ProSoft RadioLinx RLXIB-IHW User manual

RLXIB-IHW
802.11a, b, g
RadioLinx®802.11abg Industrial
Hotspot with POE and Serial Server
September 16, 2009
SETUP GUIDE

United States FCC & Industry Canada rules
OQ7IHW 3656A-IHW
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: The device
may not cause harmful interference, and it must accept any interference received, including interference that may
cause undesired operation.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
CAUTION: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to
operate the equipment.
Antenna spacing requirements for user safety
It is important to keep the radio's antenna a safe distance from the user. To meet the requirements of FCC part
2.1091 for radio frequency radiation exposure, this radio must be used in such a way as to guarantee at least 20 cm
between the antenna and users. Greater distances are required for high-gain antennas. The FCC requires a
minimum distance of 1 mW *cm2 power density from the user (or 20 cm, whichever is greater).
If a specific application requires proximity of less than 20 cm, the application must be approved through the FCC for
compliance to part 2.1093.
The installer of this radio equipment must ensure that the antenna is located or pointed in such a way that it does not
emit RF fields in excess of Health Canada limits for the general population; refer to Safety Code 6, obtainable from
Health Canada.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.
RLXIB: CSA C22.2 213-M1987 and N. American Standard ANSI/ISA 12.12.01 listing
In accordance with Canadian Standard CSA C22.2 213-M1987 and ANSI Standard ISA 12.12.01, the RLXIB series
radios have been UL listed for operation in Class I, Division 2, Groups A, B, C, and D Locations.
THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C, AND D, HAZARDOUS
LOCATIONS ONLY IF INSTALLED IN AN APPROVED ENCLOSURE AND POWERED BY A CLASS 2 POWER
SUPPLY.”Limited Power Source”.
WARNING: EXPLOSION HAZARD! SUBSTITUTION OF ANY COMPONENTS MAY IMPAIR SUITABILITY FOR
CLASS I, DIVISION 2.
WARNING – EXPLOSION HAZARD – Do not disconnect equipment unless power has been removed or the area is
known to be non-hazardous.
AVERRTISSEMENT - RISQUE D'EXPLOSION - LA SUBSTITUTION DE COMPOSANTS PEUT RENDRE CE
MATERIEL INACCEPTABLE POUR LES EMPLACEMENTS DE CLASSE I, DIVISION 2.
WARNING: EXPLOSION HAZARD! DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN
SWITCHED OFF OR THE AREA IS KNOWN TO BE NON HAZARDOUS.
AVERRTISSEMENT - RISQUE D'EXPLOSION - AVANT DE DECONNECTER L'EQUIPEMENT, COUPER LE
COURANT OU S'ASSURER QUE L'EMPLACEMENT EST DESIGNE NON DANGERUEX.

The following label is applied to the radio to indicate that it is listed under ANSI/ISA standard 12.12.01 and CSA
standard C22.2 213-M1987. This Device contains a Radio Transmitter Module
FCC ID: OQ7IHW Canada IC: 5265-IHW
Conforms to ANSI/ISA Std. 12.12.01 – Certified to CSA Std. C22.2 No. 213-M1987
Class I Division 2 10-24 Volts DC 6 Watts
48 Volts DC using the PoE Injector
Groups A, B, C & D
Max. Ambient: 60ºC Temp Code T6
Note: The Temp. Code (Temperature Code) refers to the temperature of the rating of the RLXIB radio. The T6 code
means that the maximum temperature of the unit did not exceed 135°C.
RLXIB: ATEX Approval
II 3 G
II 3 G
Ex nA nL IIC T6 X
-30C° <= Ta <=60°C
ProSoft Technology, Inc., Bakersfield, CA USA
Model: RLXIB
S/N: XXXXXXXXXX
Caution:
Read instructions before operating in Hazardous Areas
N. America
The Radio must be installed inside an IP54 enclosure which requires a special tool for access.
Product name: RLXIB
Safety Warning Statements
Explosive Atmosphere
Power, Input, and Output (I/O) wiring must be in accordance with the authority having jurisdiction
A Warning – Explosion Hazard – Do not make or break connections in an explosive atmosphere.
B Caution – Use only approved recommended power supply.
C Warning - Power supply should be installed in a non-hazardous area.
D Warning – DO NOT OPEN WHEN ENERGIZED.
E These products are intended to be mounted in an IP54 enclosure. The devices shall provide external means to
prevent the rated voltage being exceeded by transient disturbances of more than 40%. This device must be used
only with ATEX certified backplanes.
European CE certification
The radio modem has been approved for operation under the RTT&E directive, passing the following tests: ETS300-
826 (EMC), ETS300-328 (Functionality), and EN60950 (Safety).
The following is the appropriate label that is applied to the radio modem product line to indicate the unit is approved
to operate with CE certification:
The following is the appropriate label that is applied to the radio modem product line shipping package to indicate the
unit is approved to operate with CE certification:
AUS BDK FIN
FDGR IRE
ILUX NL P
ESUK
Note: Member states in the EU with restrictive use for this device are crossed out. This device is also authorized for
use in all EFTA member states (CH, ICE, LI, and NOR).

