Supermicro 1028-WTNR(T) User manual

SUPER ®
USER’S MANUAL
Revision 1.0
SUPERSERVER®
1028R-WTNR(T)

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and
documentation, is the property of Supermicro and/or its licensors, and is supplied only under a
license. Any use or reproduction of this product is not allowed, except as expressly permitted by
the terms of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Manual Revision 1.0
Release Date: January 08, 2015
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

3
Preface
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer. Installation and
maintainance should be performed by experienced technicians only.
Please refer to the server specications page on our Web site for updates on
supported memory, processors and operating systems (http://www.supermicro.
com).
Notes
For your system to work properly, please follow the links below to download all
necessary drivers/utilities and the user’s manual for your server.
•Supermicro product manuals: http://www.supermicro.com/support/manuals/
•Product drivers and utilities: ftp://ftp.supermicro.com
•Product safety info: http://super-dev/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
[email protected]
This manual may be periodically updated without notice. Please check the
Supermicro Web site for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing
a procedure.
Warning! Indicates important information given to prevent equipment/
property damage or personal injury.

4
SUPERSERVER 1028R-WTNR(T) Manual
Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
Processors ...................................................................................................... 1-2
Memory ........................................................................................................... 1-2
Serial ATA........................................................................................................ 1-2
PCI Expansion Slots ....................................................................................... 1-2
Input/Output Ports .......................................................................................... 1-2
IPMI................................................................................................................. 1-3
1-3 Server Chassis Features ................................................................................ 1-4
System Power................................................................................................. 1-4
Hard Drives Bays............................................................................................ 1-4
Front Control Panel......................................................................................... 1-4
Cooling System............................................................................................... 1-4
Chapter 2 Installation in a Rack
2-1 Preparing for Setup......................................................................................... 2-1
Choosing a Setup Location............................................................................. 2-1
2-2 Warnings and Precautions.............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions.......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-3 Installing the System into a Rack .................................................................. 2-4
Identifying the Sections of the Rack Rails...................................................... 2-4
Inner Rail Extension (optional)........................................................................ 2-5
Assembling the Outer Rails ............................................................................ 2-6
Installing the Outer Rails onto the Rack......................................................... 2-7
Sliding the Chassis onto the Rack Rails......................................................... 2-8
Installing the Server into a Two Post Rack..................................................... 2-9
Chapter 3 System Interface
3-1 Overview ........................................................................................................ 3-1
3-2 Control Panel Buttons ..................................................................................... 3-2

5
Preface
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheating..................................................................................................... 3-3
Overheat Temperature Setting ................................................................... 3-3
Responses.................................................................................................. 3-3
3-4 Drive Carrier LEDs.......................................................................................... 3-4
3-5 Power Supply LEDs ........................................................................................ 3-4
Chapter 4 Standardized Warning Statements for AC Systems
About Standardized Warning Statements....................................................... 4-1
Warning Denition........................................................................................... 4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning ........................................................................ 4-6
Equipment Installation..................................................................................... 4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies (if applicable to your system)........................... 4-12
Backplane Voltage (if applicable to your system)......................................... 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning (if applicable to your system) ................................. 4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard ............................................................................... 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-1
5-2 Connecting Cables.......................................................................................... 5-2
Connecting Data Cables ................................................................................. 5-2
Connecting Power Cables .............................................................................. 5-2
Connecting the Control Panel......................................................................... 5-2
5-3 I/O Ports.......................................................................................................... 5-3
5-4 Installing the Processor and Heatsink ............................................................ 5-4
Installing an LGA 2011 Processor................................................................... 5-4
Installing a CPU Heatsink ............................................................................... 5-7
Removing the Heatsink .................................................................................. 5-7
5-5 Installing Memory............................................................................................ 5-8
DIMM Installation ............................................................................................ 5-8
Removing Memory Modules ........................................................................... 5-8
Memory Support.............................................................................................. 5-9
5-6 Expansion Cards........................................................................................... 5-10

