cover 1
7. Leveling Glide 4
8. M8X60mm Socket Head Bolt 4
9. #10x1/2” Wood Screw Philips 16 or 20
10. Grommet 1
11. 6mm Hex Allen Wrench 1
8
6
5
7
10
1
11
4
2
3
9
BOM
ITEM QTY
PART
NUMBER
LEGACY PART
NUMBER
DESCRIPTION
1 1 126317
TOP LPL 24INX48INX0.75IN 1MM
EDGE
2 2 123595
TUBE 48IN HORIZONTAL SUPPORT 1 X
1 UHURU
3 2 123587
TUBE 24IN HORIZONTAL SIDE SUPPORT
1 X 1 UHURU
4 2 124404
WLDMNT U-LEG 24INX28IN PROPR
LOCK
5 4 123599 BRCKT CORNER CLAMP 1 X 1 UHURU
6 1 123603 BRCKT TROUGH LOCK PROPR
7 4 1222 0000.0313
GLIDE M10 X 25MM STEM X 25MM
HEX LEVELER
8 4 1443 20.0000.0586.000
0
SCREW CAP M8-1.25 60MM SH HX
STL ZNPLTD CL8.8 DIN
9 20 1311 0000.0438
SCREW SHTMET #10-12 X 1/2IN PH
PHL TY-A PT STL ZN
10 1 126372
CP2 12IN SLOT PAPPER & LINER BIN
GROMMET BLACK
11 1 129220 WRENCH ALLEN 6MM
[e-mail] 718 855 6519 PROPROFFICE.COM 2

1. Lay down the lateral support #3 and horizontal support #2 and hook the corner bracket #5 before screwing down the supports with #9.
2. Repeat the same process for each corner (Unscrew and adjust as needed)
3. Align the end frame with the mounting holes on the corner brackets and fully tighten using the provided tool #11.
ASSEMBLY INSTRUCTIONS
LOCK DESK
A
DETAIL
A
SCALE
1 : 1
[e-mail] 718 855 6519 PROPROFFICE.COM 3

4. Repeat the same process for the other side.
5. Align the cover tray over the appropriate mounting location and attach once in place.
6. Once all mounting hardware are in place and fully tighten, flip the table to its upright position and attach the grommet #10.
ASSEMBLY INSTRUCTIONS
LOCK DESK