IMPORTANT: This device is a 2.4-GHz, low-power RF device intended for office and home use in all EU and EFTA
member states, except in France where restrictive use applies.
EU Requirements
1. For outdoor use, France has a frequency restriction of 2.4GHz - 2.454GHz for an output power greater than 10mW
and below 100mW.
2. For outdoor use in France, the output power is restricted to 10mW in the frequency range of 2.454GHz –
2.4835GHz.
3. 5.15GHz – 5.35GHz is restricted to 200mW EIRP throughout the European Union.
RLXIB: Power over Ethernet Injector and Accessories "Warning"
The PoE Injector was not a part of the hazardous location or ATEX certification. Therefore, if an injector is used to
power any of the radios, the PoE injector must be installed/located outside of any area that could be known to be
hazardous. The AC power adaptor was not a part of the haz loc certification.
The RLXIB series were tested and certified to hazardous location and ATEX without any accessories included in this
certification. Therefore, any accessory added to the RLXIB series radios must be used in an area known to be non-
hazardous as they have not been subjected to hazardous location and ATEX certifications.
The preferred method of powering the radios is using the supplied power adaptor but If the PoE injector is used in an
ordinary location "only", the PoE injector must be Listed. If the PoE injector is used instead of the supplied power
adaptor, all of the wiring to and from the injector must be routed/installed inside building/plant and never
routed/installed outside of the building/plant.
Your Feedback Please
We always want you to feel that you made the right decision to use our products. If you have suggestions, comments,
compliments or complaints about the product, documentation, or support, please write or call us.
ProSoft Technology
5201 Truxtun Ave., 3rd Floor
Bakersfield, CA 93309
[phone]
[phone] (Fax)
www.prosoft-technology.com
[e-mail]
Copyright © ProSoft Technology, Inc. 2009. All Rights Reserved.
RLXIB-IHW Setup Guide
September 16, 2009
ProSoft Technology ®, ProLinx ®, inRAx ®, ProTalk®, and RadioLinx ®are Registered Trademarks of ProSoft
Technology, Inc. All other brand or product names are or may be trademarks of, and are used to identify products
and services of, their respective owners.
ProSoft Technology®Product Documentation
In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments.
User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed CD-ROM,
and are available at no charge from our web site: www.prosoft-technology.com
Printed documentation is available for purchase. Contact ProSoft Technology for pricing and availability.
North America: +1.661.716.5100
Asia Pacific: +603.7724.2080
Europe, Middle East, Africa: +33 (0) 5.3436.87.20
Latin America: +1.281.298.9109

Contents RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 5 of 19
September 16, 2009
Contents
United States FCC & Industry Canada rules......................................................................................2
Antenna spacing requirements for user safety...................................................................................2
RLXIB: CSA C22.2 213-M1987 and N. American Standard ANSI/ISA 12.12.01 listing.....................2
RLXIB: ATEX Approval.......................................................................................................................3
European CE certification...................................................................................................................3
EU Requirements................................................................................................................................4
RLXIB: Power over Ethernet Injector and Accessories "Warning" .....................................................4
Your Feedback Please........................................................................................................................4
ProSoft Technology®Product Documentation....................................................................................4
1Before You Begin 7
1.1 Install the IH Browser Configuration Tool..................................................................8
1.2 Start IH Browser........................................................................................................8
1.3 Plug In the Cables.....................................................................................................9
1.4 Detecting the Radio.................................................................................................10
1.5 Assign a Temporary IP Address .............................................................................11
1.6 Set Up the Master Radio.........................................................................................11
1.7 Save the Radio Configuration.................................................................................14
1.8 Adding and Configuring Additional Radios..............................................................14
2Verify Communication 15
3If You Encounter Problems 17
3.1 Check the Ethernet cable........................................................................................17
3.2 LED display.............................................................................................................17
3.3 Retrieve the default password.................................................................................18
3.4 Starting Over...........................................................................................................18
4What’s Next? 19