6
SUPERSERVER 1028R-WTNR(T) Manual
5-7 Serverboard Details .......................................................................................5-11
5-8 Connector Denitions ................................................................................... 5-14
Power Connectors......................................................................................... 5-14
5-9 Jumper Settings ............................................................................................ 5-20
5-10 Onboard Indicators........................................................................................ 5-22
5-11 Storage Devices ........................................................................................... 5-23
5-12 Installing Software......................................................................................... 5-24
SuperDoctor®5 ............................................................................................. 5-25
5-13 Serverboard Battery...................................................................................... 5-26
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices.................................................................................. 6-1
Precautions ..................................................................................................... 6-1
6-2 Removing Power from the System ................................................................. 6-2
6-3 Removing the Chassis Cover ......................................................................... 6-3
6-4 Control Panel .................................................................................................. 6-3
6-5 Installing Hard Disk Drives.............................................................................. 6-4
6-6 System Fans ................................................................................................... 6-7
6-7 Installing Expansion Cards ............................................................................. 6-9
6-8 Power Supply.................................................................................................6-11
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility.............................................................................. 7-1
How To Change the Conguration Data ......................................................... 7-1
7-2 Main Setup...................................................................................................... 7-2
How to Start the Setup Utility ......................................................................... 7-2
7-3 Advanced Setup Congurations...................................................................... 7-4
7-4 Event Logs .................................................................................................... 7-32
7-5 IPMI............................................................................................................... 7-34
7-6 Security Settings ........................................................................................... 7-36
7-7 Boot Settings................................................................................................. 7-37
7-8 Save & Exit ................................................................................................... 7-39
Appendix A BIOS POST Error Codes .................................................... A-1
Appendix B System Specications ........................................................ B-1

7
Preface
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web Site: www.supermicro.com.tw

8
SUPERSERVER 1028R-WTNR(T) Manual
Notes

Chapter 1
Introduction
1-1 Overview
The SuperServer 1028R-WTNR(T) is a 1U server comprised of two main
subsystems: the SC116AC2-R706WB 1U server chassis and the X10DRW-N(T)
serverboard. The 1028R-WTNRT model, with the X10DRW-NT serverboard, offers
10 Gb Ethernet capabilities. Refer to our web site to learn which operating systems
have been certied for use with this system (www.supermicro.com).
In addition to the chassis and serverboard, the following parts are included:
•Four 4-cm counter-rotating fans (FAN-0101L4)
•Two passive CPU heatsinks (SNK-P0047PSC and SNK-P0057PS)
•Riser Card (RSC-R1UW-2E16-O-P)
•Backplane (BPN-SAS3-116A-N2)
•Mounting rail set (MCP-290-00063-0N)
For your system to work properly, please follow the links below to download all
necessary drivers/utilities and the user’s manual for your server.
•Supermicro product manuals: http://www.supermicro.com/support/manuals/
•Product drivers and utilities: ftp://ftp.supermicro.com
•Product safety info: http://super-dev/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
[email protected].
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 1028R-WTNR(T) User's Manual
1-2 Serverboard Features
At the heart of the 1028R-WTNR(T) SuperServer is the X10DRW-N(T), a dual
processor serverboard based on the Intel C612 Express chipset. Below are the main
features of the system (See Figure 1-1 for a chipset block diagram).
Processors
The serverboard supports dual Intel Xeon E5-2600 (V3) processors (
LGA 2011 Socket v3). Each processor supports dual full-width Intel QuickPath
Interconnect (QPI) links of up to 9.6 GT/s one direction per QPI. Refer to the
serverboard description pages on the Supermicro web site for a complete listing
of supported processors.
Memory
The integrated memory controller supports up to 1024 GB of Load Reduced
(LRDIMM), and up to 512 GB of Registered (RDIMM) DDR4 (288-pin) ECC
2133/1866/1600 MHz memory in sixteen slots, two DIMMs per channel. Modules
of the same size and speed are recommended. See Chapter 5 for details.
Serial ATA
The server supports ten hot-swap hard drives, with eight SATA 3.0 connectors
plus two NVMe/SATA 3.0 hybrid ports, connected to an onboard storage controller
(I-SATA 0-3, S-SATA0-3, I-SATA4/5 for SATADOM).
PCI Expansion Slots
The serverboard has one PCI-Express 3.0 x32 slot. The system supports two
expansion cards by means of a riser card.
Input/Output Ports
The rear I/O ports include two Ethernet LAN ports, one dedicated IPMI LAN port,
four USB 2.0 ports, and a VGA (monitor) port. The LAN ports are:
•For 1028R-WNTR model, two 1 Gb ports
•For 1028R-WNTRT model, two 10 Gb ports
Internal headers include two USB 3.0 ports and one COM port.
The rear I/O panel also includes a UID switch and LED.