RLXIB-IHW ♦802.11a, b, g Contents
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 6 of 19 ProSoft Technology, Inc.
September 16, 2009

Before You Begin RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 7 of 19
September 16, 2009
1 Before You Begin
In This Chapter
Install the IH Browser Configuration Tool................................................8
Start IH Browser......................................................................................8
Plug In the Cables...................................................................................9
Detecting the Radio...............................................................................10
Assign a Temporary IP Address............................................................11
Set Up the Master Radio.......................................................................11
Save the Radio Configuration................................................................14
Adding and Configuring Additional Radios............................................14
The following components are included with your RLXIB-IHW radio, and are all
required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name Part Number Part Description
1 RLXIB-IHW
Radio RLXIB-IHW RadioLinx®802.11abg Industrial Hotspot with POE
and Serial Server
1 Cable Cable #15, RS232 6 foot RS232 null serial cable
1 Cable RL-CBL025 5 foot Ethernet Straight-Thru Cable
1 Antenna A2502S-OA 2 dBi Omni RP-SMA articulating, 2.4/5GHz
1 Power Supply RL-PS007-2 AC Power Adapter, 12V1.6A w/2 pin & 4 plug Set
1 ProSoft
Solutions CD Contains sample programs, utilities and
documentation for the RLXIB-IHW module.
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
In addition, you will need:
A personal computer equipped with an Ethernet port
Static IP address, Subnet Mask and Gateway information for each RLX
device you plan to install. You can obtain this information from your system
administrator.
Note: This Startup Guide is designed for use with two RLXIB-IHW radios. One radio will be setup
as a Master (AP) while the other radio will be set up as a remote repeater.

RLXIB-IHW ♦802.11a, b, g Before You Begin
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 8 of 19 ProSoft Technology, Inc.
September 16, 2009
1.1 Install the IH Browser Configuration Tool
1 Insert the ProSoft Solutions CD in your CD-ROM drive. On most computers,
a menu screen will open automatically. If you do not see a menu within a few
seconds, follow these steps:
a Click the Start button, and then choose Run.
b In the Run dialog box, click the Browse button.
c In the Browse dialog box, click "My Computer". In the list of drives,
choose the CD-ROM drive where you inserted the ProSoft Solutions CD.
d Select the file prosoft.exe, and then click Open.
e On the Run dialog box, click OK.
2 On the CD-ROM menu, select IH Browser for the RLX-IHx and RLXIB-x
Products. This action opens the Setup Wizard for IH Browser.
3 Follow the instructions on the installation wizard to install the program with its
default location and settings.
4 Follow the instructions on the installation wizard to install the program with its
default location and settings.
5 When the installation finishes, you may be prompted to restart your computer
if certain files were in use during installation. The updated files will be
installed during the restart process.
1.2 Start IH Browser
1 Click the START button, and then navigate to PROGRAMS /PROSOFT
TECHNOLOGY

Before You Begin RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 9 of 19
September 16, 2009
2 Click to start RADIOLINX IH BROWSER.
The window lists all the radios your computer can access. The MAC ID number is
essentially the serial number of the radio; this number is also printed on the side
of the radio. If a radio listing does not appear in the window, select Scan from the
File menu. If you still do not see a radio listing, see Troubleshooting.
1.3 Plug In the Cables
You can configure the RLXIB-IHW using the Ethernet port on the radio. On the
underside are three ports; Ethernet, Serial and Power (10 to 24 VDC 6 W).
From left to right: Power connector, Serial port and Ethernet port.
Use the Ethernet cable to configure the radio for the first time.

RLXIB-IHW ♦802.11a, b, g Before You Begin
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 10 of 19 ProSoft Technology, Inc.
September 16, 2009
Note: After you plug in the power cable and Ethernet cable, the radio performs a startup procedure
that includes a self-test, loading the main program, and initializing the radio. The front panel LEDs
will illuminate after approximately two seconds. The entire startup procedure can take up to 30
seconds.
After the startup procedure has completed successfully, the Power LED should
be green, meaning that the radio has power. The Ethernet LED should also be
green, meaning that the Ethernet connection is working. The RF Transmit and
RF Receive LEDs should blink.
For information on making connections, see Radio Power Requirements and
Cable Specifications.
1.4 Detecting the Radio
After the radio has completed its startup procedure, the radio will appear in the IH
Browser window.
The window lists all the radios your computer can access. The MAC ID number is
essentially the serial number of the radio; this number is also printed on the side
of the radio. If a radio listing does not appear in the window, select Scan from the
File menu.
Tip: If a radio listing does not appear in the window, open the File menu and choose Scan. If you
still do not see a radio listing, refer to Diagnostics and Troubleshooting in the RLXIB-IHW User
Manual.