1-3
Chapter 1: Introduction
Figure 1-1. Intel C612 Express Chipset Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
IPMI
IPMI (Intelligent Platform Management Interface) is a hardware-level interface
specication that provides remote access, monitoring and administration for
Supermicro server platforms. IPMI allows server administrators to view a server’s
hardware status remotely, receive an alarm automatically if a failure occurs, and
power cycle a system that is non-responsive.
6 PHASE
145W
VR12.5
VCCP1 12v
x4
P1
P1
P0
P0
DMIPE1PE2PE3
PE3DMI
PE1PE2
DDR4 DIMM
Front
port 0,1
REAR
DDR4 DIMM
#1
#2
DDR4 DIMM
A
G
x16
x16
PROCESSOR
PROCESSOR
DDR4 DIMM
#2
#1
DDR4 DIMM
DDR4 DIMM
2,3
REAR
DDR4 DIMM
B
DDR4 DIMM
C
D
SocketID 01
E
FH
#1
#2
#1
#2
#1
#2 #2
#1
#1
#2
#1
#2
SocketID 00
WIO Slots
SXB1A
SXB1B
SXB1C
Upper Lower
PCIE x16 PCIE x16
4,5
x8
x4
CPU Front
CPU Rear
Left Slot
SXB1B (Lower)
PCIE 3.0 x16
USB 2.0 USB 2.0 USB 3.0
SXB1B (Upper)
Left Slot
PCIE 3.0x16
P1_NVME0
PCIE 3.0x4
P1_NVME1
PCIE 3.0x4
UL1
Dual LAN
i350BT2/
X540AT2
NC-SI(RMIII)
JLAN1 JLAN2
RJ45 RJ45
32MB BMC
SPI Flash
DDR3
VGA
16MB BIOS
SPI Flash
BMC
AST2400
HWM
QPI
QPI
I-SATA0 I-SATA1
I-SATA2
I-SATA3
I-SATA4 I-SATA5
sSATA Gen3 [0..3]
SATA Gen3 [0..5]
USB 2.0[0..5]
USB 3.0[1/2]
LPC
USB 2.0[6]
DMI
PET[3,4,6,7]
SPI
PET[5]
TPM Header
IPMI LAN
RJ45
PHY
RTL8211E
COM1
HDR 2x5
POPE 3
LANE Reversal
PCH
S-SATA0
S-SATA1
S-SATA2 S-SATA3

1-4
SUPERSERVER 1028R-WTNR(T) User's Manual
1-3 Server Chassis Features
The 1028R-WTNR(T) is built upon the SC116AC2-R706WB chassis, Supermicro's
third-generation 1U chassis. The following are the main features.
System Power
The SC116AC2-R706WB chassis features a hot plug redundant 750W power supply
consisting of two power modules. Either module can be removed and replaced
without powering down the system.
Hard Drives Bays
The server supports ten hot-swap 2.5" hard disk drives, with eight SATA3 bays plus
two NVMe/SATA3 hybrid bays. See Chapter 6 Section 5 for details.
Front Control Panel
The control panel provides a system monitoring and control interface. LEDs indicate
system power, HDD activity, network activity, and a system overheat/fan-fail/UID
LED. A main power button and a UID button are also included.
Cooling System
The chassis has an innovative cooling design that features ve or six sets of 4-cm
counter-rotating fans located at the middle of the chassis. The sixth fan is optional.
Fan speeds are controlled by the system temperature as monitored by IPMI.

Chapter 2: Installation in a Rack
Chapter 2
Installation in a Rack
This chapter provides instructions for mounting your chassis in a rack.
2-1 Preparing for Setup
The box in which your system was shipped should include two sets of rail
assemblies, two rail mounting brackets and the mounting screws to mount the
system into the rack. Please read this chapter in its entirety before beginning the
installation procedure.
Choosing a Setup Location
Decide on a suitable location for the rack unit that will hold your system. It should
be a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical
noise and electromagnetic elds are generated. A nearby grounded power outlet.
is required
•Leave at least 25 inches clearance in front of the rack to open the front door
completely.
•Leave approximately 30 inches of clearance in the back of the rack to allow for
sufcient airow and access for servicing.
•It should be a restricted access location, such as a dedicated equipment room
or a service closet.
2-1

SUPERSERVER 1028R-WTNR(T) User's Manual
2-2
2-2 Warnings and Precautions
Rack Precautions
•Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
•In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
•Always make sure the rack is stable before extending a component from the
rack.
•You should extend only one component at a time—extending two or more
simultaneously may cause the rack to become unstable.
Server Precautions
•Review the electrical and general safety precautions in Chapter 4.
•Determine the placement of each component in the rack before you install the
rails.
•Install the heaviest server components on the bottom of the rack rst, and then
work up.
•Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
•Allow the hot plug SAS drives and power supply modules to cool before touching
them.
•Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.