Before You Begin RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 11 of 19
September 16, 2009
1.5 Assign a Temporary IP Address
You need the IP address to log into the Radio Configuration/Diagnostic Utility
and configure the radio settings. If the radio is connected to a network with a
DHCP server, the radio may already have an IP address assigned to it.
If a DHCP server is not available, or if you prefer to assign a static IP address,
you can enter a temporary IP here. You will use the Radio Configuration /
Diagnostic Utility to assign a permanent IP address.
To assign a temporary IP Address
1 In IH Browser, click to select the radio.
Tip: If a radio listing does not appear in the window, open the File menu and choose Scan. If you
still do not see a radio listing, refer to Diagnostics and troubleshooting in the RLXIB-IHW User
Manual.
2 Open the Operations menu, and choose Assign IP. This action opens the
Assign Temporary IP Address dialog box.
3 Select one of the unused IP addresses, and then click OK.
For information, see Radio Access settings.
1.6 Set Up the Master Radio
To configure the radio, double click on the radio (Radio1) in the IH Browser
window. This action opens a web browser (for example Microsoft Internet
Explorer or Firefox) and loads the IH Radio’s web configuration interface.

RLXIB-IHW ♦802.11a, b, g Before You Begin
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 12 of 19 ProSoft Technology, Inc.
September 16, 2009
Important: The radio configuration is protected by a login password. The default password for the
radio is "password" (lower case, no quotes). To prevent unauthorized access to the radio
configuration, you should change the password when you have finished the initial configuration.
Note: The master is the "root" or top-level radio in a network. You must have at least one master
radio per network. For redundancy, you can assign more than one master to a network.
To configure a Master radio, make the following changes to the web
configuration form:
Radio Network Settings
Radio Name: Enter a unique name for the radio.
Select Master as the radio mode.
Network SSID: Assign a network name (SSID) of up to 32 characters. The
radio uses this name in all network references. All radios in a network must
have the same SSID.
Channel: Select a channel and frequency range for the network or accept the
default value. Network channels allow radios to avoid sharing a frequency
with other networks in the same location. The channel list indicates the
channel number as well as the frequency (2.4 gHz or 5 gHz).
Important: The RLXIB-IHW radio is supplied with a dual-band antenna that supports both
frequency ranges. If you use a different antenna with the RLXIB-IHW radio, you must choose a
channel and frequency range supported by the antenna.

Before You Begin RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 13 of 19
September 16, 2009
Security Settings
Encryption Type: Encryption scrambles data so that only intended viewers
can decipher and understand it. Although "none" is an available encryption
type, ProSoft Technology strongly recommends encrypting all data sent and
received from every radio on your network, to help prevent your data from
being intercepted and decoded.
WPA phrase: To use WPA encryption on packets sent between the radios,
select WPA in the Encryption Type field. Next, in the WPA phrase field, enter
a pass phrase of between eight and 63 normal keyboard characters. This
phrase automatically generates an encryption key of 128 hexadecimal
characters. The default pass phrase is "passphrase" (lower case, no quotes).
For more information on encryption, see Security settings.
Because you must assign the same Network SSID and WPA phrase to the
repeater radios later in this procedure, you should write down the settings.
Note: Network SSID and WPA phrase are both case-sensitive.
Network SSID:_________________
WPA phrase:__________________
Radio Access Settings
If a DHCP (Dynamic Host Control Protocol) server is configured on your local
area network, the DHCP server can assign IP addresses automatically.
If you prefer to assign a Static (Fixed) IP address, select "Use the following IP
address", and then enter the IP Address, Subnet Mask and Default Gateway in
the Radio Access Settings area of the IH Radio web configuration form.
Important: If you intend to assign IP addresses manually, you must not duplicate an IP address
that is already in use on your network. If you are not sure what IP addresses are available, ask
your network administrator for assistance.

RLXIB-IHW ♦802.11a, b, g Before You Begin
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 14 of 19 ProSoft Technology, Inc.
September 16, 2009
1.7 Save the Radio Configuration
Before closing the Radio Configuration window, you must apply your changes.
Click Apply Changes to save your configuration and restart the radio.
Note: To discard your changes and start over, click Cancel Changes.
1.8 Adding and Configuring Additional Radios
At this point you should attach and configure any additional IHW radios you will
be using. Ensure that any new radios use a unique name, but the same Network
SSID as your master. The only difference in procedure will be in setting up each
additional radio. Instead of setting your additional radios as Masters, they should
be set as Repeaters or, more rarely, Clients, depending on their intended
purpose.

Verify Communication RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 15 of 19
September 16, 2009
2 Verify Communication
When configured, the name of each radio is preceded by an M (for Master), an R
(for Repeater), or a C (for Client) in the IH Browser window.
Look at the LEDs to ensure good link quality, as explained in LED display (page
17). After a repeater is configured, you can unplug the Ethernet cable from it.

RLXIB-IHW ♦802.11a, b, g Verify Communication
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 16 of 19 ProSoft Technology, Inc.
September 16, 2009

If You Encounter Problems RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 17 of 19
September 16, 2009
3 If You Encounter Problems
In This Chapter
Check the Ethernet cable......................................................................17
LED display...........................................................................................17
Retrieve the default password...............................................................18
Starting Over.........................................................................................18
3.1 Check the Ethernet cable
If you connect a radio and the Ethernet LED does not light on the radio, there
may be a problem with the Ethernet cable. Verify that the cable is plugged into
the radio at one end, and to an Ethernet hub or a 10/100 Base-T Ethernet switch
at the other end.
Note: The RLXIB-IHW radio auto-detects the Ethernet connection type, and does not require a
crossover cable for direct connection to a PC.
3.2 LED display
The RLXIB-IHW front panel includes a set of LEDs that indicate the radio’s
status:
LED Description
Power This green LED indicates that the radio has power.
RF Transmit This yellow LED indicates RF transmission.
RF Receive This green LED indicates RF reception.
Serial If this green LED is lit, the serial cable is connected. If this LED is flashing, a
serial packet is being transmitted or received (The serial port is not available in
the first release of the radio).
Ethernet If this green LED is lit, the Ethernet cable is connected. If this LED is flashing, an
Ethernet packet is being transmitted or received.
Signal Strength If only one of these three LEDs is lit, then the radio is linked. If two LEDs are lit,
the radio’s signal strength is fair. If all three LEDs are lit, the signal strength is
good.
If a radio is configured as a master, the middle light of the three Signal Strength
LEDs will always be on, and the bottom Signal Strength LED will always be off.
The top LED on the master will flash if any radios are linked to this master.

RLXIB-IHW ♦802.11a, b, g If You Encounter Problems
RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server Setup Guide
Page 18 of 19 ProSoft Technology, Inc.
September 16, 2009
After you first plug in the power cable and Ethernet cable to the radio, the
Power/Status LED should be green, meaning that the radio has power. If the
Ethernet LED is green, then the Ethernet connection is working. The RF Transmit
and RF Receive LEDs should blink.
All three LEDs will blink just after the radio links to the Master’s signal but before
it has been fully authenticated. Normally you will see this last only a few seconds.
If it lasts longer or never turns solid it usually means the encryption keys are not
correct.
3.3 Retrieve the default password
If you forget your password, you will be unable to change the radio settings. You
can retrieve the default password to use the software again, but you will lose all
the settings you programmed before. To retrieve the default password and return
the radio to its default settings, follow these steps:
1 Turn off power to the radio.
2 Locate the reset button hole, located to the left of the power connector.
3 Insert the end of a paperclip or similar device into the hole to press the reset
button.
4 Turn on power to the radio, and hold down the reset button for 30 seconds.
5 The radio will be reset to its default settings, including the password. You
should now be able to log in using the default password, which is "password".
3.4 Starting Over
If necessary, you can always restore the default settings that your radio was
shipped with by opening the Radio Configuration/Diagnostic Utility, logging into
the radio, and clicking on the Factory Defaults button. This will remove all
changes you have made to the radio configuration, including addressing,
naming, and security settings.

What’s Next? RLXIB-IHW ♦802.11a, b, g
Setup Guide RadioLinx® 802.11abg Industrial Hotspot with POE and Serial Server
ProSoft Technology, Inc. Page 19 of 19
September 16, 2009
4 What’s Next?
Congratulations! Your wireless network is up and running. You now need to
connect your wireless Hotspots to your network devices. ProSoft Technology
provides application connection instructions for numerous applications. Refer to
the RadioLinx Application Connection Guide located on the RadioLinx Solutions
CD.