2-3
Chapter 2 Installation in a Rack
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating
temperature of the rack environment may be greater than the ambient temperature
of the room. Therefore, consideration should be given to installing the equipment
in an environment compatible with the manufacturer’s maximum rated ambient
temperature (Tmra).
Reduced Airow
Equipment should be mounted into a rack so that the amount of airow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack
itself should be grounded. Particular attention should be given to power supply
connections other than the direct connections to the branch circuit (i.e. the use of
power strips, etc.).
To prevent bodily injury when mounting or servicing this unit in a rack, you
must take special precautions to ensure that the system remains stable.
The following guidelines are provided to ensure your safety:
•This unit should be mounted at the bottom of the rack if it is the only unit
in the rack.
•When mounting this unit in a partially lled rack, load the rack from the
bottom to the top with the heaviest component at the bottom of the rack.
•If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.
•Slide rail mounted equipment is not to be used as a shelf or a work space.

SUPERSERVER 1028R-WTNR(T) User's Manual
2-4
Inner Rails
(Pre-installed
on the chassis)
Inner Rail
Extensions
2-3 Installing the System into a Rack
This section provides information on installing the chassis into a rack unit with the
rails provided. There are a variety of rack units on the market, which may mean
that the assembly procedure differs slightly. You should also refer to the installation
instructions that came with the rack unit you are using.
These rails t a rack between 26" and 33.5" deep.
Identifying the Sections of the Rack Rails
The chassis package includes two sets of rack rails, one set for the right side of
the chassis and one for the left. Each set includes the outer rail pieces that attach
to the rack and the optional inner rail extension. The inner rails are pre-attached
to the chassis.
Figure 2-1. Identifying the Sections of the Rack Rails

2-5
Chapter 2 Installation in a Rack
Figure 2-2. Adding the Inner Rail Extension
(right side rail shown)
Inner Rail Extension (optional)
The inner rail extension can be added to allow the server to pull farther out of the
rack.
Installing the Inner Rails
1. Place the inner rail extensions on the side of the chassis aligning the hooks of the
chassis with the rail extension holes. Make sure the extension faces "outward"
just like the pre-attached inner rail.
2. Slide the extension toward the front of the chassis.
3. Secure the chassis with two screws as illustrated.
4. Repeat for the other inner rail extension.
1
1
1
2
1
3

SUPERSERVER 1028R-WTNR(T) User's Manual
2-6
Figure 2-3. Assembling the Outer Rails
Assembling the Outer Rails
Each outer rail comes in two sections that must be assembled before mounting
onto the rack.
Assembling the Outer Rails
1. Identify the left and right outer rails by examining the ends, which bend outward.
Match the left front outer rail with the left rear outer rail and the same for the
right rails.
2. Align the round post in the rear rail (B) with the round hole at the end of the slot
in the front rail (A), and slide the front section into the rear section.
Outer rail assembled
Secure to the
front of the rack
Secure to the
rear of the rack
Slide outer rails
together
Assembling the sections of
the outer rail
1
A
1
B
Round Hole
Bracket with
Square Pegs

2-7
Chapter 2 Installation in a Rack
Figure 2-4. Installing the Outer Rails to the Rack
Installing the Outer Rails onto the Rack
Each end of the assembled outer rail includes a bracket with square pegs to t into
your rack holes. If you have an older rack with round holes, these brackets must be
removed, and you must use screws to secure the rail to the rack.
Outer Rail Installation
1. Align the square pegs on the front end of the rail with the square holes on the
front of the rack (C). Push the rail into the rack until the quick release bracket
snaps into place, securing the rail to the rack. Keep the rail horizontal.
2. Adjust the rail to reach just past the full depth of your rack.
3. Align the square pegs on the rear end of the rail to the holes on the rack (D)
and push the rail into the rack until the quick release bracket snaps into place,
securing the rail to the rack.
4. Repeat the procedure for the other outer rail assembly.
1
C
1
D
Note: The gure above is for illustrative purposes only. Always install servers at
the bottom of the rack rst.
Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the oor before you slide the unit out for servicing.
Failure to stabilize the rack can cause the rack to tip over.

SUPERSERVER 1028R-WTNR(T) User's Manual
2-8
Figure 2-5. Installing the Server into a Rack
Sliding the Chassis onto the Rack Rails
Installing the Chassis into a Rack
1. Align the chassis rails with the front of the rack rails.
2. Slide the chassis rails into the rack rails, keeping the pressure even on both
sides. The spring latch engages when the chassis is part way in. Push the server
completely into the rack.
3. (Optional) Insert and tighten the thumbscrews that hold the front of the server
to the rack.
Note: The gure above is for illustrative purposes only. Always install servers at
the bottom of the rack rst.
Warning: Do not pick up the server with the front handles. They are designed
to pull the system from a rack only.
